DESCRIPTION PAGE
UIR SERIES - GAS INFRA-RED SALAMANDER BROILER 4
GAS INFRA-RED SALAMANDER UIR48 REAR PANEL VIEW 8
GAS INFRA-RED SALAMANDER UIR60 REAR PANEL VIEW 10
GAS INFRA-RED SALAMANDER OPTIONAL INTER-CONNECT GAS KIT 12
REVISION HISTORY 13
UIR SERIES INFRA-RED SALAMANDER BROILER
MODELS: UIR36/36C, UIR48, UIR60

UIR36 UIR36C UIR48 UIR60
1G01377-1-6 Main Top Back 1111
2G01376-1-6 Main Back Center 1111
3G01375-1-6 Main Top Front 1111
4G01391-1-6 Front Brace 1111
4523215 Salamander Rear Panel 1 1
4523912 Salamander Rear Panel S/S - 36 & 60" Models 1 1
62584000 Flue Back 1111
7G01372-1-6 Orifice Fitting Cover 2222
2584100 Side Liner R/H
2584101 Side Liner L/H
G01392-1-91 Main Side R/H
G01392-1-92 Main Side L/H
G01378-01-61 R/H Bottom Assembly
G01378-01-62 L/H Bottom Assembly
11 2540800 Bottom Cover (OPTION) 1
12 G01467-1-5 Angle Bracket (OPTION) 2
2582602 Bracket R/H (OPTION)
2582603 Bracket L/H (OPTION)
14 1347200 Salamander Rack 1111
15 1387200 Protecting Rod 2222
16 1031301 Broiler Rack Roller Pin 4444
17 1031302 Rack Roller Wire Spacer 4444
18 1035400 Small Roller Bearing 4444
19 F76 1/4" - 20 UNC Nut 4444
20 G01244-1 Large Roller Bearing 4444
21 F256 Lockwasher - 3/8” S/S Split 4444
22 G6424 Glider Bolt Hex 3/8 - 16 4444
23 G01247-3 Rear Bushing 4444
24 F78 3/8”-16 Nut - Hex Black 4444
25 1037286 Rack Frame Weld Assy 1111
26 G01860-3-9 Rack Veneer 1111
27 G02251-1 Pressure Test Spigot 1111
28 4517693 Rack Handle Assembly S/S 1111
29 1341905 Spring Support 1111
30 1342596 Rack Frame Assy 1111
31 F40 1/4' - 20 x 3/4” LG.Hex Bolt 4444
32 F111 1/4” Flat Washer 4444
33 1037810 Rear Bushing 4444
34 F76 1/4" - 20 Nut 4444
35 1342001 Upper Arm 2222
36 1031300 Broiler Rock Roller Bushing 4444
37 1342499 Lever Assy 1111
38 9004701 Oven Door Spring Hook 1111
39 1005803 Spring 1111
40 1342198 Handle Assy Nickel Plated 1111
41 4522398 Nameplate - US RANGE 1111
42 1039603 Gray Ball Knob 1111
43 2540700 Grease Tray Front 1111
8
9
10
1
1
1
13
1
ITEM PART NO.
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
DESCRIPTION
11
111
1
QUANTITY
CRITICAL
US RANGE PARTS IDENTIFICATION
GAS INFRA-RED SALAMANDER BROILER UIR SERIES
1
5
11

