TYAN Triumph i7230 User manual

http://www.tyan.com
1
Triumph i7230 /// S6611
Version 1.0
Copyright
Copyright © TYAN Computer Corporation, 2006. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
TYAN Computer Corp.
Trademark
All registered and unregistered trademarks and company names contained in
this manual are property of their respective owners including, but not limited to
the following.
TYAN, Taro and Triumph i7230 are trademarks of TYAN Computer Corporation.
AMD, Opteron, and combinations thereof are trademarks of AMD Corporation.
Nvidia and nForce are trademarks of Nvidia Corporation
Microsoft, Windows are trademarks of Microsoft Corporation.
SuSE,is a trademark of SuSE AG.
Linux is a trademark of Linus Torvalds
IBM, PC, AT, and PS/2 are trademarks of IBM Corporation.
Winbond is a trademark of Winbond Electronics Corporation.
Notice
Information contained in this document is furnished by TYAN Computer
Corporation and has been reviewed for accuracy and reliability prior to printing.
TYAN assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN products including liability or
warranties relating to fitness for a particular purpose or merchantability. TYAN
retains the right to make changes to product descriptions and/or specifications
at any time, without notice. In no event will TYAN be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.

http://www.tyan.com
2
Table of Contents
Chapter 1: Introduction
1.1 Congratulations Page 5
1.2 Hardware Specifications Page 5
Chapter 2: Board Installation
2.1 Board Image Page 10
2.2 Block Diagram Page 11
2.3 Board Parts, Jumpers and Connectors Page 12
2.4 Mounting the Motherboard Page 24
2.5Installing the Memory Page 25
2.6 Installing the Processor and Cooling Fan Page 27
2.7Attaching Drive Cables Page 30
2.8Installing Add-In Cards Page 32
2.9Connecting External Devices Page 32
2.10 LAN Bypass Function Page 34
2.11Installing the Power Supply Page 35
2.12Finishing Up Page 36
Chapter 3: BIOS
3.1 About the BIOS Page 37
3.2 Main BIOS Setup Page 39
3.3BIOS Main Menu Page 40
3.4BIOS Advanced Menu Page 46
3.5BIOS Security Menu Page 62
3.6BIOS Power Menu Page 64
3.7BIOS Boot Menu Page 66
3.8BIOS Exit Menu Page 67
Chapter 4: Diagnostics
4.1 Beep Codes Page 69
4.2 Flash Utility Page 69
4.3 Phoenix BIOS Post Code Page 70
Appendix I: How to Make a Driver Diskette Page 73
Glossary Page 75
Technical Support Page 81

http://www.tyan.com
3
Check the box contents!
The retail motherboard package should contain the following:
1x Triumph i7230 motherboard
1x SATA cable
1x PS/2 cable
1 x VGA Port cable
1x COM Port cable
1x TYAN driver CD
If any of these items are missing, please contact your vendor/dealer for
replacement before continuing with the installation process.

http://www.tyan.com
4
NOTE

http://www.tyan.com
5
Chapter 1: Introduction
1.1 -Congratulations
You have purchased one of the most powerful server solutions available. The
Triumph i7230 (S6611) is a high-end server motherboard, based on the Intel
E7230 (Mukilteo) chipset. It also includes the Intel ICH7RI/O and Intel
6700PXH PCI/PCI-X chipsets.
This motherboard is designed to support one Intel Pentium 4 Series processor
and 8GB of DDRII 667/533/400 memory. The S6611 is ideal for CPU, memory,
and network intensive applications required in the HPC and clustering
environments.
Remember to visit TYAN’s Website at http://www.tyan.com. There you can find
information on all of TYAN’s products with FAQs, online manuals and BIOS
upgrades.
1.2 -Hardware Specifications
Processor
s
•Single LGA775 Socket, supports Intel
Pentium D & Pentium 4 processors
with 1066/800/533 MHz Front Side
Bus as follows:
-Pentium Extreme Edition 955 & 965
-Pentium Extreme Edition 840
-Pentium D 920, 930, 940 & 950
-Pentium D 820, 830 & 840
-Pentium 4 662 & 672
-Penitum 4 631, 641, 651 & 661
-Penitum 4 630, 640, 650, 660 & 670
-Penitum 4 521, 531, 541, 551, 561 &
571
-Penitum 4 520J, 530J, 540J, 550J,
560J & 570J
-Pentium 4 520, 530, 540, 550 & 560
-Celeron D 326, 331, 336, 341, 346 &
351
-Celeron D 325J, 330J, 335J, 340J,
345J
Memory
•Four 240-pin DDR2 sockets support
up to 8GB
•Dual channel memory bus (must be
populated in pairs)
•Supports Un-buffered DDR2
667/533/400 compliant ECC/Non-
Chipset
•Intel E7230 (Mukilteo) Memory
Controller Hub
•Intel ICH7RI/O Controller Hub
•Intel 6700PXH PCI/PCI-X Controller
Hub
Integrated LAN Controllers
•Two Intel 82546 dual port Gigabit
controllers
•Four Intel 82573 PCI-E gigabit
controllers
•Configurable numbers of LAN
connections, Max. 8 ports supported
(refer to Available Models)
LAN Bypass
•Supports Bypass feature over two
pairs of LAN ports (optional)
•Bypass mode enabling is default when
power down or to be enabled by
watchdog when system failed
Accessories
•PCI-X Riser Card with 1 PCI-X slot for
1U
•PCI-X Riser Card with 3 PCI-X slots
for 2U

