U.S. Products FLOOD KING 240V Operating instructions

IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a heated
location. Use the machine indoors. Do not use outdoors.
3. Never use the machine without the pre-filter bag installed.
FLOOD KING®
240V
INFORMATION
&
OPERATING
INSTRUCTIONS
2-4-2010
CAUTION: DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THIS INSTRUCTION MANUAL
56041833 Rev D

IMPORTANT SAFETY INSTRUCTIONS
This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories,
shops and offices other than normal residential housekeeping purposes.
When using any electrical appliance, basic precautions should always be followed, including the following:
NOTE: Read all instructions before using this machine.
WARNING!
To reduce the risk of fire, electric shock, or injury:
•Do not leave the machine unattended when it is plugged in. Unplug the unit from the outlet when
not in use and before servicing.
•To avoid electric shock, do not expose to rain or snow. Store, and use, indoors.
•Do not allow to be used as a toy. Close attention is necessary when used near children.
•Use only as described in this manual. Use only the manufacturer’s recommended attachments.
•Do not use with damaged cord or plug. If the machine is not working as it should, has been
dropped, damaged, left outdoors or dropped into water, return it to a service center.
•Protect the cord. Do not: use the cord as a handle, close a door on the cord, or pull the cord around
sharp edges or corners. Do not run the machine over the cord. Keep the cord away from heated
surfaces. To unplug, grasp the plug, not the cord.
•Do not handle the plug, the cord or the machine with wet hands.
•Extension cords must be 12/3 and no longer than 50 feet. Replace the cord or unplug immediately
if the ground prong becomes damaged.
•Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint,
hair, and anything that may reduce air flow.
•Keep loose clothing, hair, fingers, and all parts of body away from openings and moving parts.
•Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes, or
any health endangering dusts. Do not use to pick up flammable or combustible liquids such as
gasoline or use in areas where they may be present.
•Turn off all controls before unplugging.
•Connect to a properly grounded outlet only.

INSPECTION:
Carefully unpack and inspect your FLOOD KING for shipping damage. Each machine is tested and
inspected before shipping. Any damage incurred during shipping is the responsibility of the carrier. You
should notify the carrier immediately if you notice damage to the box or to the machine or parts.
MAINTENANCE:
Prior to each job, inspect the recovery tank pre-filters, the stainless steel in-line filters, the float, and the
drain hose to make sure every thing is clean and able to function properly. After each job, remove and
clean both the nylon mesh pre-strainer at the vacuum inlet and the stainless steel filters in the bottom of
the recovery tank. Unscrew the clear caps off the in-line filters (located under the recovery tank) and clean
the screens often. Pump damage may occur if the filters become clogged.
Check hose clamps regularly to make sure they are tight. The pump discharges water at high
pressure. If a hose clamp becomes loose, the hose could also come loose, or fall off of the hose barb, and
leak water into the base compartment.
Lubricate the wheels, castors, latches, and quick disconnects with an all purpose silicone spray. The
vacuums and the pumps do not require any scheduled maintenance; however the vacuum motors may
require new brushes after 1000 - 1500 hours. Clean the body with an all purpose detergent, and protect it
with an automobile interior spray protectant.
Record the serial number and model of your new flood extractor here:
Serial Number: __________________ Model: FLOOD KING-240
Purchase Date:_____________
Write the name and phone number of your distributor:
____________________________________________________________________
____________________________________________________________________
be sure to register your purchase to activate your warranty
SAVE THESE INSTRUCTIONS

SET-UP:
Connect the vacuum/recovery hose to the vacuum inlet hose barb on the recovery tank. Connect the
dump hose to the hose fitting on the rear of the machine. Check filters. Put the lid on the
recovery tank. Plug the machine into a grounded outlet.
VACUUM OPERATION:
A switch is provided for each vacuum motor. The machine can operate with either one, or both, vacuum
motors running.
VACUUM SHUT-OFF:
When the recovery tank is full, the float system will shut off power to the vacuum motor(s) to prevent
water from entering the motor(s). The float may not work properly if it is extremely dirty or if there is
foam in the tank. Use a defoamer any time foam is present. Once the tank has emptied sufficiently, the
vacuums will come back on automatically.
PUMP OPERATION:
Always be sure to uncap the pump-out fitting and connect the dump hose before turning the pumps on.
Failure to do so may result in blown hoses or loose fittings; water will damage motors and switches.
The two diaphram pumps on your Flood King work together. When you turn the pump switch on, both
pumps will run, and they will continue to run until you turn them off. Do not let the pumps run dry for
extended periods of time.
Recovery Tank
Access Lid
Recovery Hose
Connection Point
Latch
Castor 10” Wheel
Drain Hose
& Pump Out Hose
Connection
(on rear)
Switches
Vacuum
Cover

