D-307631 MC-309 PG2 Installation instructions 1

1. Introduction

The device is a supervised, 2-way wireless PowerG magnetic contact device with the following features:

lBuilt-in reed switch

lAuto-enrollment process when pulling the tab

lTwo separate auxiliary hard-wired inputs support normally closed (NC), normally open (NO), end of line (EOL), double end of line(DEOL), and

triple end of line (TEOL). Both external and internal inputs can be used at the same time. These hard-wired inputs can be programmed for use with

other hard-wired sensors.

lSmart temperature-sensing capabilities

Note:

lSecond auxiliary input, DEOL, TEOL and temperature sensing support are based on panel supporting version.

lThe temperature sensing feature is supplementary only and was not evaluated by UL/ULC.

The reed switch and auxiliary inputs behave as separate transmitters, although they trigger the same RF transmitter. Removing the cover activates the

tamper switch. If configured, LED lights only when reporting alarm or tamper events. Built-in link quality indicators reduce installation time by eliminating

the need for the installer to physically approach the control panel. Smart temperature-sensing capabilities issue an alert when the ambient temperature

reaches a predetermined threshold.

2. Legend

Callout Description

AFlexible Retainer

BBreakaway base segment for back tamper

CPCBedge supports

DMounting holes

EWiring inlet

FPull tab

GLED

HThree terminal blocks for sensor

IEnroll button

JTamper switch

KN.O. switch

LN.C. switch

MEOL: N.O. switch ; 5.6 kΩ resistor

NEOL: N.C. switch ; 5.6 kΩ resistor

ODEOL: N.C. switch only ; 5.6 kΩ resistor

PTEOL: N.C. switch only ;22 kΩ resistor

Figure 1:Legend Table 1:Legend

Installation instructions

MC-309 PG2

Supervised magnetic contact

3. Mounting the device

It is highly recommended to attach the transmitter to the top of the door or window on the fixed frame and the magnet to the door or window. Ensure that

the magnet is located no more than 6 mm (0.25 in.) from the transmitter’s marked side.

Note: Once the cover is removed, a tamper message is transmitted to the receiver. Subsequent removal of the battery prevents transmission of tamper

restore, leaving the receiver in permanent alert. To avoid this, press the tamper switch when removing the battery.

Attention!The unit has an optional back tamper switch under the PCB. As long as the PCB is seated firmly within the base, the switch lever presses

against a special break-away base segment that is loosely connected to the base. Be sure to fasten the break-away segment to the wall. If the detector

unit is forcibly removed from the wall, this segment breaks away from the base, causing the tamper switch to open.

3.1. Mounting with screws

1. With the cover removed, flex the retainer and remove the PCB.

2. Mark and drill two holes in the mounting surface.

3. Align the device with the magnet according to the location marks and fasten the device and magnet to the mounting surface.

4. Fasten the base with 2 countersunk screws.

5. Mount the magnet base with the 2 supplied screws.

6. Attach the magnet to the magnet base.

3.2. Mounting with adhesive tape

1. Peel away the release liners from the two strips of double-sided adhesive tape and attach to the device and magnet.

2. Align the device with the magnet according to the location marks and fasten the device and magnet to the mounting surface.

Note: Mounting using adhesive tape is permitted only for UL/ULC residential installations.

4. Enrolling the device

For a device to operate as part of a system, it must be enrolled on the alarm system control panel using the following steps:

1. To add the new device, refer to the HOST Installation Manual and follow the enrollment procedure to select the appropriate option.

2. Identify the 7 digit serial number located on the device housing formatted ID: 110-XXXX

Note: The first 3 digits of the Device ID indicate the device type. If the panel does not support ID: 110-XXXX, it enrolls in fall back operation as W / D

Contact with ID: 101-XXXX.

3. Remove the pull tab to start the auto-enrollment process.

Alternatively, press the enrollment button, restore the tamper, or enter the number of the device printed on the label (ID: 110-XXXX / or 101-XXXX

if device type is not supported).

Note: Restoring the tamper when the panel is on registration/listening mode for a new device will generate a new request to enroll the device. Do not

restore the tamper/close the housing in this panel mode, unless when adding a new device through this method.

