Ultra start 660 series User manual

WWW.ULTRASTARTERS.COM

FCC/ID Notice

This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause

undesired operation.

CAUTION: Changes or modifications not expressly approved by the part responsible for compliance

void the user’s authority to operate this devise.

INSTALL GUIDE

Technical Support- 866.698.5872

660 Series Advanced 2-Way Remote

Vehicle Security System

Table of Contents Page 2

Components

Wiring Diagram Page 3

Installation Tips Page 4

Pre-Installation Suggestions

Installation Suggestions Page 4

Mounting The Module

Installing The Program Button

Connecting The Starter Disable

Connecting The Dome Light Supervision

Under Hood Connections

Mounting The Siren

Wire Connectors Page 5

13 Pin Main Harness Connector

4 Pin Red Connector- Keyless Entry

4 Pin Additional Sensor Input

2 Pin Starter Disable Connector

Installation Page 6-7

Basic Installation - Quick start

Shock Sensor Programming

Test The System

Programming Page 7-9

Program Overview & System Reset

Program Menu 1 (User Settings)

Program Menu 2 (Alarm Settings)

Operations Page 10

Single & Dual Car Operation

Transmitter Programming

Battery Replacement

Other Features Page 11

System Service Mode

Service Mode- By remote

Diagnostics Page 12

- Control Module - Starter Disable Harness

- One 2way AM Transmitter - 4 pin Aux Sensor Harness

- One AM 1way Transmitter - Multi-Tone Siren

- AM 2way Antenna With Integrated - Window Decal

LEDs and Program/Valet Switch - Installation and Owner Manuals

- 13 Pin Main Harness

- 4 Pin Keyless Entry Harness With Driver’s Door Priority Output

Components

Table of Contents

PAGE 2

SECURITY SYSTEM

INSTALL GUIDE

Green

Red

Blue

Pink

Lock Output

Unlock Output

12vts Low Current

2nd Unlock

(-)500ma

(+)500ma

Programmable Output

Voltage Inverter Output

Sensor Full - Warn

(-)500ma Input

(-) trigger Input

SIDE VIEW

REAR VIEW

**500ma outputs are low current and are designed to activate relays.

Built-in Starter Disable Relay (Normally Connected 87a & 30)

Wiring Diagram

PAGE 3

SECURITY SYSTEM

INSTALL GUIDE

Switched Ignition Ignition Input

(+) Input

(-) Door Input

(-) Input

Negative Door Pin

(+) Door Input

(+) Input

Positive Door Pin

Hood Input

(-) Input

Hood Pin Switch

(+) Siren

3amp

Siren Output (+)

(-) When Armed

500ma

(-) While Armed

Dome Light

Dome Light Output

500ma

(-) Trunk Release (-) Trunk Release

500ma

(+) Park Lights

15amp

Park Lights

Chassis Ground Ground

(-) Input

Constant Power Main Power

(+) Input

Horn/ Channel 5

500ma

Programmable

Channel 4

500ma

Programmable

ACTIVE RF ANTENNA** Status Led’s

Program Button

**The antenna MUST be connected for the system to operate

Green

Purple

Blue

Brown

Orange

Blk/White

Grey

White

Black

Red

Pink

Wht/Blue

Yellow

Green

Red

Black

Sensor Pre - Warn

Sensor Ground

Sensor Power

(-)500ma Input

(-)500ma Output

(+)500ma Output

(-) trigger Input

Ground Output

12volt Output

Auxiliary Sensor Connector This connector can be used to add additional

Alarm Sensors such as Radar, Glass Break or an additional shock sensor for

coverage at the rear of the vehicle.

Recommended Installation Procedures

Mounting the Module

Installing The Antenna

Connecting The Starter Disable

BEFORE STARTING INSTALLATION:

- Discuss the optional system features with the customer.

- Take a few minutes to review the installation and owners manuals.

- Do a walk around the vehicle and check for any damage.

- If installing a LED discuss the placement with customer before installing.

Never mount the module in the engine compartment. Select a location under the dash

to install the main module. Be certain that the module is securely attached and does not

obstruct any serviceable areas. Mount the module so that it cannot be seen if looking

under the dash as it could be easily unplugged by a thief. The module must be free from

all moving parts such as brake, clutch and gas pedals linkages.