UIR36 UIR36C UIR48 UIR60
44 2601301 Grease Tray 1111
45 G01917-1 Elbow - 1/8" NPT Street 1111
46 G01435-1 Elbow Flanged 2222
47 G01410-1 Valve Hi-Lo 1/4" NPT to 7/16 CC 2222C
48 G01471-1-8 7/16 Inlet Tubing - Left 1111
49 G01472-1-8 7/16 Inlet Tubing - Right 1111
50 G01473-1-81 7/16 Steel Tubing x 16.312" R/H - Valve to Orifice 1111
51 G01473-1-82 7/16 Steel Tubing x 16.312" L/H - Valve to Orifice 1111
52 G01243-1 Straight Connector Fitting 1/4" NPT X 7/16CC 2222
53 G6809 Valve Pilot 1/4 Tube 2222
54 G01494-16 1/4 Aluminum Tubing x 19” - Pilot 2222
55 4521448 1/2" NPT Tee 1111
56 G01569-1 Reducer Bushing 1/2" To 1/4" NPT 2222
57 G01474-1 Elbow Reducer 1/2" To 1/4" NPT 1111
58 G01412-01-8 Manifold Assy 1111
59 1815602 Pilot Bracket LH/RH 2222
1806601 Natural Gas - IR SAL Pilot Burner
1806602 Propane Gas - IR SAL Pilot Burner
61 4521449 Elbow-Street 1/2" NPT 90 DEG 1111
62 G01411-XX Orifice Fitting Less Orifice Hood 2222
G01411-48 Orifice Fitting C/W #48 Hood (Natural)
G01411-55 Orifice Fitting C/W #55 Hood (Propane)
64 CK117 Burner Assembly 2222
65 G01477-9 Nipple 1/2" NPT x 16" Raw (Top Gas Connection) 1111
2127503 Regulator Nat 6.0IN W/C
2127500 Regulator LP 10IN W/C
67 4512853 Main Front S/S 1111
68 4523213 Lower Front Panel 1
G01384-01-61 Valve Housing R/H Assembly
G01384-01-62 Valve Housing L/H Assembly
70 1819001 Salamander Grease Shield 1111
71 4523228 Salamander Upright Bracket L/H & R/H 22
72 4523229 Upright Side Veneer 22
73 2588601 Strip Filler R/H 1111
74 2588600 Strip Filler L/H 1111
75 G01918-5 Bushing ¾ to 1/2 NPT Brass 1111
76 2612000 Heat Shield Front S/S (Only Used with Range Mount Models) 1111
77 2612100 Heat Shield Bottom S/S (Only Used with Range Mount Models) 1111
78 4523226 Salamander Support L/H 1111
78A 4523227 Salamander Support R/H 1111
84 G01387-02-9 Support Bracket Assembly 2
G01380-2-8 Main Back AZ 1
G01380-2-9 Main Back S/S (OPTION) 1
86 4527469 GIR/UIR Series Salamander Knob Assembly 2222C
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
2
166
63
260
ITEM PART NO. DESCRIPTION
CRITICAL
QUANTITY
222C
222C
111C
85
111169
US RANGE PARTS IDENTIFICATION
GAS INFRA-RED SALAMANDER BROILER UIR SERIES

Notes

ITEM PART NO. DESCRIPTION UIR48
4523896 48" Salamander Rear Panel (Standard) 1
4523913 48" Salamander Rear Panel S/S (OPTION) 1
2 4524043 48" Salamander Centre Support 1
3 4523898 48" Salamander Upright - Left Hand 1
4 4523897 48" Salamander Upright - Right Hand 1
5 4523899 48" Salamander Front Panel 1
6 4524055 48" Salamander Anti Sway Bracket 1
US RANGE PARTS IDENTIFICATION
GAS INFRA-RED SALAMANDER UIR48 REAR PANEL VIEW
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
1

ITEM PART NO. DESCRIPTION UIR60
10 4523282 60" Salamander - High Shelf Support 1
4523265 60" High-Shelf Front Panel W/Salamander LT 1
4523900 60" High-Shelf Front Panel W/Salamander RT 1
4523901 60" High-Shelf Front Panel W/Salamander LT & BG RT 1
12 4523112 Upright - High Shelf 2
4523914 24" High Shelf /Salamander Back Standard 1
4523915 24" High Shelf /Salamander Back S/S (OPTION) 1
14 4523293 24" Shelf 1
US RANGE PARTS IDENTIFICATION
GAS INFRA-RED SALAMANDER UIR60 REAR PANEL VIEW
* NOT ILLUSTRATED
RECOMMENDED STOCK PARTS
11
13

GARLAND PARTS IDENTIFICATION
GAS INFRA-RED SALAMANDER OPTIONAL INTER-CONNECT GAS KIT

REV. # PAGE # ITEM # NOTE DATE
New Book - Model: UIR Series Infra-Red Salamander Broiler May 14/10