5. Inserting or replacing the battery

To insert the battery, complete the following steps:

1. Insert a flat-edged screwdriver into the slot and push upward to remove cover.

2. Remove the screw and separate the cover from the base.

3. Observe polarity.

4. Connect the sensor wire to the terminal block.

To replace the battery, complete the following steps:

1. Remove the cover

2. Wedge a flat head screwdriver under the battery

3. Twist the screwdriver using the base as a lever to remove the battery.

Note:

lWhen manually programming wireless devices, if a device has been powered up for more than 48 hours it cannot be enrolled into the system until

the device has been tampered and restored. When programming the panel using the Quick Enroll procedure, follow the steps detailed in Enroll the

Device into the System.

lAfter restoring a low battery, the system may take up to 5 minutes to clear the trouble.

Caution: Battery may explode if mistreated. Do not recharge, disassemble, or dispose of the battery in a fire. Replace the battery with type GP, Part

No. CR-123A only. Use of another battery may present a risk of fire or explosion. See the owner's manual for safety precautions.

D-307631 MC-309 PG2 Installation instructions 2

6. Low battery detection

Note:For ULinstallations, the detector is for use with ULListed control units only.

The device includes low-battery condition detection. When this condition is detected, a trouble message transmits to the compatible receiver/control

panel. This provides visual identification of the unit that requires a battery change.

Note:After restoring a low battery, the system may take up to five minutes to clear the trouble.

7. Temperature display

Refer to the PowerMaster Installation Manual for the temperature display procedure.

Note:This is based on the supporting panel version.

8. Placement testing / local diagnostic test

Before permanently mounting any wireless device, temporarily mount the device and perform a placement test by completing the following steps:

1. Separate the base of the device from the cover.

2. Press the tamper switch once and release it.

3. Put the cover on the device to return the tamper switch to its normal (undisturbed) position. Then secure the front cover to the base with the case

closure screw.

4. Open the door or window and verify that the red LED blinks, indicating detection.

5. After two seconds, the LED blinks three times.

Table 2 indicates received signal strength:

LEDresponse Reception

Three green LEDblinks Strong

Three orange LED blinks Good

Three red LEDblinks Poor

No blinks No communication

Table 2:Signal strength

Important: Only GOOD or STRONG signal strengths are acceptable. If you receive a POOR signal from the device, re-locate and re-test the device

until a GOOD or STRONG signal is received.

Note:

lFor UL/ULC installations, only STRONG signal levels are acceptable. After installation, verify the product functionality in conjunction with the

compatible receivers of the PowerMaster Control Panel.

lFor detailed placement instructions, refer to the control panel Reference Guide.

9. Wiring the auxiliary input

Note: Auxiliary input is for supplementary use only and was not evaluated by UL.

1. Connect the auxiliary sensor contacts across the auxiliary input terminals.

2. If the auxiliary input is defined as NC type, series connected NC sensor contacts must be used exclusively. An EOL resistor is not required.

3. If the auxiliary input is defined as a NO type, parallel connected NO sensor contacts must be used exclusively. An EOL resistor is not required.

4. For EOL supervision, NC sensor contacts can be used. A 5.6 kΩ EOL resistor must be wired at the far end of the zone loop.

Figure 2: Alarm circuit options with EOLresistors

Note:

lFor UL installations, the device connected to the initiating circuit must be located in the same room as the transmitter.

lFor UL/ULC installations, connect only UL/ULC listed devices to the auxiliary wiring input.

lAn alarm message is transmitted once the loop is opened or short circuited.

D-307631 MC-309 PG2 Installation instructions 3

10. Configuration

Table 3 shows the available programmable options:

Alarm LED -

Default- [Y]

Enables the devices LED to activate when an alarm event occurs.Note: Disable LED to achieve higher battery life time for

commercial use.

Reed Switch -

Default [Y] Enables or disables the reed switch.

External Inputs -

Default[Y] Enables or disables the external input.

Supervision -

Default [Y] Enables supervision of the device.

Temperature

Sensor Default Enables or disables the temperature sensor. Note: Based on panel supporting version.

Table 3:Programmable options

11. Selections

Zone EOL/DEOL/TEOL- Default [01]

Configures auxiliary inputs as one fo the following options:

[00] Disabled [01] EOL/DEOL/TEOL [02] Normally Open

[03] Normally Closed

Note:DEOL and TEOLare based on panel supporting version.

