Ultra chef UC430SB User manual

ULTRA CHEF
ULTRA CHEF
accessories
Model # UC430SB
OWNER’S MANUAL
ULTRA CHEF
ULTRA CHEF
accessories
ULtRA ChEf
Gas Grill
• IF A REPLACEMENT IS NECESSARY, PLEASE CONTACT EITHER OUR CUSTOMER SERVICE DEPARTMENT OR YOUR LOCAL DEALER.
• THE USE OF UNAUTHORIZED PARTS CAN CREATE UNSAFE CONDITIONS AND ENVIRONMENT.
• FOR OUTDOOR USE ONLY.
• READ THE MANUAL CAREFULLY BEFORE ASSEMBLING AND OPERATING THE APPLIANCE.
• ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDREN AWAY.
• RETAIN THE MANUAL FOR FUTURE REFERENCE.
• REMOVE ANY TRANSIT PROTECTION BEFORE ASSEMBLING AND OPERATING THE APPLIANCE.
• THIS APPLIANCE MUST BE KEPT AWAY FROM INFLAMMABLE MATERIALS.
• PLEASE WEAR PROTECTIVE GLOVES WHEN HANDLING PARTICULARLY HOT COMPONENTS.
• PLEASE READ THE CARE AND WARRANTY INFORMATION CAREFULLY BEFORE USE.
• MOCHT VERVANGING NODIG ZIJN, NEEM a.u.b. ÓF CONTACT OP MET ONZE AFDELING KLANTENSERVICE ÓF MET UW PLAATSELIJKE DEALER.
• GEBRUIK VAN NIET-GEAUTORISEERDE ONDERDELEN KAN LEIDEN TOT ONVEILIGE SITUATIES EN OMGEVING.
• ALEEN VOOR GEBRUIK BUITENSHUIS.
• LEES VÓÓR MONTAGE EN GEBRUIK DE GEBRUIKSAANWIJZING NAUWKEURIG DOOR.
• VRIJ BEREIKBARE ONDERDELEN KUNNEN ERG HEET ZIJN. BUITEN BEREIK VAN JONGE KINDEREN HOUDEN.
• BEWAAR DE GEBRUIKSAANWIJZING OM LATER NA TE KUNNEN SLAAN.
• VERWIJDER ALLE TRANSPORTBESCHERMING VÓÓR MONTAGE EN GEBRUIK VAN DIT TOESTEL.
• DIT TOESTEL MOET UIT DE BUURT VAN ONTVLAMBARE MATERIALEN WORDEN GEHOUDEN.
• DRAAG a.u.b. BESCHERMENDE HANDSCHOENEN, IN HET BIJZONDER BIJ HET HANTEREN VAN HETE ONDERDELEN.
• LEES a.u.b. VÓÓR GEBRUIK DE GEBRUIKS- EN GARANTIE-INFORMATIE ZORGVULDIG DOOR.
• WENDEN SIE SICH AN UNSEREN KUNDENDIENST ODER IHREN LOKALEN HÄNDLER, UM INFORMATIONEN ZUR BESTELLUNG VON
ERSATZ TEILEN ZU ERHALTEN.
• DIE VERWENDUNG VON NICHT AUTORISIERTEN TEILEN KANN ZUR ENTSTEHUNG GEFÄHRLICHER BEDINGUNGEN UND UMGEBUNGEN FÜHREN.
• NUR FÜR DEN GEBRAUCH IM FREIEN.
• LESEN SIE DIESES HANDBUCH VOLLSTÄNDIG DURCH, BEVOR SIE DAS GERÄT MONTIEREN UND IN BETRIEB NEHMEN.
• ZUGÄNGLICHE TEILE KÖNNEN SEHR HEISS SEIN. KLEINE KINDER VOM GRILL FERNHALTEN.
• BEWAHREN SIE DIESES HANDBUCH ZUR WEITEREN REFERENZ AUF.
• ENTFERNEN SIE JEGLICHE TRANSPORTVERPACKUNG, BEVOR SIE DAS GERÄT MONTIEREN UND IN BETRIEB NEHMEN.
• DIESES GERÄT VON BRENNBAREN MATERIALIEN FERNHALTEN. BEIM UMGANG MIT BESONDERS HEISSEN KOMPONENTEN SOLLTEN
SCHUT ZHANDSCHUHE GETRAGEN WERDEN.

