OPERATION INSTRUCTIONS
INTRODUCTION
CONGRATULATIONS on your choice of a Super Rage™ Alarm & Remote Engine Starter by Crimestopper
Security Products Inc. This booklet contains the information necessary for operating your system. If any
questions arise, contact your installation dealer or Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e. Power,
Ground, Lights, Siren, etc.
-OPTIONAL: Optional features are connected only if desired or agreed upon by the installing dealer i.e. Door
Locks, Horn Honk, Dome light illumination, Starter Kill, L.E.D., Trunk Pop, etc. These features may require
additional parts and labor charges. Consult with your installer about these features before installation.
CONTACT INFORMATION: This device complies with FCC Rules part 15. Operation is subjec
t
to the following two conditions: 1) This device may not cause
interference, and (2) this device must accept any interference tha
t
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or T
V
interference caused by unauthorized modification to this
equipment. Such modification could void the user's authority to
operate the equipment.
TECHNICAL SUPPORT (800)-998-6880
Monday - Friday 8:00am - 4:30pm Pacific
Website: www.crimestopper.com
E-mail: [email protected]
CRIMESTOPPER
SECURITY PRODUCTS, INC.
1770 S. TAPO STREET
SIMI VALLEY, CA. 93063 REV. A 9.2003

TABLE OF CONTENTS
Operation Cautions & Warnings……..………..…………………………………………………………….………2
Operating Instructions - Alarm……………………………………………………….………..……………..……..3-6
LED Diagnostics………………..…………………………………………………………………….………..…..….6
Remote Engine Control………………………...…………………………………………………….………...…..6-10
Optional Turbo Timer Mode……………………...…………………………………………………………..…..….11
Anti-Carjack Protection...……………………………………….………….……..…………...…………..……...…12
Transmitter Programming……………………………….……………………………………………..………….…13
2 Vehicle Operation……...………………………….……………………………….………….……………...……14
Troubleshooting: “Before you call section”……………………………………………………………………..….15
OPERATION CAUTIONS & WARNINGS
CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident
resulting from the use of this equipment. This system is designed to be professionally installed into a car or
vehicle in good running order. Items, such as parking brake, door switches, and all engine safety features,
must be in perfect working condition.
DAMAGE resulting from misuse or negligence is NOT covered under warranty and will be subject to
repair and / or replacement charges.
IT IS ABSOLUTELY THE OWNER’S SOLE RESPONSIBILITY TO: A) Understand the operation of this
system and its safety features. B) Check for proper operation of these safety features prior to accepting
delivery of the vehicle from the installation facility. C) Check and maintain the condition of the vehicle and all
items relative to the proper operation of this system and its safety features.
DO NOT remote start the vehicle in a closed garage. Make sure that the vehicle is outdoors, a garage door
is open, or there is adequate exhaust ventilation. Failure to observe this rule could result in injury or death
from poisonous Carbon Monoxide fumes. This is especially important when using the Timed Self-Start feature
of the unit 2

OPERATING INSTRUCTIONS - ALARM
Active Arming / Locking:
Press and release button #1 (Lock symbol) on the transmitter. The
System will arm and confirm with one siren chirp, one light flash, and
the LED will begin to flash. Power locks will lock (if equipped).
Starter disable circuit will turn on. After a short delay to allow the
vehicle and electronics to settle, the system will be completely
armed.
#3
#1
CS-2011RS TRANSMITTER BUTTONS
#2
#4
START
ARM/
TRUNK
REMOTE
START
UNLOCK
2-CAR
LOCK
DISARM
SEE
PG. 14
Disarming: / Unlocking
Press and release button #2 (Unlock symbol) on the transmitter.
System will disarm and confirm with two siren chirps, two light
flashes, and the LED will turn off. Power locks will Unlock and
Interior Dome light will turn on (if installed with these optional
features)
Disarming While Tripped (Triggered):
Disarming the System while it is triggering requires TWO presses of the #2 Unlock Button. The first press of
Button #2 Resets the alarm cycle only (system still armed) while a second press will disarm/unlock the system.
Silent Arming/Disarming (On demand):
To Arm or Disarm the system without siren chirps, press and release both Buttons #2 (Unlock) and #4 (Start)
at the same time. System will Arm or Disarm without siren chirps that one time. Flashing lights and LED will
be the only indicators of Arm/Disarm status. If the system was tripped while you were way, 4 chirps will be
heard to notify you that the system was tripped.
Silent Arming/Disarming (Chirp Defeat):
This system can be programmed to silent arm and disarm using the normal lock and unlock buttons. Flashing
lights and LED will be the only indicators of armed or disarm status. Check with your installer or follow
programming option instructions in the installation manual.
Alarm Triggering
An intrusion into the vehicle or hard impact to the body will sound the alarm and flash the lights for 1 minute.
After 1 minute the trigger cycle will automatically stop and alarm will remain armed to continue protecting the
vehicle. If a door is left open after an intrusion then the unit will cycle a maximum of 5 minutes and continue to
protect the other un-tampered or unopened zones. 3