Table 4:Selections

12. Range coverage directions

Figure 3: Range coverage directions

Non-metallic surface Supports Metallic surface

Open mm (in) Close mm (in) Direction Open mm (in) Close mm (in)

21 (0.83)

20 (0.78)*

17 (0.67)

16 (0.63)*

11 (0.43)

14 (0.55)*

8 (0.31)

7 (0.27)*

15 (0.59)

14 (0.55)*

14 (0.55)

11 (0.43)*

13 (0.51)

10 (0.39)*

10 (0.39)

7 (0.27)*

34 (1.34)

27 (1.06)*

28 (1.1)

21 (0.83)*

23 (0.91)

20 (0.78)*

20 (0.78)

17 (0.67)*

Note: Values stated above may vary by up to 10%. For UL installations, the gaps cannot be greater than the above measurements. For steel

installations, the gaps cannot be less that 3.175 mm.

* For UL Installations

Table 5:Range coverage directions

D-307631 MC-309 PG2 Installation instructions 4

13. Specifications

Frequency band: NA amd LATAM: 915 MHz;

Europe and rest of world: 433MHz, 868 MHz

Frequency bands maximum power: 868.0 MHz - 868.6 MHz 12 dBm (15 mW)

868.7 MHz - 869.2 MHz 12 dBm (15 mW)

433.22 MHz - 434.64 MHz 6dBm (4 mW)

Communication protocol: PowerG

Alarm input: One internal, two external

Supervision: Signaling at four minute intervals

Tamper alert: Reported when a tamper event occurs

Battery type: 3 V Lithium CR-123A type battery GP

Battery life expectancy: 8 years with typical use / 5 years with typical commercial use (LED disabled)

Note: Battery life not validated by UL/CUL.

Battery supervision: Automatic transmission of battery condition data as part of periodic status report and

immediately upon low battery condition detection

Temperature range: -10 ºC to +55 ºC (14 °F to 131 °F). UL/ULC only verified the range 0 ºC to 49 ºC (32 ° F to 120

°F)

Relative humidity: Up to a maximum 93 % RH, non-condensing

Dimensions (LxWxD): 81 mm x 34 mm x 25 mm (3.2 in. x 1.3 in. x 1.0 in.)

Weight (including battery): 53 g (1.9 oz)

Auxiliary input cable length: 10 m max, AWG22

Auxiliary input EOL resistor: 5.6 KΩ

Installed by service persons and for use in indoor non-hazardous locations only.

Low battery trouble level: 2.5 V

Compatible receivers: PowerMaster 10/30 PG2

14. Compliance with standards

The MC-309 PG2 complies with the following standards:

Europe: EN 300220, EN 301489, EN 50130-4, EN 61000-6-3, EN 62368-1, EN 50131-1, EN 50131-2-6 Grade 2, Class II and

EN 50131-6 Type C.

Hereby, Visonic Ltd. declares that the radio equipment type MC-309 PG2 is in compliance with Directive 2014/53/EU.

The full text of the EUdeclaration of conformity is available at the following internet address:

http://www.visonic.com/download-center

USA:FCC-CFR 47 Part 15, UL-UL 634

Canada: IC-RSS-247, ULC - C634

Security Grade: Designed according to EN 50131-1, EN 50131-2-6, and EN 50131-6 Type C:this equipment can be applied in

installed systems up to and including Security Grade 2.

Environmental Class: EN-50131-2-6 Class II

Certified by Applica Test & Certification A S in accordance with EN50131-2-6, EN 50131-5-3, EN50131-6, EN 50130-4, EN

50130-5. Security Grade 2 and Environmental Class II.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

D-307631 MC-309 PG2 Installation instructions 5

television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

Cet équipment a été testé et jugé conforme aux limites s'appliquant à un appareil numérique de classe B, conformément à la Partie 15 des

réglementations de la FCC. Ces limites ont été élaborées pour offrir une protection raisonnable contre les interferences nuisibles dans une installation

résidentille.

This class B digital apparatus complies with Canadian ICES-003.

Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.

WARNING!Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to

operate the equipment.

This device complies with Part 15 of the FCC Rules and RSS-247 of ISED. Operation is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Le présent appareil est conforme aux CNR d’ISED applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions

suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d’en compromettre le fonctionnement.