2
Technicalinformation
ModelUC430SBPSS
ApplianceCategoryI3+(28‐30/37)I3B/P(30)

Countries
BE,CH,CYCZ,ES,FR,GB,GR,HU,IE,IT,LT,LU,
LV,PT,SK,SI
BG,CY,CZ,DK,EE,FI,HR,HU,
IS,IT,LT,LU,MT,NL,NO,RO,
SE,SI,SK,TR
TypeofgasG30G31G30/G31
GasPressure20‐30mbar37mbar30mbar
TotalHeatInput(Hs)15kW
(1086.60g/h)
15kW
(1072.05g/h)
15kW
(1086.60g/h)
main0.97mm0.97mm0.97mmInjector
side0.89mm0.89mm0.89mm
SerialNo:
NapoleonApplianceCorporation,214BayviewDrive,Barrie,ON,CanadaL4N4Y8
0063/10


Identificationcode:0063BU7081
(*Injectorsizemarkedclearlyontheburnervalve)

IMPORTANT:
Readthefollowinginstructionscarefullyandbesureyourbarbecueisproperlyinstalled,assembledandcared
for.Failuretofollowtheseinstructionsmayresultinseriousbodilyinjuryand/orpropertydamage.

Ifyouhaveanyquestionsconcerningassemblyoroperation,consultyourdealerorLPGGasCompany.

Neverstoreasparecylinderunderthebarbecueshelvesorinsidethetrolleyhousing.AnyLPGcylindernot
attachedtotheBBQforuseshouldbestoredoutdoorsandwellawayfromtheappliance.


*Thisapplianceisnotintendedtouseonrecreationalvehiclesoramarineenvironment.
*Donotputgascylinderinsidethecabinetforusing.
*Themaximumloadingweightforthesideburnerandsidetableis20pounds(9kgs).Pleasedonotplace
anythingmorethan20pounds(9kgs)onthesideburnerorsidetable.




3

CLEARANCETOCOMBUSTIBLES
Alwaysmaintain915mmminimumclearancetocombustiblematerialsattherearandsidesoftheBBQ.

DonotusethisBBQunderoverheadcombustiblesurfaces

4
PartsDiagram

5
PartsList

6
*1.
*2.
Liftleftcartpanel(8)ontoleftsideofbottompanel.Securecartpanelandbottompanel
usingthreeM6X10screws(11).
Attachlockingcasters(14)andunlockingcaters(15)tofeetofbottompanel(13).
Unlockingcastersinfrontsideandlockingcastersinbackside.Securecasters
usingfourM6X10screws(11)foreachcaster.Tightenusingaspanner.

7
*3.
*4.
Liftrightcartpanel(12)ontorightsideofbottompanel.
SecurecartpanelandbottomusingthreeM6X10screws(11).
Putrearpanel(10)betweenrightcartpanelandleftcartpanelfrombackofthe
cart.SecurerearpanelusingtwoM6X10screws(11)oneachsideoflegs.

8
*5.
*6.
Assembledoorbrace(9)onfronttopofcart.Securebraceandcartpanelsusingtwo
M6X10screws(11)oneachsideoflegs.
Assembleleftandrightdoor(21,22).

9
Carefullylowertheheadunit(6)ontothecartbetweenthetwobraces.Alignthetwo
holesoneachsideofthegrillheadwiththetwoholesoneachbraceusingtwoM6X10
screws(11)oneachsideofcartbrace.
Attachtheleftfrontshelfpanel(5)totheleftshelf(4)withM6X10screws(11)
*7.
*8.
Thissteprequirestwopeopletoliftandpositionheadunit(6)ontocart.

10
Beforeassemblingleftsideshelf(4)andrightsideburnershelf(7),loosenthescrewon
theleftandrightsideplateoftheheadunit(6).Liftleftsideshelfandrightsideburner
shelfandputdownvertically.Sideshelfandsideburnershelflockedontheheadunit.
TightentheloosescrewandsecureusingfourM6X10screws(11)oneachsideshelf.
*9.
Pleasenotethesideshelvesmayappeartobe‘warped’beforetheyareattachedtothehead

unit.Thisisperfectlynormalandwillbecomerigidoncetheyareattached.

11
*10.
*11.
Instructionforfixingcastironburner(18)ontherightsideshelf.
Openthelidonrightsideshelfandputthecastironburner(19)inthehole.Connect
theburnerwiththeconnectornearby.SecuretheburnerusingtwoM4X8screws(17).
Installelectrodeofrightsideburner.
CheckandmakesuretheS/Sgasflowtubeofthecast
ironburnerisclearofdebrisbeforeassembly!
2xM4X6
Connector
Igniterlead
Ignitionwireelectrode

12
*12.
*13.
Placetheflametamers(3)overtheburners.
Placecookinggrates(2)intogrillbottom.
Grateswirerunningfronttobackshouldbefacingupward,sidetoside
wiresdownward.

