TYAN S5517 User manual

Single LGA1155 socket supports (1) I3/I5/I7 32nm/ 22nm
series CPU
Intel® Q67 PCH
(2) 240-pin DDR3 DIMM slots support up to 16GB U-DDR3
*1600/1333/1066MHz without ECC memory
(1) PCI-E Gen.2/ Gen.3* x16 slot
(1) PCI-E Gen.2 x8 slots (w/ x4 link)
(4) SATA-II connectors w/ RAID 0, 1, 10, 5 support
(2) SATA-III connectors
(2) GbE LAN
(8) USB2.0 ports on rear I/O
Intel®Q67 Chipset
Entry single-socket for Embedded
Product
S5517
S5517AG2NR
Specifications are subject to change without notice. Items pictured may only be representative.
SINGLE-SOCKET
EMBEDDED
PLATFORM
* Features provided by i3/i5/i7, 22nm(Ivy Bridge)CPU

USA
Tel: [phone]
Fax: [phone]
Taiwan
Tel: [phone]
Fax: [phone]
China
Shanghai Tel: [phone] Ext 1366
China Tel:-86-010-62555015 Ext 8302
Japan
Tel: [phone]
Fax: [phone]
Europe
Sales: [phone]
Technical Support: [phone]
Block Diagram
Block Diagram
Specifications
TYAN Business Unit
MITAC INTERNATIONAL CORP.
S5517
S5517AG2NR
(Specifications are subject to change without notice. Items pictured may only be
representative.)
Intel® Core i3/ i5/ i7 32nm/22nm series processors
LGA 1155/ (1)
Max up to 95W
Intel®Q67
Nuvoton 5577D
(2) DIMM slots
Unbuffered Non-ECC DDR3 1600*/ 1333/1066
Up to 16GB
2 Channels
1.5V
Expansion
Slots
(1) PCI-E Gen.2/Gen3* x16 slot
(1) PCI-E Gen.2 x8 slot (w/ x4 link)
(2)
Intel®82583V
Intel®82579LM
Connector (6) SATA
Controller Intel®Q67
Speed (2) 6.0 Gb/s (blue color), (4) 3.0 Gb/s (black
color)
RAID RAID 0/1/10/5 (Intel RST)
D-Sub 15-pin / DVI-D
Up to 1920x1440
Intel®Q67
Realtek ALC888
High Definition Audio
Nuvoton WPCT210AA0WX (Optional)
TPM v1.2
(8) USB 2.0 ports (at rear)
(1) header
(1) D-Sub 15-pin VGA port
(1) connector
LINE_IN, LINE_OUT, MIC_IN connectors
(2) GbE ports
SSI/ATX 24-pin + 4-pin power connectors
(1) 2 x 5 header
(4) SATA-II and (2) SATA-III connectors
Nuvoton 5577D
Monitors voltage for CPU, memory, chipset &
power supply
Total (4) 4-pin headers
Monitors temperature for CPU & system
environment
8MB / AMI
Plug and Play (PnP) /PCI2.3 /WfM2.0
/SMBIOS2.3 /PXE boot / ACPI 2.0 power
management /Power on mode after power
recovery / User-configurable H/W monitoring
/ Auto-configurable of hard disk types
Input /Output
Front Panel
System
Monitoring
BIOS
Brand / ROM size
SATA
COM
Power
VGA
USB
Audio Chipset
Feature
TPM (Optional) Version
Chipset
Graphic
Connector type
Resolution
Chipset
Chipset
PCI-E
Port Q'ty
Processor
Supported CPU Series
Socket Type / Q'ty
Thermal Design Power
(TDP) wattage
PCH
Super I/O
LAN
Storage SATA
Controller
DVI
Audio
Chipset
Memory
Supported DIMM Qty
DIMM Type / Speed
Capacity
Memory channel
Memory voltage
PHY
Feature
RJ-45
Voltage
Fan
Temperature
Flex ATX
9"x7.5" (228.6x190.5mm)
Operating
System
Please refer to our OS supported list.
Class B
Yes
0° C ~ 55° C (32° F~ 131° F)
- 40° C ~ 70° C (-40° F ~ 158° F)
90%, non-condensing at 35° C
RoHS Yes
(1) S5517 Motherboard
(1) User's manual / (1) Quick Ref. Guide
(1) TYAN installation CD
(1) I/O Shield
SATA (6) SATA signal cables
USB (1) CCBL-035J, 2-port USB bracket cable
Physical
Dimension
Regulation
Operating
Environment
Package
Contains
Form Factor
Operating Temp.
RoHS 6/6 Compliant
Motherboard
In/Non-operating
Humidity
OS supported list
FCC (DoC)
CE (DoC)
Non-operating Temp.
Board Dimension
Installation CD
I/O Shield
Cable
Manual
USB6/7/12/13
USB4/11
PCI-E HS5
SATA3.0
SATA2.0
SATA2.0
SATA3.0
SATA2.0
SATA2.0
VGA-DSUB RGB
DVI-D CONN DDPD
SM Link1
LPC
USB8/9
PCI-E HS6
SM Link
SPI
VRM 12
PCI-E
-
DDR3 channel A
PCIE GEN2 x16
PEG GEN1/GEN2/GEN3 Slot
1066/1333
FAN CONTROL
Headers
HECETA
Socket H2
LGA1155
ATX4P
FDI Link x4 DMI
PCH
Cougar
Point
Intel 82583V
Super IO (Nuvoton 5577D)
FANCIRHW MonitorCOM 1
SPI FLASH
64MBIT SKT
SATA
SATA
SATA
SATA
SATA
SATA
Rear USB 2.0 x2
+ RJ45
Intel 82579L Rear USB 2.0 x2
+ RJ45
PCIE HS1-4
PEG GEN1/GEN2 x8 Slot
PCIE GEN2 x4
USB 2, 3
Front USB x2
Front USB x2
USB 0, 1
TYPE A USBx1
TYPE A USBx1
Rear USBx4
USB10
USB5
AZALIA
3 Stacked Audio Ports
FIO Audio
HDA Header
Audio Codec
INT SPKR
Q67
* Features provided by i3/i5/i7, 22nm(Ivy Bridge)CPU
