Joslyn JSP series Technical Document

Surge Protective Devices
Installation, Operation
and Maintenance Manual
PN 750-0100-001 C00
JSP JSPR
SURGE
PROTECTION
SURGE
PROTECTION
Joslyn
TM TM

2
JOSLYN®JSPTM, JSPR INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Table of Contents
tnbpowersolutions.com/joslynsurge
Guide to Installation and Assistance ............................. 3
Pre-Installation Checklist ..................................... 4
Service Configurations ....................................... 5
Conductor Sizing and Routing .................................. 6
Upstream Overcurrent Protection Device .......................... 7
Mounting................................................. 8
Indoor vs. Outdoor Installation.................................. 8
Conduit Openings .......................................... 8
Electrical Connections ...................................... 10
Connecting Form “C” Dry Contacts ............................. 11
Remote Monitoring ........................................ 11
Verification and Power Up.................................... 12
Troubleshooting ........................................... 13
Installation Assistance ...................................... 13
Standards and Listings...................................... 13
Return and Warranty Procedures............................... 13
Warranty Statement ........................................ 14

3
JOSLYN®JSPTM, JSPR INSTALLATION, OPERATION AND MAINTENANCE MANUAL
W A R N I N G !
THE JSP SERIES WARRANTY IS VOIDED if the unit is damaged as a
result of improper installation or the installer’s failure to verify the
following conditions prior to installation.
W A R N I N G !
HAZARDOUS VOLTAGES PRESENT: Improper installation or
misapplication may result in serious personal injury or damage to the
electrical system. Read the complete installation instructions before
proceeding with installation. Remove all power to the electrical panel
before installing or servicing the SPD.
W A R N I N G !
IMPORTANT SAFETY INSTRUCTIONS: All work must be performed
by licensed and qualified personnel. The electrical system must be
properly grounded in accordance with the U.S. National Electrical
Code, state and local codes or other applicable codes for this SPD to
function properly. This device is suitable for installation where the
available short circuit current is 200,000 rms symmetrical amperes
up to 600VAC or less. For countries outside of the US follow applicable
electrical specifications for the country the unit is being used in.
W A R N I N G !
Check to ensure that a proper bond is installed between neutral and
ground at the transformer upstream from all 3-Phase Wye, 3-Phase
High-Leg Delta or Split-Phase JSP Series device (See NEC Article 250).
If the transformer is not accessible, check the main service
disconnect/panel for the NG bond. Lack of a proper bond will
damage JSP Series and void the warranty.
W A R N I N G !
Do not HIPOT the JSP Series units or the electrical system to which
the JSP Series unit is connected without disconnecting the JSP Series
units conductors including phases, neutral and ground.
Guide to Installation and Assistance Thank you for choosing the Joslyn® JSPTM Series Surge Protective Device (SPD).
We look forward to fulfilling your facilitywide surge protection needs.
Should you have questions about installing the JSP Series please
call Joslyn®Technical Support at 800.238.5000 or 804.236.3300
Monday through Friday, 8:00 a.m. to 5 p.m. (EST). Or, email us at
[email protected].
This manual provides guidelines for the proper installation of the JSP Series
of devices. Proper product selection and compliance with these guidelines
will help your new suppression system provide years of reliable service. If
installers are unsure about the facility electrical configuration or have other
installation-related questions, it is recommended they consult with a master
electrician or other qualified electrical professional.
When shortcuts are taken or installation procedures are not followed, the
JSP Series may become damaged or may not provide adequate protection. It
is extremely important to follow these installation procedures carefully.

