turck TBEN-LG EtherNet/IP User manual

TBEN-LG EtherNet/IPTM
Configuration Guide
Date: 03.20.2015
Version: 1.4
TURCK Inc.

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 2
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 3
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
Table of Contents
Table of Contents..................................................................................................................... 3
Introduction ........................................................................................................................... 5
TBEN-LG................................................................................................................................... 7
TBEN-LG Product Line.......................................................................................................... 7
Part Numbers ................................................................................................................... 7
Connection Diagrams ....................................................................................................... 8
LED Diagnostics...................................................................................................................11
Ethernet Ports and Device Fault LEDs.............................................................................12
Power LED ......................................................................................................................13
IO LEDs TBEN-LG-16DIP................................................................................................14
IO LEDs TBEN-LG-16DOP..............................................................................................14
IO LEDs TBEN-LG-8DIP-8DOP.......................................................................................15
IO LEDs TBEN-LG-16DXP ..............................................................................................15
IO Data Format.....................................................................................................................16
TBEN-LG-16DIP..............................................................................................................16
TBEN-LG-8DIP-8DOP.....................................................................................................17
TBEN-LG-16DOP............................................................................................................17
TBEN-LG-16DXP.............................................................................................................18
Setting up IP Address...........................................................................................................19
Address Switches in Static Rotary ...................................................................................19
BOOTP/DHCP Mode (300/400).......................................................................................20
Note:................................................................................................................................20
When the device is set to 500 (PGM) mode, its IP address can be further changed using
either the IP Address Tool or WEB page. ........................................................................20
PGM-DHCP Mode (600)..................................................................................................21
Note:................................................................................................................................21
When the device is set to 600 (PGM-DHCP) mode, its IP address can be further changed
using either the IP Address Tool or WEB page................................................................21
PGM Mode (500, 600) .....................................................................................................22
PGM (500) and Web Server.............................................................................................22
IP Address Tool...............................................................................................................24
PGM (500) and IP address tool........................................................................................25
Restore Mode (0).............................................................................................................27
Factory Reset Mode (900) ...............................................................................................27
TBEN EtherNet/IP Configuration............................................................................................28
TBEN Configuration Using EDS Files...................................................................................28
Configure EtherNet/IP User Interface...............................................................................29
Create RSLogix5000 Project............................................................................................30
Install EDS File(s)............................................................................................................31
Create new TBEN Module...............................................................................................33
Configure Connection and data format ............................................................................36
Module Definition Data Format ........................................................................................37

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 4
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
TBEN Data Tags..............................................................................................................38
TBEN-LG Configuration Parameters................................................................................40
Configuration Assembly Data Structure...........................................................................41
TBEN-LG Profile Info.......................................................................................................45
TBEN Configuration Using Generic Device ..........................................................................46
Configure TBEN-LG-16DIP..............................................................................................47
Configure TBEN-LG-16DOP............................................................................................47
Configure TBEN-LG-8DIP-8DOP.....................................................................................48
Configure TBEN-LG-16DXP ............................................................................................48
Configure Connection......................................................................................................49
TBEN Web Server...............................................................................................................50
Home Page......................................................................................................................50
Login / password..............................................................................................................51
Network Configuration .....................................................................................................52
Station Configuration .......................................................................................................53
Station Diagnostics..........................................................................................................54
Ethernet Statistics............................................................................................................54
IO Parameters.................................................................................................................55

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 5
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
Introduction
The guide provides information about device features, connection diagrams and LED diagnostics.
It also shows how to set up device IP address using different tools. TBEN-LG devices can be configured
with EDS files, or using a generic device profile. Device web server provides advanced configuration and
diagnostics information. TURCK IP address tool is used for quick discovery of TURCK devices residing
on different VLANS.
The guide, together with the data sheets, provides sufficient information for using TBEN in DLR
(device level ring) or QC (quick connect) applications. DLR application does not require any specific de-
vice setup, as devices are ready for DLR networks. QC mat be enabled or disabled by a single configura-
tion bit, part of configuration data tag. Address conflict detection (ADC) is implemented and enabled in
the device by default. TBEN supports up to 3 TCP connections and 6 CIP connections, and it may be
configured with 3 PLCs using Exclusive Owner, Input only or Listen Only connections.

