TYAN TOMCAT I815E User manual

Tyan S2060
Tomcat i815e
Motherboard User’s Manual
Revision 1.01
Copyright © Tyan Computer Corporation, 2000. All rights reserved. No part of this
manual may be reproduced or translated without prior written consent from Tyan
Computer Corp.
All registered and unregistered trademarks and company names contained in this
manual are property of their respective companies including, but not limited to the
following.
Tomcat i815e S2060 is a trademark of Tyan Computer Corporation.
AMI is a trademark of American Megatrends Incorporated
Windows is a registered trademark of Microsoft Corporation.
IBM, PC, AT, PS/2 are trademarks of IBM Corporation.
INTEL, Pentium III, Celeron are trademarks of Intel Corporation.
Red Hat Linux is a trademark of Red Hat Corporation.
Information contained in this publication has been carefully checked for accuracy and
reliability. In no event will Tyan Computer be held liable for any direct or indirect,
incidental or consequential damage, loss of use, loss of data, or other malady resulting
from errors or inaccuracies of information contained in this manual. The information
contained in this document is subject to change without notice.

TableofContents
1.Introduction............................................................................................... 4
Overview......................................................................................... 4
Icons................................................................................................ 5
HardwareSpecifications/Features.............................................. 6
SoftwareSpecifications................................................................ 8
TechnicalSupport......................................................................... 8
Returning MerchandiseforService............................................ 8
2.BoardInstallation.................................................................................. 10
Unpacking.................................................................................... 10
Installation................................................................................... 10
QuickReferenceforJumpers..................................................... 12
Mapof MotherboardJumpers.................................................. 13
SettingJumpers........................................................................... 15
ClearCMOSandReset PW........................................................ 15
BIOSFlashTL.............................................................................. 15
ChassisIntrusion AlarmConnector..........................................16
SoftPowerConnector................................................................. 17
Mounting the Motherboard in the Chassis.............................18
InstallingMemory........................................................................18
Installingthe CPUandCooling Fan......................................... 21
ConnectingIDE and Floppy Drives......................................... 22
InstallingAddon Cards............................................................ 24
Connecting PS/2, USB, Ethernet*,Serial & Parallel Devices 25
Connectingthe Power Supply................................................... 26
EthernetSetupand Use*........................................................... 26
FrequentlyAsked Questions.................................................... 30
3.BIOSConfiguration..............................................................................32
MainSetup................................................................................... 33
AdvancedMenu......................................................................... 33
ConfigureNat366 SerialPort(s) andParallel Port................... 34
IDEConfiguration....................................................................... 34
FloppyConfiguration................................................................. 36
BootSettingsConfiguration..................................................... 37
EventLogConfiguration........................................................... 38
ChipsetMenu.............................................................................. 39
GMCHConfiguration..................................................................39

ICHConfiguration.......................................................................... 41
PCI/PnPMenu.............................................................................. 41
PowerMenu.................................................................................... 43
BootMenu...................................................................................... 44
SecurityMenu................................................................................ 44
ExitMenu......................................................................................... 45
4.SystemResources.................................................................................... 46
BeepCodes..................................................................................... 46
TroubleshootingSystem Problems............................................. 47
DisplayedErrorMessages........................................................... 48
FlashUtility..................................................................................... 50
Appendix-Glossary...................................................................................... 52
* Indicates an optional feature available on some models of Tomcat i815e.

http://www.tyan.com
4
Chapter 1
Introduction
Overview
The Tomcat i815e is a quality, high performance motherboard designed for Socket 370
Type Intel Pentium III / Celeron microprocessors. The Tomcat i815e utilizes the Intel
i815e Chipset with AMI BIOS and can support CPU speeds of 500 MHz through
800 MHz, and host bus speeds of 66MHz to 133MHz. For CPU speed support,
please refer to the CPU Compatibility Chart in Tyan’s website:
http://www.tyan.com/support/html/pentiumii_iii_ppga.html
The Tomcat i815e motherboard, provides high performance capabilities that are ideal
for a wide range of demanding applications such as CAD, CAM, CAE, desktop
publishing, 3D modeling, animation, and video production.
This integrated high-performance system board in an ATX form factor offers more
features and expandability than other ATX boards in its class. Some of the features
included are onboard UltraDMA 66 / 100, onboard digital link sound (optional) and
built-in Intel 3D Graphics accelerator for enhanced graphics performance.
chapter 1
Introduction

S2060 Tomcat i815e
5
INTRO
Flexibility and expandability have been designed into the Tomcat i815e.
With I/O and drive controller support built onboard (along with the many
onboard features previously mentioned), the AGP 2x / 4x slot and six PCI slots
are free for more add-on expansion cards.
Remember to take a look at Tyan’s web site located at
http://www.tyan.com. There you can findinformation on all of Tyan’sproducts
along with FAQs, distributors list, drivers, and BIOS setting explanations.
Icons
In order to help you navigate this manual and set up your system, we have
added several icons to our format.
This icon alerts you to particularly important details regarding the
setup or maintenance of your system. This icon often appears next to
information that may keep you from damaging your board or system.
While we will often point out the most vital paragraphs in a chapter,
you should always read every word in the text. Failing to do so can
lead to exasperation and expense.
Wherever possible, we have included step-by-step instructions for
setting up your system, which are indicated by this icon. However, it
is in your best interest to read an entire section (and perhaps the
entire manual) before you begin to install your motherboard.
While we have alerted you to potential dangers in several places in
the manual with this icon, these warnings should not be regarded as
the whole of your safety regimen. Never forget that computers are
electrical devices, and are capable of delivering a shock. Prevent
damage to yourself and to your board: always ensure that your
system is turned off and unplugged whenever you are working with
it, and that you are equipped with a static safety device. If a static
safety device is not available to you, remember to touch any un-
painted metal surface in your case before handling your board.
procedure
1.
2.
3.
warning
!
important!

