ubicquia ubihub AP6 User manual

1
© 2021 Ubicquia Inc. | All rights reserved. Patent pending. Public use approved. | 2058 v2 October 2021
Installation Guide
1. Product Overview
1.1 View of UbiHub parts from top
Before installation, please read this
instructional guide completely and save
for future reference.
1.2 View of UbiHub parts from bottom

2
© 2021 Ubicquia Inc. | All rights reserved. Patent pending. Public use approved. | 2058 v2 October 2021
1.3 Package Contents
•UbiHub Unit (with open cap
attached)
•Mounting Clamp
•Mounting Clamp Inserts (additional)
•Dual-Camera
•Grounding Cable
1.4 Required Tools (Not Included)
•3/16” Hex bit driver / Wrench
•Standard Screwdriver or 5/16”
Socket for grounding screw
•Deep drive ½” Socket
•Torque driver (capable of at min
40.in lb)
•Grounding clamp, lug, or extra
length of grounding cable as
needed
•Safety Tether (for ensuring device
safety during installation)
2. Unpacking the UbiHub
2.1 Open the top of the packaging as
indicated on the outside of the box.
Do not remove the UbiHub from
the box at this time.
2.2 Ensure that all items listed in the
package contents (ref 1.2) are
included in the box. If any item is
missing, e-mail support@ubicquia.
com or call 1.954.678.6191
(Monday through Friday 9am to
5pm EST).
2.3 Remove the mounting clamp
from foam insert and unwrap the
protectivelm.Caution:DONOT
remove the UbiHub from the box
yet.
3. Preinstall Clamp
3.2 Mounting Clamp
The mounting clamp has inserts
availabletot1.25”diameter
pole arms.
Without inserts, the mounting
clamptspolesthatare2.3/8”in
diameter.
*Contact Ubicquia if you require a
clamp insert, but did not receive
a set.
3.1 Measure and Preinstall Clamp
Theclamptsa2.3/8”(60.3
mm) diameter pole, with
optional replacement inserts
to accommodate for a smaller
pole diameter, and can be
adjusted between 6.04” -
10.57” (153.5-268.6 mm) for
horizontal travel along the
device, and between 1 7/8” - 3
7/8” (49-99mm) vertical travel
to accommodate pole distance.

3
© 2021 Ubicquia Inc. | All rights reserved. Patent pending. Public use approved. | 2058 v2 October 2021
3.4 Use a 3/16” Hex bit driver to
unscrew and remove the clamp
adjustment cover from the clamp.
Discard as this piece is no longer
needed.
3.5 Align the shuttles on the top of the
clamp with the rail openings on
the bottom of the UbiHub housing
while still in the box. There is a
single orientation for assembly.
3.6 Slide the clamp along the housing
rails and hand-tighten into position
for now.
NOTE: If clamp placement was
premeasured, or if installing
multiple units on the same
luminaire type, set the clamp
position using the reference
dimensions on both the housing
and clamp, then tighten all
adjustment bolts to 40 in-lbs
torque.
3.3 OPTIONAL: Measure the distance
from the NEMA socket to the
closest point on the pole that will
allow for the Ubihub to be seated
level to the luminaire.
NOTE: Record position
horizontal and vertical
dimensions on UbiHub and
clamp for later use in multiple
installations of the same
luminaire type.

4
© 2021 Ubicquia Inc. | All rights reserved. Patent pending. Public use approved. | 2058 v2 October 2021
3.7 Open the clamp with the swivel
locking nut up out of the way. If
your pole arm is smaller than 2.3/8”
(60.3 mm), you will install a clamp
insert set into the clamp. Clamp
inserts are available in 1.25” sizes,
and come as a set of two.
The inserts are clearly marked with
a numeral 1 or 2, denoting the
top clamp insert from the bottom
clamp insert. The inserts should
be placed into the corresponding
location in the clamp, ensuring a
completet.Theyshouldnotbe
loose after install. Move on when
theclampinsertsarermlyin
place.
4.1 Attach the provided grounding
cable to the UbiHub housing
using the grounding screw with
a standard screwdriver or 5/16”
socket. Note the location for the
safety tether attachment.
WARNING:
Ubicquia requires the
attachment of a safety tether to
both the device and the lift to
prevent accidental drops.
ALWAYS wear safety gear
such as gloves and grounding
protection during installation.
4. Preinstall Grounding Cable

