TV One 1T-DVI-RH User manual

Instruction Manual
1T-DVI-RH
DVI Repeater With HDCP

2

Table Of Contents
1.0 Introduction 4
2.0 Specifications 5
3.0 Checking Package Contents 5
4.0 Connecting The Hardware 6
5.0 Operating The Unit 6
6.0 Troubleshooting 6
7.0 Limited Warranty 7
8.0 Regulatory Compliance 7
9.0 Contact Information 8

1.0 INTRODUCTION
Thanks for purchasing this 1T-DVI-RH DVI Repeater from TV One. The 1T-DVI-
RH DVI Repeater is designed to extend the distance a DVI signal with HDCP can
be sent up to 40 feet (24 meters). Our professional video conversion products
have been serving the industry for over twenty years. TV One offers a full line of
high quality Video Scalers, Scan Converters, Analog-Digital (DV, SDI, DVI)
Converters, Standards Converters, Digital Video Recorders, Frame
Synchronizers, Time Base Correctors, LCD Monitors, Matrix Routing Switchers
and Distribution Amplifiers.
1.1 Liability Statement
Every effort has been made to ensure that this product is free of errors. TV One
cannot be held liable for the use of this hardware or any direct or indirect
consequential damages arising from its use. It is the responsibility of the user of
the hardware to check that it is suitable for his/her requirements and that it is
installed correctly. All rights reserved. No parts of this manual may be
reproduced or transmitted by any form or means electronic or mechanical,
including photocopying, recording or by any information storage or retrieval
system without the written consent of the publisher.
TV One reserves the right to revise any of its hardware and software following its
policy to modify and/or improve its products where necessary or desirable. This
statement does not affect the legal rights of the user in any way.
All third party trademarks and copyrights are recognised. The TV One logo, TV
One-task and CORIO are the registered Trademarks of TV One. All other
trademarks are the property of their respective holders.
1.2 FEATURES
The 1T-DVI-RH DVI Repeater with HDCP has many features that enable it to
perform in a superior manner. Among those features you will find:
•Ultra-Compact, High Performance Unit
•Resolutions up to 1600x1200
•DDC Pass-thru from Display
•HDCP Compliant
•Extends DVI Signals 40 feet (using premium cable)
•Cascade up to 3 units (using premium cable)
•Rugged Metal Case
4

2.0 SPECIFICATIONS
Performance
Maximum Distance 40 Feet (Note 1)
Maximum Cascade 3 Units (Note 1)
Maximum Pixel Rate 165Mhz @ 40’ (12m) Maximum
Maximum Resolution 1600x1200@60Hz
I/O Connectors DVI-I Female
Indicators
Power On LED
Mechanical
Size (H-W-D) 1.15”x3”x4.65” (29x75x118mm)
Weight (Net) 11 oz (305g)
Warranty
Limited Warranty 2 Years Parts and Labor
Environmental
Operating Temperature 0°to +48°C (+32°to +120°F)
Operating Humidity 10% to 85%, Non-condensing
Storage Temperature -10°to +70°C (+14°to +158°F)
Storage Humidity 10% to 85%, Non-condensing
Power Requirements
External Power Supply 9VDC@600ma
Regulatory Approvals
Amplifier Units FCC, CE
Power Supplies UL, CE, CSA
Accessories Included
1x AC Power Cable US, UK or Euro Type
1x Operations Manual
Notes (1) Use Premium 24 gauge cable, such
as Z-Plus Grade.
3.0 CHECKING PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make certain
the following items are contained in the shipping carton:
•1T-DVI-RH DVI-I HDCP Compliant Amplifier
•1x AC Power Adapter
•1x Operations Manual
Note: Please retain the original packing material should the need ever arise to
return the unit. If you find any items are missing, contact your reseller or TV One
immediately. Have the Model Number, Serial Number and Invoice available for
reference when you call.
5