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 6
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 7
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
TBEN-LG
TBEN-LG Product Line
The TBEN-LG series are multiprotocol communication adapters and they support Modbus
TCP/IP, EtherNet/IP and PROFINET communication protocols. All protocols are enabled “out-
of-box” by default. After power up, a multiprotocol station queries all necessary ports to detect
what protocol is used. The “Active Fieldbus Protocol” is defined as the first protocol to do one of
the following actions:
−Modbus TCP Write to output register range.
−EtherNet/IP Establish Class 1 Exclusive Owner connection to device.
−PROFINET Connect request.
This “Configuration Guide” shows TBEN-LG-8DIP-8DOP in an EtherNet/IP environment to de-
scribe features and configuration procedures of the TBEN-LG series.
Part Numbers
Part Number Input description Output description Ethernet
Number of inputs
Input type
Inputs per con- nector
PNP / NPN type
Number of outputs
Output type
outputs per connector
Maximum out- put load
Short circuit protection
Ethernet ports
Configuration Assembly
DLR
QC
ACD
TBEN-LG-16DIP 16 2S 2 PNP ✔#2
2 ✔
✔ ✔ ✔
TBEN-LG-16DOP 16 2G 2 1A
#1
✔
2
✔ ✔ ✔ ✔
TBEN-LG-16DXP 16 2X 2 PNP 16 2X 2 1A ✔
2
✔ ✔ ✔ ✔
TBEN-LG-8DIP-8DOP 8 2S 2 PNP 8 2G 2 1A ✔
2
✔ ✔ ✔ ✔
Key: 2S: Two PnP inputs per connector
2X: Dual combined input/output per connector, PNP / 1A
2G: Two outputs per connector, 1A each
#1: 2A output when single output per connector is used
#2: Inputs protected per connector; outputs are individually protected
DLR Device Level Ring
QC Quick Connect; QC time 100msec
ACD Address Conflict Detection and resolution

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 8
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
Connection Diagrams
Device Type
Ethernet
M12, d-coded
IN
M12, a-coded
Power (7/8“)
TBEN-LG-16DIP
P1 P2
1 = TD+ 1 = RD+
2 = RD+ 2 = TD+
3 = TD-3 = RD-
4 = RD-4 = TD-
(see „Note 1“)
C0 … C7
1 = VAUX1 (+)
2 = Second input
3 = V1 (-)
4 = First input
5 = FE
(see „Note 2“)

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 9
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
Device Type
Ethernet
M12, d-coded
IN
M12, a-coded
Out
M12, a-coded
Power (7/8“)
TBEN-LG-8DIP-8DOP
P1 P2
1 = TD+ 1 = RD+
2 = RD+ 2 = TD+
3 = TD-3 = RD-
4 = RD-4 = TD-
(see „Note 1“)
C0 … C3
1 = VAUX1 (+)
2 = Second input
3 = V1 (-)
4 = First input
5 = FE
C4 … C7
1 = VAUX2 (+)
2 = Second output
3 = V2 (-)
4 = First output
5 = FE
TBEN-LG-16DOP
P1 P2
1 = TD+ 1 = RD+
2 = RD+ 2 = TD+
3 = TD-3 = RD-
4 = RD-4 = TD-
(see „Note 1“)
C0 … C7
1 = VAUX2 (+)
2 = Second output
3 = V2 (-)
4 = First output
5 = FE

