uAvionix pingEFB ADS-B Receiver
QUICK START GUIDE

specications
safety
• The pingEFB ADS-B Receiver adds an additional layer of
situational awareness to aircraft operations in the airspace.
Accordingly, pilots must remain vigilant of surrounding air
trac at all times during ight to ensure safe operation.
• Never operate the software or vehicle in a way that could be
dangerous to you, other people or property.
• It is your responsibility to ensure that you understand and
comply with all local laws and regulations.
Input Voltage/Current 5V / 500mW
Size 34 x 19 x 8 mm
Weight 5 grams
MTL 1090MHz
Dynamic Range
-84 dBm
-81 to 0 dBm
MTL 978MHz
Dynamic Range
-93 dBm
-90 to -3 dBm
Supported Interface Micro-USB

uAvionix pingEFB receives trac information
(ADS-B/ADS-R and TIS-B) on both UAT (978 MHz) and
1090 ES (1090 MHz).
When in proximity to a ground station it also
receives ight information (FIS-B) and additional
trac (TIS-B) over UAT.
Received data is sent to Stratux for use with
compatible EFB applications.
1. Connect
2. Congure
3. Launch
4. Track
Quick Start Guide

Connect 1
Connect pingEFB to your Stratux hardware using a Micro-
USB cable or a Micro-USB OTG adapter.
pingEFB should be mounted with the antenna oriented
vertically.

2
Congure
Connect your EFB device to the Stratux Wi-Fi Network and
enable Ping ADS-B on the settings page.
Open a web browser.
Access the conguration page
by entering the IP address for
your Stratux conguration.
The default is http://192.168.10.1
From the Menu select
Settings
Tap to toggle the Ping ADS-B
option to Enabled.

3
Launch
Launch your Stratux compatible Electronic Flight Bag (EFB)
application.

4
Track
Congure your EFB as necessary receive Stratux data. In most
applications it will be automatically detected.
ADS-B trac and ight information should begin streaming to
the application when in range.
Typical iOS Electronic Flight Bag is shown below with trac.

5
Notes
Reception is dependent on a number of factors including
pingEFB location, orientation and aircraft conguration.
ADS-B ground station reception will usually not be available
until in-ight. Ground stations provide additional trac and
ight information (FIS-B) data.
pingEFB requires Stratux v1.1 or later.
The latest Stratux builds and support are available at:
http://stratux.me