The antenna should be mounted in the top center of the windshield with the antenna mast

facing downwards. First ensure that the glass is clean and dry, remove the plastic from the

adhesive tape then press against the glass.

This system contains a built-in Starter disable relay. The brown starter kill wire from

the wire harness bag will connect to the module as normally connected. (87a & 30)

Cut the brown wire in half, then locate the vehicles starter wire. This wire will switch to

12volts in the crank/start position only. Cut this wire in half and confirm that the

vehicle will not start. Connect the brown wires, one to each side of the cut starter wire.

Route the brown wires to the main module and connect.

This output can be used to activate the interior lights upon disarming the alarm, connect

this output to a relay to activate the interior light. The dome light output will stay active for

30 seconds upon disarm.

Recommended Pre-Installation Procedures

Mounting The Siren

Choose a location in the engine compartment that is away from high sources of heat

and direct exposer to water. The siren should be mounted as well as grounded to solid

metal. Run the wiring for the siren so that it can not be seen or reached from below the

vehicle.

PAGE 4

SECURITY SYSTEM

INSTALL GUIDE

Brown (+) Siren Output Positive output for siren*

Pink Channel 4 Output Programmable - See menu 2**

Wht/Blue Channel 5 Output Programmable - See menu 2***

Red Main Power Input Constant 12 Volt input

Black Ground Input System ground input

Grey (-) Trunk Release Negative trunk release. 500ma****

White (+) Park lights Programmable - 10amp Maximum

Orange (-) When Armed Negative output when system is armed****

Blk/White (-) Dome Light Dome light supervision****

Purple (+) Door Input Positive door pin switch input

Green (-) Door Input Negative door pin switch input

Blue (-) Hood Input Negative input from hood pin switch

Yellow Ignition Input Input from vehicles ignition wire

Green Door Lock Programmable - menu 1, setting 3.

Red 12 Volt Output Output for voltage inverter only*****

Blue Door Unlock Programmable - menu 1, setting 3.

Pink Second Unlock Programmable - menu 1, setting 3******

4 Pin Connector Red

4 Pin Connector Blue

4 Pin Connector White

This connector is for the RF antenna. The antenna also contains 2 LEDs and the

Program Button.

Blue Sensor Full Warn Input trigger for addition alarm sensor(s)

Green Sensor Pre Warn Input trigger for addition alarm sensor(s)

Black Ground Output Ground output for addition alarm sensor(s)

Red 12 Volt Output 12 volt output for additional alarm sensor(s)

* This output is designed to operate one siren. If more than one is being added, a relay

must be installed to avoid damaging the module.

**Channel 4 is activated by holding the Star button on the transmitter.

*** Channel 5 must be programmed to activate on the # button. This channel works on

the horn output, if the 5th channel is programmed the horn output will function as

5th Channel.

****500ma outputs are low current and are designed to activate relays.

*****This is a low current 12volt output designed for use with a voltage inverter.

******This output will activate on the second press of unlock within 3 seconds.

14 Pin Connector

PAGE 5

SECURITY SYSTEM

INSTALL GUIDE

2 Pin Connector (Brown wire with female connectors)

Starter Disable harness. See page 4 for installation instructions

14 Pin Power Connector

Step 2- Plug-In The Module

Step 3- Program, Test And Adjust The Shock Sensor

Test The System

When all the connections are done, the control module can be plugged in. Before connecting the

control module, make sure the ignition is in the OFF position. Plug in the 6 pin harness then the 14

pin followed by any other connectors that were used.

Black Ground Input System ground input.

Yellow Ignition Input Input from vehicles ignition wire.

Red Main Power Input Constant power input.

White (+) Park lights Programmable - menu 2, setting 3.

Brown (+) Siren Output Positive output for siren.

Green* (-) Door Input Negative door pin switch input.

Purple* (+) Door Input Positive door pin switch input.

*Test for door pin type (Positive or Negative) then connect the appropriate wire (Green or Purple)

To program the Shock Sensor.

1.Press and hold the Lock and Unlock buttons for 5 seconds.

2.The system will chirp and the park lights will flash three times then stay “ON”.

3.Within 10 seconds impact vehicle in a safe place (i.e. - Window pillar) with amount of force

wanted to activate alarm. The siren will chirp upon learning the impact.

