Ubiquiti ETH-SP User manual

Model: ETH-SP
Quick Start Guide
®

Hardware Overview
Grounding Point
Eth In/Out
ETH IN/OUT Passive, surge-protected
RJ45 Ethernet ports.
Grounding Point The ETH-SP must
be grounded by one of the following
methods:
• Using the included Self-Tapping Screw
to ground the ETH-SP directly to a
grounded metal pole or structure; or

• Using an M5 machine screw and
nut (not included) to attach a drain
wire that is connected to a remote
grounding block or structure.
Package Contents
• ETH-SP
• M5 Self-Tapping Screw
• M5 Serrated Washer
Installation Requirements
Mounting accessories and optional
drain wire are not included.
Pole-Mounting:
• Drill with a 4.5 mm drill bit
• (1) Metal strap or cable tie
Wall-Mounting:
• (2) Screws (≤ 5 mm screw head)
• (1) M5 machine screw and nut
• (1) Drain wire (≤ 16 AWG, ≤ 40 cm)

Connect a Drain Wire (Optional)
If a drain wire is used to properly ground
the ETH-SP, attach it to the Grounding
Point with an M5 machine screw and nut
(not included).
Note: Place the included Serrated
Washer between the screw and
drain wire.

Installation
Install the ETH-SP near an Ethernet
device, either on a pole or a wall.
Follow the appropriate steps for your
installation:
Pole-Mounting
1. Thread a metal strap or cable tie (not
included) through the slot located on
the back of the ETH-SP.

Note: If the Ethernet device is
mounted on the pole with a metal
strap, you may use the same strap
to attach the ETH-SP.
2. Wrap the strap or tie around the pole
and secure it to the pole.

3. Remove the port cover by pressing
on the center and sliding the cover
downward.
Note: If you are using a drain wire
for grounding, proceed to the last
section, Connecting Ethernet.

4. Drill a 4.5 mm pilot hole into the pole
through the center of the Grounding
Point of the ETH-SP.
4.5 mm
Drill Bit

5. Insert the included Self-Tapping Screw
into the Serrated Washer and pilot
hole. Securely fasten the screw to
ensure the Grounding Point is bonded
to the pole.

Wall-Mounting
1. Secure two screws (not included) to
the wall, spaced 38 mm apart.
38 mm
2. Leave a gap of 3 mm from the screw
head to the wall.
≤ 5 mm
3mm

3. With the drain wire already attached,
secure the ETH-SP to the wall by
inserting the screw heads into the
keyhole slots on the back of the
ETH-SP.

Connecting Ethernet
Connect two Ethernet cables to the RJ45
ETH IN/OUT ports. Then connect one of
the cables to the Ethernet device and
the other cable to the LAN.

Specifications
ETH-SP
Dimensions 91 x 61 x 32.5 mm
(3.58 x 2.4 x 1.28")
Weight 80 g
(2.82 oz)
Interface Connections (2) RJ45 Female Connectors
ESD/EMP Protection
Absorbing Transient Current
with Response to Surge Voltage
from 100V/s to 1kV/us
DC Spark-Over Voltage 90V @ 100V/s
Maximum Impulse
Spark-over Voltage 700V @ 1kV/us
Discharge Current 5kA (Maximum)
0.5kA (Normal)
Maximum Insulation
Resistance 1G ohm @ 50V
Maximum Capacitance 1.0 pF @ 1 MHz
Data Line Protection RJ45 10/100/1000 Ethernet
IEEE 802.3af PoE
Support Yes
Shock and Vibration
Certication ETSI300-019-1.4 Standard
Operating
Temperature
-30 to 65° C
(-22 to 149° F)
Operating Humidity 10 to 90% Noncondensing

Safety Notices
1. Read, follow, and keep instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by
the manufacturer.
WARNING: Do not use this
product in a location that can be
submerged by water.
WARNING: Avoid using this
product during an electrical
storm. There may be a remote risk
of electric shock from lightning.
*640-00135-01*
640-00135-01

Electrical Safety Information
1. Compliance is required with respect to voltage,
frequency, and current requirements indicated
on the manufacturer’s label. Connection to a
different power source than those specified
may result in improper operation, damage
to the equipment or pose a fire hazard if the
limitations are not followed.
2. There are no operator serviceable parts inside
this equipment. Service should be provided only
by a qualified service technician.
3. The equipment requires the use of the ground
wire as a part of the safety certification,
modification or misuse can provide a shock
hazard that can result in serious injury or death.
4. Contact a qualified electrician or the
manufacturer if there are questions about the
installation prior to connecting the equipment.
5. Protective bonding must be installed in
accordance with local national wiring rules and
regulations.
Limited Warranty
UBIQUITI NETWORKS, Inc (“UBIQUITI NETWORKS”)
warrants that the product(s) furnished hereunder
(the “Product(s)”) shall be free from defects in
material and workmanship for a period of one

(1) year from the date of shipment by UBIQUITI
NETWORKS under normal use and operation.
UBIQUITI NETWORKS’ sole and exclusive obligation
and liability under the foregoing warranty shall
be for UBIQUITI NETWORKS, at its discretion, to
repair or replace any Product that fails to conform
to the above warranty during the above warranty
period. The expense of removal and reinstallation
of any Product is not included in this warranty. The
warranty period of any repaired or replaced Product
shall not extend beyond its original term.
Warranty Conditions
The above warranty does not apply if the Product:
(I) has been modified and/or altered, or an
addition made thereto, except by Ubiquiti
Networks, or Ubiquiti Networks’ authorized
representatives, or as approved by Ubiquiti
Networks in writing;
(II) has been painted, rebranded or physically
modified in any way;
(III) has been damaged due to errors or defects
in cabling;
(IV) has been subjected to misuse, abuse,
negligence, abnormal physical,
electromagnetic or electrical stress,
including lightning strikes, or accident;
(V) has been damaged or impaired as a result of
using third party firmware;