http://www.tyan.com
6
ECC DIMM
•Supports 128MB, 256MB, 512MB,
1GB, 2GB DIMM
•Supports standard SEC-DED with 72-
bit ECC DIMM
System Management
•Total eight 3-pin fan headers with
control and tachometer monitoring
•Monitors voltage for CPU, Memory &
Power Supply
•Monitors temperature for CPU &
environment
•Pin header for Fault LED,
Power/Suspend LED & HDD activity
LED
•One pin header for Chassis Intrusion
detection
•Supports Serial console Redirection
•Watch Dog Timer supported
Integrated I/O
•One 40-pin IDE connector or one 50-
pin compact Flash type II connector
(configurable)
•Four SATA connectors
•One pin header for USB ports
(supports two USB 2.0 devices)
•Two shrouded header for serial port
•One shrouded header for parallel port
•One pin header for PS/2 mouse and
keyboard
•One pin header for VGA port
•One pin header for Switch/LED
connection with NMI, SM-Bus,
Chassis Intrusion supported
Form Factor
•ATX form factor (12”x 10.5”; 305 x
265mm)
Networking Security
(S6611T4P4H)
•One board Cavium CN-1010-X-G
Security Macro Processor supports
IPsec/SSL (refer to Available Models)
Back Panel I/O Ports
•One serial port with D-Sub connector
•Two USB 2.0 ports with dual-stack
USB connector
•Up to eight LAN ports with RJ45
connector includes Transformer &
LED (refer to Available Models)
•Up to four LAN ports with SFP Fiber
connectors (refer to Available Models)
Integrated 2D/3D Graphics
•ATi ES1000 PCI graphics controller
with 16MB frame buffer
Expansion Slots
•One 64-bit 133MHz PCI-X slot (3.3V)
•Supports up to 3 PCI-X devices with
Riser Card
•One Mini-PCI Slot
BIOS
•Phoenix BIOS on 8Mbit Flash ROM
•Supports ACPI 2.0
•Supports boot from USB device
•Power-on mode control for AC power
loss recovery

http://www.tyan.com
7
Available Models
Part Number GbE
Fiber GbE Copper Encryption Chip Remarks
S6611T4P4H
4 ports 4 ports CN-1010-X-GStandard Model
S6611P8B2 N/A 8 ports N/A Standard Model
(Support LAN Bypass
Function)
S6611T4H 4 ports N/A CN-1010-X-G
S6611T2P2H
2 ports 2 ports CN-1010-X-G
S6611P4H N/A 4 ports CN-1010-X-G
S6611T2P4H
2 ports 4 ports CN-1010-X-G
S6611T4P44 ports 4 ports N/A
S6611T4P2 4 ports 2 ports N/A
S6611T2P22 ports 2 ports N/A
S6611P4 N/A 4 ports N/A

http://www.tyan.com
8
NOTE

http://www.tyan.com
9
Chapter 2: Board Installation
Precautions: The Triumph i7230 supports SSI, EPS12V type power supplies
(24pin + 8pin) and will not operate with any other types. For proper power
supply installation procedures see page 35.
DO NOT USE ATX 2.x or ATXGES power supplies as they will damage the
board and void your warranty.
How to install our products right…the first time
The first thing you should do is reading this user’s manual. It contains important
information that will make configuration and setup much easier. Here are some
precautions you should take when installing your motherboard:
(1) Ground yourself properly before removing your motherboard from the
antistatic bag. Unplug the power from your computer power supply and
then touch a safely grounded object to release static charge (i.e. power
supply case). For the safest conditions, TYAN recommends wearing a
static safety wrist strap.
(2) Hold the motherboard by its edges and do not touch the bottom of the
board, or flex the board in any way.
(3) Avoid touching the motherboard components, IC chips, connectors,
memory modules, and leads.
(4) Place the motherboard on a grounded antistatic surface or on the
antistatic bag that the board was shipped in.
(5) Inspect the board for damage.
The following pages include details on how to install your motherboard into your
chassis, as well as installing the processor, memory, disk drives and cables.
NOTE
DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN
DAMAGED.

http://www.tyan.com
10
2.1-Board Image
This picture is representative of the latest board revision available at
the time of publishing. The board you receive may or may not look
exactly like the above picture.
The following page includes details on the vital components of this
motherboard.