13
Legwire
*14.
*15.
Toassemblewarmingrack(1),insertlegwiresintoholeson
leftandrightsidepanelofmainbody.
Hangoilbox(19)rightunderholeofoiltray.
Oiltray

14
*16.
*17.
Connectgasregulatorandgashoseassemblytoconnectorofleftsideofgrill
mainbody.Securehoseandconnectorusingspanner.
NOTE:alwayscheckleakagewithsoapywater!
Intheunlikelyeventofthepiezoelectricignitionnotworking,usethemanual
lightingfunctionfoundintheinsideofthedoor.Carefullyplaceamatchintothe
topofthelightingpoleandlightasshown.

15
zDONOTusetherearbackwithallothersburnersatthesametime.
CONNECTINGTHEGASCYLINDERTOTHEAPPLIANCE
Thisapplianceisonlysuitableforusewithlow‐pressurebutane,propaneorLPGmixturegas
andfittedwiththeappropriatelow‐pressureregulatorviaaflexiblehose.Thebarbecueissettooperate‐
*28mbarregulatorwithbutanegas
*37mbarregulatorwithpropanegas
*30mbarora50mbarregulatorwithLPGmixture
DO
zUsespannertotightenallgasfittings.

zCheckgashoseandlineconnectionfordamage,
cutsorcrackseachtimebeforeusingthe
appliance.

zAlwaysleaktestwithsoapywater.

zCheckmainburnersregularlyforinsectnests
suchasspiders,ants,etc.Nestsaredangerous
andneedtobefullycleaned.

zUsetheapplianceinwellventilatedareas.

zCooltheappliancebeforereplacinganylidor
cover.

zAccessiblepartsmaybeveryhot.Alwayskeep
childrenawayfromtheappliance.

zHavethegascylinderfilledbyanauthorized
Propanesupplier.

zAlwayswearprotectivegloveswhenhandling
hotcomponents.

zClosethegascylindervalveaftereachuse.

zCleanthegreasetrayregularly.

zKeeptheapplianceawayfromcombustible
material,gasoline,flameliquidsorvapours.

z“Burningoff”thebarbecueaftereveryuse(for
approx15minutes)willkeepexcessivefood
residuetoaminimum.
DONOT
zLeanoverappliancewhenlighting.
zLeavecookingfoodunattended.
zStorecombustiblematerial,gasolineorflammable
liquidsorvapourswithinvicinityofbarbecue.
zUseappliancewithanycoveron.
zUseplasticorglassutensilsonthebarbecue.
zUsetheapplianceinstrongwinds.
zDismantlecontrolvalves.
zTestforgasleakswithanakedflame.
zStoresparegascylindersinthecabinet.
zLaythegascylinderdown(alwayskeepupright).
zUseapplianceindoors.
zModifytheconstructionsoftheapplianceorthe
sizeofanyburner,injectororificeoranyother
components.
zMovetheapplianceduringuse.
zObstructanyventilationoftheappliance.
zAllowtheflexiblegassupplyhoseoranyelectrical
cordtocomeincontactwithanyheatedsurfaceof
theappliance.
zUsecharcoaloranyothersolidfuelinthis
appliance.
zDisconnectanygasfittingswhiletheapplianceis
inuse.
zUsearustyordentedgascylinderwithadamaged
gasvalve.

16
PleaseconsultyourLPGdealerforinformationregardingasuitableregulatorforthegascylinder.
RegulatorandHose
UseonlyregulatorandhoseapprovedforLPGasattheabovepressures.Thelifeexpectancyofthe
regulatorisestimatedas10years.Itisrecommendedthattheregulatorischangedwithin10yearsof
thedateofmanufacture.
Theuseofwrongregulatororhoseisunsafe;alwayscheckthatyouhavethecorrectitems
beforeoperatingthebarbecue.

Thehoseusedmustconformtotherelevantstandardforthecountryofuse.Thelengthofthehosemustbe
0.7meters(minimum)and1.5meters(maximum).Wornordamagedhosemustbereplaced.Ensurethatthe
hoseisnotobstructed,kinked,orincontactwithanypartofthebarbecueotherthanatitsconnection.Itis
recommendedthatthehoseischangedwithin1yearofthedateofmanufacture.
StorageofAppliance
Storageofanapplianceindoorsisonlypermissibleifthecylinderisdisconnectedandremovedfromthe
appliance.Whentheapplianceisnottobeusedforaperiodoftimeitshouldbestoredinitsoriginal
packagingandstoredinadrydustfreeenvironment.
GasCylinder
Thegascylindershouldnotbedroppedorhandledroughly!Iftheapplianceisnotinuse,thecylindermustbe
disconnected.Replacetheprotectivecaponthecylinderafterdisconnectingthecylinderfromtheappliance.