5
20
19
22
21
24
43
28
36
52
53
50
43
33
45
47
43
46
45
32
34
43
43
47
73
46B
46A
46A 46B
25
51
17
18
2
43
49
48
54
43
43
57
56
55
50
70
72
58
54A
71
18
67
1
4
62
61
60
5
3
11
11
16
14
12
30
64
25
60
65
4A
4B
5A
9
10
64
63
62
FLOOD KING 240V

46B 1466 Hose barb/elbow
47 1468 Hose, 1.9 cm X 7.6 cm
48 152 “T” brass
49 372 Elbow, brass, 45 degree
50 928 Louver, 3”, includesscrews
51 2019 Power cord, 7.5 m
52 237 Cap,withchain
53 379 Hosefitting
54 152A Washer,flat,S/S
54A 237A Washer,rubber
55 910-24-50 Axle,62.23cmlong
56 27A Axlecap
57 2084 Wheel,25.4cm
58 905 Castor. 10 cm
59 SUBBS-13 Base, black
60 408D Vacuummotor, 3-stage
61 MA-9 Manifold,vacuum
62 1056 Screen,wirefilter,vacinlet
64 1477 Gasket,undervacmanifold
65 FP Cover,overvacuums
67 937 Coupling, PVC
70 801 HingePin
71 2079 Hose,reinforced, 25.4 cm
72 1476 Strap, stop, 43 cm
73 908B Latch and strike
1 2077 Hose Barb, 3.8
2 1463 Eblow,ABS,45 degrees(3)
3 1464 Bushing, 5 cm slip
4SUBVT-25 Tank, recovery
4A 2070B Lid, and ring, 15.25 cm
4B 1129 Gasket, for vacuum lid
5 FP521 Strainer bag, vac inlet
9 1434 Switch plate
10 FP578 Switch, SPST
11 1130 Strap, velcro
12 1518 Hose Clamp
14 1060B Hose, drain
16 1060C Plug, drain hose
17 2068 Float,switch
18 230 Retainer, cord
19 196 Clamp, cable
20 1518 Tie wraps, 12.7 cm
21 1349 Spacer, float
22 290 Washer, flat, rubber
24 1350 Bracket, float mounting
25 2069 Filter, inlet, 60 mesh
28 1168 Nipple, PVC, 1.9 cm X 3.5 cm
32 1468 Hose, 1.9 cm ID X 55.88 cm
33 1468 Hose, 1.9 cm ID X 35.5 cm
34 1468 Hose, 1.9 cm ID X 33 cm
36 378 Hose barb, brass
43 380 Hose clamp
45 2074 Filter, in line, 50 mesh
46 2067B Pump, dump
46A N/A Hose barb. from pump
ItemItem
ItemItem
Item PP
PP
Parar
arar
art Not No
t Not No
t No DescriptionDescription
DescriptionDescription
Description
MISCELLMISCELL
MISCELLMISCELL
MISCELLANEOUS PANEOUS P
ANEOUS PANEOUS P
ANEOUS PARAR
ARAR
ARTSTS
TSTS
TS
919C Vacuum Inlet Hose
717 Hose Cuff, for Vac Hose
956A Drain Hose, 15 m
971 Mesh bag, for hoses
FLOOD KING
PART LIST
240V
ItemItem
ItemItem
Item PP
PP
Parar
arar
art Not No
t Not No
t No DescriptionDescription
DescriptionDescription
Description

SPECIFICATIONS:
One, 7.5 m, 12 gauge, 3-wire with hospital grade plug
13 Amps, total
343 liter
2’ X 25’
Two 3-stage vacuum motors
100 inches/170 cfm
520 AW (in operational range)
Electronic Float / Auto ON/OFF
Two diaphram bilge pumps
One 3/4” X 50’
10.5 GPM
One 80 micron polyester mesh strainer at the water inlet to
the recovery tank
Two 60 mesh S/S filters in recovery tank
Two 50 mesh S/S screens in-line
38.5 Kg
POWER CORD:
POWER CONSUMPTION:
RECOVERY CAPACITY:
VACUUM INTAKE HOSE:
VACUUM MOTOR(s):
WATER LIFT/CFM:
AIR WATTS:
OVERFLOW PROTECTION:
DISCHARGE PUMPS:
DISCHARGE HOSE:
DISCHARGE RATE:
FILTER SYSTEM:
WEIGHT:

425-322-0133 / 800-257-7982 / FAX: [phone]
11015 - 47th Ave. W. / Mukilteo, WA 98275
VISIT US AT: http://www.usproducts.com