To comply with FCC and IC RF exposure compliance requirements, the device should be located at a distance of at least 20 cm from all persons during

normal operation. The antennas used for this product must not be co-located or operated in conjunction with any other antenna or transmitter.

Le dispositif doit être placé à une distance d'au moins 20 cm à partir de toutes les personnes au cours de son fonctionnement normal. Les antennes

utilisées pour ce produit ne doivent pas être situés ou exploités conjointement avec une autre antenne ou transmetteur.

W.E.E.E. Product Recycling Declaration

For information regarding the recycling of this product you must contact the company from which you originally purchased it. If you are

discarding this product and not returning it for repair then you must ensure that it is returned as identified by your supplier. This

product is not to be thrown away with everyday waste.

European Directive 2002/96/EC Waste Electrical and Electronic Equipment.

15. Warranty

Visonic Limited (the “Manufacturer") warrants this product only (the "Product") to the original purchaser only (the “Purchaser”) against defective

workmanship and materials under normal use of the Product for a period of twelve (12) months from the date of shipment by the Manufacturer. This

Warranty is absolutely conditional upon the Product having been properly installed, maintained and operated under conditions of normal use in

accordance with the Manufacturers recommended installation and operation instructions. Products which have become defective for any other reason,

according to the Manufacturers discretion, such as improper installation, failure to follow recommended installation and operational instructions, neglect,

willful damage, misuse or vandalism, accidental damage, alteration or tampering, or repair by anyone other than the manufacturer, are not covered by

this Warranty.

There is absolutely no warranty on software, and all software products are sold as a user license under the terms of the software license agreement

included with such Product.

There is absolutely no warranty on software, and all software products are sold as a user license under the terms of the software license agreement

included with such Product.

The Manufacturer does not represent that this Product may not be compromised and/or circumvented or that the Product will prevent any death and/or

personal injury and/or damage to property resulting from burglary, robbery, fire or otherwise, or that the Product will in all cases provide adequate

warning or protection. The Product, properly installed and maintained, only reduces the risk of such events without warning and it is not a guarantee or

insurance that such events will not occur.

Conditions to Void Warranty: This warranty applies only to defects in parts and workmanship relating to normal use of the Products. It does not

cover:

* damage incurred in shipping or handling;

* damage caused by disaster such as fire, flood, wind, earthquake or lightning;

* damage due to causes beyond the control of the Seller such as excessive voltage, mechanical shock or water damage;

* damage caused by unauthorized attachment, alterations, modifications or foreign objects being used with or in conjunction with the Products;

* damage caused by peripherals (unless such peripherals were supplied by the Seller;

* defects caused by failure to provide a suitable installation environment for the products;

* damage caused by use of the Products for purposes other than those for which they were designed;

D-307631 MC-309 PG2 Installation instructions 6

* damage from improper maintenance;

* damage arising out of any other abuse, mishandling or improper application of the Products.

Items Not Covered by Warranty: In addition to the items which void the Warranty, the following items shall not be covered by Warranty: (i) freight cost

to the repair centre; (ii) customs fees, taxes, or VAT that may be due; (iii) Products which are not identified with the Seller's product label and lot number

or serial number; (iv) Products disassembled or repaired in such a manner as to adversely affect performance or prevent adequate inspection or testing

to verify any warranty claim. Access cards or tags returned for replacement under warranty will be credited or replaced at the Seller's option.

THIS WARRANTY IS EXCLUSIVE AND EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, OBLIGATIONS OR LIABILITIES, WHETHER

WRITTEN, ORAL, EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE, OR OTHERWISE. IN NO CASE SHALL THE MANUFACTURER BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR

INCIDENTAL DAMAGES FOR BREACH OF THIS WARRANTY OR ANY OTHER WARRANTIES WHATSOEVER, AS AFORESAID.

