REFRIGERATOR/FREEZER
MODEL 2175RF
Capacity: 4.2 cubic feet of refrigeration and
1.5 cubic feet of freezer
Defrost Type: Frost-free
Colors: Stainless Steel, Black, White
Feature Benefit
Refrigerator and frost-free freezer • 4.2 cu. ft of refrigeration can be maintained at 34°-45°F
• 1.5 cu. ft of freezer internal temperatures between 0° and +5°F
Freezer flexibility • Freezer is located in a vertical position along the side, allowing
for greater storage flexibility
• Removable white vinyl-coated wire shelf can be positioned
either in the middle of the freezer compartment or at the
bottom for storage of taller items
Touch Control Digital Technology • Full-featured, easy-view command center - right at your
fingertips
• Easy to set and see the refrigerator temperatures
• Manages key model functions and provides user alerts
Open door alarm Audible alert when door is left open
Optional 3/4" full overlay door
panel
• Provides a fully integrated appearance with surrounding décor
while maintaining zero door clearance
•Easytoinstall
• Black and white models only
• Must order kit number U-OL2175
Standard door will accept a 1/4"
panel
• Ability to match surrounding décor and cabinets
• Black and white models only
Built-in or freestanding • Provides custom look
• No additional clearance around sides, top or rear for
ventilation. Do not obstruct front grille.
Stainless steel model • Offers a full wrap stainless door and cabinet, along with a
curved, sculpted stainless door handle and a stainless-like grille
• Must order right- or left-hand hinged
Three fully encapsulated, curved
glass shelves
Contains spills while providing an upscale appearance. Easy to
clean.
Two contoured, adjustable
in-door storage shelves
Easy access, flexible storage
Self-closing door • Engages when the door is open 8-10"
• Ensures a positive door seat and prevents bounce-back
Field-reversible doors • Flexible installation options - can fit any location with easy
access
• Black and white models only
Integrated handle • Sleek designer look that does not add depth to the cabinet
when built in
• Black and white models only
Vinyl-clad cabinets • Textured, rich look. More resistant to scratching, peeling and
flaking.
• Cabinet extends to the floor
• Black and white models only
Recessed interior light • Automatically illuminates when door is opened
• Does not interfere with product access or storage
Leveling legs • Achieve a more precise undercounter fit
• Durable, strong legs will not bend when unit is installed
Sabbath or “Black Out” mode • Easily turns off all lights and control displays
• Automatically resets after 36 hours
Contemporary grille design Integrates seamlessly into surrounding cabinetry
Outdoor use The stainless model is deemed suitable for outdoor use by UL.

D
imensions Specifications
&
8900 North 55th Street • Milwaukee, Wisconsin 53223
Phone: [phone] • Fax: [phone] • www.u-line.com
04/15/06 © 2006 U-Line Corporation Printed In U.S.A.
Refrigerator/Freezer Model 2175RF
Specifications Capacities
(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.
Stainless steel model must be ordered right- or left-hand hinged.
Stainless steel models: Allow 2-1/2" clearance on hinge side for 90° door opening when installed against a wall.
Please visit www.U-Line.com for Installation Guide.
All specifications subject to change without notice.
2175RF
2175RF
(Stainless Steel)
23-15/16
(60.6)
*POWER CORD
*ON BACK OF UNIT 5-7/8
(14.9)
2-7/8
(7.3)
34-1/8
(86.7)
FULL
RETRACT
HEIGHT
35-1/8
(89.2)
FULL
EXTEND
HEIGHT
3-3/8
(8.6)
23-11/32
(59.3)
21
(53.3)
25-13/32
(64.6)
23-3/32
(58.6)
21
(53.3)
INCHES (CENTIMETERS)
Shipping Weight:
Black and White Models
Stainless Steel Models
120 lbs (54 kg)
138 lbs (63 kg)
(1) Running Amps 2.5
(1) Maximum Start-up Amps 6.5
Refrigerator volume 4.2 cubic
feet
Freezer volume 1.5 cubic
feet
Approximate daily ice production N/A
Ice storage N/A
