Ultra Viev DP-12 User manual

UM-UV-621-12-Q418V1 www.austin-hughes.com
User Manual
dedicated LCD display solutions
Aluminum front bezel
OP-12
Universal Mounting Open Frame
AP-12
12.1” LCD
Front NEMA4 / IP65
DP-12
Designed and manufactured by Austin Hughes
Aluminum front cover
NAP-12

UM-UV-621-12-Q418V1 www.austin-hughes.com
Legal Information
First English printing, December 2018
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. We are not liable for any injury or
loss that results from the use of this equipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with
temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing
damage to other equipment or injury to persons nearby.
■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the
power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current
labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed
on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being
damaged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power
supply or on other hardware may cause damage, fire or electrical shock.
■Only qualified service personnel should open the chassis. Opening it yourself could damage the equipment and
invalidate its warranty.
■If any part of the equipment becomes damaged or stops functioning, have it checked by qualified service personnel.
What the warranty does not cover
■Any product, on which the serial number has been defaced, modified or removed.
■Damage, deterioration or malfunction resulting from:
□Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or
failure to follow instructions supplied with the product.
□Repair or attempted repair by anyone not authorized by us.
□Any damage of the product due to shipment.
□Removal or installation of the product.
□Causes external to the product, such as electric power fluctuation or failure.
□Use of supplies or parts not meeting our specifications.
□Normal wear and tear.
□Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures:
■Re-position or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

UM-UV-621-12-Q418V1 www.austin-hughes.com
Contents
< Part. 1 > AP-12 / NAP-12
1.1 Package Content P.1
1.2 Structure Diagram & Dimension P.2 - 3
1.3 Mounting Hardware & Installation P.4
< Part. 2 > DP-12
2.1 Package Content P.5
2.2 Structure Diagram & Dimension P.6 - 7
2.3 Mounting Hardware & Installation P.8
< Part. 3 > OP-12
3.1 Package Content P.9
3.2 Structure Diagram & Dimension P.10 - 11
3.3 Mounting Hardware & Installation P.12
< Part. 4 > Specifications / OSD
4.1 Product Specifications P.13 - 14
4.2 On-screen Display Operation ( OSD ) P.15
< Part. 5 > Options
5.1 Option Table P.16
5.2 AV2.2 Upgrade : S-Video + BNC & Audio P.17
5.3 Projected Capacitive ( 2-point touch )
Resistive / Capacitive ( 1-point touch ) P.18 - 19
5.4 DC Power : 12V / 24V / 48V P.20
5.5 TV ( Analog ) P.21 - 22

UM-UV-621-12-Q418V1 www.austin-hughes.com
■It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediately.
Unpacking
Before Installation
How To Clean Your LCD Monitor
Caution :
3
4
■To avoid the risk of electric shock, make sure your hands are dry before unplugging your monitor from or
plugging your monitor into an electrical outlet.
■When you clean your monitor, do not press down on the LCD screen. Pressing down on the screen can
scratch or damage your display. Pressure damage is not covered under warranty.
■Use only cleansers made specifically for cleaning monitors and monitor screens. Cleansers not made to
clean monitors and monitor screens can scratch the LCD display or strip off the finish.
■Do not spray any kind of liquid directly onto the screen or case of your monitor. Spraying liquids directly
onto the screen or case can cause damage which is not covered under warranty.
■Do not use paper towels or abrasive pads to clean your monitor. Using an abrasive pad or any wood
based paper product such as paper towels can scratch your LCD screen.
Cleaning Your Monitor
To clean your LCD safely, please follow these steps :
Disconnect the power cord.
Gently wipe the surface using a clean, dry microfiber cloth. Use as little pressure as possible.
1
2
Cleaning Tough Marks and Smudges
To remove tough marks and smudges, please follow these steps :
Disconnect the power cord.
Spray a small amount of non-abrasive cleanser on a microfiber cloth.
Gently wipe the surface. Use as little pressure as possible.
Wait until your monitor is completely dry before plugging it in and powering it up.
1
2
Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to your
microfiber cloth first, not directly on the parts you are cleaning.

UM-UV-621-12-Q418V1 www.austin-hughes.com
12.1” LCD Display
P. 1
AV2.2 upgrade I/O
Audio
Power
out - in - in
Video PC
VGAS-VideoBNC
Basic I/O
P. 1
12.1" LCD display X 1
6ft VGA cable X 1
Power adapter X 1
Power cord X 1
AP-12 / NAP-12
Mounting hardware X 1 pack
- Mounting bracket x 2 pcs
- M4* 6mm screw x 4 pcs
- M4* 50mm screw x 4 pcs
Power VGA
< Part 1 > AP-12 / NAP-12
< 1.1 > Package Content

