TypeS Plug & Glow User manual

Instruction Manual
PACKAGE CONTENTS
ON / OFF
Plug & GlowTM
Smart Lighting Hub Controller
24”
Hardwire
Cables
36” Power
Cable with 12V
Power Adapter
Automotive
Smart Lighting
Hub Controller

TECHNICAL SPECIFICATIONS INSTALLATION
Note the
portion of
strip that is
cut-off is
no longer
usable.
12V DC
12V DC
12V DC
3M
3M
3M
3M
3M
3M
• Choose your desired location.
( – see suggestions above)
• Clean surface thoroughly with
isopropyl alcohol. Dry completely.
• Peel off the 3M™ tape backer and
carefully apply to the desired area.
Note:
• For use with 12V power only
• Suitable temperature for
installation is 70°F (21°C) or above.
• If needed LED strips can be cut – ONLY
cut where scissors mark is shown.
Working voltage: DC 12V Only
Bluetooth distance: No obstacle 30ft
Frequency band: 2.4GHZ
Types of LED: 5050 SMD RGB
Maximum LED: 20ft (total combined)
Maximum amperage draw: 3A

POWER
Two Power options available
12V Plug-in power adapter
12V Hardwire
3A fuse
1) Select your desired power connection
and connect to the Plug & GlowTM Smart
Lighting Hub Controller
2) Connect LED strip with extension cable
to the Smart Lighting Hub Controller.
Use arrow indication to match the
correct direction.
Note the
portion of
strip that is
cut-off is
no longer
usable.
b
b
ON/OFF
a
Light will ONLY work when
power arrows are aligned
as shown above
LED Strips Extension
Cables
Smart Lighting
Hub Controller
APP INSTALLATION
• Install Smart Lighting APP on your Smart
phone. Scan above QR code to find the
compatible APP for iOS or Android.
• Or you can search for the APP through
the APP Store or Google Play by:
• Once installed, open the
APP and begin enjoying
your Plug & Glow™
experience.
bb
b
a
Scan to download APP
Compatible with iPhone 4s &
higher, iPad3, iPad Mini, iPad Air
& higher, and iPod touch 5th
Generation & higher.
Requires iOS 7.0 or higher.
Compatible with phones
with Android™ 4.3 or higher.
Note: not all Android™ phones
are equipped with Bluetooth®
Smart v4.0 required for
this application.
Scan to download APP
WINPLUS TYPE S LED
+-
• Choose your desired location.
( – see suggestions above)
• Clean surface thoroughly with
isopropyl alcohol. Dry completely.
• Peel off the 3M™ tape backer and
carefully apply to the desired area.
Note:
• For use with 12V power only
• Suitable temperature for
installation is 70°F (21°C) or above.
• If needed LED strips can be cut – ONLY
cut where scissors mark is shown.

USING THE APP Cont..
A
B
C
D
E
F
USING THE APP
• Install Smart Lighting APP on your Smart
phone. Scan above QR code to find the
compatible APP for iOS or Android.
• Or you can search for the APP through
the APP Store or Google Play by:
• Once installed, open the
APP and begin enjoying
your Plug & Glow™
experience.
Home Page
Tap “Smart LED Hub” Icon to start
APP will automatically pair to the Hub
when both are powered on (including
Bluetooth) and within 30ft

Master On/Off Switch
A
BLED Zone Functions:
Connect and control up to four
separate zones.
On/Off: Press each zone icon to turn
LED On or Off.
Move Zone Icon:
Press and hold zone icon, select
“Move” to position each zone icon at
your desired location.
Rename Zone Icon:
Press and hold zone icon, select
“Rename” to rename each icon.
(Note: Maximum 4 characters).
Select Multiple:
You can select multiple zones and
control the same setting at once.
Press and hold zone icon, select
“Select Multiple” then select your
desired zone by pressing “Confirm”.
To ungroup your selection, press and
hold zone icon and select “Ungroup”.
Select Vehicle Schematic:
Press>, select your desired vehicle
schematic.
C
D
E
F
Save Preset:
You can save your favorite settings.
After creating your setting, press
"Save Preset" and enter your preset
name. You can save up to 10 preset
settings.
Select Preset:
You can select your previously saved
preset setting, press "Select Preset"
and choose your saved setting.
Delete Saved Preset Setting:
To delete a saved preset setting,
press "Select Preset" and press and
hold the preset setting that you wish
to delete. Press “Yes” to delete.
Select Color:
Choose from up to 49 different
colors. Press "Select Color", select
your desired color and press
“Confirm”.
Brightness:
Slide bar to adjust brightness setting
LED Mode:
Choose from 8 different modes
Note: Music Mode is sound activated.
Speed:
Slide bar to adjust the speed of the
movement from each LED Mode.