OPERATING INSTRUCTIONS - ALARM
Prior intrusion Alert
This system will notify you if the alarm was tripped while you where away. Upon disarming, the two normal
disarm chirps will be heard then the system will emit 4 additional siren chirps. Check your vehicle for any
signs of a break in or tampering. Also see LED Diagnostics Section to determine the cause of the trigger.
Remote Panic Protection
To sound the alarm in an emergency situation or to draw attention to your vehicle, press and hold Button #1
(Lock) for at least 3 seconds until the siren sounds. Press Button #2 (Unlock) to reset panic mode.
Arming With Shock Sensor Bypass
To arm the alarm and bypass shock sensor protection, press Button #1 as normal then press and release
Button #1 and #2 together within 2 seconds. You will hear 3 extra siren chirps indicating shock sensor bypass
for this arming cycle only.
Open Zone Alert / Bypass
Upon arming, this system will warn you if a door is left open. After a 60 second setup delay (for extended
dome lights) has elapsed, if the system detects a fault or a door left open, the siren will chirp 5 times along
with 5 light flashes. This zone will be automatically bypassed and the alarm will protect all other zones.
Pre-Warning Shock Protection
The Pre-warning (warn-away) feature will activate when a low-level shock or vibration detected by the
system’s shock sensor. The alarm will chirp the siren 5 times and flash the lights once to help deter any
further tampering with the vehicle.
Passive Arming Mode: (Programmable)
Passive (automatic) arming occurs 30 seconds after the ignition is turned off and the last door is closed. Upon
closing the last door, the unit will flash the lights twice and LED will be flashing rapidly to confirm passive
countdown. If a door is reopened within the 30 second period, the countdown stop and begin again when the
door is closed. Passive arming provides failsafe protection in case you forget to arm the system.
Passive Locking: (Programmable)
The CS2011RS system can be programmed to passively lock the doors when the system passively arms.
The default setting is OFF because passive locking increases the risk of locking the keys in the vehicle.
Trunk/Hatch Pop (Optional, Remote AUX. Output 1)
This feature is designed to interface with existing Factory power trunk or power hatch release systems and
may require additional parts and/or labor charges. Press and release Button #3 (Trunk) on the transmitter to
pop/open the trunk/hatch. If the system is armed, it will also disarm when the button #3 is pressed.
4

OPERATING INSTRUCTIONS - ALARM
Remote AUX. Output 2 (Optional)
This system contains a second auxiliary output to activate other accessories or devices. To activate the
systems’ Second Auxiliary Output, press and hold Button #3 (Trunk Symbol) on the transmitter for more than 2
seconds. This is a momentary output that will stay active as long as the remote button is held down. Remote
output #2 requires programming before operation. Check with your installer or follow programming option
instructions in the installation manual.
Dome Light Illumination (Optional)
This feature will turn on the vehicle’s dome light upon disarming for 30 seconds or until the key is inserted and
turned on. This will provide illuminated entry to your vehicle in dimly lit areas for safety and security.
Emergency Override (Disarm)
If you have lost the transmitter or it stops working for any reason and the Alarm is armed, you will have to
disarm the system manually. Open the door with the key [alarm will sound], turn the ignition on, and press the
override/program button for about 5 seconds. The Alarm will disarm and allow you to use the vehicle until you
can repair/replace the remote. Note that you may need to put the system into valet mode to prevent passive
arming.
Valet Mode (Enter manually or using the remote)
To disable Alarm and Remote Engine Starting for vehicle servicing or otherwise, turn the ignition on and press
the override/program button [about 5-7 seconds] until you hear (3) siren chirps and the LED turns on solid.
Repeat the process to exit VALET mode. To enter / exit valet via the remote, press and hold both buttons #1
(Lock) and Button #2 (unlock) together for about 3 seconds until 3 chirps are heard. Repeat this step to exit
via the remote transmitter. Lock/Unlock and AUX features will still operate in when in VALET mode however
remote start and alarm functions are inhibited.
Valet Park Mode (Using the remote transmitter only)
Note: Valet Park mode is only accessible when using the remote transmitter. Valet park mode allows you to
turn over the vehicle to a valet allowing access to drive/lock/unlock your vehicle, but alarm will trigger if the
trunk is opened. To activate Valet Park, press and hold both buttons #1 (Lock) and Button #2 (unlock)
together for about 6 seconds. 3 chirps will be heard first when unit goes into regular Valet and as you
continue to hold both buttons you will hear 2 more chirps. LED will flash slowly when in Valet Park. Repeat
step to exit Valet Park mode.
5

