FEATURES
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
C2275DWR
COMBO®MODELS / RF
C2275DWR 20 00 Se r i e S
Overlay
Stainless
Black
• 3.0 cubic feet overall refrigerator capacity and 2 cubic feet of freezer capacity
maximizes storage
• Daily ice rate of up to 6 lbs and storage of up to 10 lbs of crescent ice cubes
(1/2"W x 3/4"H x 2-1/2"L)
• No drain, easy and inexpensive installation, only required a 1/4" diameter outside
line
• Touch glass digital control featuring easy view command center manages key
functions and provides user alerts such as an audible door open alarm
• Digital controlled single-zone convection cooling system provides a stable and
consistent environment for optimum food and beverage storage
• Refrigerator temperature setting from 34 to 45˚ F provides flexibility for preserving
a wide variety of items
• Sabbath / Blackout mode turns off all lighting, controls display and automatically
resets after 36 hours
• Patented frost-free technology
• UL residential listing
• Lighted stainless steel interior allows for easy viewing of contents
• Clear organizing bin in top drawer holds wine, 2-liter bottles and other items and
slides back and forth for access to items beneath
• Optional slide and divide organizer must be purchased separately PN: U-26013
• Black vinyl clad textured cabinet is more resistant to scratching, peeling and flaking
• Overlay can be converted to a black model with purchase of a black handle kit
PN : 26070-01
• Due to full extension of drawers, anchoring device included and required for all
installations
• Overlay model accepts a full 3/4" overlay panel and can be fully integrated into all
styles of cabinetry
• Allow 1/4" width overall for proper installation (see backside for details)
• No additional clearance around sides, top or rear of unit is needed for ventilation
• Durable, factory installed level legs provide a more precise undercounter fit
• Do not obstruct front grille air flow
INTEGRATION INTERIOR / EXTERIOR PERFORMANCE
The Combo®Models
bring together abundant
ice supply with generous
refrigeration capacity in the
convenience of one unit.
C2275DWR – Combo®
Model drawer delivers three
appliances in one. Top drawer
holds up to 3 cubic feet of
refrigerator space with clear
top sliding bin while lower
drawer houses both ice maker
and freezer.
*To obtain a black model with a black handle, black integrated kit #26070-01-5 must be ordered.

DIMENSIONS AND SPECIFICATIONS
Please visit www.u-line.com for installation guide.
All specifications are subject to change without notice.
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
C2275DWR
COMBO®MODELS / RF
Height 33-7/8" (86.0)
Width 23-15/16" (60.8)
Depth 23-5/8" (60)
With stainless steel handle 25-1/2" (64.7)
Shipping Weight:
Black model 158 lbs (72 kg)
Stainless model 162 lbs (74 kg)
Running amps 2.5
Maximum start-up amps 26.5
Amps pertain to voltage rating 110/115 volt, 60 Hz
Capacities:
Defrost technology Manual defrost
Refrigerator volume 3 Cu. Ft
Freezer volume 2 Cu. Ft
Approximate daily ice production Up to 6 lbs
Ice Storage Up to 10 lbs
OVERALL DIMENSIONS C2275DWR
Stainless U-C2275DWRS-00
Black
U-C2275D-
WROL-00 with
Black Integrated
handle 26070-01-S
Overlay U-C2275DWROL-00
C2275DWRS Stainless Model and
C2275DWROL Black Model
24"
Minimum
24-3/16"
34-1/4"
to
35-1/8"
E
D
W
5-3/4”
6-1/16”
8-3/8”*
3-1/8”*
3-1/8”*
9-5/16”
Legend: E - Electrical W - Water D - Drain
*Can Vary Up To +1” Depending On Height Of Leveler Legs
Overlay
Stainless Steel
33-7/8"
23-3/8"
3-7/8"
23-1/4"
33-7/8"
23-15/16"
23-15/16"
3-7/8"
Overlay
Stainless Steel
33-7/8"
23-3/8"
3-7/8"
23-1/4"
33-7/8"
23-15/16"
23-15/16"
3-7/8"
