User & Installation Guide
LAM1741
Ceramic
Touch Control Hob

02_
LAMONA Appliances
Dear Customer,
Congratulations on your choice of hob which has been designed to give you excellent service.
The user manual will help you use your product quickly and safely.
•
• Please read this user manual before installing and using the hob.
• Always follow the safety instructions.
• Keep this user manual within easy reach for future reference.
• Please read any other documents supplied with the product.
Remember that this user manual may also applicable for other models and there maybe some minor
differences between the illustrations and your product.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips about usage.
Warning for possible hazards to health and property.
Warning possibility of electric shock.
This product’s packaging material is recyclable. Help recycle it and protect the
environment by dropping it off in the municipal receptacles provided for this purpose.
Your product also contains a great amount of recyclable material. It is marked with this
label to indicate the used appliances that should not be mixed with other waste. This
way, the appliance recycling organised by your manufacturer will be done under the
best possible conditions, in compliance with European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment. Contact your town hall or your retailer for the used
appliance collection points closest to your home. We thank you doing your part to protect
the environment.

_ 03
User manual LAM1741
Index
Index
01 - Before Using the hob 04
02 - Safety 04
General 04
Fire safety advice 05
Fire Safety 05
Ifapancatchesre   05
Deep fat frying 05
If you have an Electrical Fire 05
03 - Using your hob 06
Touch controls 06
Controls layout 06
Initial setup 06
Functions 07
Timed cooking 08
Safety shut off 08
04 - Cleaning and Maintenance 09
Ceramic hob glass 09
05 - Trouble Shooting 10
06 - Installation 11
General Information 11
Positioning 11
Connect to the electricity supply 14
Technical Data 15
07 - Your guarantee 16

04_
LAMONA Appliances
Before Using the hob
• Makesurethatyouhaveremovedallpackaging,wrappings,stickersandlmsfromthehobsurface.
• Itisrecommendedthatyoucleanandwashthehobsurfacebeforeusingforthersttime.
• Apply a thin coat of ceramic hob cleaner to the hob to help maintain and protect it.
01 - Before using the hob
This appliance is for domestic cooking
purposes only. It must not be used for other
purposes, for example room heating.
General
• WARNING: This appliance and accessible its
parts may become hot during use. To avoid
burns, children less than 8 years of age should
be kept away unless continuously supervised.
• This appliance can be used by children aged
8 years and above, persons with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
must not play with the appliance. Cleaning
and user maintenance must not be made by
children without supervision.
• WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in
are.NEVERTrytoextinguisharewithwater
but switch off the appliance and then cover
amee.g.withalidorreblanket.
• WARNING: Always position pans over
the centre of the cook zone, and turn the
handles to a safe position so they cannot be
accidentally knocked or grabbed.
• WARNING: Don’t leave pans on the hob when
you’re not around - take them off the cook
zone if you have to leave the kitchen even if
you think it will only be for a moment, while
you answer the door or phone.
• WARNING: Keep electrical leads from trailing
over or going near the hob.
• WARNING: If you use a griddle plate ensure
it is completely cool before attempting to lift
it from the hob as residual heat may cause
burns, Always use oven gloves to protect your
hands.
• The appliance has a glass hob top, make
sure you do not drag pans across the ceramic
surface as this will lead to scratches and
damage.
• Do not use the hob surface as a chopping
board or food preparation area as this may
lead to it becoming damaged.
• Do not use the hob if the glass is cracked, as
electrical parts are directly beneath. To avoid
the possibility of electric shock, turn off the
electricity supply to the hob at the socket and
arrange a service call.
• The glass ceramic can get hot whilst cooking;
even though the cook zone itself does
not generate heat. The heat generated is
conducted back from the hot pans.
• Metallic objects such as knives, forks, spoons
and lids should not be placed on the hob
surface since they can get hot.
• Ensure you switch off the appropriate cook
zone individually or by the central on/off key
whenyouhavenishedcooking,donotrely
upon the automatic pan detection system as
your means of switching “off” the appliance.
02 - Safety

