Turbo Incanto TIA732 User manual

TIA732
Induction Hob
Instruction Manual

1
Contents
1. Safety instructions ........................................................................2
2. Installation ....................................................................................5
3. Description of the appliance .........................................................8
4. Error Code ..................................................................................10
5. Pots and pans and how to use them ...........................................11
6. Maintenance and cleaning ..........................................................13
7. Troubleshooting..........................................................................15
8. Environmental note ....................................................................16

2
1. Safety instructions
Important
This appliance generates magnetic field in the direct vicinity.
ATTENTION: People with PACEMAKERS must ensure that their pacemaker has been designed
in conformity with the norms in force. It is recommended that the manufacture or your doctor
is consulted to verify any incompatibility.
Important
This appliance generates short range magnetic field therefore people with other types of
electrical medical equipment, such as hearing aids for the deaf, must ensure they confirm
to the norms regarding electromagnetic disturbances.
This appliance has been designed for family use only. In case of doubts or questions,
please contact the manufacturer.
Keep the packing material away from children (plastic bags, parts in foamed plastic, etc.
they could be potentially dangerous.
To prevent electrical shocks, contact the technical service centre for any repairs.
Make sure that installation and electrical connections are carried out by qualified
personnel, following the manufacturer’s instructions and in conformity with local norms
in force.
The hob must be installed and grounded by qualified personnel. Do not repair or replace
any part of the appliance unless specifically recommended in this manual. All other
interventions must be carried out by qualified technicians.
This hob comes with a cooling fan with air vent underneath the worktop itself. If there is a
drawer under the worktop, do not put any paper or small light objects in it as they could
be sucked up by the fan, damaging it or compromising its function.
Do not use aluminium foil to protect parts of the hob.
Do not leave the kitchen unattended when cooking food where high contents of oil or fat
are used, the oil could catch fire. If the oil catches fire never put out with water.
Immediately suffocate the fire with a lid and turn off the hob.
Do not cook on the hob if the glass is broken. Water or cleaning products could filter
through the breakage and cause electrical shocks. Immediately contact qualified
personnel as soon as you notice a breakage.
Keep the area around the hob free from combustible material (plastic, paper etc.) or
flammable liquids, these can catch fire, metal parts can heat up and cause burns.

3
Children must not be in the kitchen when the hob is in use.
After use, when the cooking element or entire hob is turned off, a residual heat indicator
will come on, showing an H (hot) for each cooking area that was used: this indicates that
the corresponding cooking area is still dangerous.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of
electric shock.
A steam cleaner is not to be used.
Metallic objects such as knives, forks, spoons and lids should not be placed on the hob
surface since they can get hot.
the appliance is not intended to be operated by means of an external timer or separate
remote-control system.
Danger of fire: Do not store items on the cooking surfaces.
CAUTION: The cooking process has to be supervised. A short term cooking process has
to be supervised continuously.
WARNING: Use only hob guards designed by the manufacturer of the cooking appliance
or indicated by the manufacturer of the appliance in the instructions for use as suitable
or hob guards incorporated in the appliance. The use of inappropriate guards can cause
accidents.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision orinstruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Means for disconnection must be incorporated in the fixed wiring in accordance with the
wiring rules.
WARNING: The appliance and its accessible parts become hot during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless continuously supervised.
After use, turn off the hob using the command device and do not rely on
the pan detector.

4
Important
The heating elements do not work if the pan has a diameter that is too small or not
magnetically detectable.To verify that the material of the pan is suitable,that is ferrous, use
a magnet.To prevent damage to the electronic circuit, the hob has a sensor that constantly
controls the temperature of the circuit itself: in the case of overheating the hob
automatically reduces power or turns itself off until a safe temperature is reached.