(VI) has no original Ubiquiti MAC label, or
is missing any other original Ubiquiti
label(s); or
(VII) has not been received by Ubiquiti within 30
days of issuance of the RMA.
In addition, the above warranty shall apply only if:
the product has been properly installed and used at
all times in accordance, and in all material respects,
with the applicable Product documentation; all
Ethernet cabling runs use CAT5 (or above), and for
outdoor installations, shielded Ethernet cabling is
used, and for indoor installations, indoor cabling
requirements are followed.
Returns
No Products will be accepted for replacement
or repair without obtaining a Return Materials
Authorization (RMA) number from UBIQUITI
NETWORKS during the warranty period, and the
Products being received at UBIQUITI NETWORKS’
facility freight prepaid in accordance with the RMA
process of UBIQUITI NETWORKS. Products returned
without an RMA number will not be processed and
will be returned freight collect or subject to disposal.
Information on the RMA process and obtaining an
RMA number can be found at:
www.ubnt.com/support/warranty

Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED
HEREIN, UBIQUITI NETWORKS, ITS AFFILIATES,
AND ITS AND THEIR THIRD PARTY DATA, SERVICE,
SOFTWARE AND HARDWARE PROVIDERS HEREBY
DISCLAIM AND MAKE NO OTHER REPRESENTATION
OR WARRANTY OF ANY KIND, EXPRESS, IMPLIED
OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,
REPRESENTATIONS, GUARANTEES, OR WARRANTIES
OF MERCHANTABILITY, ACCURACY, QUALITY OF
SERVICE OR RESULTS, AVAILABILITY, SATISFACTORY
QUALITY, LACK OF VIRUSES, QUIET ENJOYMENT,
FITNESS FOR A PARTICULAR PURPOSE AND
NON-INFRINGEMENT AND ANY WARRANTIES
ARISING FROM ANY COURSE OF DEALING, USAGE
OR TRADE PRACTICE IN CONNECTION WITH SUCH
PRODUCTS AND SERVICES. BUYER ACKNOWLEDGES
THAT NEITHER UBIQUITI NETWORKS NOR ITS
THIRD PARTY PROVIDERS CONTROL BUYER’S
EQUIPMENT OR THE TRANSFER OF DATA OVER
COMMUNICATIONS FACILITIES, INCLUDING THE
INTERNET, AND THAT THE PRODUCTS AND SERVICES
MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS
INHERENT IN THE USE OF COMMUNICATIONS
FACILITIES. UBIQUITI NETWORKS, ITS AFFILIATES
AND ITS AND THEIR THIRD PARTY PROVIDERS
ARE NOT RESPONSIBLE FOR ANY INTERRUPTIONS,
DELAYS, CANCELLATIONS, DELIVERY FAILURES,
DATA LOSS, CONTENT CORRUPTION, PACKET LOSS,

OR OTHER DAMAGE RESULTING FROM ANY OF THE
FOREGOING. In addition, UBIQUITI NETWORKS does
not warrant that the operation of the Products will
be error-free or that operation will be uninterrupted.
In no event shall UBIQUITI NETWORKS be
responsible for damages or claims of any nature
or description relating to system performance,
including coverage, buyer’s selection of products
(including the Products) for buyer’s application and/
or failure of products (including the Products) to
meet government or regulatory requirements.
Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY LOCAL LAW,
IN NO EVENT WILL UBIQUITI OR ITS SUBSIDIARIES,
AFFILIATES OR SUPPLIERS BE LIABLE FOR DIRECT,
SPECIAL, INCIDENTAL, CONSEQUENTIAL OR OTHER
DAMAGES (INCLUDING LOST PROFIT, LOST DATA,
OR DOWNTIME COSTS), ARISING OUT OF THE USE,
INABILITY TO USE, OR THE RESULTS OF USE OF
THE PRODUCT, WHETHER BASED IN WARRANTY,
CONTRACT, TORT OR OTHER LEGAL THEORY, AND
WHETHER OR NOT ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES.

Note
Some countries, states and provinces do not allow
exclusions of implied warranties or conditions, so
the above exclusion may not apply to you. You
may have other rights that vary from country to
country, state to state, or province to province.
Some countries, states and provinces do not allow
the exclusion or limitation of liability for incidental
or consequential damages, so the above limitation
may not apply to you. EXCEPT TO THE EXTENT
ALLOWED BY LOCAL LAW, THESE WARRANTY TERMS
DO NOT EXCLUDE, RESTRICT OR MODIFY, AND ARE
IN ADDITION TO, THE MANDATORY STATUTORY
RIGHTS APPLICABLE TO THE LICENSE OF ANY
SOFTWARE (EMBEDDED IN THE PRODUCT) TO YOU.
The United Nations Convention on Contracts for the
International Sale of Goods shall not apply to any
transactions regarding the sale of the Products.
Compliance
Industry Canada
This Class B digital apparatus complies with Canada
CAN ICES-3(B)/NMB-3(B).
Cet appareil numérique de la classe B est conforme à
la norme CAN ICES-3(B)/NMB-3(B) Canada.