THE MANUFACTURER SHALL IN NO EVENT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, CONSEQUENTIAL OR PUNITIVE

DAMAGES OR FOR LOSS, DAMAGE, OR EXPENSE, INCLUDING LOSS OF USE, PROFITS, REVENUE, OR GOODWILL, DIRECTLY OR

INDIRECTLY ARISING FROM PURCHASER’S USE OR INABILITY TO USE THE PRODUCT, OR FOR LOSS OR DESTRUCTION OF OTHER

PROPERTY OR FROM ANY OTHER CAUSE, EVEN IF MANUFACTURER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

THE MANUFACTURER SHALL HAVE NO LIABILITY FOR ANY DEATH, PERSONAL AND/OR BODILY INJURY AND/OR DAMAGE TO

PROPERTY OR OTHER LOSS WHETHER DIRECT, INDIRECT, INCIDENTAL, CONSEQUENTIAL OR OTHERWISE, BASED ON A CLAIM THAT

THE PRODUCT FAILED TO FUNCTION. HOWEVER, IF THE MANUFACTURER IS HELD LIABLE, WHETHER DIRECTLY OR INDIRECTLY,

FOR ANY LOSS OR DAMAGE ARISING UNDER THIS LIMITED WARRANTY, THE MANUFACTURER'S MAXIMUM LIABILITY (IF ANY) SHALL

NOT IN ANY CASE EXCEED THE PURCHASE PRICE OF THE PRODUCT INVOLVED, WHICH SHALL BE FIXED AS LIQUIDATED DAMAGES

AND NOT AS A PENALTY, AND SHALL BE THE COMPLETE AND EXCLUSIVE REMEDY AGAINST THE MANUFACTURER. SOME

JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THESE

LIMITATIONS MAY NOT APPLY UNDER CERTAIN CIRCUMSTANCES.

When accepting the delivery of the Product, the Purchaser agrees to the said conditions of sale and warranty and he recognizes having been informed

of.

The Manufacturer shall be under no liability whatsoever arising out of the corruption and/or malfunctioning of any telecommunication or electronic

equipment or any programs.

The Manufacturers obligations under this Warranty are limited solely to repair and/or replace at the Manufacturer’s discretion any Product or part

thereof that may prove defective. Any repair and/or replacement shall not extend the original Warranty period. The Manufacturer shall not be

responsible for dismantling and/or reinstallation costs. To exercise this Warranty the Product must be returned to the Manufacturer freight pre-paid and

insured. All freight and insurance costs are the responsibility of the Purchaser and are not included in this Warranty.

This warranty shall not be modified, varied or extended, and the Manufacturer does not authorize any person to act on its behalf in the modification,

variation or extension of this warranty. This warranty shall apply to the Product only. All products, accessories or attachments of others used in

conjunction with the Product, including batteries, shall be covered solely by their own warranty, if any. The Manufacturer shall not be liable for any

damage or loss whatsoever, whether directly, indirectly, incidentally, consequentially or otherwise, caused by the malfunction of the Product due to

products, accessories, or attachments of others, including batteries, used in conjunction with the Products. This Warranty is exclusive to the original

Purchaser and is not assignable.

This Warranty is in addition to and does not affect your legal rights. Any provision in this warranty which is contrary to the Law in the state or country were

the Product is supplied shall not apply.

Governing Law: This disclaimer of warranties and limited warranty are governed by the domestic laws of Israel.

Warning

The user must follow the Manufacturer’s installation and operational instructions including testing the Product and its whole system at least once a week

and to take all necessary precautions for his/her safety and the protection of his/her property.

* In case of a conflict, contradiction or interpretation between the English version of the warranty and other versions, the English version shall prevail.

4/18

16. End-User License Agreement

IMPORTANT - READ THIS END-USER LICENSE AGREEMENT ("EULA") CAREFULLY BEFORE OPENING THE DISK PACKAGE,

DOWNLOADING THE SOFTWARE OR INSTALLING, COPYING OR OTHERWISE USING THE SOFTWARE.

THIS EULA IS A LEGAL AGREEMENT BETWEEN OU AND VISONIC LTD. (“TYCO”) AND GOVERNS YOUR USE OF THE SOFTWARE

ACCOMPANYING THIS EULA, WHICH SOFTWARE INCLUDES COMPUTER SOFTWARE AND MAY INCLUDE MEDIA, PRINTED MATERIALS,

AND "ON-LINE" OR ELECTRONIC DOCUMENTATION (COLLECTIVELY, THE "SOFTWARE"). BY BREAKING THE SEAL ON THIS PACKAGE,

DOWNLOADING THE SOFTWARE OR INSTALLING, COPYING OR OTHERWISE USING THE SOFTWARE, YOU AGREE TO BE BOUND BY THE

TERMS OF THIS EULA. IF YOU DO NOT AGREE TO ALL OF THE TERMS AND CONDITIONS OF THIS EULA, DO NOT OPEN, DOWNLOAD,

INSTALL, COPY OR OTHERWISE USE THE SOFTWARE.

