Ultraframe Loggia User manual

Electric radiant panel heater
Installation Guide
JAN 2017 V2

The Loggia electric radiant panel heater is specifically designed
to give you comfortable, controllable warmth when and where it’s
needed.Radiant heat does not directly warm air but warms objects
and we therefore recommend that furniture etc. be kept one metre
clear from the front of the heater.
IMPORTANT SAFETY ADVICE
1. WARNING: THIS HEATER MUST BE EARTHED.
2. This heater is for use as an indoor Ʈxed appliance and is
NOT FOR PORTABLE USE.
3. DO NOT use heater outdoors.
4. DO NOT operate switches etc. with wet hands.
5. Ensure that the heater is switched oƬwhen cleaning.
6. DO NOT use where ưammable gases or liquids are stored.
7. This heater will be hot when in use. To avoid the possibility
of burns do not let bare skin touch hot surfaces.
Momentary contact should not cause any harm.
8. DO NOT allow small children to play with the heater.
9. To avoid over heating do not obstruct the air circulation
around the heater. Never cover the heater or allow
curtains or furniture to touch or cover any part of the
casing. Heaters are not to be used for drying clothes.
10. The installation of this heater should be carried out by an
electrician and be in strict accordance with current IEE
Regulations.
Wiring
Regulations and all relevant Building Regulations.
11. Before connecting the heater, check that the supply
voltage is the same as that marked on the heater.
12. If the ưexible mains lead gets damaged DO NOT USE
the heater.
13. There are no user serviceable parts inside the heater.
Technical Support
Tel: [phone]
Email: [e-mail]
Wiring the plug
The Loggia electric radiant panel heater is supplied with a mains
cord length which should be suƱcient to allow connection to a
convenient 5A fused spur, or socket outlet via a 13 amp plug (not
supplied, see Ʈtting detail below).
Either must be Ʈtted with the
correctly rated fuse which is 5A.
Prepare lead for connection to a
5A plug as follows:
E – Green & Yellow core,
Length 41mm O/ All,
Strip oƬinsulation to expose
8mm of bare wire.
L – Brown core,
Length 20mm O/ All,
Strip oƬinsulation to expose
8mm of bare wire.
N – Blue core,
Length 35mm O/ All,
Strip oƬinsulation to expose
8mm of bare wire.
PRESS CORD BETWEEN
GRIPS BEFORE CONNECTING
CONDUCTORS TO TERMINALS.
WARNING!
THIS APPLIANCE MUST BE EARTHED.
THE HEATER MUST NOT BE FIXED
IMMEDIATELY BELOW A SOCKET OUTLET.
PLEASE READ THESE NOTES BEFORE INSTALLATION
AND PASS TO THE HOMEOWNER FOR FUTURE REFERENCE.

COMPONENTS LIST
Security cable Heater
Corner bracket
50mm screw
Loggia radiant panel heaters fit inside large corner
columns and small/large abutments.
Select the correct place near an electrical supply, ensuring that the
warmed air will be able to circulate freely in the room/area being heated.
Loggia radiant panel heaters are primarily designed to be mounted
vertically, however due to their unique design, may also be mounted
horizontally.
The Ʈrst desicion when installing is orientation. In the vertical and
horizontal mounting, the switch must always be at the bottom.
INSTALL YOUR NEW HEATER (Vertical, large corner column illustrated)
Use the mounting brackets as a
template to determine the hole
centres.
2
Mark the heater mounting centres
(1550mm) in the required place – re-
check the heater mounting centres.
The radiator itself is 1900mm long -
with 2100mm high frames, mark down
340mm from the ceiling or eaves.
1
Fix the brackets using the 4
holes provided.
4
When you are happy with the
positions, drill the wall. N.B. If drilling
into one of the Loggia columns, the
screws provided will be ok. If drilling
into the host wall on an abutment
situation, additional anchors (not
supplied) will be needed.
3
When both wall brackets are Ʈxed
you can now lift the heater onto the
brackets.
6
Attach security cable to back of
heater.
5
When the heater is securely Ʈtted to
the wall and connected to a suitable
power supply point, power can then
be switched on. N.B. If using with a
Loggia 7 day programmer, now move
to this stage and see seperate guide
provided with the timer/programmer.
8
Attach the security cable to the
wall, ensuring it is taut and the
radiator cannot be lifted clear of
the brackets (security device).
7
340mm
1550mm

www.ultraframe.co.uk
Ultraframe (UK) Ltd, Salthill Road, Clitheroe, Lancashire. BB7 1PE
Job No. 3399 LHP020 v2 AVJ 500 01/17 It is Ultraframe’s policy to continually seek to improve its products, processes and services, and we reserve the right to change speciƮcations without prior notice. Ultraframe is a trading name of Ultraframe (UK) Limited.
OPERATING
If you have NOT ordered a Loggia 7 day programmer to work with the electric radiant panel heater,
turn on the switch at the end of the radiator. The switch should illuminate to confirm that power is
now available to the heater. If the switch does not illuminate when operated, first ensure that the
wall connection is switched on. If that does not solve the problem, then we recommend that you
consult your electrician.
Manual control (when no programmer has been ordered)
Near to the switch referred to above, there is an LED which lights up red to indicate that the heater is warming up. The panel surface
temperature is factory preset. Please note, that in manual control, your heater will not automatically control room temperature.
If the LED shows green, and the heater does not warm up, it means that it may need to be set to operate in manual mode by following this
procedure:
A: If the panel is on, switch it oƬ.
B: Switch it on for about three seconds then switch it oƬagain.
Do this 5 times in succession, and your heater should be back in manual control.
In manual operating mode the heater can be switched on and oƬby using the power switch on the heater, or via the supply point.
Should you in future require automatic room temperature and/or time control, then a LHC001/LHC005 control may be purchased
seperately. Speak to your Loggia retailer about this. Full instructions would be provided to enable the heater to be connected wirelessly.
Wireless room thermostat timer programmer (optional purchase)
For wireless operation refer to the instructions provided with the LHC001/LHC005 7 day programmable thermostat/timer/
programmer.
Cleaning
To clean, simply wipe with a damp cloth, but do not allow any water to enter the heater.
SAFETY – OVERHEATING
All heaters are Ʈtted with a thermal safety fuse. If the heater severely overheats then the thermal fuse will fail. When that occurs the heater
will not operate and must be returned to the manufacturer - via your Loggia retailer - for repair and servicing.
After sales service
Loggia electric radiant panel heaters have a one year warranty. Within this period Ultraframe will repair or exchange this product free of
charge provided it has been installed and operated correctly according to these instructions and has not been subjected to misuse.
Your rights under this guarantee are additional to statutory rights.
For after sales service contact your retailer. It would assist your retailer when processing your call if you can have available the serial
number and some details of the fault.
Please do not return a product you consider faulty without Ʈrst obtaining returns approval.
PLEASE PASS THS INSTALLATION GUIDE TO THE HOMEOWNER/USER FOR FUTURE REFERENCE.