_ 05
User manual LAM1741
• WARNING: The appliance must never be
disconnected from the mains supply during
use as this will seriously affect the safety and
performance, particularly in relation to surface
temperatures becoming hot and component
partsnotworkingefciently.Thecoolingfan(if
tted)isdesignedtorunonafterthecontrol
has been switched off.
Avoid damage to the appliance
• The ceramic glass of the hob can be damaged
by objects falling onto it. Be especial careful
with heavy jars of food being stored in
cupboards above the hob, we recommend
storing them away from the hob area.
• The edge of the glass can be damaged by
being knocked by cookware.
• Cookware made of cast iron, cast aluminium
or with damaged bottoms can scratch the
ceramic glass if pushed across the surface.
• Objects that melt and things that boil over can
burn onto the ceramic glass and should be
removed as soon as possible.
• To avoid damage to cookware and the ceramic
glass, do not allow sauce pans or frying pans
to boil dry.
• Do not use the cooking zones with empty
cookware or without cookware in place.
Fire safety advice
Mostkitchenresoccurwhenpeoplearedistracted
or leave things unattended, so remember:
If you’re called away from the hob - by the phone or
someone at the door, either take pans off the heat,
or switch off your hob.
Don’t let yourself be distracted while cooking.
Ifyoudohaveareinthekitchen,don’ttakeany
risks - get everyone out of your home and call the
Fire Service
If a pan catches re:
• Do not move it as it’s likely to be extremely hot.
• Turn off the heat if it’s safe to do so, but never
lean over a pan to reach the controls.
• Usereblanketoradamptea-toweltocover
the pan.
• Ifyouhaveputthereout,leavethepanto
cool completely.
Deep-fat frying presents more
dangers in your kitchen
• Neverllachippan(orotherdeepfatfryer)
more than one-third full of oil.
• Donotuseareextinguisheronapanof
burning oil - the force of the extinguisher can
spreadthereandcreateareball.
If you have an electrical re in the
kitc h e n:
• Pull the plug out, or switch off the power at the
fusebox-thismaybeenoughtostopthere
immediately
• Smothertherewithareblanket,orusea
dry powder or carbon dioxide extinguisher
• Remember: never use water on an electrical or
cookingoilre.
Safety

06_
LAMONA Appliances
Touch Controls
The touch controls for your hob have been designed
toprovideyouwithngertipcontrolofyourhob,
providing accurate and repeatable power settings
for cooking and an easy clean surface that can be
easily wiped over. When a cook zone is activated the
power setting is displayed for each zone individually,
Controls layout
a. ReferredZone(x4)
b. Minute Minder / Fault code
c. Upper Left Zone
d. Lower Right Zone
e. Minus‘-’(PowerLevel/Time)
f. Power On/off
g. Timer
h. Upper Right Zone
i. Lower Right Zone
j. Plus‘+’(PowerLevel/Time)
k. Lock
Initial set up
Before switching on the power supply to the
appliance,switchoffanybrightlights(suchas
cookerhood)andensuretheapplianceisnotin
direct sunlight.
This is to enable the electronic controls to calibrate
its sensitivity against natural ambient lighting
(approx30seconds).
Failure to observe the above will result in the hob
notfunctioningcorrectly,(Displayshowing“FL”).
To rectify remove all strong lighting sources and
re-apply power.
The hob should complete the calibration procedure
satisfactorily and lighting such as cooker hoods can
be used normally.
03 - Using the hob - electric ceramic
a
c
d
h
i
g
e j
f k
b
Using the hob