4
JOSLYN®JSPTM, JSPR INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Pre-Installation Checklist ✓Confirm that the voltage(s) and service configuration shown on the JSP Series
product label are consistent with the voltage and service configuration of the
facility. A model number is on the right side of the JSP Series unit. Each model
number corresponds to the configurations printed in Table 1:
Example of a SPD model number: JSP(R)160-3Y208-F
1These are the only voltages available on the 60, 80, and 100kA systems.
NOTES:
• xxx denotes surge rating per phase (60, 80, 100, 120, 160, 200, 240, 300, 400)
• JSPR units are only available in 120 and 160kA.
• The power system operation frequency is between 47–63Hz.
Confirm that the environmental conditions are consistent with the
following ranges:
• Ambient Temperatures: Between -40° and +158°F (-40º to 70º C).
• Relative Humidity: Between 5% and 95% non-condensing.
• Altitude: Less than 13,000 feet (4000 m).
MODEL NOMINAL L-N L-L CONFIGURATION
VOLTAGE VOLTAGE VOLTAGE
RANGE RANGE
JSP(R)xxx-1P1201120 108-132 N/A 1-Phase, 2-Wire + Ground
JSP(R)xxx-1P2401240 216-264 N/A 1-Phase, 2-Wire + Ground
JSP(R)xxx-1S2401120/240 108-132 216-204 Split-Phase, 3-Wire + Ground
JSP(R)xxx-3Y2081120/208 108-132 187-229 3-Phase, 4-Wire + Ground
JSP(R)xxx-3Y3801220/380 198-242 342-418 3-Phase, 4-Wire + Ground
JSP(R)xxx-3Y4151240/415 216-264 374-457 3-Phase, 4-Wire + Ground
JSP(R)xxx-3Y4801277/480 249-305 432-528 3-Phase, 4-Wire + Ground
JSP(R)xxx-3H2401120/240 108-132 (A, C) 216-264 3-Phase, High-Leg
187-229 (B) 4-Wire + Ground
JSP(R)xxx-3Y600 347/600 312-382 540-660 3-Phase Wye, 4-Wire + Ground
JSP(R)xxx-3D2401240 N/A 216-264 3-Phase Delta, 3-Wire + Ground
JSP(R)xxx-3D380 380 N/A 342-418 3-Phase Delta, 3-Wire + Ground
JSP(R)xxx-3D480 480 N/A 432-528 3-Phase Delta, 3-Wire + Ground
JSP(R)xxx-3D600 600 N/A 540-660 3-Phase Delta, 3-Wire + Ground
tnbpowersolutions.com/joslynsurge
Table 1: Configuration Table
JSP Series Options
F Transient filter that meets UL 1283 (Not recommended when using telecommunication rectifiers)
B Surge Counter (not available on JSP 60–100kA units or the JSPR series)
S NEMA 4X stainless steel enclosure
M Advanced monitoring (available in 60–100kA units only)
JSP(R) 160 — 3Y 208 — F
Model
kA Rating
Voltage
Configuration
Options
Sample Model Number Scheme

5
JOSLYN®JSPTM, JSPR INSTALLATION, OPERATION AND MAINTENANCE MANUAL
30–200 AMP, 2-POLE 1
CIRCUIT BREAKER
JSP SERIES
L1
L2
G
N
EARTH
GROUND
Xo BOND
CONDUCTORS 2
FURNISHED WITH
JSP SERIES
L1
N
L2
NG
L1
L2
N
G
30–200 AMP, 1-POLE 1
CIRCUIT BREAKER
JSP SERIES
G
N
EARTH
GROUND
Xo BOND
CONDUCTORS 2
FURNISHED WITH
JSP SERIES
L1
L1
N
N
G
NG
L
Figure 2
2-Phase, 3-Wire
Figure 1
1-Phase, 2-Wire
Figure 4
3-Phase Delta, 3-Wire
Figure 3
3-Phase Wye, 4-Wire
30–200 AMP, 3-POLE 1
CIRCUIT BREAKER
JSP SERIES
EARTH
GROUND
Xo BOND
B
N
CA
NG
N
G
CONDUCTORS 2
FURNISHED WITH
JSP SERIES
A
B
C
G
N
ABC
30–200 AMP, 3-POLE 1
CIRCUIT BREAKER
B
CA
NG
JSP SERIES
CONDUCTORS 2
FURNISHED WITH
JSP SERIES
A
B
C
G
ABC
G
EARTH
GROUND
Service Configurations Figures 1–5 show the electrical relationship between JSP Series unit
and these five basic service configurations: 1-Phase, 2-Wire;
2-Phase, 3-Wire; 3-Phase Wye, 4-Wire; 3-Phase Delta, 3-Wire and
3-Phase High-Leg Delta, 4-Wire.
Continued

