U-Line 2175WC Owner's manual

F
eatures Benefits
&
8900 North 55th Street • Milwaukee, Wisconsin 53223 • Phone: [phone] • Fax: [phone]
www.u-line.com
WINE CAPTAIN®
MODEL 2175WC
Capacity: Up to 48 bottles (0.75 L)
Defrost Type: Automatic (cycle) Defrost
Colors: Stainless Steel and Black
Feature Benefit
Zones Maintains wine at their proper serving temperature
Top Approximately 55°F (Red)
Middle Approximately 50°F (White)
Bottom Approximately 45°F (Sparkling)
Safely stores three or two types, or a single type, of wine
Stable temperatures Stable, consistent temperatures provide longer-term storage
capability.
Touch Control Digital
Technology
• Elegantly integrated into the bottom maple-trimmed
wine rack
• Provides ability to set the middle temperature and see the
temperatures in all three temperature zones
• Manages key model functions and provides user alerts
Black interior Elegant visual appearance
Adjustable on/off interior light • Automatically illuminates when the door is opened
• May be manually turned on when door is closed for
viewing one’s wines
• Auto shut-off after four hours
• Recessed so as not to interfere with access to wine
Open door alarm Audible alert when door is left open
Full extension slide-out vinyl-
coated wine racks
Allow for easy access to all wine bottles and prevents bottles
from slipping
Contoured maple-trimmed wine
racks
Wood can be stained or replaced with a solid surface
material to match surrounding décor.
Maple-trimmed display rack This lower positioned display rack slants your wine bottles at
an approximate 40° angle, allowing for an elegant
presentation of your wine.
Built-in Provides custom look. No additional clearance around sides,
top or rear of unit for ventilation. Do not obstruct front
grille.
Black model Offers a black elegant integrated handle and grille with a
black vinyl-clad steel cabinet
Stainless steel model • Offers a seamless stainless steel-trimmed glass door with a
sculpted stainless steel handle and a full wrap stainless
cabinet, and a stainless-like grille
• Must order right- or left-hand hinged
Tinted, thermal glass door Protects wine from potentially harmful ultraviolet light rays
Self-closing door Ensures a positive door seal and prevents door bounce back
Field-reversible doors Flexible installation options. Black model only.
Black vinyl-clad cabinet • Textured look, more resistant to scratching, peeling or
flaking
• Black model only
Leveling legs More precise undercounter fit, durable, factory-installed
Sabbath or “Black Out” mode Easily turn off all lights and control displays. Automatically
resets after 36 hours.
Contemporary grille design Integrates seamlessly with surrounding cabinetry

D
imensions Specifications
&
8900 North 55th Street • Milwaukee, Wisconsin 53223
Phone: [phone] • Fax: [phone] • www.u-line.com
04/15/06 © 2006 U-Line Corporation Printed In U.S.A.
Wine Captain®Model 2175WC
Specifications Capacities
(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.
Anchoring device included with unit
Stainless steel model must be ordered right- or left-hand hinged.
Stainless steel models: Allow 2-1/2" clearance on hinge side for 90° door opening when installed against a wall.
To prevent potential interior liner damage, please consult the Installation Guide if you choose to stain the wood trim on the
wine racks.
Please visit www.U-Line.com for Installation Guide.
All specifications subject to change without notice.
2175WC 2175WC (Stainless Steel)
23-15/16
(60.6)
*POWER CORD
*ON BACK OF UNIT
5-7/8
(14.9)
2-7/8
(7.3)
3-3/8
(8.6)
34-1/8
(86.7)
FULL
RETRACT
HEIGHT
35-1/8
(89.2)
FULL
EXTEND
HEIGHT
23-1/4
(59.1)
21
(53.3)
25-19/32
(65)
23-1/4
(59.1)
21
(53.3)
INCHES (CENTIMETERS)
Shipping Weight:
Black Models
Stainless Steel Models
138 lbs (63 kg)
145 lbs (66 kg)
(1) Running Amps 2.4
(1) Maximum Start-up Amps 9.8
Refrigerator volume N/A
Freezer volume N/A
Approximate daily ice production N/A
Ice storage N/A
Wine bottle storage (0.75 L) Up to 48