OPERATING INSTRUCTIONS - ALARM
Optional M.A.P. (Mobile Accessories Protection)
This system can be programmed to provide Crimestopper’s unique M.A.P. (Mobile Accessories Protection)
feature that allows you to prevent unauthorized access of your vehicles Audio, Cellular, Navigation, or
Entertainment systems. This feature is OPTIONAL and will requires extra parts and labor for installation.
Consult your installation dealer about MAP before or during installation. The CS2011RS must be
programmed for MAP operation. When the system is put into Valet Park mode, M.A.P. will prevent stereo,
entertainment, navigation, or cellular system from being used.
LED DIAGNOSTICS
The CS-2011RS system includes disarm diagnostics, through the RED LED light, that will help in determining
what caused the last trigger of the alarm system. This is a valuable tool in determining how the vehicle was
tampered with or if there is a false alarm problem in which case you can make the necessary adjustments to
correct the problem. When the system is disarmed with the remote you will hear the normal 2 chirps, then 4
quick chirps that indicate the alarm was triggered while you were away. Check the LED light for a sequence
of flashes:
Shock Sensor = 1 Flash Door = 2 FlashesHood/Trunk = 3 Flashes Ignition = 4 Flashes
Diagnostics will reset when the Ignition is turned on or when the system is re-armed.
REMOTE ENGINE CONTROL
REMOTE ENGINE STARTING - SUCCESSFUL START
1) Press and release the remote start button on the remote transmitter. System will chirp 3 times for audible
confirmation. (Chirps can be programmed on or off-See Option programming in the installation manual.)
2) Parking lights flash once, then turn on solid, Ignition/Accessory circuits turn on.
3) After 6 seconds Starter Motor engages, Parking lights and Accessory circuits turn off while cranking.
4) Engine Starts and Runs. Parking Lights and Accessory turn back on, Doors Lock.
5) Engine will remain running for programmed run time until reset with Brake pedal. If needed, the engine can
be turned off with remote transmitter.
6

REMOTE ENGINE CONTROL
REMOTE ENGINE STARTING - SUCCESSFUL START DIAGRAM:
AFTER
IGN
3
STARTER
THEN
FLASH 1X
SOLID
SOLID
SEC.
START
REMOTE ENGINE STARTING - UNSUCCESSFUL START
In the event that the engine does not start on the first attempt, the system shuts down for a few seconds, then
attempts to restart the engine a 2nd and 3rd time. For hard starting engines, the unit will allow a starter crank
time of up to13 seconds maximum. This should provide ample cranking time for difficult starts, but is limited to
13 seconds to help prevent damage to the starter from over cranking.
1) If engine starts on 2nd or 3rd attempt, see steps 4 & 5 above of "Successful Start".
2) If Third attempt fails to start engine, the system will turn off and doors will remain locked. NO FURTHER
ATTEMPTS WILL BE MADE AUTOMATICALLY UNLESS YOU PRESS THE START BUTTON AGAIN.
TURNING OFF A REMOTE STARTED ENGINE:
1) Engine is running in Remote Start (Parking lights ON).
2) Press and release the Start button.
3) Engine & parking lights turn OFF, Doors remain locked or will re-lock if applicable.
TURNING OFF A REMOTE STARTED ENGINE DIAGRAM:
START
7