6
JOSLYN®JSPTM, JSPR INSTALLATION, OPERATION AND MAINTENANCE MANUAL
tnbpowersolutions.com/joslynsurge
CAUTION: The JSP Series unit’s performance will be limited
severely if the conductors are (a) too long, (b) are of too small a wire
gauge, (c) have too many bends or (d) have sharp bends. For optimum
performance never exceed 10' conductor lengths.
The factors listed above should be addressed during the design of an
installation to reserve a suitable place for the JSP Series unit next to its
point of connection to the electrical system. The selected mounting location
should allow for the shortest possible conductor runs and a direct route with
a minimum of bends. If bends are required, they should be sweeping bends.
Do not make sharp 90° bends for appearance purposes because they will
severely decrease the effectiveness of JSP Series unit.
Binding or twisting conductors together using tie-wraps or electrical tape
increases the protection performance of the device.
The conductor length should be as short as possible to ensure the maximum
level of protection. Wires are marked with (Phase A, B, C, Line 1, Line 2,
Neutral or Ground) depending on the model.
Conductor Sizing & Routing
Note: High-Leg Orange must be B Phase
A
30–200 AMP, 3-POLE 1
CIRCUIT BREAKER
AB
BC
C
N
N
G
NG
JSP SERIES
CONDUCTORS 2
FURNISHED WITH
JSP SERIES
A
C
B
G
N
EARTH
GROUND
Xo BOND
1 All JSP Series units can be connected without an
upstream breaker/fuse.
2 JSP 60 through 100kA and all JSPR units are furnished
with #10AWG leads.
Figure 5
3-Phase High-Leg Delta, 4-Wire

7
JOSLYN®JSPTM, JSPR INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Upstream Overcurrent
Protection Device
Joslyn recommends installing the JSP unit by following conductor size for
phase, ground and neutral connections. The conductor length should be as
short as possible to ensure the maximum level of protection.
Table 2: Maximum Recommended Conductor Size
The JSP Series unit is a Type 1 SPD which is suitable for use in both Type 1
and Type 2 SPD applications. The JSP Series unit is a one-port SPD and is
to be connected in parallel with the electrical system. It may be connected
via a circuit breaker, molded case switch, fused switch, or connected directly
to the bus of the panelboard or switchboard it is protecting. If direct bus
connection is used, Joslyn®recommends installing the JSP Series unit behind
a disconnect switch or other disconnecting means for ease of serviceability.
If the SPD is connected to a dedicated OCPD, a 60A breaker is recommended
(30A minimum, 200A maximum).
JSP Models Conductor size
JSP-120 #6AWG
JSP-160 #6AWG
JSP-200 #4AWG
JSP-240 #4AWG
JSP-300 #4AWG
JSP-400 #4AWG
• 60 through 100kA units are shipped with #10AWG leads. Leads should be
shortened during installation in order to minimize conductor length.
• 120 through 400kA units are shipped with compression box lugs.
The set screws on the box lugs should be torqued to 20 in-lbs.
• Terminals are identified with markers (Phase A, B, C, Line 1, Line 2,
Neutral or Ground)
Conductor Sizing & Routing
(JSP)

8
JOSLYN®JSPTM, JSPR INSTALLATION, OPERATION AND MAINTENANCE MANUAL
13"
11"
Mounting
(JSP)
Mounting
(JSPR)
Indoor vs. Outdoor Installations
Mount the JSP to the building structure using construction methods and
hardware appropriate for your site. Install the conduit and pull the conductors
as specified in Table 2.
Mount the JSPR to the building structure using construction methods and
hardware appropriate for your site.
Mount the JSPR into the wall. Electrician can mount to the back wall, if the
back wall is made of structural material such as masonry or plywood. (Drywall
is not a structural material). If back wall is not made of structural material, the
electrician can create brackets to hold the SPD to the adjacent studs.
After the drywall has been installed, install Flush Mounting Plate (FMP) by first
removing the JSPR enclosure lid. Place the FMP over enclosed body. Attached
the FMP to the wall using the enclosed hardware kit. Screw the lid back on to
the enclosure body.
JSPR 120, 160 Weight: 30 lbs. (13.6 kg)
NEMA 4 enclosures are suitable for indoor or outdoor use. NEMA 4X (stainless
steel) enclosures are suitable for corrosive environments as well. For direct
sunlight applications, Joslyn suggests shading the monitoring components.
All conduits and fittings must be rated and properly installed so that the final
installation maintains the NEMA rating.
If desired, punch holes at this time for the conduit or nipple or wait until
the JSP unit is mounted to the building structure. Punch holes only in the
designated areas as shown in the following illustration.
tnbpowersolutions.com/joslynsurge
Conduit Openings
(JSP)