http://www.tyan.com
6
Chapter 1
Introduction
Hardware Specifications/Features
Processor Information •Single PGA370 Socket
•Intel® Pentium III (FC-PGA) 500 mhz-800MHz*
•Intel® Celeron (FC-PGA) 533 mhz - 600 MHz*
•Intel® Celeron (PGA370) 300 mhz - 533 mhz*
•On-board VRM
•Frontside Bus support for 66 / 100 / 133 MHz
Expansion Slots •One 2x / 4x mode 3.3V / 1.5V AGP slot
•Six 32-bit PCI slots
•Total seven usable slots
Chipset Information •Intel® i815e AGPset
•MCH + ICH2 + FWH (4Mb)
•National PC87366 LPC Super I/O Chipset
Hardware Monitoring •National PC87366 hardware monitoring chip
•3-pin fan monitoring headers
•2-pin Chassis intrusion header
•Flexible temperature and voltage sensing
•3-pin Wake on LAN header (optional)
•3-pin Wake on Ring header (optional)
Memory*** •Three 3.3V 168-pin DIMM sockets
•Supports up to 512 MB PC100 / PC133
Unbuffered, non-ECC, non-registered SDRAM
IntegratedPCIIDE •Dual channel master mode
•Up to four Enhanced IDE devices
•Support for UDMA 33/66/100 IDE drives and
ATAPI compliant devices
Integrated I/O •One Floppy connector for up to two drives
•Two 9-pin UART serial ports
(one port is via cable -optional)**
•One 25-pin ECP/PPP parallel port
•PS/2 keyboard and mouse ports
•Four USB ports (two ports via cable -optional)**
SeeTyan websitefor Memory Compatibilitydetails:http://www.tyan.com
***

S2060 Tomcat i815e
7
INTRO
Integrated LAN Controller •One Intel® ICH2 s/82562M “Kinnereth”
(Manfuacturing Option) controller
•10/100 Mbps data transfer rate
•3-pin Wake on LAN (optional)
Integrated 2D/3D Graphics •Intel i815e D.V.M. Technology graphics core
•Integrated 230 Mhz DAC
•Integrated H/W Motion Compensation
engines
•Optional 4 MB PC133 SDRAM AGP In-Line
Memory Module (AIMM) to improve graphics
performance
•Standard 15-pin Analog VGA port
Integrated Audio •Software audio codec
(Manufacturing Option) •Line-in, line-out, mic and game / MIDI ports
•4-pin CD-ROM audio header (ATAPI)
BIOS •AMI BIOS 4 Mbit Flash
•Supports APM 1.2 & ACPI 1.0
•Auto detection of memory size
•Auto configuration of IDE hard disk types
•User settings of hardware monitoring
•Mutliple boot options
•DMI 2.0 compliant
FormFactor •ATX 2.03 (12” x 8”)
•One 20-pin ATX power connector
•Stacked mouse and keyboard ports
•Stacked two USB; one RJ-45 with LED
ports (optional)
•Stacked one serial, one video, and one parallel
port
•Stacked audio and game / MIDI ports (optional)
Regulatory •FCC Class B (Declaration of Conformity)
•European Community CE
(Declaration of Conformity)
SeeTyan website for CPU CompatibilityList:
http://www.tyan.com/support/html/pentiumii_iii_ppga.html
*
Extracables availablefor sale at etyan: http://www.etyan.com
**

http://www.tyan.com
8
Chapter 1
Introduction
Software Specifications
OS •Operates with Windows 98/ME,
Windows 2000, and Red Hat Linux 6.2
Technical Support
If a problem arises with your system, you should turn to your dealer for help first.
Your system has most likely been configured by them, and they should have the best
idea of what hardware and software your system contains. Hence, they should be of
the most assistance. Further, if you purchased your system from a dealer near you,
you can actually bring your system in to them to have it serviced, instead of attempt-
ing to do so yourself (which can have expensive consequences).
Help resources:
1. See FAQ and beep codes sections of this manual.
2. See Tyan web site for FAQ, bulletins, driver updates, etc: http://www.tyan.com
3. Contact your dealer or distributor for help BEFORE calling Tyan.
4. Check the Tyan user group: alt.comp.periphs.mainboard.tyan
Returning Merchandise for Service
During the warranty period, contact your distributor or system vendor FIRST for any
product problems. This warranty only covers normal customer use and does not cover
damages incurred during shipping or failure due to the alteration, misuse, abuse, or
improper maintenance of products.
For Resellers Only:
A receipt or copy of your invoice marked with the date of purchase is required before
any warranty service can be rendered. You can obtain service by calling the manufac-
turer for a Return Merchandise Authorization (RMA) number. The RMA number
should be prominently displayed on the outside of the shipping carton and the package
should be mailed prepaid, or hand-carried to the manufacturer. Tyan will pay to have
the board shipped back to you.

S2060 Tomcat i815e
9
INTRO
Thispageleftblankintentionally.

http://www.tyan.com
10
Chapter 2
oard Installation
chapter 2
Board Installation
Unpacking
The motherboard package should contain the following:
(1) Tomcat i815e mainboard
(1) 34-pin floppy cable
(1) 80-wire, 40-pin ATA-66/100 IDE cable with blue connector included
(1) Tomcat i815e User’s Manual
(1) Driver CD
(1) I/O shield included (optional)
Installation
You are now ready to install your motherboard. The mounting hole pattern of the
Tomcat i815e matches the ATX system board specifications. Your chassis should
support a standard ATX mainboard form factor.
How to install our products right... the first time.
What’s the first thing I should do?
The first thing you should do is read this user’s manual. It contains important
information which will make configuration and setup much easier.