REMOTE ENGINE CONTROL
ENTERING YOUR REMOTE STARTED VEHICLE:
1) With engine running, Remote Unlock/Disarm system (If armed) or open door with key.
2) Enter vehicle and be careful not to step on brake pedal! (Remote Start Reset)
3) Turn Ignition to ON/RUN position, then press brake pedal to reset the Remote Starter & Shift out of park.
4) Remote starter will reset instantly when the brake is pressed. Parking lights will turn off and the ignition key
is now controlling your vehicle.
IDLE DOWN MODE (TAKE-OVER OPERATION)
This mode allows the unit to take over operation of your idling, parked vehicle while the ignition key is
removed and you exit the vehicle. The vehicle is put into a remote running condition before you exit and it will
remain running for the programmed run time, until you return, or until the remote start button is pressed.
Examples:
You pull up to a convenience store for a quick stop, "Idle Down" mode keeps engine running when you
exit the vehicle, (with keys in hand) remote lock/arm alarm. When you return, unlock/disarm alarm, turn
ignition ON and drive away. This mode can also be used on Turbo vehicles that need idle for cool-down.
IDLE DOWN MODE - EXITING THE VEHICLE:
1) With engine running, press and release the Start button. Siren will chirp 3 times for confirmation.
2) Parking Lights will turn ON.
3) Doors will unlock, or if brake pedal is being depressed doors will unlock when it is released.
4) Turn OFF Ignition and remove key. Engine should remain running.
5) Exit vehicle then remote lock doors if desired.
6) Engine will remain running for programmed run time, until you return, or press the remote start button.
SOLID
IGN
OFF
UNLOCK
START
ENTERING A VEHICLE DURING “IDLE-DOWN” or “INFINITY RUN” MODES:
See “ENTERING YOUR REMOTE STARTED VEHICLE” section above.
8

REMOTE ENGINE CONTROL
INFINITY RUN MODE
This mode allows the vehicle’s engine to remain running INDEFINITELY. This mode can be beneficial to law
enforcement vehicles or commercial vehicles that need to remain running unattended for long periods of time.
INFINITY RUN MODE – EXITING THE VEHICLE:
1) Follow steps on the last page for “IDLE DOWN MODE - EXITING THE VEHICLE”, except press the remote
start button TWO times at STEP #1.
2) Parking Lights will start flashing instead of coming on solid, and doors will unlock.
3) Turn Ignition switch OFF, remove key and exit the vehicle. Engine should remain running.
4) The vehicle’s parking lights will flash for the programmed run time of 12, 24, or 36, or 48 minutes and then
switch to solid while motor runs indefinitely or until fuel supply runs out.
IGN
OFF
2X
FLASH FOR PROGRAMMED
RUN TIME, THEN SOLID
START
ENTERING A VEHICLE DURING “IDLE-DOWN” or “INFINITY RUN” MODES:
See “ENTERING YOUR REMOTE STARTED VEHICLE” section at top of page 8.
9

REMOTE ENGINE CONTROL
TIMED SELF START MODE
This mode allows the vehicle to be programmed to self-start every 4 hours and run for the programmed run
time. This can be helpful during extremely cold conditions where engine fluid freeze-up is a concern. THE
VEHICLE MUST BE OUTDOORS OR IN A WELL VENILATED AREA.
TIMED SELF-START MODE – EXITING THE VEHICLE:
1) Have engine running with the Key, then press and release the Start button.
2) Within the next 10 seconds press the valet/program button once.
3) Parking Lights will turn OFF for about 5 seconds, and doors will unlock.
4) Turn Ignition switch OFF, remove key and exit the vehicle. Engine should remain running.
5) To turn off the engine, press the remote start button. The parking lights will flash 4 TIMES as a
confirmation that the unit is in Timed Self-Start Mode.
6) The Vehicle will Start by itself every 4 hours until driven with key or started via remote control.
IGN
SOLID
OFF
UNLOCK
PRESS 1X
WITHIN 10 SEC. LIGHTS OFF 5 SEC.
FLASH 4X
LOCK
START
STAR T
RESETTING TIMED SELF START MODE
To reset the timed self-start mode, start the vehicle using the key or the remote control
10