4.0 CONNECTING THE HARDWARE
Please study the panel drawings below and become familiar with the signal input,
output and power input.
5.0 OPERATING THE UNIT
•Turn off DVI Source and the DVI capable monitor.
•Connect a DVI extension cable between the DVI Source and the ‘DVI
In’ port of repeater.
•Connect a DVI extension cable between the monitor and the ‘DVI out’
port of repeater.
•Connect the DC power cord from the AC Adapter to the unit and plug
the AC adapter into an active AC socket.
•Turn on the DVI Source and DVI capable monitor.
6.0 TROUBLESHOOTING
If the repeater does not appear to be functioning, make certain that both the DVI
source and DVI capable monitor are functioning correctly by connecting the DVI
source directly to the monitor using a cable with a length of 6 feet or less. If the
signal is present, make certain that the Power On LED is lighted on the 1T-DVI-
RH. If it is, measure the cable length you are attempting to use between the
source to the repeater and the repeater to the monitor. The cable from the source
to the repeater should be 6 foot long or less and the cable to the monitor must be
no longer than 40 feet. Note that you must use high quality 24 gauge cables to
achieve the distance specified. Lastly, Inspect the cables and connectors for
damage.
After trying the above suggestions should the problem still persist, contact your
dealer for additional suggestions before contacting TV One. Should the dealer’s
technical personnel be unable to assist you, contact TV One via our support
website: http://tvone.crmdesk.com. Create a technical support request on the
site and our support team will respond within a short period of time.
6

7.0 LIMITED WARRANTY
LIMITED WARRANTY – With the exceptions noted in the next paragraph, TV
One warrants the original purchaser that the equipment it manufactures or sells
will be free from defects in materials and workmanship for a period of two years
from the date of purchase. Should this product, in TV One’s opinion, prove
defective within this warranty period, TV One, at its option, will repair or replace
this product without charge. Any defective parts replaced become the property of
TV One. This warranty does not apply to those products which have been
damaged due to accident, unauthorized alterations, improper repair,
modifications, inadequate maintenance and care, or use in any manner for which
the product was not originally intended.
Items integrated into TV One products that are made by other manufacturers,
notably computer hard drives and liquid crystal display panels, are limited to the
term of the warranty offered by the respective manufacturers. Such specific
warranties are available upon request to TV One.
If repairs are necessary under this warranty policy, the original purchaser must
obtain a Return Authorization Number from TV One and return the product to a
location designated by TV One, freight prepaid. After repairs are complete, the
product will be returned, freight prepaid.
LIMITATIONS - All products sold are "as is" and the above Limited Warranty is in
lieu of all other warranties for this product, expressed or implied, and is strictly
limited to two years from the date of purchase. TV One assumes no liability to
distributors, resellers or end-users or any third parties for any loss of use,
revenue or profit.
TV One makes no other representation of warranty as to fitness for the purpose
or merchantability or otherwise in respect of any of the products sold. The
liability of TV One with respect to any defective products will be limited to the
repair or replacement of such products. In no event shall TV One be responsible
or liable for any damage arising from the use of such defective products whether
such damages be direct, indirect, consequential or otherwise, and whether such
damages are incurred by the reseller, end-user or any third party.
8.0 REGULATORY COMPLIANCE
The 1T-DVI-RH has been tested for compliance with FCC and CE regulations.
The Power Adaptor/Supply has been tested for compliance with UL, CSA, CE
regulations.
7

9.0 CONTACT INFORMATION
Should you have questions or require assistance with this product in areas
not covered by this manual, please contact TV One at the appropriate
location shown below:
TV One USA
1350 Jamike Drive
Erlanger, KY 41018
USA
Tel [phone]
Fax [phone]
[email protected]
www.tvone.com
TV One Europe
Continental Approach
Westwood Industrial Estate
Margate, Kent CT9 4JG, UK
Tel [phone]
Fax [phone]
[email protected]
www.tvone.co.uk
TV One Latin America
2790 NW 79 Ave
Miami, FL 33122
USA
Tel [phone]
Fax [phone]
[e-mail]
www.tvonela.com
TV One Mercosur
Honduras 5849, 2nd Floor, Office C
(C1414BNI) Capital Federal
Buenos Aires, Argentina
Tel [phone]
Fax [phone]
[email protected]
www.tvonela.com
TV One Asia
10F, NO.34, Sec. 2
San-Min Rd, Panchiao City
Taipei Hsien 220
Taiwan R.O.C.
Tel [phone]
Fax [phone]
[email protected]
www.tvoneasia.com
TV One China
Rm. A 17C,
Regalia Building No.29,
Xiangcheng Rd.
Pudong, Shanghai
China (200122)
Tel [phone]
Fax [phone]
[email protected]
www.tvonechina.com