4. The Shock Sensor is now programmed.

5. Press the Unlock button to exit the Program Mode.

To test the Shock Sensor.

1. Press the Lock button once to arm the system.

2. Wait five seconds then impact the vehicle. Lighter impacts to the vehicle should trigger the warn

away (The siren will chirp three times). A harder impact to the vehicle will trigger the full

alarm.(The siren will activate for 60 seconds then turn off).

3. To deactivate the alarm when triggered, press the unlock button twice.

To adjust the Shock Sensor.

1. Repeat the shock sensor learning.

- If the sensor was to sensitive, impact the vehicle with greater force.

- If the sensor was not sensitive enough, impact the vehicle with less force.

*For best results ensure that the Control Module is mounted securely to the vehicle.

1. Open all the vehicles windows.

2. Press the Lock button to arm the system.

3. Wait five seconds (or until the dome light goes out) then reach in through a window and open

the door.

The alarm will then activate (repeat on all the doors).

4. Test the Shock Sensor again and adjust if necessary.

5. Insure that all additional features are working as intended.

6. If necessary proceed to Program Mode to adjust the programmable outputs.

Quick Start Install

Step 1 - Connect All Of the Following Wires

Your Basic Install Is Complete!

PAGE 6

SECURITY SYSTEM

INSTALL GUIDE

Program mode allows you to adjust the settings and options of your system.

Your system has been intelligently designed by installers with years of experience. The system’s

default settings do not require any program changes in most cases. However, this system does

incorporate a highly advanced programming system that includes 2 menus with numerous options

and settings that can be easily adjusted for custom installations and applications.

Entering Program Mode

Changing the Programmable Settings

To Enter Program Mode

1) Make sure ignition is in the off position.

2) Within three seconds turn the key ON - OFF - ON - OFF - ON. Leave Key ON.

3) Press and release the Program Button one time.

4) Park lights will come and the siren will chirp to confirm entering Program Mode.

5) Select Desired Program Menu by the following:

Press Button #1 Lock User Options Page 8.

Press Button #2 Unlock Alarm Settings Page 9.

6) The selected mode will be confirmed by a siren chirp and one park light flash.

7) The Program Menu may be changed at any time by pressing the transmitter buttons as

above, this allows the installer to change a setting from one menu, then quickly jump to

another menu and change another setting without exiting Program Mode.

8) Program Mode will be exited if there is no activity for 30 second or if the key is turned to the

“Off” position. This will be confirmed by one siren chirp and park light flash.

Note: If unit does not enter Program Mode, turn ignition off and repeat steps 1-4.

** The ignition wire(Yellow) MUST be connected to the vehicle’s ignition wire. If it is not

connected it will not be possible to enter the Program Modes.

To Select and Change A Program Setting:

1) Enter Program Mode.

2) Select the desired Program Menu. (See pages 8&9)

3) Press & release the Program Button the correct number of times to select the desired

Program Setting(as listed on pages (8&9).The park lights will flash and the siren will chirp to

indicate the current setting that is selected.

4) Press and hold the Program Button until the parking lights / siren confirm the selected setting.

The park lights will flash and the siren will chirp to indicate the option selected within the setting.

5) Turn the ignition key “Off” to exit Program Mode.

SYSTEM RESET

STEP 1 - Within three seconds turn the key ON-OFF-ON-OFF-ON (Leave the Key ON).

STEP 2 - Press and release the Program Button.

STEP 3 - Park Lights will come ON

STEP 4 - Press the Program Button a second time and hold for 8 seconds until the park lights

flash 3 times and siren chirps 3 times.

System is now re-set to factory defaults.

NOTE: Reset to defaults does not delete the transmitters from memory.

Programming Overview

PAGE 7

SECURITY SYSTEM

INSTALL GUIDE

Setting 1- Ignition Auto Lock

Menu 1 - User Settings

Setting 2- Horn Honk Settings

Setting 3- Door Lock Options

Setting 4 -Sensor - Enable / Disable

Setting 5 - Passive / Active Arming

Setting 6 - Active / Passive Locks

1 Double Pulse Unlock 1 Flash Single .75 second lock and double unlock pulse

2 3 Second Lock & Unlock 2 Flashes 3 second pulses for lock & unlock

*3 0.75 Second Pulses 3 Flashes 0.75 second pulses for lock and unlock

1 Passive Arming 1 Flash Auto Arms 30 seconds after last door is closed

2 Active Arming With Rearm 2 Flashes Unlock is pressed and no door is within 30 sec.

* 3 Active Arming 3 Flashes Alarm arm by remote transmitter only.

