U-Line Echelon 2075DWRRSS User manual

1. Just under 24 inches wide
BENEFIT: Fits into a standard 24 inch wide
cabinet opening.
2. Multiple organizing features
a. Adjustable Slide & Divide organizer comes
standard in the top drawer and can be used in
either drawer. Consumer can adjust the
organizer from front to back, and side to side.
b. Clear organizing bin for top drawer can
accommodate wine bottles, two-liter bottles, or
other items. The bin is designed to slide from the
front to rear of the drawer allowing easy access
to items in or beneath the bin.
c. Bottom drawer crisper can be removed from
either side of the drawer to easily bring fruit or
vegetables to a sink, counter top, or bar.
d. Glass crisper shelf allows customer to easily see
contents of the crisper. Crisper shelf can easily
be fully removed to accommodate storage of
taller items.
BENEFIT: Use of all organizing features allow
consumers to customize their refrigeration space.
3. Stainless steel units come standard with a
seamless full wrap stainless steel drawer front,
sculpted stainless handles and a black vinyl clad
cabinet.
BENEFIT: The seamless full wrap stainless steel
drawers with sculpted handles distinguish this unit
from heavier, “commercial” looks and reduces
assembly time in the field and overall cost.
4. Stainless steel drawer interiors
BENEFIT: Corrosion resistant, sleek professional
appearance.
5. Consumer friendly, self diagnosing controller
BENEFIT: In the rare event of a problem, a
flashing LED indicator light explains if there is a
need to call for service.
EXCLUSIVE FEATURES OF ÉCHELON™
Model 2075DWRR
Drawer Refrigerator
A 5.5 cubic foot built-in under the counter
refrigerated drawer unit.
3/4" WOOD OVERLAY
SUPPLIED BY CUSTOMER
24
(61) WITH 3/4"
OVERLAY FRAME
23-15/16
(60.8)
* POWER CORD
INCHES (CENTIMETERS)
* ON BACK OF UNIT
3-3/8
(8.6)
34-1/8
(86.7)
FULL
RETRACT
HEIGHT
2-7/8
(7.3)
35-1/8
(89.2)
FULL
EXTEND
HEIGHT
5-7/8
(14.9)
23-1/4
(59.1) 21
(53.3)
See Overlay Door Panel Preparation Instructions

1. Easy to set, adjustable, LED temperature
controller
BENEFIT: Digital readout of temperature setting
and actual drawer temperatures. Easy ability to see
and adjust to desired temperature.
2. Black units come standard to accept a full
overlay drawer panel
BENEFIT: Provides a fully integrated appearance
with surrounding cabinetry. Overlay panels are
easily attached to drawers.
3. Full overlay capability allows the customer to
choose the size of the gap between drawer
panels (either 1/2 or 1/4 inch gap)
BENEFIT: This provides the customer greater
flexibility in matching surrounding cabinetry.
4. Black units come with flush mounted black
drawer panel and will accept a custom 1/4 inch
thick panel
BENEFIT: Allows customer to achieve a custom,
built-in look by matching surrounding cabinetry.
Drawers come standard from the factory equipped
to be used with full overlay panels. For 1/4 inch
custom panel applications, replacement drawer
handles are required. Part number 11926-4-BLK.
5. Heavy duty, full extension drawer slides
BENEFIT: Allows easy accessibility to contents in
the back of drawers.
SUPERIOR FEATURES OF ÉCHELON™
2075DWRR
ADDITIONAL FEATURES
1. Automatic (cycle) Defrost
2. Anchoring Device included
3. Interior light in each drawer
4. Vinyl clad steel cabinet (black)
5. Adjustable leveling legs
6. Available in black and stainless steel
BENEFITS
Maintenance free defrosting.
Unit must be installed under a counter and must be
anchored to prevent tipping if both drawers are open
when full.
Automatically illuminates when drawers are opened.
Textured, rich look. Resistant to scratching, peeling
and flaking.
More precise under the counter fit, durable factory
installed.
Blends with all cabinet colors.