9
JOSLYN®JSPTM, JSPR INSTALLATION, OPERATION AND MAINTENANCE MANUAL
CAUTION: Careful consideration must be made when selecting
an area for conduit entry. There are several components inside the
enclosure that may interfere with the conduit entry path, therefore,
ensure the path is clear of all objects before drilling. Damages caused
by installation errors are not covered under the product warranty.
See Figures 6A and 6B for conduit openings and enclosure dimensions.
Conduit Openings
(continued)
Figure 6A
Conduit Openings and
Enclosure Mounting
Dimensions
(JSP)
Dim JSP 60, 80, 100 JSP 120, 160 JSP 200, 240, 300, 400
H1 6.00 (152.4) 10.00 (254.0) 14.00 (355.6)
H2 6.75 (171.5) 10.75 (273.1) 14.75 (374.7)
H3 7.50 (190.5) 11.50 (292.1) 15.50 (393.7)
W1 6.00 (152.4) 8.00 (203.2) 12.00 (304.8)
W2 4.00 (101.6) 6.00 (152.4) 10.00 (254.0)
D – 6.20 (157.5) 6.20 (157.5)
D1 4.16 (105.7) – –
D2 2.00 (50.8) – –
All measurements in inches (mm)
(W1)
(W2)
(H1)
(H2)
(H3)
(D1) (D2)
3/4" MYERS HUB
ø0.31 (7.87)
JSP 60–100
(W1)
(W2)
(H1)
(H2)
(H3)
ø0.31 (7.87)
(D)
1.36"
(34.5 mm)
3.20"
(83.8 mm)
Allowable Area For Conduit Entry
JSP 120–160
(W1)
(W2)
(H1)
(H2)
(H3)
ø0.31 (7.87)
(D)
Allowable Area For Conduit Entry
1.36"
(34.5 mm)
3.20"
(83.8 mm)
JSP 200–400
DIMENSIONAL SPECIFICATIONS

10
JOSLYN®JSPTM, JSPR INSTALLATION, OPERATION AND MAINTENANCE MANUAL
CAUTION: Prior to installation ensure the system configuration and
voltage is equivalent to the JSP Series unit being installed.
Electrical Connections
Following all applicable National Electrical Code standards as well as state and
local codes, connect phase, neutral* (white wires) and ground (green wires) to
the JSP Series unit.
JSPR units come with 36" of #10AWG conductors. Each phase conductor is
labeled (Phase A, B or C). Ensure that the conductor lengths are kept as short
and straight as possible. On all high-leg delta systems, the high-leg (208V LN)
must be connected to the Phase B of the SPD. (Color coded orange according
to NEC).
*The 3-Wire + Ground Delta JSP Series units do not have a neutral conductor.
All measurements in inches (mm) and pounds (kg)
Figure 6B
Enclosure Mounting Dimensions
(JSPR)
Dim JSPR 120, 160
H1 10.00 (254.0)
H2 10.75 (273.1)
H3 11.50 (292.1)
W1 8.00 (203.2)
W2 6.00 (152.4)
D1 4.20 (106.9)
D2 2.00 (50.8)
Weight 30 (13.6)
tnbpowersolutions.com/joslynsurge
(D1) (D2)
(W1)
(W2)
Ø0.31 (7.87)
3/4"
MYERS
HUB
(H1)
(H2)
(H3)
