Ultra UF3412X User manual

Thank you for selecting our product for your home. We hope that you are completely satisfied with your purchase.
Please read below instructions carefully before installing new faucet.
Tools you will need:
• Adjustable Wrench
• Water Supply Lines
• Pipe Tape
• Screwdriver
• Silicone Sealant
Care & Maintenance:
- To keep the product clean & shining, follow the steps below:
• 1. Rinse with clean water & dry with a soft cloth.
• 2. Do not clean with soaps, acid, polish, abrasives, or harsh cleaners.
• 3. Do not use cloth with a coarse surface.
• 4. Unscrew the aerator and clean when necessary.
- This installation manual is subject to change without further notice.
- Please read your care and maintenance documentation to determine the limits of
proper use.
- This product has been manufactured and tested to the highest quality standards .
We offer our customers thoughtfully crafted fixtures & accessories, engineered for
enduring performance over years of use.
Prior to Installation:
• Turn off the hot and cold water supply at the angle stops
and turn on the old faucet to release any built up pressure.
Remove existing faucet. Clean sink or countertop to
remove any debris, plumber’s putty, or silicone.
• Place bucket under angle stops. Turn on to flush any debris
prior to installing new plumbing. Shut off angle stops.
• Pre-drilled hole size requirement: 1-1/4” (min) – 1-3/8” (max)
• Max countertop thickness: 1-1/2”
Single Handle Lavatory Faucet
With Pop-up Drain
Model#: UF3412X
Installation:
1.Place new faucet through rubber washer (A) for
single hole installation, For 3 hole installation,
place new faucet through rubber washer,
escutcheon and base plate and mounting holes
in sink.
3A.Stainless steel Braided Faucet supply Tubes:
This the simplest of all installations.If you are
using stainless steel braided faucet supply tubes,
this faucet requires one end of the supply tube to
have a 1/2” female IPS connection.The other end
of this supply tube must match the thread on the
water supply fittings or shut off valve under your
sink.Once you have identified the required tube,
carefully follow the manufacture’s installations
instructions for each tube.
3B.Ball Nose Flexible Supplies: If you are using
ball-nose flexible supplies to connect the faucet
to water supply lines;Slip coupling nut behind
ball-nose of flexible supply tube. Ball nose
coupling will go Partially into IPS shank or fitting.
Tighten coupling nut (DO NOT OVER TIGHTEN).
lnstall opposite end according to manufacture’s
instructions for both tubes.
2.Insert the rubber washer(B), metal washer, and
secure the faucet with the mounting nut.
3A 3B
BEFORE PROCEEDING
.
WARNING:A professional is recommended to install this product! This product should
be installed in accordance with all local and state plumbing and building codes.
One hole installation Three holes installation
Rubber washer-A
Rubber washer-B
Metal washer
Mounting
Escutcheon
and
Base plate
4A.Pop up Drain Installation:
a.Remove flange(01),rubber washer(02),from the
pop-up assembly.
b.Put the pipe body(04) into the sink hole,install the
rubber washer(02) and the flange(01),tighten the
mounting nut(03) use wrench.
01
02
03
04
Pop up Drain Installation
4B.Unscrew the nut(08) from the pipe body(04),
retain the white washer(06), then take off the
spring clip(09) from the ball rod(07).insert the
stopper(05),insert the ball rod into the side hole
of drain,slide the nut on and tighten securely.
05
06
07
08
09
04
[phone]

5: a. Insert lift rod into sink hole,through the linker
hole,Tighten the lock nut.
b:Move the linker along the ball rod,pull the lift
rod knob up and down,move the linker at proper
location.
Aeratory
assembly
Limited Lifetime Warranty
Ultra faucets warrants to the original purchaser that its products will be free from
defects in workmanship and materials. All Ultra Faucets are provided with a life time
limited warranty. This warranty does not cover any other labor or service charges
associated with the removal,repair,or reinstallation of Ultra Faucets products. This
express warranty does not apply to products that have been damaged as a result of
misuse,abuse,negligence,accident,faulty installation or maintenance practices
and/or used in any manner contrary to those recommended by the manufacturer.
Exploded Drawing
RP(Replacement Parts)
4C.Install the spring clip(09) on the ball rod,
simultaneously,insert the linker(10).
09
10
4D: a. Insert lift rod into sink hole,through the
linker hole,Tighten the lock nut(11).
b:Move the linker along the ball rod,pull the
lift rod knob up and down,move the linker at
proper location.
11
lift rod
a b
RP35051
Single handle
RP50803&50802
Button & Screw
85211
Rubber washer-B
85208
Metal washer
85210
Mounting nut
RP85207
Bolt
RP35109
Aerator assembly
RP30004
Pop-up Drain
Lift rod assembly
RP35004
Cap
RP35015
Bonnet
RP50819
Cartridge
RP35111
Escutcheon
RP50713
Base plate
Body assembly
RP70706
Screws
Cover plate
RP35114
Rubber washer-A