_ 07
User manual LAM1741
Using the hob
Functions
Lock
a
c
d
h
i
g
e j
f k
b
A Red LED indicates when the key lock is active, to
deactivate/activate, touch the Key Lock key for 1
second.
The key lock is deactivated when the Red LED
switches off.
IfanyofthecookzonesareON,thekeylock
functionlocksallthekeysexcepttheON/OFFkey.
If the cook zones are OFF, the key lock function
locksallthekeys,includingtheON/OFFkey.
Note:TheKeyLockisautomaticallyactivatedevery
time the electricity supply is switched off and back
on to the hob.
To avoid unintentional switching on of the
appliance, e.g. by small children and pets, we
recommend activation of the key lock feature.
Switching on the hob
• Touch and hold the on/off symbol for 3
secs. The hob will beep and all energy level
indicators will display “0”.
• If no other symbol is selected within 10 secs
the hob will turn off.
Operating a zone
• Select the desired zone by touching its own
symbol.Thecorrespondingdisplaywillash
“0”. Touch “+” or “-” to set the power level.
After10secsthedisplaywillstopashingand
a beep is heard.
• To adjust the power level, touch the zone
symboluntilthedisplayashes.Adjustthe
“+” or “-” to the desired power level. After 10
secsthedisplaywillstopashingandabeep
is heard.
Switching a zone off
• To turn off a zone, touch and hold the desired
zonesymboluntilthedisplayashes.Adjust
the “-” symbol down to “0”. After 10 secs
the zone will switch off, the display will stop
ashingandabeepisheard.
• To turn off all zones together, touch and hold
the on/off symbol for 1 sec.
Notes on use
• The power settings on the hob do not indicate
any set temperature and cannot be used to
judge one element against another.
• During cooking, the elements will cycle on and
off. This is normal.
Auto heat-up
• Select the desired zone by touching its own
symbol.Thecorrespondingdisplaywillash
“0”. Touch “+” until 9 is reached then press
the “+”again. A dot will appear next to the
“9.”andtheywillbothstarttoashfor10
secs. This indicates that auto heat up is on.
During this time the desired power level must
be set. After 10 secs a bleep sounds and the
dotbecomesxed.Thezonewillbesetatthis
level.
• If “0” or “9” are selected whilst in auto heat up
mode the function is cancelled

08_
LAMONA Appliances
Timed cooking
Refered
zone
LED’s
Timer
All 4 cooking zones can be operated under the
timer independently and at the same time for
up to 99 minutes. When the set time expires the
timer will beep and the cook zone will switch off
automatically.
To set the timed cooking to a zone:
• Set the desired zone power level as described
previously.
• Whilstthecookzonepowerlevelisashing
touch the timer key and the timer will
illuminate “00” and two Red LEDs will
illuminatetherstonewillbeashingonthe
timer to indicate the activated timed cook
zone and the second one “00.” Indicates that
the time can be adjusted.
• Using the “+” or “-” symbols, set the time
required in minutes.
To check remaining time:
• Touch the symbol for the desired zone followed
by the timer symbol.
To adjust the set time:
• Touch the symbol for the desired zone followed
by the timer symbol.
• Using the “+” or “-” symbols, reduce or
increasethetimerequired(inminutes).
To deactivate timed Cooking:
Touch the symbol for the desired zone followed by
the timer symbol.
Adjust the “-” symbol down to “0”. At the end of the
cooking time
At the end of the cooking time the buzzer will
activatefor1minandthezone’sLEDwillash.
Touch any key to deactivate.
Residual heat indicator
After a zone is switched off it will display “H” whilst
it remains hot.
lock:
• When the system is in child lock the controls
are deactivated. To lock and unlock the hob
touch and hold the key symbol.
Safety shut off
• If the power level of a zone is not changed
for a long period of time the zone will
automatically switch off. The length of time will
depend on the power setting, see table below
Power Level Max.timeon(hrs)
110
2 5
3 5
4 4
5 3
6 2
7 2
8 2
9 1
Using the hob

