Full Overlay Drawer Panel
Preparation and Installation
Instructions for
Models C2275DWR and 2275DWRR

www.U-LineService.com 211/2007
Full Overlay Drawer Panels
Drawer Panel Preparation
Full overlay drawer panels completely cover the drawer
fronts and handles to give a built-in appearance. Overlay
units are shipped ready for full overlay installation.
Note: For standard installations, both drawers mount the
same and a 1/2" gap is achieved between drawers.
1. Cut the overlay to the following dimensions.
Full Overlay Dimensions:
Width: 23-3/4"
Height: 14-3/4"
IMPORTANT
The thickness of the wood overlay panel must be 3/4".
The door panel must not weigh more than 20 lbs.
Drawer Panel Installation
Removing Existing Drawer Fronts
1. Open drawer. Pull drawer gasket out of groove (top
edge of drawer only). Start in the middle and pull
outward, moving toward the edge (see Figure 1). This
may take some force.
2. Remove and save the two screws located at the ends of
the handle (see Figure 2 ). Remove the handle.
3. Remove existing panel and cardboard spacer. Discard
the spacer.
Attaching the Full Overlay Panel
1. If user-supplied cabinet handles will be used, attach
their hardware to the overlay panel at this time.
IMPORTANT
User-supplied cabinet handles MUST be counter bored to
make sure mounting hardware is below surface of overlay
panel. Failure to do so can cause damage to overlay panel
and/or drawer. Overlay panel will not sit flush to drawer if
mounting hardware is not counter bored.
2. Place and tape the existing drawer panel on the back of
the overlay panel (see Figure 3 ).
3. Drill the five holes (5/32
" drill 3/8 " deep) through both
panels according to Figure 4 .
Gasket
Handle Screw
Figure 1 Figure 2
Drawer Panel
Bottom of
Wood Panel
Back of
Wood
Panel
Side of
Wood Panel
Tape
11/32"
Bottom
3/8"
Both Sides
Figure 3
Top of
Wood Panel
14-3/4"
1"
11-7/8"
1"
23-3/4"
5/32" x 3/8" Deep –
5 Places
Vinyl Coated
Steel Panel
11-13/16"
1"
2-15/16"
Figure 4

11/2007 3www.U-LineService.com
CAUTION
It is important to ensure that all drilled holes are drilled to
the correct depth in order to avoid splits in the wood
when hardware is installed.
4. Remove tape adjoining the panels and enlarge the five
holes in the drawer panel using a 0.201
" (#7) drill.
5. Attach the drawer panel to the overlay panel using
#10 x 5/8
" wood screws and nylon spacers. The nylon
spacers fit between the overlay panel and the door
panel as shown in
Figure 5 . The spacers allow the
original drawer panel to slide back into the 1/4 " -thick
drawer front reveal (channel).
IMPORTANT
Drawer panel and overlay panel must be aligned properly
or the drawer will not operate correctly.
Assembling the Drawer Front
1. Install the assembled panel by sliding the original door
panel back into the drawer front.
2. Replace the handle assembly and secure with the two
screws removed in Step 2 under Removing Existing
Drawer Fronts.
3. Starting at the corners and working toward the center,
push the drawer gasket back into place.
Checking Drawer Alignment
The unit’s drawers are aligned at the factory before
shipment. However, their alignment could have been
disturbed during shipment or during overlay panel
installation.
See Figure 6. Check each drawer to confirm that it is
aligned:
•Side-to-Side — When viewed from the top, the
drawer front should be square with the sides of the
cabinet.
•Front-to-Back — When viewed from the side, the
drawer front should be straight with the cabinet’s
sides, not cocked forward or back.
•Top-to-Bottom — When viewed from the front, the
drawer should be level horizontally.
If either drawer is not aligned, carefully follow
instructions to remove that drawer, make the necessary
adjustment and re-install the drawer.
Drawer Panel
Typical
Wood Panel
Plastic
Spacer
Five
Required
#10 x5/8"
Round
Head Screw
Five Required
Figure 5
Figure 6
Aligned
Side-to-Side
Aligned
Front-to-Back
Aligned
Top-to-Bottom

