U-Line H-4026 User manual

PAGE 1 OF 4 0415 IH-4026
H-4026, H-4027
PORTABLE BLOWER
1-800-295-5510
uline.com
π
NOTE: Save these instructions.
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions
should always be followed, including the following:
WARNING! Read all instructions before using
this portable blower.
To reduce the risk of fire, electric shock, or injury:
• Do not use machine in standing water.
• Avoid electrical shock; do not handle the plug or
machine with wet hands. To unplug the cord, grasp
the plug. Do not pull on the cord.
• Use machine only as described in this manual. Do
not use in ways it was not intended.
• Turn off all switches and unplug the electrical cord
when not in use and before servicing.
• Do not allow to be used by untrained personnel.
Close attention is necessary when used near
children.
• If the machine is not working as it should, has been
dropped, damaged, or left outdoors, call Uline
Repairs team before using.
• Do not operate portable blower if cord is damaged.
Call Uline Repairs team for repair information.
• Do not run the power cord under carpeting, throw
rugs, runners or similar coverings. Place the power
cord away from traffic areas to prevent tripping.
• Do not use extension cords or outlets with
inadequate current-carrying capacity. Do not
use with a damaged cord or plug. Connect the
machine only to a properly grounded outlet (refer to
GROUNDING). Avoid damaging cord (closing doors
on cord, pulling around sharp edges or corners, hot
surfaces, or running machine over cord).
• This machine creates suction and contains a
revolving fan. Keep hair, loose clothing, fingers, and
all other parts of the body away from openings and
moving parts. Do not insert any objects into the
openings of the machine.
• Do not use in areas where flammable and/or
explosive vapor or dust is present to avoid the
possibility of fire or explosion. Some cleaning fluids
can produce such vapors.
• Do not allow air inlet openings on either side of the
machine to be obstructed; this could cause the
motor to overheat.
• Do not allow debris near front air exhaust opening
which could be thrown by the air stream.
• This unit is thermally protected.
• Use only on GFCI-protected receptacles.
• Use indoors only. Do not use outdoors or expose
to rain.
• Do not use an extension cord with this blower.
• Do not direct air flow at face or any part of body.
• Do not use the portable blower with any solid-state
speed control device.
SAFETY

PAGE 2 OF 4 0415 IH-4026
This appliance must be grounded. If it should malfunction
or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of electric
shock. This appliance is equipped with a cord having an
equipment-grounding conductor and grounding plug.
The plug must be plugged into an appropriate outlet that
is properly installed and grounded in accordance with
all local codes and ordinances.
DANGER! Improper connection of an
equipment-grounding conductor can result in
risk of electric shock. Check with a qualified
electrician or service person if you are in
doubt as to whether the outlet is properly
grounded. DO NOT modify the plug provided
with the appliance. If it will not fit the outlet,
have proper outlet installed by a qualified
technician.
This appliance is for use on a nominal 120 volt circuit
and has a grounding plug that looks like the plug
illustrated in Figure 1. A temporary adapter which
looks like the adapter illustrated in Figure 2 may be
used to connect this plug to a two-pole receptacle, as
shown, if a properly grounded outlet is not available.
The temporary adapter should be used only until a
properly grounded outlet, Figure 2, can be installed by
a qualified electrician. The grounding tab extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used, it must be held in place
by a metal screw.
NOTE: In Canada, the use of a temporary
adapter is not permitted by the Canadian
Electrical Code.
GROUNDING
Figure 2
Figure 1
OPERATING
Sanitaire’s portable blower is intended to move air and
to dry floors, walls, furniture, etc. Durable and easy to
operate with an effective balance of static pressure and
airflow, the units are suitable for a variety of applications.
1. Portable blower is shipped ready-to-use. Prior to
plugging the unit into the power source, inspect
completely for any shipping damage.
CAUTION! To reduce the risk of electric shock,
connect only to an outlet provided with a
Ground Fault Circuit Interrupter device.
2. Place the portable blower on a stable, flat dry surface.
3. Place the portable blower into the desired operating
position (See Figures 3 and 4) while making sure
unit operates normally.
a. 4 airflow positions for H-4026 model:
b. 3 airflow positions for H-4027 model:
4. All portable blowers in operation must be supervised
at all times.
PORTABLE BLOWER STORAGE
Up to 4 portable blowers can be stacked
on their sides for storage. (See Figure 5)
NOTE: Stacking feature is
not secure for transportation.
Figure 4
0º 20º 90º
Figure 3
0º 20º 45º 90º
Figure 5
Grounded Outlet Box
Grounded Outlet Box
Adapter
Metal Screw
Grounding Tab
Grounding blade
is longest of the
three prongs

PAGE 3 OF 4 0415 IH-4026
Telescoping handle and wheels are available on H-4027
model. (See Figure 6)
To use handle, push in release button, pull handle up until
it locks into place. Tilt the unit back onto the wheels and
roll to desired location.
OPERATING CONTINUED
MAINTENANCE
TROUBLESHOOTING
WARNING! To reduce the risk of fire, electric
shock or injury; DO NOT attempt to service the
unit while appliance is plugged in.
PERIODIC MAINTENANCE
1. Check power cord for any breaks, separations
or cuts.
2. Make sure the ground pin or grounding prong is
intact or the machine will be unsafe to operate.
3. To keep the portable blower clean, use a damp
cloth to wipe the surface of the housing.
4. Never clean the portable blower with water directly.
5. When not in use, unplug and store the portable
blower in a dry indoor place out of reach of
children.
Figure 6
IF THE BLOWER WILL NOT RUN:
1. Check electrical cord. Ensure is it firmly seated in
wall outlet.
2. Check GFCI and reset if tripped.
3. Check to see if building circuit breaker is tripped. If
circuit is overloaded, move cord to different GFCI outlet.
4. Motor overheated and tripped thermal protection;
turn off and unplug. Wait 30 minutes to let cool
before running.
OPERATING ISSUE CAUSES RECOMMENDATIONS
Blower not running. No power input.
Switch not turned on.
Fan wheel jammed.
Intake or exhaust blocked.
Plug in and check circuit breaker.
Turn on switch.
Remove material jamming fan wheel.
Turn unit off and allow to cool,
then remove blockage.
Blower vibrates. Accumulation of dirt on fan blades. Clean fan blades.
For any problem not listed above, call Uline Repairs team for service information.

PAGE 4 OF 4 0415 IH-4026
TECHNICAL DATA
MODEL H-4026 H-4027
Volt/Frequency 115 V/6 0 H z 115 V/6 0 H z
Power 1/2 HP 1/2 HP
AMPS 5.0 5.0
Unit Weight 20.4 lbs 23.6 lbs
Speeds 3 3
Unit Size (L x W x H) 15.9 x 15.7 x 16.3 15.9 x 17 x 17.5
Telescopic Handle and Wheel No Yes
Cord Length 25 ft 25 ft
Overheating Protection Thermally Protected Thermally Protected
Rated Airflow (On High) 2,800 CFM 2,800 CFM
Positions 4 (0º, 20º, 45º, 90º) 3 (0º, 20º, 90º)
Housing ABS ABS