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 10
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
Device Type
Ethernet
M12, d-coded
IN
M12, a-coded
Out
M12, a-coded Power (7/8“)
TBEN-LG-16DXP
P1 P2
1 = TD+ 1 = RD+
2 = RD+ 2 = TD+
3 = TD-3 = RD-
4 = RD-4 = TD-
(see „Note 1“)
C0 … C7
1 = VAUX1 (+)
2 = Second input
3 = V1 (-)
4 = First input
5 = FE
DXP allows for any
combination of IO per
single connector
C0 … C7
1 = VAUX2 (+)
2 = Second output
3 = V2 (-)
4 = First output
5 = FE
Note 1:
The pin-out of P1 and P2 are “crossed over”. P1 has a “NIC-Type” connection and P2 has a “Switch-
Type” connection. The TBEN devices are configured with Auto-MDIX enabled when not used for fast
startup / quick connect. In that case the switch detects the cabling type itself.
With the crossed connection of P2 it is possible to connect multiple devices in a row without Auto-MDIX
with 1:1 EtherNet cables. This ensures that the switch could establish a link quickly for fast start-up devic-
es.
Note 2:
VAUX1 = V1 – 0.2 VDC (voltage drop over protective circuit)
VAUX2 = V2 – 0.2 VDC (voltage drop over protective circuit)

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 11
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
LED Diagnostics
The notation of the IO LEDs (LD04 … LD72) is “LDxy”. It is linked to the appropriate channel
and is coded as follows:
LDxy key:
−x: connector number: 0, 1,…, 7 (C0, C1, …, C7)
−y: signal pin number of the appropriate connector ( 2, 4)
−LD24: connector 2, pin 4

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 12
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
Ethernet Ports and Device Fault LEDs
LED Status Description
LD_P1 and LD_P2 (same functionality for all device types)
off No Ethernet link
LD_P1 , LD_P2 green on Link 100MBit. The LED flashes during data transfer.
( yellow / green ) yellow on Link 10MBit. The LED flashes during data transfer.
yellow on / green on Not valid state
LD_BUS (same functionality for all device types)
off No supply voltage
green on Active connection to a master
LD_BUS green blinking Ready for operation
( red / green ) red on IP address conflict is detected or restore mode (0 /
900 switch position),
red flashing Blink / Wink is active (command sent from the IO
assistant, IP address tool)
alternating
red on / green on Auto-negotiation and/or DHCP/BOOTP waiting for IP
address assignment
LD_ERR (same functionality for all device types)
off No supply voltage
LD_ERR green on Normal operation
( red / green ) red on Diagnostics active
red on / green on Not valid state

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 13
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
Power LED
LED Status Description
LD-PWR (device powered by V1 only)
TBEN-LG-16DIP
LD_PWR
( green ) off V1 power off or undervoltage < 18V
on V1 and V2 power on
LD_PWR (device powered by V1 and V2)
TBEN-LG-8DIP-8DOP
TBEN-LG-16DOP
TBEN-LG-16DXP
LD_PWR
( green )
off V1 power off or undervoltage < 18V
green on V1 and V2 power on
flashing
V1 power on
V2 power off or undervoltage < 18V

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 14
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
IO LEDs TBEN-LG-16DIP
LED Status Description
Input Channel I0,…,I15 LEDs
Channel LEDs: LD02 … LD74 (Channel CH02 … Channel CH74)
TBEN-LG-16DIP
LD02,...,
LD72
LD04,…,LD7
4
( red / green )
off Input inactive
green on Input active
red flashing Power overload at the connector “x”, both LEDs of
the input channels CHx2 and CHx4 are flashing.
IO LEDs TBEN-LG-16DOP
LED Status Description
Output Channel O0,…,O15 LEDs
Channel LEDs: LD02 … LD74 (Channel CH02 … Channel CH74)
TBEN-LG-16DOP
LD02,...,
LD72
LD04,…,LD7
4
( red / green )
off
Output inactive
green on Output active
red on Power overload at the corresponding output chan-
nel CHxy