www.U-LineService.com 411/2007
Adjusting Drawer Alignment
WARNING
SHOCK HAZARD — The unit must be unplugged
from the wall outlet during drawer removal,
adjustment and re-installation.
Drawer Removal
1. Confirm that the unit is
unplugged from wall
outlet.
2. Unplug the drawer ’ s
connection wiring (top
drawer only).
3. Remove the mounting
screws. See
Figure 7 .
4. Pull the drawer
completely out of the
unit.
CAUTION
Use care when handling the drawer. Drawer edges,
drawer rail and the unit’s slide may be sharp.
IMPORTANT
Drawer adjustments are made by moving the slide that
carries the drawer’s rail. Minor adjustments may be made
by loosening one of the slide’s mounting screws, adjusting
the slide and retightening the screw. Severe adjustments
may be made by removing the slides’ mounting screws,
drilling new mounting holes and remounting the slide.
Side-to-Side Adjustment
See Figure 8. The drawer
will need a Side-to-Side
Adjustment if, when
viewed from the top, the
drawer front is not square
with the sides of the
cabinet. This is caused by
one of the slides being
mounted too far forward
on the unit’s liner.
Minor Adjustment:
Note: The mounting holes
on the slide are slightly
larger than the screws’
diameter.
1. Loosen the slide’s
mounting screws.
2. Push the slide
backward.
3. Retighten the screws.
See
Figure 9 .
Severe Adjustment:
Note: The slides have
extra mounting holes that
may be used.
1. Remove the slide’s
mounting screws.
2. Reposition the slide so
it is the same distance
from the front of the
liner as the other slide.
Measure to confirm.
3. Mark new drilling holes
using different sets of mounting holes on the slide. See
Figure 10 .
Note: Front location holes are shown. Corresponding rear
holes will also need to be marked.
4. Drill all the new holes with a #30 drill bit.
5. Remount the slide.
Front-to-Back Adjustment
See Figure 11. The drawer
will need a Front-to-Back
Adjustment if, when
viewed from the side, the
drawer front is cocked
forward or back. This is
caused by the front slide
mountings not being level
with the rear slide
mountings.
Mounting
Screw
Figure 7
Top View of Unit
Not Aligned Side-to-Side
Figure 8
Push Slide
Backward
Loosen
Mounting Screws
Figure 9
Mark and Drill New
Mounting Holes
Push Slide
Backward
Figure 10
Not Aligned Front-to-Back
Side View of Unit
Figure 11

11/2007 5www.U-LineService.com
Minor Adjustment:
Note: The mounting holes
on the slide are slightly
larger than the screws’
diameter.
1. Loosen one slide’s
mounting screws.
2. Level the slide.
3. Retighten the screws.
See
Figure 12 .
4. Repeat procedure for
the other slide.
Severe Adjustment:
Note: The slides have
extra mounting holes that
may be used.
1. Loosen one slide’s rear
mounting screws.
2. Remove the slide ’ s
front mounting screws.
3. Reposition the slide so
it is level.
4. Mark new front drilling
holes using a different
set of mounting holes on the slide. See
Figure 13 .
5. Drill the new holes with a #30 drill bit.
6. Remount the slide.
7. Repeat procedure for the other slide.
Top-to-Bottom (and Left-to-Right)
Adjustment
See Figure 14. The drawer will need a Top-to-Bottom
Adjustment if, when viewed from the front, the drawer is
not level horizontally. Viewed from the top, one side will
protrude. This is caused by one of the slides being
mounted higher than the other slide on the unit’s liner.
Minor Adjustment:
Note: The mounting holes
on the slide are slightly
larger than the screws’
diameter.
1. Loosen one slide’s
mounting screws.
2. Push the slide upward
or downward to match
the position of the
other slide.
3. Retighten the screws.
See
Figure 15 .
4. Repeat the procedure with the other slide if necessary.
Severe Adjustment:
Note: The slides have
extra mounting holes that
may be used.
1. Remove one slide’s
mounting screws.
2. Reposition the slide so
it is the same distance
from the bottom of the
liner as the other slide.
Measure to confirm.
3. Mark new drilling holes
using different sets of
mounting holes on the slide. See Figure 16 .
Note: Front location holes are shown. Corresponding rear
holes will also need to be marked.
4. Drill all the new holes with a #30 drill bit.
5. Remount the slide.
Re-installation of Drawer
CAUTION
Use care when handling the drawer. Drawer edges,
drawer rail and the unit’s slide may be sharp.
1. Set the drawer’s rails onto the slides.
2. Re-install the rails ’ mounting screws. See Figure 7 on
Page 4.
3. Plug in the drawer ’ s connection wiring (top drawer
only).
Screws Should
Be Loose
Level the Slide
Figure 12
Mark and Drill New
Mounting Holes
Level the Slide
Figure 13
Figure 14
Not Aligned Left-to-Right
Top View of UnitFront View of Unit
Not Aligned
Top-to-Bottom
Push Slide
Upward or
Downward
Loosen
Mounting Screws
Figure 15
Mark and Drill New
Mounting Holes
Push Slide
Upward or
Downward
Figure 16

©2007 U-Line Corporation
Publication No. 30198E
11/2007 Rev. B
U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in
undercounter icemakers, Combo®icemaker/refrigerators, Wine Captain®wine storage units,
refrigerators, refrigerated drawers and refrigerator/freezers.
For more than four decades, U-Line has distinguished itself as the leader in built-in
undercounter ice making, refrigeration and wine storage appliances.
Who to Call
Service Information
If the need for service arises, contact the dealer from
whom the unit was purchased. State the Model Number
and Serial Number and explain the problem. The Model
and Serial Number plate is located inside unit at upper
right hand corner.
If you need to locate a service company, you can go online
at www.U-LineService.com and search for a service
company by zip code.