5
2. Installation
Preparing the unit for a built-in appliance
1. Drill a hole on the table surface according to the size shown in the drawing.For the
purpose of the installation and use,a minimum of 50mm space shall be preserved around
the hole.
Be sure the thickness of the table surface should be at least 30mm.please select heat-
resistant table material to avoid larger deformation caused by the heat radiation from the
cooker.As shown in the Figure 1.
2. ATTENTION: important assembly instructions for keeping the induction module cold.
3. Do not install the hob on top of a refrigerator or dishwasher.If the hob is installed on top of
a drawer put a shelf in between as shown(50mm).If shelves are put in between ensure
that they allow air to flow(30mm).

6
Product Dimensions
WARNING
The kitchen units that are in direct contact with the appliances must be heat-proof (min.
95°).
The appliance can be installed on a work surface with a thickness of between 30 and 40
mm and near to walls which are higher than the work surface,maintaining a minimum
distance of 100 mm.
Carry out all cutting of the unit and work surface then carefully remove shavings or
sawdust before inserting the appliances.
To ensure a correct ventilation of the hob please comply with the dimensions shows in
figures .
Always refer to the manufacturer for specific instructions.
Make sure the surface is level and square and that no part interferes with the space
required for installation.
Prepare the cut as indicated(see installation dimensions).

7
Installing the hob
WARNING
Risk of cutting.
Be careful of cutting edges.
End parts in foamed plastic - be careful.
During transportation these could cause slight injury or cuts.
Remove the material and envelope of documents from the packaging.
Before proceeding with installation read the work instructions carefully.
Step.1
Put a towel or cloth on the work surface.Place the hob face down
on the protected surface.
Step.2
Apply the strip seal,supplied with the hob,which is for sealing it onto
the work surface.
Do not use silicone. Apply the seal to the edge of the bottom of the
hob,leaving about 3mm from the edge of the glass.
Apply the seal all around the circumference.
Cut any excess and bring the two ends of the seal together so they
match.
Step.3
Fix the brackets on the front side and rear side by screw.Put the induction hob in the cut-out
cabinet.
Attention:
The electric hob is recommended to be installed by professional. Please never conduct the
operation by yourself.
The wall and the heating area above the table surface shall withstand heat.
To avoid danger, the induction cooker hob must be installed into the cabinet before use.
Applicable cabinet material: wood, marble resin etc.

8
3. Description of the appliance
Control Panel
Schematic diagram of the control panel
Instruction
1
ON/OFF：Turn on or turn off the machine.
2
CHILD LOCK: Press the button one time tolockit.Other button can't operate
when it is lock. Long press the button to unlock.
3
UP：Increase the power level or add the time.
4
DOWN：Reduce the power level or reduce the time.
5
Display：It shows time.
6
Timer：Setting the time as you need.

9
Operation
Operate and display requirement
(1) Standby status:
Plug in and connect to the electrical supply,the buzzer will“beep”andall indicator lights
and all characters on thedigital display are lit on for 1S and the child lock indicator lights
are not on,indicating that the induction cooker is in standby state.
(2) Work status:
A:"on / off" buttonusedfor switching on and off the induction cooker
a: In the standby mode, press the “+” button or “-” to turn on the burner to enter the
working mode. The default P1 firepower, the digital tube displays P1.
b: In the working state, press the “ON/OFF” button to turn off the working state of the
burner and return to the standby state.
B: Power level adjustment
In working mode,press the +/- button to adjust the power level.
Each time the“+”button is pressed, the power level increases by one unit; Each time the “-”
button is pressed, the power level reduces by one unit;
Power level:P1,P2,P3,P4,P5,P6,P7,P8,P9.
Min power level:P1
Max power level:P9.
During the cooking process, various faults can be detected. If that occurs, the appliance
will enter intofault alarm processing state.
Power management
Each burner is 2000W max. If both burners are set to max power P9, the second burner
that is turned on will beset at max power and reduces the power of the first burner. At any
time, the total max power is set at 3000W.
C: Timer Control(It is valid only under working state)
Under working status, press “timer”button to set the timer.Digital tube display the timing
and flash, press the +/- button to set the timer.After adjusting the time, press timer button
one time to enter the timing state, or 5 seconds no operation of the key will automatically
enter the timing state. The timing time is displayed at this time.
Each time the“+” button is pressed, the timer increased by one minute; Long press (hold
for 3 secs) “+”button,the timer will be incremented by minutes.
Each time the “-” button is pressed, the timer reduced by one minute;Long press “-
”button,the timer will be reduced by minutes.
Min time:1 minute
Max time: 99 minutes.
Adjustable time range:0-99 minutes not recyclable.
The first time a timer is set, the default timing starts at "00".The corresponding induction
cooker will automatically switch off after the timing time is reached.