EXTENDABLE WARNING
WARNINGS:
1. Do not install or use product if it, in any way, impairs
the safe operation of your vehicle.
2. NEVER use the APP while operating your vehicle.
Use the APP when vehicle is stationary only.
3. Follow manufacturer’s instructions to ensure the
product is properly & safely installed.
4. Check your state or provincial laws before installing.
Vehicle owner must comply with all applicable laws.
5. This product is intended solely for decorative
purposes. Manufacturer and Seller assume no liability
for installation or use, which are solely the responsibility
of the purchaser.
6. This product is not DOT approved and is designed
and intended for interior uses only. Not for use in
extreme temperature such as under hood applications.
7. The Manufacturer and Seller are not responsible or
liable for consequential, incidental, or indirect damages,
whether to person or property, resulting from the
installation or improper use of this product.
PROP 65 WARNING: This product contains lead, a
chemical known to the state of California to cause
cancer, birth defects or other reproductive harm.
Have a comment or question?
Email us at: [email protected]
or visit us online at: www.winplususa.com
Type S Plug & GlowTM kits can be extended
up to maximum of 20ft (6m) using
compatible extension strips.
To function properly extension strips must
be connected to the same type of strip. (see
examples below)
Plug & Glow Red/ Blue/ White + Multi color Extension
12V DC 12V DC
+
Winplus North America, Inc.
820 South Wanamaker Avenue, Ontario, CA 91761 USA
Tel: [phone]
© 2015 Winplus North America, Inc.
All rights reserved.
3M™ is a trademark of 3M Company.
Save Preset:
You can save your favorite settings.
After creating your setting, press
"Save Preset" and enter your preset
name. You can save up to 10 preset
settings.
Select Preset:
You can select your previously saved
preset setting, press "Select Preset"
and choose your saved setting.
Delete Saved Preset Setting:
To delete a saved preset setting,
press "Select Preset" and press and
hold the preset setting that you wish
to delete. Press “Yes” to delete.
Select Color:
Choose from up to 49 different
colors. Press "Select Color", select
your desired color and press
“Confirm”.
Brightness:
Slide bar to adjust brightness setting
LED Mode:
Choose from 8 different modes
Note: Music Mode is sound activated.
Speed:
Slide bar to adjust the speed of the
movement from each LED Mode.
iPhone, iPad and iPod touch are trademarks of Apple Inc.
Android is a trademark of Google Inc.
Multi color + Multi color extension
+12V DC12V DC
Multi color + Multi color Micro Light Extension
+
12V DC
Maximum 5ft each
port or total
combined 20ft
+
Multi color Micro Light + Multi color Micro Light extension

OPTIONAL ACCESSORIES
WARNINGS:
1. Do not install or use product if it, in any way, impairs
the safe operation of your vehicle.
2. NEVER use the APP while operating your vehicle.
Use the APP when vehicle is stationary only.
3. Follow manufacturer’s instructions to ensure the
product is properly & safely installed.
4. Check your state or provincial laws before installing.
Vehicle owner must comply with all applicable laws.
5. This product is intended solely for decorative
purposes. Manufacturer and Seller assume no liability
for installation or use, which are solely the responsibility
of the purchaser.
6. This product is not DOT approved and is designed
and intended for interior uses only. Not for use in
extreme temperature such as under hood applications.
7. The Manufacturer and Seller are not responsible or
liable for consequential, incidental, or indirect damages,
whether to person or property, resulting from the
installation or improper use of this product.
PROP 65 WARNING: This product contains lead, a
chemical known to the state of California to cause
cancer, birth defects or other reproductive harm.
ML-55256_V1
Scan to learn more
ACCESSORIES AVAILABLE TO
TAKE YOUR EXPERIENCE TO
THE NEXT LEVEL
PLUG & GLOWTM
SPLITTERS & EXTENSION CABLES
LED EXTENSION PACK
12” & 36”
MULTI -COLOR
USE ONLY MULTI-COLOR
MICRO LIGHT & STRIP EXTENSIONS
12v DC
iPhone, iPad and iPod touch are trademarks of Apple Inc.
Android is a trademark of Google Inc.
FCC
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) This device must accept any interference
received, including interference that may cause
undesired operation.
The manufacturer is not responsible for any radio or
TV interference caused by unauthorized
modifications or change to this equipment. Such
modifications or change could void the user’s
authority to operate the equipment.
IC
This radio transmitter (identify the device by
certification number or model number if Category II)
has been approved by Industry Canada to operate
with the antenna types listed below with the
maximum permissible gain indicated. Antenna types
not included in this list, having a gain greater than
the maximum gain indicated for that type, are
strictly prohibited for use with this device.
CE
Hereby, Winplus North America Inc., declares that
this Plug&Glow Smart LED is in compliance with the
essential requirements and other relevant
provisions of Directive 1999/5/EC.
Environment friendly disposal
You can help protect the environment!
Please remember to respect local
regulations. Return any non-working
electrical components to an appropriate
waste disposal center.
0700
Antenna Type Max. Antenna Gain(dBi)
PCB printed antenna 0