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 15
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
IO LEDs TBEN-LG-8DIP-8DOP
LED Status Description
Input Channel I0,…,I7 LEDs
Channel LEDs: LD02 … LD34 (Channel CH02 … Channel CH34)
TBEN-LG-8DIP-8DOP
LD02, LD04,
LD12, LD14,
LD22, LD24,
LD32, LD34,
( red / green )
off Input inactive
green on Input active
red flashing Power overload at the connector “x”, both LEDs of
the input channels CHx2 and CHx4 are flashing.
Output Channel O0,…,O7 LEDs
Channel LEDs: LD42 … LD74 (Channel CH42 … Channel CH74)
TBEN-LG-8DIP-8DOP OUTPUTS
LD42, LD44,
LD52, LD54,
LD62, LD64,
LD72, LD74,
( red / green )
off Output inactive
green on Output active
red on Power overload at the corresponding output
channel CHxy.
IO LEDs TBEN-LG-16DXP
LED Status Description
IO Channel IO0,…,IO15 LEDs
Channel LEDs: LD02 … LD74 (Channel CH02 … Channel CH74)
TBEN-LG-16DXP
LD02,...,LD72
LD04,…,LD7
4
( red / green )
off IO inactive (input or output)
green on IO active (input or output)
2 x red flashing Power overload at the connector “x”, both LEDs of
the input channels CHx2 and CHx4 are flashing.
red on
Power overload at the corresponding output
channel CHxy.
green on / flashing red
e.g. LD22
Output channel CH22 active (solid green / flashing
red).
Power overload at the input channel CH24 (flashing
red)

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 16
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
IO Data Format
Abbreviations:
I0…I15: Inputs
O0…O15: Outputs
FCE: Force mode active
CFG: I/O configuration error
COM: Communication lost on the internal bus
V1: V1 too low
V2: V2 too low
DiagWarn: Summarized diagnostic of the device
EM0: Summarized diagnostic of the device
ECx : Error Code bit x in error-code bit area
SRO0…15: Short circuit recovery mode of outputs 0…15
Err Vaux0…7: Auxiliary supply error on connector 0…7
Err Out0…15: Short circuit output 0…15
Inv.I0…I15: Inverted input signal 0…15
TBEN-LG-16DIP
Note: a blank field means reserved or not used.

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 17
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
TBEN-LG-8DIP-8DOP
TBEN-LG-16DOP

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 18
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
TBEN-LG-16DXP

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 19
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
Setting up IP Address
TBEN has three rotary switches which are used to set either the last octet of the device IP ad-
dress or device mode of operation. Valid address range and mode of operation are:
The address switches are pre-set out of box to 600 (PGM-DHCP mode). IP address can be as-
signed immediately using DHCP server.
General procedure for IP address setup is:
−Set rotary switches to desired mode (300, 400, 500, 600)
−Cycle power to the station
−Run IP address utility to assign IP address
−Set address switches to static rotary position or PGM mode
−Cycle power to the station
The TBEN station IP address can be configured and/or changed in following ways:
−Using static rotary mode
−BootP Server utility
−DHCP Server utility
−TBEN Web page
−IP Address tool
Address Switches in Static Rotary
When address switches are in static mode, the last octet may be dialed in 1-254 range.
Addresses 0 and 255 are reserved and cannot be used.
Following example shows the last octet set to of address xx.xxx.xxx.173
Setting rotary switches to any other position not listed on the device or data sheet sets device
into DHCP mode and bus LED flashes green / red.

TBEN-LG EtherNet/IPTM Configuration Guide
TURCK •3000 Campus Drive •Minneapolis, MN 55441-2656 20
Phone: [phone] •Toll Free: 800.544.7769 •Fax: [phone] •www.turck.us
BOOTP/DHCP Mode (300/400)
The TBEN rotary switches, when set to 300 or 400, allow for IP address assignment as follows:
−Set the rotary switches to 300 to enable BOOTP mode and power cycle the device
−Set the rotary switches to 400 to enable DHCP mode and power cycle the device
−Run BOOTP or DHCP utility and assign IP address
−Set the rotary switches either to 500 (PGM mode) or to a number that matches the last
octet of the assigned IP address (e.g. 125)
−Power cycle the device
Note:
When the device is set to 500 (PGM) mode, its IP address can be further changed using
either the IP Address Tool or WEB page.