_ 09
User manual LAM1741
04 - Cleaning & maintenance
Ceramic glass hobs
• It is recommended that you clean and wash
thehobsurfacebeforeusingforthersttime.
Apply a thin coat of ceramic hob cleaner to the
hob to help maintain and protect it.
• The ceramic hob top can be cleaned using a
clean, damp cloth or kitchen paper. Do not
use a used dishcloth or sponge as they can
leavealmofdetergentonthesurfacewhich
can lead to discolouration. Please ensure that
the elements are cooled fully to avoid steam
burns.
• You can use a specialist ceramic cleaner to
restore the surface, but use sparingly to avoid
coating the hob top too thickly. Too much
cream cleaner will lead to discolouration. Use
a dry, clean cloth to polish the surface.
• For stubborn marks, a specialist hob scraper
can be used.
• Do not use steam cleaners or high pressure
cleaning equipment.
• Regular cleaning will prevent any salts or
minerals from accumulating on your hob and
discolouring the glass.
• Wipe any spillage as soon as possible.
• Clean the hob top as regularly as possible, this
will prevent any build up of grease which may
bearehazard.
• Foodswithhighsugarcontent(toffee,fruit
juice,jam,etc.)thatboiloverwhilecooking,or
spattered sugar stains must be immediately
removed using a scraper even if hot.
• Do not use abrasive products, bleach, hob
cleaner spray or pan scourers.
• Notes:
• The edge of the ceramic glass will always
appear to be a different colour than the top
surface due to the ground safety edge.
• Scratches or dark stains on the ceramic glass
that cannot be removed do not affect the
function of the appliance.
Safety when cleaning
For cleaning, the appliance must be switched off
and cooled down.
WARNING Risk of burns from residual heat.
Cleaning and maintenance

10_
LAMONA Appliances
05 - Trouble shooting
If you encounter a problem, it is often something minor, please read some of the suggested tips below.
The hob is not working Check the fuse/circuit breakers to see if you are experiencing a power
failure
The hob has turned itself off Check that the main on/off switch has not been touched or covered
accidentally, remove any objects on the hob and try turning it back
on again.
Repairs Repairs are to be carried out by trained service technicians.
Display F and letters If “F” and letters appear on the display, your unit has detected a
fault, the following table lists actions you should take to correct the
problems
Error codes
Hob Status
Codes Fault Description Action
H Residual Heat “ H” will switch off when
glass surface drops below 60oC
Hob Status
Codes Fault Description Action
F0 Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
FA Touch Control Error Switch the power off and on,The system will reset and the hob should
now be working correctly
FU Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
FJ Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
FC Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
Fr Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
Fc or F Overheat / Temperature Problem Allow hob to cool then Switch the power off and on, The system will
reset and the hob should now be working correctly
FE Overheat / Temperature Problem Allow hob to cool then Switch the power off and on, The system will
reset and the hob should now be working correctly
Ft Overheat / Temperature Problem Allow hob to cool then Switch the power off and on, The system will
reset and the hob should now be working correctly
FL Poor Ambient Light Conditions Switch off lighting in area, Clean hob surface, Switch the power off and
on, The system will reset and the hob should now be working correctly
If any of the above problems persist please contact the customer service line for further assistance,
Trouble shooting

_ 11
User manual LAM1741
06 - Installation
Installation
General information
Installationshouldonlybecarriedoutbyaqualied
installer or engineer.
Please pay attention to the following points;
Although every care has been taken to ensure
this appliance has no burrs, or sharp edges, We
recommend that you wear protective gloves when
installing and moving this appliance. This will
prevent injury.
Thehobshouldnotbettedaboveawashing
machine, a fridge or a freezer. Wall surfaces above
the work surface and in the immediate vicinity of
the cooking hob must be heat resistant.
Laminated surfaces and the adhesive used for
xingthemmustbeheatresistantinordertoavoid
any damage.
The space for air circulation, located underneath
and at the back of the hob improves its reliability by
ensuringthatitwillcooldown,efciently.
Installations should be carried out in line with the
NationalRegulationsapplicablewiththisproduct
type.
Note: Avoid installing the appliance next to doors
and under windows. This will avoid the potential
for hot cookware being knocked off the hob when
doors and windows are opened
Built-in appliances may only be used after they have
been built-into suitable built-in units and surfaces
that meet the required standards.
Positioning
Choosing your installation
• Make sure that the air inlets through the
ventilator grids underneath the hob are never
blocked.
Installing the hob over a unit with a drawer or
door
• The Hob’s air outlet is underneath work
surface. If necessary, remove the front
crosspiece of the unit to allow suitable
ventilation.
• We recommend that you install this appliance
in a work top which is a minimum 38mm deep.
• Thehobcanbettedintoaworktoplessthan
38mm deep, but the 20mm gap between hob
base and appliance or cabinet partition must
be maintained.
Installation above an oven
• Refer to the manufacturer’s instructions for
clearances above the oven. We recommend a
minimum 20mm gap between the bottom of
the hob and appliance
40mm Hob
Worktop
Screw
50mm Hob
Worktop
Screw
30mm Hob
Worktop
Screw
Worktop
25mm
oven or partition
Hob
5mm
In the case of a Pyrolytic oven
• If installing the hob above a pyrolytic oven,
additional provision for air circulation /
ventilation may be required. Due to the
excessive temperatures attained during
pyrolysis, using the hob at the same time may
cause the thermal safety device within the hob
to operate.
Clearances and dimensions – requirements
• Noshelforoverhangofcombustiblematerial
should be closer than 650mm above the hob.