UM-UV-621-12-Q418V1 www.austin-hughes.comP. 2
Rear case
LCD panel
Protective 3mm glass
6mm aluminum front bazel
Audio speaker ( for Audio or TV option )
LCD membrane
Remote sensor
1
2
3
4
5
6
1
2
3
4
6
AP-12
NAP-12
5
Model Product Dimension
(W x D x H) Packing Dimension (W x D x H) Net Weight Gross Weight
AP-12
NAP-12 344.7 x 68.2 x 256 mm 13.6 x 2.7 x 10.1 inch
515 x 117 x 429 mm
20.3 x 4.6 x 16.9 inch
3.5 kg
7.7 lb
5.5 kg
12.1 lb
7
7
< 1.2 > Structure Diagram
Rear view
Bottom view
Front view
Rear view
Side View

UM-UV-621-12-Q418V1 www.austin-hughes.com
12.1” LCD Display
P. 3
Front View Side View
Rear View
AP-12
NAP-12
UNIT : mm
1mm = 0.03937 inch
Bottom View
< 1.2 > Dimension

UM-UV-621-12-Q418V1 www.austin-hughes.comP. 4
■Hardware and M4*4 pcs for VESA mount are not provided
VESA mount ( 75*75mm )
M4 screw
■Install 2 mounting brackets with 4 x M4*6mm screws
■Adjust the LCD panel with 4 x M4*50mm screws and fix it on the surface.
Steps
1
x 2 pcs
Mounting
bracket
x 4 pcs
M4*6mm screw
2 3
x 4 pcs
M4*50mm screw
Hardware set part no. UV-BK#1
< 1.3 > Installation
( I) Panel mount
( II ) VESA mount ( 75*75mm )

UM-UV-621-12-Q418V1 www.austin-hughes.com
12.1” LCD Display
P. 5
AV2.2 upgrade I/O
Audio
Power
out - in - in
Video PC
VGAS-VideoBNC
Basic I/O
Power VGA
12.1" LCD display X 1
6ft VGA cable X 1
Power adapter X 1
Power cord X 1
DP-12
< Part 2 > DP-12
< 2.1 > Package Content

UM-UV-621-12-Q418V1 www.austin-hughes.comP. 6
DP-12
< 2.2 > Structure Diagram
Front view
1
2
3
4
5
Rear case
LCD panel
6mm aluminum front cover
Audio speaker, pair
LCD membrane
1
2
3
5
4
Front view Side View
Rear view
Bottom view
Model Product Dimension
(W x D x H) Packing Dimension (W x D x H) Net Weight Gross Weight
DP-12 313.7 x 63.5 x 255 mm
12.4 x 2.5 x 10 inch
515 x 117 x 429 mm
20.3 x 4.6 x 16.9 inch
3 kg
6.6 lb
5 kg
11 lb

UM-UV-621-12-Q418V1 www.austin-hughes.com
12.1” LCD Display
P. 7
Front View Side View
Rear View
DP-12
UNIT : mm
1mm = 0.03937 inch
Bottom View
< 2.2 > Dimension

UM-UV-621-12-Q418V1 www.austin-hughes.comP. 8
■Hardware and M4*4 pcs for VESA mount are not provided
VESA mount ( 75*75mm )
M4 screw
< 2.3 > VESA mount Installation

UM-UV-621-12-Q418V1 www.austin-hughes.com
12.1” LCD Display
P. 9
AV2.2 upgrade I/O
Audio
Power
out - in - in
Video PC
VGAS-VideoBNC
Basic I/O
Power VGA
12.1" LCD display X 1
6ft VGA cable X 1
Power adapter X 1
Power cord X 1
OP-12
< Part 3 > OP-12
< 3.1 > Package Content

UM-UV-621-12-Q418V1 www.austin-hughes.comP.10
Rear case
LCD panel
Audio speaker ( for Audio or TV option )
Universal open frame mounting
LCD membrane
Extended remote sensor membrane cable
( 66cm from AD board to sensor end )
1
2
3
4
5
1
2
5
OP-12
4
3
Model Product Dimension
(W x D x H) Packing Dimension (W x D x H) Net Weight Gross Weight
OP-12 341.7 x 62.2 x 253 mm
13.5 x 2.5 x 10 inch
515 x 117 x 429 mm
20.3 x 4.6 x 16.9 inch
2.5 kg
5.5 lb
4.4 kg
9.7 lb
6
6
Front view
Rear view
Side View
Bottom view
< 3.2 > Structure Diagram

UM-UV-621-12-Q418V1 www.austin-hughes.com
12.1” LCD Display
P. 11
Front View Side View
Rear View
OP-12
UNIT : mm
1mm = 0.03937 inch
Bottom View
< 3.2 > Dimension

UM-UV-621-12-Q418V1 www.austin-hughes.comP.12
Hardware and M4*4 pcs for VESA mount are not provided
( I) Universal mount
( II ) VESA mount ( 75*75mm )
M4 screw
< 3.3 > Installation