1. SCOPE OF LICENSE. The Software may include computer code, program files and any associated media, hardware or software keys, printed

material and electronic documentation.The Software may be provided to you pre-installed on a storage device (the media) as part of a computer

system or other hardware or device (“System”). The Software is protected by copyright laws and international copyright treaties, as well as other

intellectual property laws and treaties. All title and intellectual property rights in and to the Software (including but not limited to any images,

D-307631 MC-309 PG2 Installation instructions 7

photographs, and text incorporated into the Software), the accompanying printed materials, and any copies of the Software, are owned by Tyco

and/or its suppliers. The Software is licensed, not sold.All rights not expressly granted under this EULA are reserved by Tyco and its suppliers.

2. GRANT OF LICENSE. This EULA grants you the following rights on a non-exclusive basis:

a. General. This EULA permits you to use the Software for which you have purchased this EULA. Once you have purchased licenses for the number of

copies of the Software that you require, you may use the Software and accompanying material provided that you install and use no more than the

licensed number of copies at one time. The Software is only licensed for use with specified Licensor-supplied Systems. If the Software is protected by a

software or hardware key or other device, the Software may be used on any computer on which the key is installed. If the key locks the Software to a

particular System, the Software may only be used on that System.

b. Locally Stored Components.The Software may include a software code component that may be stored and operated locally on one or more devices.

Once you have paid the required license fees for these devices (as determined by Tyco in its sole discretion), you may install and/or use one copy of such

component of the Software on each of the devices as licensed by Tyco.You may then use, access, display, run or otherwise interact with ("use") such

component of the Software in connection with operating the device on which it is installed solely in the manner set forth in any accompanying

documentation or, in the absence of such, solely in the manner contemplated by the nature of the Software.

c. Remotely Stored Components.The Software may also include a software code component for operating one or more devices remotely.You may

install and/or use one copy of such component of the Software on a remote storage device on an internal network with all of the devices and may

operate such component with each device over the internal network solely in the manner set forth in any accompanying documentation or, in the

absence of such, solely in the manner contemplated by the nature of the Software; provided however, you must still acquire the required number of

licenses for each of the devices with which such component is to be operated.

d. Embedded Software/Firmware. The Software may also include a software code component that is resident in a device as provided by Tyco for

operating that device.You may use such component of the Software solely in connection with the use of that device, but may not retrieve, copy or

otherwise transfer that software component to any other media or device without Tyco's express prior written authorization.

e. Backup Copy.You may make a back-up copy of the Software (other than embedded software) solely for archival purposes, which copy may only be

used to replace a component of the Software for which you have current valid license. Except as expressly provided in this EULA, you may not otherwise

make copies of the Software, including the printed materials.

3. OTHER RIGHTS AND LIMITATIONS.Your use of the Software is subject to the following additional limitations.Failure to comply with any of

these restrictions will result in automatic termination of this EULA and will make available to Tyco other legal remedies.

a. Limitations on Reverse Engineering and Derivative Works. You may not reverse engineer, decompile, or disassemble the Software, and any attempt

to do so shall immediately terminate this EULA - except and only to the extent that such activity may be expressly permitted by applicable law

notwithstanding this limitation. You may not make any changes or modifications to any portion of the Software, or create any derivative works, without

the written permission of an officer of Tyco (except as provided in Section 3(f) of this EULA with respect to “open source” software). You may not

remove any proprietary notices, marks or labels from the Software. You shall institute reasonable measures to ensure compliance with the terms and

conditions of this EULA by your personnel and agents.

b. Copyright Notices. You must maintain all copyright notices on all copies of the Software.

c. Transfer.You may only transfer your rights under this EULA (i) as part of a permanent sale or transfer of all of the devices for which the Software is

licensed as applicable; (ii) if you transfer all of the Software (including all component parts, the media and printed materials, any upgrades and this

