DT Research DT302RP Assembly instructions

Rugged Tablet
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2023, DT Research, Inc. All Rights Reserved. BOG121223 DT302RP ENG
INTRODUCTION
Thank you for acquiring the DT302RP Rugged Tablet. It features the integraon of a
10.1” LED-backlit, sunlight readable (800 nits) touchscreen and a high-performance,
energy-ecient Intel® Core™ processor within a slim, durable, anmicrobial
enclosure. The DT302RP Rugged Tablet is available with Microso® Windows®
operang system. The soware operang system features web browser, client/server
compung soware, media player, accessories, and applicaons support..
PACKAGE CONTENTS
• One DT302RP with Baery Pack and Handstrap
• AC-DC Power Adapter with Power Cord
• Basic Operaon Guide
DT302RP

2
Button Functions
BUTTON ACTION
Power Buon
Programmable Buons
Brightness Buons
Baery Latch *Push the switch up to unlock the latch, then slide the latch le to remove the baery.
Input/Output Ports
Ethernet Port
Audio Jack
USB 3.0 Port
USB Type-C Port
DC-In Jack
Front & Back Cameras (Oponal)
Barcode Scanner (Oponal)
1
2
3
4
A
B
C
D
F
G
E
4
1
F
F
G
A
C
D
E
B
3
PRECAUTIONS
• Always exercise care when operang and handling the DT302RP.
• Do NOT apply excessive pressure to the display screen.
• We recommend using the Digital Pen (oponal) to keep the screen clean.
• Avoid prolonged exposure of the display panel to any strong heat source.
Wherever possible, the DT302RP should face away from direct light to reduce
glare.
• If the AC-DC power adapter is used to recharge or power the tablet, do NOT use
any AC-DC adapter other than the one provided or acquired from the manufac-
turer or its partners.
• In the unlikely event that smoke, abnormal noise, or strange odor is present,
immediately power o the DT302RP and disconnect all power sources. Report
the problem to your device provider immediately.
• Never aempt to disassemble the DT302RP, as this will void the warranty.
BASIC FEATURES
The DT302RP rugged tablet integrates a bright display, USB ports, and embedded
networking elements such as wireless LAN or oponal 4G.
A DT302RP typically integrates an 802.11ac wireless LAN (WLAN) adapter that may
connect to other wireless devices or access points. If your DT302RP does not come
with such a network adapter, please consult your device provider to establish the
desired network connecvity.
NOTE:
To obtain protecon consistent with any IP rang for the device, the I/O (audio,
power, USB, card reader, etc.) port doors must be closed. If the IP protecon is
compromised by mishandling or misuse, such as by leaving port doors open or
improperly closed, any resulng product damage will not be covered under any
DT Research warranty.
2
3
2

OPERATION
Powering ON and OFF
To acvate the DT302RP, push and quickly release the Power Buon. The display will
come on in a few seconds. To put the DT302RP in Standby mode, push and quickly
release the Power Buon. To turn the DT302RP o for extended storage, power
o safely using any soware funcon that “shuts down computer” provided in the
soware operang system.
NOTE:
The baery pack shipped with your tablet may be low in power—please use
the AC-DC adapter with the DT302RP when seng up for the rst me to fully
charge the baery pack, or use the oponal baery charger kit.
NOTE:
When the baery pack is charging, the blue-colored Baery LED should blink
slowly. If plugging in the AC-DC adapter does not trigger this blinking acvity
and the LED stays dark, the baery pack(s) may have been drained substanally.
Try unplugging/replugging the AC-DC adapter to the DT302RP a few mes to
acvate the charging process.
NOTE:
To conserve power, use (push and quick release) the Power Buon to put the
tablet in “Standby” mode while not in use. Pushing briey on the same buon
will wake up the system within seconds.
NOTE:
For DT302RP, avoid using the Power Buon (“hold 4+ seconds” feature) to turn
o the tablet—this form of hardware shutdown is intended to be a means of
recovery from lockups, and not as normal operaon.
4
Start Up
If the power up (from Standby mode or otherwise) is successful, the appropriate
interface will be displayed aer a launch sequence of several seconds. The wireless
LAN connecon may take 10-15 seconds to be established.
Configuring the Mobile Tablet
The DT302RP may be congured using the ulies and methods dictated by
the soware operang system. The DT302RP should be congurable for various
properes such as user proles, network features, and several system elements.
Wireless Networking
Wireless LAN
The DT302RP is oen delivered with an embedded (user-inaccessible) 802.11ax
WLAN adapter equipped with a hidden custom antenna.
• Through the support of typical WLAN adapters, the DT302RP should be able to
detect all 802.11 access points in the vicinity for you to select the access point of
your choice for connecon.
• The SSID and WEP/WPA/WPA2 (if enabled) parameters on the DT302RP and the
access points have to match. The SSID is case-sensive and it is recommended
that you enable WEP/WPA/WPA2 encrypon (or advanced alternaves) for
secure access.
• When WEP/WPA/WPA2 is enabled, you may need to consult your network
administrator or your networking equipment literature to properly congure
associated sengs such as Authencaon mode, etc.
• Refer to the access point operang manuals for seng up the 802.11 access
points.
5

USING THE MOBILE TABLET
Peripherals Support
Through its USB ports, the DT302RP supports a wide range of USB-based peripherals.
These peripherals are applicable for soware installaon, applicaons storage, data
storage, and system soware recovery and updates.
For More Support
Users can download the Tablet Modules Basic Operaon Guides from the DT Research
website.
If the DT302RP comes with a Mobile broadband module, please contact your product
and/or service provider for the SIM Card installaon procedures.
Enable the Backup Battery
The DT302RP backup baery compartment comes with an insulaon scker, which
isolates the baery from the contacts in the baery compartment. This scker
prevents the baery from draining during storage and shipment. Please remove the
scker before using the tablet to enable the backup baery to funcon. If storing the
tablet for a long me, it is advised to set the main baery into shipping mode and
put something like the scker on the backup baery buon to disable the backup
baery.
6
To Hold the Tablet
Le hand: grip the le back side of the tablet
with your le hand four index ngers, with
thumb resng on the top of the back side of the
tablet and palm securely against the back.
Right hand: grip the right back side of the tablet
with your right hand four index ngers, with
thumb resng on the top of the back side of the
tablet and palm securely against the back.
7
Federal Communication Commission Interference
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protecon against harmful interference in
a residenal installaon. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instrucons, may cause harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a parcular
installaon. If this equipment does cause harmful interference to radio or
television recepon, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Cauon: Any changes or modicaons not expressly approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules.
Operaon is subject to the following two condions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operaon.
This device and its antenna(s) must not be co-located or operang in
conjuncon with any other antenna or transmier.
This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du
Canada.