10
D: Child Lock
Standby state or working state: child lock indicator lightextinguished, you can long press
the child lock button to enter into lockedmode. Other keys will be invalid except on/off
button at this time.
Unlock: Long press the child lock button for 2S.
Lock: The child lock indicator light is not on, long press the child lock button for 2S to enter
into locking state and the child lock indicator light will stayin the locked state.
4. Error Code
Error
Code
Possible Cause
Description
E0
No pan or pot,or their
size,material etc. is not
suitable, or not placed
precisely in the middle of the
cooking area.
If no suitable pan or pot is placed on after
20s,the hob will turn off automatically;if suitable
pan or pot is placed within 20s,the hob will start
to work.
E1
Voltage is too low.
Lower than AC 160V±5% will alarm.
E2
Voltage is too high.
Higher than AC 270V±5% will alarm.
E3
IGBT overheat.
IGBT reaches 105±5℃for 3s(It can recover
automatically when temperature decrease 50℃-
70℃).
E4
Hob surface sensor open-
circuit
Power on and judge within 2 minutes.
Hob surface sensor short-
circuit
Power on and judge within 10S.
E5
IGBT sensor open-circuit
Power on and judge within 2 minutes.
IGBT sensor short-circuit
Power on and judge within 10S.
E6
Hob surface overheat.
Hob surface temperature higher than set value.
E7
Hob surface sersor become
invalid.
Check that if the surface sensor assembly is
properly installed or replaced with the
thermistor.
E9
Communication failures.
Unplug or poor contact.
EA
Line fault.
Coil panel is not connected.

11
5. Pots and pans and how to use them
Attention
The pots and pans that can be used on this hob must be made of ferromagnetic material.
They can be made of enameied steel, cast iron or special pans of stainless steel for
induction. The diameter of the pan should be at least 11cm.
To make sure a pan is suitable, try using a magnet to see if it sticks to the bottom of the
pan. Never use normal thin steel nor anything containing even just an amount of glass,
terracotta, copper or aluminium.
The display of the cooking area will show if the pan is suitable, if the power indicator
flashes the pan is not suitable or the diameter of the bottom is too small for the diameter
of the cooking area.
The pots and pans must be placed precisely in the middle of the cooking area.
In some cooking areas an internal diameter is indicated,with a lighter outline,which
advises the user to go to a smaller cooking area,ifavailable,with smaller diameter pan.This
is to obtain optimim performance and efficiency. You can however use pans with smaller
diameters than this limit.
Safety reminding
A dedicated power protectionair
switch must be incorporeted in
the fixed wiring in accordance
with the wiring rules.
Never use the hob in high
temperature environment.
Never wash the hob with water
derectly. Steam cleaner is not to be
used.

12
Never have the hob to
workwithout food in pot,
otherwiseits operational
performancemay be affected and
dangermay happen.
For sealed foods such ascanned
goods, please do notheat them
before openingtheir covers so as to
avoidany dangers of explosion due
toheating expansion.
The appliance is not intended to be
used bychildren or
handicappedpersons, unless they
havebeen supervised by a
responsible person to ensure they
can use it safely.
Do not place rough or
uneven appliances, which may
damage the ceramic surface.
If the surface is cracked, pull out
the plug to avoid the possibility of
electric shock.
Do not put any detergents or
flammable materials in the
equipment installed under the hob.
Because the hob can generate
very high temperature, please
use a pot resistant to a
temperature of over 200.
After being used, the
corresponding heating zone of the
hob is still hot. Never touch the hob
surface to avoid burn.
If the supply is damaged, it must be
replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.