EULA); (iii) if you do not retain any copies of any portion of the Software; (iv) if the recipient agrees to the terms of this EULA; and (v) if the Software is an

upgrade, such transfer must also include all prior versions of the Software. You agree that failure to meet all of these conditions renders such transfer

null and void.

d. Termination. Without prejudice to any other rights, Tyco may terminate this EULA if you fail to comply with the terms and conditions herein. In such

event, you must immediately destroy all copies of the Software and all of its component parts.To the extent the Software is embedded in hardware or

firmware, you will provide prompt access to Tyco or its representative to remove or lock Software features or functionality as Tyco determines.

e. Subsequent EULA. Tyco may also supersede this EULA with a subsequent EULA pursuant to providing you with any future component, release,

upgrade or other modification or addition to the Software. Similarly, to the extent that the terms of this EULA conflict with any prior EULA or other

agreement between you and Tyco regarding the Software, the terms of this EULA shall prevail.

f. Incorporation of “Open Source” and other Third Party Software. Portions of the Software may be subject to certain third party license agreements

governing the use, copying, modification, redistribution and warranty of those portions of the Software, including what is commonly known as “open

source” software.A copy of each applicable third party license can be found in the file README.TXT or other documentation accompanying the

Software. Such open source software is not subject to any warranty and indemnity set forth in this EULA.By using the Software you are also agreeing

to be bound to the terms of such third party licenses.If provided for in the applicable third party license, you have a right to receive source code for such

software for use and distribution in any program that you create, so long as you in turn agree to be bound to the terms of the applicable third party

license, and your programs are distributed under the terms of that license.A copy of such source code may be obtained free of charge by contacting

your Tyco representative.

g. Trademarks. This EULA does not grant you any rights in connection with any trademarks or service marks of Tyco, its affiliates or its suppliers.

h. Rental. You may not sublicense, rent, lease or lend the Software. You may not make it available to others or post it on a server or web site or

otherwise distribute it.

i. Software Keys. The hardware/software key, where applicable, is your proof of license to exercise the rights granted herein and must be retained by

you.Lost or stolen keys will not be replaced.

j.Demonstration and Evaluation Copies. A demonstration or evaluation copy of the Software is covered by this EULA; provided that the licenses

contained herein shall expire at the end of the demonstration or evaluation period.

D-307631 MC-309 PG2 Installation instructions 8

k. Registration of Software. The Software may require registration with Tyco prior to use. If you do not register the Software, this EULA is automatically

terminated and you may not use the Software.

l. Additional Restrictions. The Software may be subject to additional restrictions and conditions on use as specified in the documentation accompanying

such Software, which additional restrictions and conditions are hereby incorporated into and made a part of this EULA.

m. Upgrades and Updates. To the extent Tyco makes them available, Software upgrades and updates may only be used to replace all or part of the

original Software that you are licensed to use.Software upgrades and updates do not increase the number of copies licensed to you.If the Software is

an upgrade of a component of a package of Software programs that you licensed as a single product, the Software may be used and transferred only as

part of that single product package and may not be separated for use on more than one computer or System.Software upgrades and updates

downloaded free of charge via a Tyco authorized World Wide Web or FTPsite may be used to upgrade multiple Systems provided that you are licensed

to use the original Software on those Systems.

n. Tools and Utilities. Software distributed via a Tyco-authorized World Wide Web or FTP site (or similar Tyco-authorized distribution means) as a tool

or utility may be copied and installed without limitation provided that the Software is not distributed or sold and the Software is only used for the intended

purpose of the tool or utility and in conjunction with Tyco products.All other terms and conditions of this EULA continue to apply.

4. EXPORT RESTRICTIONS. You agree that you will not export, re-export or transfer any portion of the Software, or any direct product thereof

(the foregoing collectively referred to as the "Restricted Components"), to IRAN, NORTH KOREA, SYRIA, CUBA and SUDAN,including any

entities or persons in those countries, either directly or indirectly (“Tyco’s Position”).You also agree that you will not export, re-export or transfer

the Restricted Components to any other countries except in full compliance with all applicable governmental requirements, including but not

limited to applicable economic sanctions and constraints administered by any Israeli governmental authority, including, but not limited to the Israeli

Ministry of Defense, by any applicable treaty, applicable export control measures administered by Israel , U.S. Treasury Department and

applicable export control measures administered by the U.S. Department of Commerce and U.S. Department of State, any other U.S.

government agencies, and measures administered by the European Union or the government agencies of any other countries.Any violation by

you of the applicable laws or regulations of the U.S. or any other government, or where you breach Tyco’s Position notwithstanding whether or

not this is contrary to any aforementioned applicable laws or regulations, will result in automatic termination of this EULA.