5
© 2021 Ubicquia Inc. | All rights reserved. Patent pending. Public use approved. | 2058 v2 October 2021
5. Mounting the Unit
5.2 Only for APAI units: Place the
attached camera assembly on top
of the UbiHub unit in the box and
then gently remove the unit from
the box.
NOTE: The camera is shipped
wrapped in protective
packaging and connected to
the unit. Do not remove the
protective packaging until
instructed to.
CAUTION: Be careful not to
swing, slam, or knock the
camera during installation. The
camera should be placed atop
the unit during install, whenever
possible.
5.1 Remove the UbiHub from the
shippingboxbyrstgentlylifting
the unit with the attached camera
placed on top. The camera is
shipped pre-installed and connected
totheunitbyacable.Caution:Take
care not to swing, slam, or knock
the camera during installation. The
camera should be placed atop
the unit during install, whenever
possible.
Make sure clamp is open with the
swivel locking nut up out of the way
before installing on the luminaire.
5.3 Attach a safety tether to both
UbiHub and the lift using the tether
ring on the UbiHub
If your luminaire has a photocell
installed, remove it and set it aside
for later.
6. Prep for Installation
6.1 Verify the NEMA socket on
the luminaire is oriented in the
correct direction. The North
indication on the NEMA (N >)
should face away from the pole
of the luminaire.
If your NEMA socket orientation
does not match the image
above, then you will need to
adjust the NEMA to match.
6.2 Follow the instructions below
that match the type of NEMA
socket on the luminaire to adjust
theorientation:
NOTE: The UbiHub works with
3, 5, and 7 pin NEMA options.

6
© 2021 Ubicquia Inc. | All rights reserved. Patent pending. Public use approved. | 2058 v2 October 2021
6.3 Line up the NEMA plug on the
UbiHub with the NEMA socket
on the luminaire. The UbiHub
shouldbeslightlyo-angleof
the luminaire by 15 degrees once
inserted.
NOTE: Make sure the NEMA
plug and NEMA socket remain
parallel during installation.
NOTE:CREExtures/NEMAwill
need to be locked in
6.4 Once plugged, rotate the UbiHub
towards the pole to lock the NEMA
connecter in place. Stop once the
clamp is aligned with the pole.
6.6 Adjust the clamp vertically as
necessary to ensure the device
is parallel with the bottom of the
luminaire to ensure there is no
undue stress or strain on the NEMA
socket.
6.5 Close the clamp around the
pole by rotating the clamp latch
upwards and securing with the
swivel locking nut. Use 1/2”
socket to tighten the locking nut
to 40 in-lbs torque.
B. Pull the inside (grey) section of
the NEMA connector out slightly
and twist until the N > is facing in
the correct direction (away from the
luminaire pole).
A. Use a screwdriver to remove the
two screws. Unscrew the NEMA
connector and lift then turn the
NEMA connector until the N > is
facing in the correct direction (away
from the luminaire pole).

7
© 2021 Ubicquia Inc. | All rights reserved. Patent pending. Public use approved. | 2058 v2 October 2021
6.7 A. Once unit is leveled, tighten
the vertical adjustment screws to
40 in-lbs torque using the 3/16”
Hex bit driver.
B. Then tighten the horizontal
adjustment screws to 40 in-lbs
torque using the 3/16” Hex bit
driver.
7.1 The installer will need to select
which grounding option to use
based on local regulations and
guidelines, as well as selecting the
correct grounding clamp based on
arm type, diameter, etc.
STOP! Ensure UbiHub is
connected, grounded, and
securedrmlyinplacebefore
moving on.
7. Grounding Cable Installation
6.8 Remove tether from unit.
NOTE: Remove all protective
packaging material from the
camera prior to installation.
6.10 Tighten the camera top screw to
15 in-lbs torque using the 3/16”
Hex bit driver.
CAUTION: The unit must
be grounded in accordance
with the local codes or
regulationsdenedbythelocal
inspector. The surface where
the grounding clamp will be
installed must be prepared to
ensure metal to metal contact.
6.9 Place the UbiHub APAI camera
over the vertical adjustment
bolts on the mounting clamp
by toeing in the bottom and
rotating upward into place.
Ensure the camera cable is
not crimped or pinched while
installing onto the clamp.