12_
LAMONA Appliances
Installation
• There must be a minimum clearance of 50mm
between the edges of the hob and any side
walls; this clearance must be maintained up to
420mm above the worktop.
• When installing an extractor hood above the
hob, refer to its manufacturer’s instructions
Clearances and dimensions – requirements
• There must be a minimum clearance of 50mm
between the rear edge of the hob and the rear
wall. This clearance must be maintained up to
650mmabovetheworktop(unlessotherwise
statedinyourextractormanual)
560mm
50mm Min
55mm min
400mm min
490mm
Minimum distance
between carcasses must
be equal to width of hob
*
Minimum height to extractor
as recommend in extractor
instruction manual
*
50mm min between hob and rear wall
(>60mm to cut out aperture)
Fitting into worktop
Cut a hole in the work surface to the required size.
(560mmx490mm)asillustratedabove.
A clearance of at least 60mm should be maintained
between the cutout and any rear or side wall.
The worktop must be of heat-resistant material or
covered with heat-resistant material.
Protecting the cut-out
The types of chipboard used for work surfaces swell
relatively quickly in contact with humidity.
Apply a special varnish or adhesive to the cut edge
to protect it from steam or condensation which may
form under the work surface under the hob.
This hob can be installed conventionally
(glassabovetheworktop)orrecessedintothework
topforausht.
Conventional Installation
Apply the self adhesive seal to the underside edges
of the hob glass. For best results, the seal should
be adhered along each side in turn, as close to
the edge as possible, and trimmed at each corner,
taking care to ensure a neat join. Place the hob in
the aperture, checking the hob glass is covering the
work top along all four sides.
Set the front edge of the appliance parallel with the
front of the work top.
Locate and attach the securing clamps as required,
Tighten the screws so that the hob is pulled down
rmlyagainsttheworktop,thusensuringagood
seal.
Recessed method
Recess the work top to the appropriate depth
(Approx5mm)andshapetotthehob(add1mmto
overall glass size.
Apply the self adhesive seal to the underside of
the hob glass. For best results, the seal should be
adhered along each joint in turn, as close to the
edge as possible, and trimmed at each corner,
taking care to ensure a neat join. Insert the hob into
the recess, ensuring that the foam seal is sitting
correctly.
Locate and attach the securing clamps to the
front and rear underside of the hob, using the
screws provided. Tighten the screws so that the
hobispulleddownrmlyagainsttheworktop,thus
ensuring a good seal.
Youmaywanttollanygapbetweenthehobtop
glass and the work top surface with silicone sealant.