5. U.S. GOVERNMENT RESTRICTED RIGHTS. The Software is Commercial Computer Software provided with "restricted rights" under Federal

Acquisition Regulations and agency supplements to them. Any use, duplication or disclosure by the U.S. Government is subject to restrictions as

set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFAR 255.227-7013 et. seq. or 252.211-

7015, or subparagraphs (a) through (d) of the Commercial Computer Software Restricted Rights at FAR 52.227-19, as applicable, or similar

clauses in the NASA FAR Supplement. Contractor/manufacturer is Visonic Ltd., 24 Habarzel St., Tel-Aviv, Israel 69710.

6. LIMITATION OF LIABILITY & EXCLUSION OF DAMAGES.

a.LIMITATION OF LIABILITY. IN NO EVENT WILL TYCO’S AGGREGATE LIABILITY (INCLUDING, BUT NOT LIMITED TO, LIABILITY FOR

NEGLIGENCE, STRICT LIABILITY, BREACH OF CONTRACT, MISREPRESENTATION AND OTHER CONTRACT OR TORT CLAIMS) ARISING

FROM OR RELATED TO THIS EULA, OR THE USE OF THE SOFTWARE, EXCEED THE AMOUNT OF FEES YOU PAID TO TYCO OR ITS

RESELLER FOR THE SOFTWARE THAT GIVES RISE TO SUCH LIABILITY. BECAUSE AND TO THE EXTENT THAT SOME JURISDICTIONS DO

NOT ALLOW THE EXCLUSIONS OR LIMITATIONS OF LIABILITY ABOVE, THESE MAY NOT APPLY TO YOU.

b.EXCLUSION OF OTHER DAMAGES. UNDER NO CIRCUMSTANCES SHALL TYCO OR ANY OF ITS RESELLERS OR LICENSORS BE LIABLE

FOR ANY OF THE FOLLOWING: (I) THIRD PARTY CLAIMS; (II) LOSS OR DAMAGE TO ANY SYSTEMS, RECORDS OR DATA, OR LIABILITIES

RELATED TO A VIOLATION OF AN INDIVIDUAL'S PRIVACY RIGHTS; OR (III) INDIRECT, INCIDENTAL, SPECIAL, CONSEQUENTIAL,

PUNITIVE, RELIANCE, OR COVER DAMAGES (INCLUDING WITHOUT LIMITATION, LOSS OF PROFITS, BUSINESS INTERRUPTION, LOSS

OF DATA OR BUSINESS INFORMATION AND LOST SAVINGS), IN EACH CASE EVEN IF TYCO HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES.YOU ARE SOLELY RESPONSIBLE AND LIABLE FOR VERIFYING THE SECURITY, ACCURACY AND ADEQUACY OF ANY

OUTPUT FROM THE SOFTWARE, AND FOR ANY RELIANCE THEREON. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF

INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR THE LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS, SO SOME OF THE

ABOVE LIMITATIONS MAY APPLY TO YOU ONLY TO THE EXTENT PERMITTED BY THOSE LAWS.

GENERAL. If any provision of this EULA is found to be unlawful, void, or for any reason unenforceable, then that provision shall be severed from this

EULA and shall not affect the validity and enforceability of the remaining provisions. You should retain proof of the license fee paid, including model

number, serial number and date of payment, and present such proof of payment when seeking service or assistance covered by the warranty set forth

in this EULA.This EULA is governed by the laws of Israel, without giving effect to any choice or conflict of law provision or rule that would cause the

application of the laws of any jurisdiction other than Israel.Each of the Parties submits to the exclusive jurisdiction of any court sitting in Tel Aviv, Israel for

purposes of resolving any and all disputes arising under or related to these terms and conditions.The parties specifically exclude the application of the