13
6. Maintenance and cleaning
1. Please shut off the power and pull out the plug before cleaning of the appliance.
2. Clean the appliance when it cools down completely.
3. To remove dirt, please select illustrious detergent.
4. After removing dirt, please use neat wet cloth to clean the unit.
5. Do not clean with water directly, water gets inside may cause malfunction.
6. Keep the crystal glass plate and pan clean before cooking, otherwise dirt after charring is
very difficult to clean and the plate may get discoloration.
7. You may clean air vent / air entry’s dirt using vacuum cleaner to suck up. If there is dirt
with oil, add a little illustrious detergent with tooth-brush to clean.
8. Don’t use caustic impregnates to clean. It may damage the cooker by chemical reaction.
Do not use scrubbing brush or polishing powder to clean the induction cooker.
Important
Periodically check that dust does not deposit under the fan or in the discharge openings,
this could obstruct ventilation for cooling the electronic system, reducing the efficiency of
your hob.
The hob could be damaged if hard and sharp edged objects fall on it, it is recommended
that such objects be kept away from the hob where they cannot fall on it.
Do not put hot pans on the control area or on the edge of the hob, do not use pans with a
raised design or pattern on the base, they could scratch the hob.

14
Cleaning techniques
Attention:When chemical products heat up they can corrode and damage the glass,
moreover the fumes can be dangerous for your health.
Clean the surface when it is completely cold except for the following: dried sugar, syrupy
sugar, tomato sauce, milk, these must be removed immediately with the scraper.
Cleaning after each use:
Dry any splashes with a damp spongeor paper
towel, rinse and dry. If any stains remain, use some vinegar, rinse
and dry.
Cleaning with cream detergents for glass hobs:
Apply a small amount of cream detergent for hobs, when dry,
shine the surface with a soft cloth or paper.
Do not use these products:
Abrasive powders or detergents, spray products for ovens, whitening products, sponges with
abrasive surfaces, steel wool balls or synthetic ones. These products could seriously damage
your hob.

15
7. Troubleshooting
Problem
Possible causes
What to do
The appliance does not
work, the control lights
are all off.
The appliance is not powered,
the plant is defective.
Check that the appliance is
connected, that thereis
electricity and that the current
limiter or differential has not
intervened.
The appliance turns off
during use and an
intermittent acoustic
signal is emitted.
The control may be dirty or
utensils may be on it.
Press any key to stop the
acoustic signal, clean the control
area or remove any utensils and
continue cooking.
During cooking the hob
makes a noise.
Thetechnology of induction
heating is based on the
capacity of certain materials to
vibrate when subject to high
frequency waves. In some
conditions whese vibrations
can produce noise.
This is normal.
The control lights
continue to flash when
the hob is in use.
The pan that is being used is
not suitable for induction.
Verify that the pan is made of
suitable material by using a
magnet.
The fan continues to
work even after the
appliance has been
turned off.
The electronics of the
appliance have a high
temperature and must cool
down.
This is normal. Once the
appliance has cooled down the
fan will automatically turn off.

16
8. Environmental note
Note: Before discarding an old appliance, switch off and disconnect it from the power supply.
Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person.
This appliance is marked according to the European directive 2002/96/EC on Waste electrical
and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this product.
DISPOSAL OF THE APPLIANCE
Old appliances should not simply be disposed of with normal household
waste, but should be delivered to a collection and recycling centre for electric
and electronic equipment. A symbol shown on the product, the instruction
manual or the packaging shows that it is suitable for recycling.
Materials used inside the appliance are recyclable and are lapelled with information
concerning this By recycling materials or other parts from used devices you are making a
significant contribution to the protection of our environment.
Information on appropriate disposal centre for used devices can be provided by your local
authority.