Cylindersmustbestoredoutdoorsinanuprightpositionandoutofthereachofchildren.Thecylindermust
neverbestoredwheretemperaturescanreachover50°C.Donotstorethecylindernearflames,pilotlights
orothersourcesofignition.DONOTSMOKEwhileusing.

17
ConnectiontoAppliance
Beforeconnection,ensurethatthereisnodebriscaughtintheheadofthegascylinder,regulator,burnerand
burnerparts.

Spidersandinsectscannestwithinandclogtheburnertubes.Acloggedburnercanleadtoafirebeneath
theappliance.

Cleanburnerholeswithaheavy‐dutypipecleaner.

Fitthehosetotheapplianceusingaspannertotightenitontotheconnectionthread.Ifthehoseisreplaced
itmustbesecuredtotheapplianceandregulatorconnectionswithhoseclips.Disconnecttheregulatorfrom
thecylinder(accordingtothedirectionssuppliedwiththeregulator)whenthebarbecueisnotinuse.

TheBarbecuemustbeusedinawell‐ventilatedarea.Donotobstructtheflowofcombustionairtothe
burnerwhenthebarbecueisinuse.ONLYUSETHISBARBECUEOUTDOORS.
BEFOREUSECHECKFORLEAKS
Nevercheckforleakswithanakedflame,alwaysuseasoapywatersolution
ToCheckforLeaks
Make2‐3fluidouncesofleakdetectingsolutionbymixingonepartwashingupliquidwith3partswater.
Ensurethecontrolvalveis“OFF”.
ConnecttheregulatortothecylinderandON/OFFvalvetotheburner,ensuretheconnectionsaresecurethen
turnONthegas.
Brushthesoapysolutionontothehoseandalljoints.Ifbubblesappearyouhavealeak,whichmustbe
rectifiedbeforeuse.
Retestafterfixingthefault.TurnOFFthegasatthecylinderaftertesting.
Ifleakageisdetectedandcannotberectified,DOnotattempttocureleakagebutconsultyourgasdealer.




18
LIGHTINGYOURBARBECUE

Thisbarbecueisdesignedforuseoutdoors,awayfromanyflammablematerials.Itisimportantthatthere
arenooverheadobstructionsandthatthereisaminimumdistanceof1mfromthesideorrearofthe
appliance.Itisimportantthattheventilationopeningsoftheappliancearenotobstructed.Thebarbecue
mustbeusedonalevel,stable,non‐flammablesurface.Theapplianceshouldbeprotectedfromdirect
draughtsandshallbepositionedorprotectedagainstdirectpenetrationbyanytricklingwater(e.g.rain).Parts
sealedbythemanufacturerorhisagentmustnotbealteredbytheuser.Nomodificationsshouldbemade
toanypartofthisbarbecueandrepairsandmaintenanceshouldonlybecarriedoutbyaregisteredservice
engineer.
ForSafeUseOfYourGrillAndToAvoidSeriousInjury:
∙DONOTletchildrenoperateorplayneargrill.
∙KEEPgrillareaclearandfreefrommaterialthatburn.
∙DONOTblockholesinbottomorbackofgrill.
∙Checkburnerflamesregularly.
∙Usegrillinwell‐ventilatedspace.NEVERuseinenclosedspacessuchascarport,garage,porch,coveredpatio,or
underanoverheadstructureofanykind.
∙DONOTusecharcoalorceramicbriquettesinagasgrill.(Unlessbriquettesaresuppliedwithyourgrill)
∙USEgrillatleast3ft.fromanywallorsurface.Maintain10ft.clearancetoobjectsthatcancatchfireorsourcesof
ignitionsuchaspilotlightsonwaterheaters,liveelectricalappliances,etc.

∙Apartmentdwellers:
CheckwithmanagementtolearntherequirementsandfirecodesforusinganLPGasGrillinyourapartment
complex.Ifallowed,useoutsideonthegroundfloorwithathree(3)footclearancefromwallsorrails.DONOT
useonorunderbalconies.
∙NEVERattempttolightburnerwithlidclosed.Abuildupofnon‐ignitedgasinsideaclosedgrillishazardous.
∙NEVERoperategrillwithLPTankoutofcorrectpositionspecifiedinassemblyinstructions.

∙AlwayscloseLPTankvalveandremovecouplingnutbeforemovingLPTankfromspecifiedoperationposition.