1 Sensors Disabled 1 Flash Shock sensor and Aux. Sensor disabled

* 2 Sensors Enabled 2 Flashes Shock Sensor and Aux. sensor enabled.

1 Active Locking 1 Flash Doors do not auto-lock with passive arming

*2 Passive Locks 2 Flashes Doors Auto-Lock with passive arming.

1 Ignition Lock & Unlock Enabled 1 Light Flash Doors Lock/Unlock when the key is turned On/Off

2 Ignition Lock Only 2 Light Flashes Doors Lock when ignition key is turned ON only

*3 Ignition Auto Lock Disabled 3 Light Flashes Doors do not Lock or Unlock with Ignition key

1 Lock & Unlock chirps Disabled 1 Flash A audible chirp for Panic Mode only

*2 Chirps Enabled 3 Flashes Chirp indication for all functions

Press the Program Switch 1 time to select setting 1 (This will be confirmed by 1 LED flashes)

Press and hold the Program Switch until you receive the appropriate # of park light flashes and/or siren chirps.

Release the Program Switch. Press the Program momentarily to move to next program step or repeat to change selection.

Press the Program Switch 2 times to select setting 2 (This will be confirmed by 2 LED flashes)

Press and hold the Program Switch until you receive the appropriate # of park light flashes and/or siren chirps.

Release the Program Switch. Press the Program momentarily to move to next program step or repeat to change selection.

Press the Program Switch 3 times to select setting 3 (This will be confirmed by 3 LED flashes)

Press and hold the Program Switch until you receive the appropriate # of park light flashes and/or siren chirps.

Release the Program Switch. Press the Program momentarily to move to next program step or repeat to change selection.

Press the Program Switch 4 times to select setting 4 (This will be confirmed by 4 LED flashes)

Press and hold the Program Switch until you receive the appropriate # of park light flashes and/or siren chirps.

Release the Program Switch. Press the Program momentarily to move to next program step or repeat to change selection.

Press the Program Switch 5 times to select setting 5 (This will be confirmed by 5 LED flashes)

Press and hold the Program Switch until you receive the appropriate # of park light flashes and/or siren chirps.

Release the Program Switch. Press the Program momentarily to move to next program step or repeat to change selection.

Press the Program Switch 6 times to select setting 6 (This will be confirmed by 6 LED flashes)

Press and hold the Program Switch until you receive the appropriate # of park light flashes and/or siren chirps.

Release the Program Switch. Press the Program momentarily to move to next program step or repeat to change selection.

PAGE 8

SECURITY SYSTEM

INSTALL GUIDE

Setting 1 - Car Finder/ 5th Channel

Menu 2- Alarm Settings

Setting 2 - Secure Program Mode

Setting 3 - Park Light Output

Setting 4 - Horn Honk Timing

Setting 5 - 4th Channel Settings

Setting 6 - Car Jack Mode

Setting 7 - Horn/ 5th Channel

1 Car Finder OFF 1 Light Flash Car Finder Mode Disabled

*2 Car Finder ON 2 Light Flashes Car Finder Mode activated when # button is held.

**To operate the 5th channel on button #4, setting 7 must be programmed for 5th channel output.

1 Parking Lights on Disarm 1 Flash Park Lights on for 30 seconds on disarm

2 Negative Park Light 2 Flashes Switches Park Light and the Trunk Release outputs

3* Normal Parking Lights 3 Flashes 2 Park Light Flashes on disarm

1 5ms Pulsed Output 1 Flash Short (Quiet) Pulses

2 20ms Pulsed Output 2 Flashes Long (Loud) Pulses

*3 10ms Pulsed Output 3 Flashes Normal (Medium) Pulses

1 Secure Program Active 1 Flash Ignition “ON” and Program switch held for 15 seconds

2* Normal Program Active 2 Flashes Ignition “ON” and Program switch held for 5 seconds