_ 13
User manual LAM1741
Installation
DONOTtsiliconesealantundertheglasshob
instead of foam seal.
1
1. Self adhesive seal
Worktop Hob
CONVENTIONAL INSTALLATION
1
Worktop Hob
RECESSED METHOD
1. Self adhesive seal
2. Silicone sealant
2 1
Fixing brackets
Installation advice :
Depending on the cabinets, the worktop thickness
and the hob positioning, it is possible for the hob
base and/or the clamp brackets to interfere with
parts of the cabinet.
If necessary cut away cabinetry and use appropriate
xingbracketsforyourinstallation
53mm min
Side wall
Rear wall
560mm (60cm hobs)
660mm (70cm hobs)
860mm (90cm hobs)
Worktop cutout sizes
53mm min
490mm 60 - 70cm 370mm 90cm
Typical Installation positions
Typical Installation positions
Seal
Underside of hob
Secure the hob to the worktop by means
of the brackets provided, taking the thickness
of the worktop into account
.
40mm Hob
Worktop
Screw
50mm Hob
Worktop
Screw
30mm Hob
Worktop
Screw
Worktop
25mm
oven or partition
Hob
5mm

14_
LAMONA Appliances
Connect to the electricity Supply
This appliance must be earthed. Only connect
to the electrical mains terminal with the power
switched off. The electrical mains terminal is live.
Follow the terminal block connection schematic.
Loose and inappropriate connections can make the
terminal overheat.
Ensurethecableclampisttedcorrectlyand
securely.
A device must be provided in the electrical
installation which allows the appliance to be
disconnected from the mains at all poles with a
contact opening of at least 3mm.
We recommend that the appliance is connected
by a competent person who is a member of a
“Competent Person Scheme” who will comply with
the required local regulations.
Connection should be made with a suitable cable.
Ensure that you route all mains electrical
cables well away from any adjacent heat source,
such as an oven or grill.
Firstly open the terminal block cover using a small
atbladedscrewdriverinthedoorreleasetabs
shown below.
Strip the wires & connect to the terminal block as
shown in the terminal block schematic.
Fit the cable clamp & secure with the screw
provided.
Close the terminal box, ensuring that the cover is
engaged on the locking tabs.
Note; The cable clamp has a ratchet type
mechanism on the right hand side of the retaining
arm.
Door release tab
Cable clamp screw
Cable clamp ratchet
1
2
3
1
2
3
1
2
Live
Neutral
Earth
1
2
BROWN / L1
BLUE / N
GREEN/YELLOW / PE
230V.....240V
Terminal Block Connection
Schematic
Installation

_ 15
User manual LAM1741
Technical data
Technical Data
Electrical Supply 220~240V50Hz
TotalPowerRating@220-240V
~50Hz(kW) 7.2
Hob Details
Cook Zone Normal Power
Rating kW
LH Front 2.1
LH Rear 1.2
RH Rear 1.8
RH Front 1.2
HobDimensions(WXDXH)mm 590 x 520
CutOutRequired(WxD)mm 560 x 490
Cable Type HORR-F5 4.0mm ², 3 core or equivalent
Installation

16_
LAMONA Appliances
07 - Your guarantee
Product Guarantee Details (UK only)
Yourappliancehasthebenetofacomprehensivemanufacturer’sguaranteewhichcoversthecostof
breakdown repairs. (Details of which are shown on your Proof of Purchase Document).
• Anyclaimduringtheperiodoftheguarantee(MUSTBEACCOMPANIEDBYTHEPROOFOFPURCHASE)
• The product must be correctly installed and operated in accordance with the manufacturer’s
instructions and used for normal domestic purposes.
• This guarantee does not cover accidental damage, misuse or alternations which are likely to affect the
product.
• The guarantee is invalid if the product is tampered with, or repaired by any unauthorised person.
(The guarantee in no way affects your statutory or legal rights)
What to do if you need to report a problem-
Please ensure you have ready:
• Theproduct’smodel&serialnumbers
• Howdens Proof of Purchase document
• Your full contact details
Call the Service Line on 0845 00 60 006
Your guarantee

_ 17
User manual LAM1741

18_
LAMONA Appliances
Notes

_ 19
User manual LAM1741
Notes

If supplied, please stick your self adhesive product rating plate
here, or make a note of the product serial number below in the
box below for future reference.
SerialNumber:...........................................................................................
ISSUE v3-130712