19
LightingInstructions:
1. Readinstructionbeforelighting.
2. OpenthelidandmakesurealltheknobsareontheOFFposition.
3. Connecttheregulatortothegasbottle.Turnthegassupply“ON”atthecylinder.Checkwiththeuseof
soapywaterforanygasleakagebetweenthebottleandtheregulator.
4. PushdownandturntheknobanticlockwisetoHIGHposition(aclickingsoundisheard).Thusthe
burnercouldbelit.Iftheburnerdoesnotlight,repeatthisprocess.
5. AdjusttheheatbyturningtheknobtotheHigh/Lowposition.
6. Tolightupotherburners,repeatthesameprocessfortheadjacentburnerandcontinueinsequence
untilalltheburnersarelit.
7. ToturnerthebarbecueOFFturnthecylindervalveorregulatorswitchtothe“OFF”positionandthen
turnallofthecontrolknobsontheapplianceclockwisetothe“OFF”position.
1.Neverlightorusethesideburnerwiththesideburnerlidintheclosedposition.
2.Neverattempttothelightthesideburnerwithapotovertheburner.Lightthe
burnerfirst,andthenplacethepotovertheburner.
3.Thesideburnerisdesignedforpotswithadiameterof60‐260mm.
4.Sideburnerlidcannotbeusedasworktable,donotputanythingonthesideburner
lidevenwhenitisnotinuse.
5.Donotusethebackburnerwithotherburnersatthesametime.
Ifanyburnerfailstoignite,turnthecontrolknoboff(clockwise)andalsoturnthecylindervalveoff.Wait
fiveminutesbeforeattemptingtorelightwithignitionsequence.Neverusethesideburnerwiththelidinthe
closedposition.Neverattempttolightthesideburnerwithapotovertheburner.Lighttheburnerfirst,and
thenplacethepotovertheburner.

Beforecookingforthefirsttime,operatethebarbecueforabout15minuteswiththelidclosedandthegas
turnedonHIGH.Thiswill“heatclean”theinternalpartsanddissipateodourfromthepaintedfinish.(The
colourofcookingareamaychangealittle.Thisisnormalanditisthenatureofmaterial)


CleanyourbarbecueaftereachUSE.DONOTuseabrasiveorflammablecleaners,asitwilldamagetheparts
oftheproductandmaystartafire.Cleaninwarmsoapywater.

20
AbnormalOperation
Anyofthefollowingareconsideredtobeabnormaloperationandmayrequireservicing:
‐Yellowtippingoftheburnerflame.
‐Sootingupofgrillplates.
‐Burnersnotignitingproperly.
‐Burnersfailingtoremainalight.
‐Burnersextinguishedbytrolleydoors.
‐Gasvalves,whicharedifficulttoturn.

CLEANINGANDCARE
This  appliance  should  be  checked  and  serviced  by  an authorized  service  person  every  year  to  ensure  theappliance  remains 
in  a  safe  operation  condition. 

Allcleaningandmaintenanceshouldbecarriedoutwhenthebarbecueiscoolandwiththefuel
supplyturnedOFFatthegascylinder.DONOTremovethedriptrayuntiltheBBQhascooled.

GeneralGrillCleaning

● DONOTmistakebrownorblackaccumulationofgreaseandsmokeforpaint.Interiorsofgasgrillsarenot
paintedatthefactory(andshouldNEVERbepainted).Applyastrongsolutionofdetergentandwateror
useagrillcleanerwithscrubbrushoninsidesofgrilllidandbottom.Rinseandallowtocompletelyairdry.
DONOTapplyacausticgrill/ovencleanertopaintedsurfaces.
● Plasticparts:washwithwarmsoapywaterandwipedry.
● DONOTuseabrasivecleaners,degreasersoraconcentratedgrillcleaneronplasticparts.Damagetoand
failureofpartscanresult.
● Porcelainsurfaces:becauseofglass‐likecomposition,mostresiduecanbewipedawaywithbackingsoda/
watersolutionorspeciallyformulatedcleaner.Usenonabrasivesourcingpowderforstubbornstains.
● Paintedsurfaces:washwithmilddetergentornonabrasivecleanerandwarmsoapywater.Wipedrywitha
softnonabrasivecloth.
● Stainlesssteelsurfaces:Tomaintainyourgrill’shighqualityappearance,washwithmilddetergentand
warmsoapywaterandwipedrywithasoftnonabrasiveclothaftereachuse.Backed‐ongreasedeposits
mayrequiretheuseofanabrasiveplasticcleaningpad.
