U-Line 75F Configuration guide

8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX 414.354.7905 U-LINE.COM

75F

mARinE / RF

Black White

FE ATURES

• 5.7 cubic feet overall freezer capacity maximizes storage and preservation of food

and beverage items

• Mechanical dial control

• Freezertemperaturesettingfrom0to5˚F

• Mechanical controlled passive cooling system

• 220 volt model available with a 4 – 6 week order lead time

• UL Commercial listed only

• Four 4mm tempered glass shelves with bullnose edges

• 2 door bins

• Vinyl coated cabinet helps withstand tough marine environments

• Corrosion resistant marine grade hardware provide better product longevity

in harsh environments

• Field reversible door with zero clearance door swing eases installation

• Optional door lock

• Fieldreversibledoorwithzeroclearancedoorswingsimpliesinstallation

• Models will accept a 1/4" insert panel

• No additional clearance around sides, top or rear of unit is needed for ventilation

• Sleek and contemporary look provides a very clean, high-end aesthetic

• Donotobstructfrontgrilleairow

• For proper installation and cut-out dimensions, see backside for details

75F

inTEGRATiOn inTERiOR / ExTERiOR PERFORmAnCE

DIMENSIONS AND SPECIFICATIONS

Please visit www.u-line.com for installation guide.

All specifications are subject to change without notice.

OVERALL DIMENSIONS

8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX 414.354.7905 U-LINE.COM

75F

23 15/16"

75F

3 9/16"

34 1/8"

23 3/16"

24"

24-3/16"

34-1/4"

35-1/8"

75F

Black 110V ULN-75FB-00

White 110V ULN-75FWH-00

Black 110V ULN-75FB-13

White 110V ULN-75FWH-13

White 220V ULN-75FHW-02

MARINE / RF

Height 34-1/8" (86.8)

Width 23-15/16"" (60.9)

Depth 23-3/16" (59.2)

Shipping weight: 114 lbs (51.8 kg)

Running amps 2.5

Maximum start-up amps 18.0

Amps pertain to voltage rating 110/115 volt, 60 Hz

Optional in 220/230 voltage, 50/60 Hz

Capacities:

Defrost technology Manual defrost

Freezer volume 5.7 Cu. Ft

75F Black and White Model