http://www.tyan.com
11
2.2 -Block Diagram
Triumph i7230 (S6611)Block Diagram

http://www.tyan.com
12
2.3 -Board Parts, Jumpers and Connectors
PWR1 PWR2
FAN5
FAN1
LCM
COM2
COM1
USB1
LAN8
LAN7
LAN6
LAN5
LAN3
LAN4
LAN1
LAN2
CPU1
DIMM1
DIMM2
DIMM3
DIMM4
COM3
JP29
CF1
SATA1
SATA2
SATA4
SATA3
PCIX-S1
MPCI1
P80
KM1
USB2
TYFP1
VGA1
LPT1
IDE1
FAN6
FAN2
FAN7
FAN3
FAN8
FAN4
CMOS
LED1
LED2
LED3
LED4
This diagram is representative of the latest board revision available at the time of
publishing. The board you receive may not look exactly like the above diagram.
Jumper Legend
©© OPEN -Jumper OFF, without jumper cover
©© CLOSED –Jumper ON, with jumper cover

http://www.tyan.com
13
Jumper/Connector Function
FAN1/FAN2/FAN3/FAN4/
FAN5/FAN6/FAN7/FAN8 3-pin Fan Connector with Tachometer
LCM LCM Header
USB2 USB Front Panel Connector
SATA1/SATA2/SATA3/SATA4 SATA Connectors
VGA1 VGA Connector
TYFP1 Front Panel Header
COM2/COM3 Serial Port Header
CF1 Compact Flash Connector
MPCI1 Mini PCI Socket
KM1 Keyboard Mouse Header
JP29 Power Switch Header
CMOS Clear CMOS Jumper
(Close 1-2) Default
(Close 2-3) Clear CMOS
LPT1 Parallel Port Header
IDE1 Hard Disk Connector
P80 Reserved for Testing

http://www.tyan.com
14
FAN2
FAN7
FAN8
FAN6
FAN5
FAN1
FAN4
FAN3
COM2
COM3
VGA1

http://www.tyan.com
15
FAN1~FAN8:3-pin Fan Connector with Tachometer
FAN1~FAN8
+12V
GND
Tachometer
1
Use these headers to connect the cooling fans to
the motherboard to keep the system stable and
reliable.
This connector supports the tachometer monitoring
and auto fan speed control.
J15: FAN1 J17: FAN2 J22: FAN3 J20: FAN4
J16: FAN5J18: FAN6J21: FAN7J9: FAN8
Pin 1 Pin 2 Pin 3
GND +12V Tachometer
VGA1:VGA Connector
1
2
15
16
One 15-pin VGA connector is provided for
connection to a VGA monitor.
Pin Signal Pin Signal
1Red 2Green
3Blue 4NC
5GND 6GND
7GND 8GND
9+5V 10 GND
11 NC 12 DDC Data
13 HSYNC 14 VSYNC
15 DDC Clock 16 KEY
COM2 (J6) & COM3 (J14): Serial Port Header
COM2
1
9
2
10
COM3
10 2
9 1
The mainboard offers two 9-pin headers as serial port
COM2 and COM3. You can attach a serial mouse or
other serial devices directly to it.
Pin Signal Pin Signal
1DCD 2DSR
3RXD 4RTS
5TXD 6CTS
7DTR 8RI
9GND 10 KEY

http://www.tyan.com
16
CF1
LCM

http://www.tyan.com
17
CF1: Compact Flash Connector
Pin
Signal Pin Signal
1GND 26 GND
2D3 27 D11
3D4 28 D12
4D5 29 D13
5D6 30 D14
6D731 D15
7CS# 32 CS1#
8GND 33 GND
9GND 34 IORD#
10 GND 35 IOWR#
11 GND 36 WE#
12 GND 37 INTRQ
13 VCC 38 VCC
14 GND 39 CSEL#
15 GND 40 NC
16 GND 41 RST#
17 GND 42 IORDY#
18 A2 43 DMARQ
19 A1 44 DMACK#
20 A0 45 DASP#
21 D0 46 PDIAG#
22 D1 47 D8
23 D2 48 D9
24 NC 49 D10
25 GND 50 GND
LCM (J19): LCM Header
1 5
2 6
Pin
Signal Pin Signal
1+5V 2RXD
3KEY 4GND
5+5VSB 6TXD
1
2
26
27
50
25

http://www.tyan.com
18
KM1
TYFP1
USB2

http://www.tyan.com
19
KM1 (J12): Keyboard Mouse Header
10 2
9 1
Use this header to connect to a keyboard or mouse.
Signal Pin Pin Signal
+5V 12+5V
Key 34Key
KB Data 56MS Data
GND 78GND
KB Clock 910 MS Clock
TYFP1:Front Panel Header
SMbus Clock
SMbus Data
5Vsb
Ext. Interrupt
(NMI)
+3.3V
Reset SW-
GND
HDD LED-
HDD LED+
17 15 13 11 9 7 5 3 1
18 16 14 12 10 8 6 4 2
INTRU-
GND
Key
WLED-
WLED+
GND
Power S/W-
Power LED-
Power LED+
The motherboard
provides one front
panel header for
electrical
connection to the
front panel
switches and
LED’s.
USB2 (J8): USB Front Panel Header
10 2
9 1
Use this header to connect to front panel USB connector.
Pin Signal Pin Signal
1+5V 2+5V
3- Data 0- 4Data 1-
5Data 0+ 6Data 1+
7GND 8GND
9KEY 10 NC

http://www.tyan.com
20
CMOS
JP29
LPT1