8
© 2021 Ubicquia Inc. | All rights reserved. Patent pending. Public use approved. | 2058 v2 October 2021
8.1 Remove the open cap by twisting
counterclockwise and pull out.
CAUTION: Double check the
mounting bracket is snug and
secure and ensure the blue
lmshavebeenremovedfrom
the camera lenses and top light
sensor.
8. Installing Photocell (Optional)
8.3 Installation of the UbiHub is now
complete. Make sure UbiHub and
all elements are connected and
securedrmlyinplace.
8.2 Insert the photocell into the NEMA
connector on the top of the UbiHub
and twist clockwise until locked in
place.
CAUTION: The UbiHub
does not need a photocell to
function, but should always
have something installed in
the NEMA. Never leave the top
NEMA socket open.
If installing a lighting controller, follow
steps 8.1 and 8.2.

9
Support and Technical Specications:
ModelAP6:UBH-H-WI
ModelAPAI:UBH-H-AI
FCCID:2AECKUBH01
ContainsFCCID:XMR201903EG25G
ContainsFCCID:XMR201807EP06A
UBIHUB TYPICAL SPECIFICATIONS
Power
Operating Temperature: -40° C to 50° C
Input Voltage: 100-480 VAC
Max Current: 1.5A
Max Power: 95W
Frequency: 50/60 Hz
Power Metering ANSI C12.20, class 0.5
Max Load Power 1200W
Product Characteristics
Weight 4.5kg / 9.92 lb
Dimensions 386mm x 208mm x 70mm
Warranty 5 Years
Certications
Safety ETL US
UL 62368
FCC Part 15 Subpart C,
Part 15 Subpart B, Class B
Part 15 Subpart E
Ingress Level IP65
Impact Rating IK07
Vibration ANSI C136.31
Installation Characteristics
Mounting Cobra head luminaire mount
2 3/8 inch pole
Cobra head luminaire mount
1.25 inch pole
Operating Humidity Up to 90%
Wind Survivability Up to 241km/h (150 mi/h)
Altitude Max 2000 m
FCC statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
thefollowingtwoconditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference
that may cause undesired operation.
ChangesormodicationsnotexpresslyapprovedbyUbicquia,Inc.could
void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and , if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turningtheequipmentoandon,theuserisencouragedtotrytocorrect
theinterferencebyoneormoreofthefollowingmeasures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthatto
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
RF
Antenna Type Passive antennas
4-in-1MIMO,exiblePCBmonopole
type antenna optimized for WiFi 6
frequencies
Antenna Gain Up to 6dBi
Peak Transmit Power 2.4GHz:26dBm
(Tx port/chain + 5GHz:26dBm
combining gain) 5GHz:26dBm
Frequency bands ISM (2.4-2.484GHz)
U-NII-1 (5.15-5.25GHz)
U-NII-2A (5.25-5.35GHz)
U-NII-2C (5.47-5.725GHz)
U-NII-3 (5.725-5.895GHz)
LTE Module Options supported

© 2021 Ubicquia Inc. | All rights reserved. Patent pending. Public use approved. | 2058 v2 October 2021
www.ubicquia.com
Safety Statements and Warnings
This product has been ETL listed and complies with U.S. product safety
standards.
WARNING statements describe conditions that may lead to personnel
injury including potentially fatal injuries if the device is not properly
installed and warnings are not properly followed.
CAUTION statements describe conditions that may lead to equipment
damage.
• Electricalshockcancauseseriousorfatalinjury.Onlyqualiedpersonnel
should install, maintain or troubleshoot this equipment.
•Installation must be carried out strictly according to the steps in this
manual, including use of relevant tools and equipment as required. For
example:safetygloves,devicetether,warninglabels,ashlamp,helmet,
and/or work clothes, etc.
•In the process of installation, please ensure the weather is suitable for
outdoor high power electrical work. If possible, the installer should avoid
installing in the rain, or allowing the NEMA to get wet.
WARNING
•The product is required to be installed and to be connected to mains
powerbyaskilledorqualiedpersonnelinaccordancewithlocaland
national codes or regulations.
•Suitably rated approved circuit breaker is to be attached during end
installation as per applicable local and national codes or regulations.
•Suitable lightning arrester is intended to be installed during end
installation as per applicable local and national codes or regulations.
WARNING
RF Exposure Compliance - to meet FCC and ISED limits for RF
exposure, this device must be installed to provide a separation distance
greater than 40 cm from all persons during normal operation.
