U-Line 29R Manual

8900 North 55th Street ▪Milwaukee, WI ▪53224-9540 ▪414-354-0300 ▪(fax) 414-354-7905
BI-95 13 15/32” H x 12 15/16” W
BI-98 15 15/16”H x 13 15/16” W
29 Series 21 13/32” H x 19 13/16” W
1115 Series 26 15/16” H x 13 15/16” W
1175 Series 26 15/16” H x 22 15/16” W
¼” CUSTOM INSERT PANEL SIZES
ORIGINS
o Zero clearance with a flush/flat door panel.
o Door will accept a raised panel. Allow proper clearance, on hinge
side when installing a raised panel. Amount of clearance will
depend on raised panel thickness.
o The maximum panel thickness when inserted into the door reveal
(channel) is ¼” thick.
o For raised panels on BI 95, BI98 series and 29 series models the
depth of the reveal is ¼” on both sides and bottom and ½” on top.
o For raised panels on 1115, and 1175 series models the depth of
the reveal is ¼” on both sides, bottom, and top.
o Panel not to exceed 20 pounds.
o Conversion information: 1 inch = 2.54 cm
30164 Rev B