UM-UV-621-12-Q418V1 www.austin-hughes.com
12.1” LCD Display
P.13
< Part 4 >
< 4.1 > Product Specifications
Mechanical Design AP-12 NAP-12 DP-12 OP-12
Protection 6mm front bezel NEMA 4 / IP65 front cover open frame
Front Panel Black, RAL 9005 -
Rear Casing Black, RAL 9005
VESA mount 75 x 75 mm
Universal mount - - ready
Desktop stand option option -
Panel mount bundled - -
Video
VGA Analog 0.7Vp-p
Option
Composite ( BNC ) NTSC & PAL
S-Video ( 4-pin ) NTSC & PAL
DVI DVI-D single link
HDMI HDMI 1.2 / HDCP 1.1
Audio Option
Input
Connector
Impedance / Power level
3.5mm stereo jack
30kΩ/ 750mV
Output
Connector
Resistance / Power level
3.5mm stereo jack
30kΩ/ 2.8V
Speaker:
Dual Stereo 2W x 2
*When the audio output is connected, speaker output is OFF
Power
Input Auto-sensing 100 to 240VAC, 50 / 60Hz
Consumption:
Screen ON Max. 14W
Power saving mode Max. 4W
Power button OFF Max. 1W
Compliance
EMC FCC & CE certified
Safety CE / LVD certified
Environment RoHS2 & REACH compliant
LCD Panel
Panel Size ( diagonal ) 12.1-inch TFT color LCD
Native resolution 800 x 600
Brightness ( cd/m2) 450
Contrast Ratio ( typ. ) 700:1
Colors 262 K
Viewing Angle ( L/R/U/D ) 80/80/65/75
Response Time ( ms ) 35
Dot pitch ( mm ) 0.3075
Display Area ( mm ) 246H x 184.5V
Surface treatment Anti-glare
Surface hardness 3H
Backlight Type LED
MTBF ( hrs ) 50,000

UM-UV-621-12-Q418V1 www.austin-hughes.comP.14
Environmental Conditions
Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Altitude 16,000 ft
Storage /
Non-operating
Temperature -20 to 60°C degree
Humidity 5~90%, non-condensing
Altitude 40,000 ft
Shock 10G acceleration ( 11ms duration )
Vibration 10~300Hz 0.5G RMS random vibration
Physical Specification AP-12 NAP-12 DP-12 OP-12
Product ( W x D x H )
mm 344.7 x 68.2 x 256 253.7 x 58.1 x 191 341.7 x 62.2 x 253
inch 13.6 x 2.7 x 10.1 10 x 2.3 x 7.5 13.5 x 2.5 x 10
Packing ( W x D x H )
mm 515 x 117 x 429 515 x 117 x 429 515 x 117 x 429
inch 20.3 x 4.6 x 16.9 20.3 x 4.6 x 16.9 20.3 x 4.6 x 16.9
Net Weight 3.5 kg / 7.7 lb 3.5 kg / 7.7 lb 3 kg / 6.6 lb 2.5 kg / 5.5 lb
Gross Weight 5.5 kg / 12.1 lb 5.5 kg / 12.1 lb 5 kg / 11 lb 4.4 kg / 9.7 lb
Chassis color Dark
Chassis materials Aluminum
Applicable Format
VGA Input PC Signal 800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
640 x 400 x 70Hz
640 x 350 x 70Hz
Audio Signal 2ch Linear PCM
HDMI Input PC Signal Same as VGA
HDMI 1.2 720 x 480 x 50 / 60Hz ( 576p / 480p )
Audio Signal 2ch Linear PCM
* In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals,
the LCD may display incorrectly on a full screen. If so, please adjust the display card setting on display
size to fix the issue.
< 4.1 > Product Specifications

UM-UV-621-12-Q418V1 www.austin-hughes.com
12.1” LCD Display
P.15
Exit the OSD screen
Toggle analog, digital & video connection (DVI-D and video options only)
Scrolls through menu options and adjusts the displayed control
(To auto adjustment by pressing the button for 5 seconds)
Display the OSD menu
Power on / off LCD
Power light
Green = On
Orange = Power saving
Membrane Switch Function
OSD Configuration Page
Image:
for the brightness, contrast, color temp, red, green, and blue
Geometry:
for the auto adjust, H position, V position, phase and clock
Video:
for the colour, tint, sharpness, noise reduction, DCDi and TV Setup
Audio:
for volume, bass, treble, balance, AVL and mute
Misc:
for the language, OSD position, graphic mode, ratio, reset and timer
< 4.2 > On-screen Display Operation ( OSD )

UM-UV-621-12-Q418V1 www.austin-hughes.comP.16
( 1 ) AV2.2 upgrade comes with RC-2 remote controller.
( 2 ) TV option comes with RC-2 remote controller.
*Remote Controller
Options AP / NAP DP OP
S-Video + Composite ( BNC ) ✓✓✓
DVI-D ✓✓✓
Audio ✓✓✓
Touchscreen ✓✓✓
DC Power ✓✓✓
TV * ✓✓✓
< Part 5 > Option
< 5.1 > Option Table
