UltraLux SCRF2 User manual

ver.1.1
1
www.ultralux.bg
1
www.ultralux.bg
Multichannel RF remote control switches
DESCRIPTION
Multichannel switches allow lighting to be controlled of up to four channels. The range is presented with
three models:
•two channel –SCRF2, three channel –SCRF3 and four channel –SCRF4.
TECHNICAL DETAILS
•Input voltage: 220-240 V AC/ 50-60 Hz
•Output channels: 2 (SCRF2), 3 (SCRF3), 4 (SCRF4)
•Frequency: 2.4 GHz
•Load per channel: ≤500 W –active load (incandescent lamp)
≤300 W –capacitive load (energy saving and LED lamps)
•IP rate: IP20
•Dimensions receiver: 101/48/25 mm
•Dimensions remote control: 140/20/19 mm
•Remote distance: up to 30 m (at open area)
•Working voltage: 2хААА batteries (included)
•Holder for wall mounting
•Working temperature: -10⁰ C ÷ +40⁰ C
•Warranty: 2 years
WIRING DIAGRAM
SCRF2 SCRF3 SCRF4
REMOTE CONTROL
SCRF2 SCRF3 SCRF4
Button
Function
SCRF2
SCRF3
SCRF4
1
Turn ON channel А
ON/OFF channel А
ON/OFF channel А
2
Turn OFF channel А
ON/OFF channel В
ON/OFF channel В
3
Turn ON channel B
ON/OFF channel С
ON/OFF channel С
4
Turn OFF channel B
Turn OFF all channels
after 1 minute
ON/OFF channel D
5
Turn ON all channels
Turn ON all channels
Turn ON all channels
6
Turn OFF all channels
Turn OFF all channels
Turn OFF all channels
NOTE: Every multichannel switch is factory paired to its remote
control and is not affected by the operation of other remote controls!
1
2
3
4
1
2
3
4
1
2
3
4
65

ver.1.1
2
www.ultralux.bg
2
www.ultralux.bg
READ THE INSTRUCTIONS BEFORE MOUNTING OR REPLACEMENT
•Performing any activity with the power supply on constitutes potential hazard of electric shock.
Prior to mounting, power supply must be switched off by using the main switch!
•Multichannel switch may only be connected to a properly functioning electrical system with
compliance with the applicable standards. Activities related to connection to the power supply are
to be commissioned to a person with appropriate authorization. The mounting must be performed
in accordance to the scheme provided.
•The importer/supplier bears no responsibility for damages resulting from failure to comply with
these instructions.
INSTRUCTIONS
Every multichannel switch set have unique RF communication code. This RF code can be programmed on
both the receiver and the remote control after the previous one is deleted first. Also, each remote control
can store only one RF control code, i.e., each new device must copy the RF code to the main one.
•Pairing new remote control
To add new remote controls, they need to have the same number of control channels and copy the RF
code of the main remote control. It is possible to add an unlimited number of remote controls.
1. Main remote control: Press and hold “5”key for 5 seconds. The indicator of the remote control
will flash quickly, means it enters the pairing code transmission status.
2. New remote control: Press and hold “2”key for 5 seconds.
3. Indicator of the new remote controller flash three times after successful code learning.
•Clearing RF Code from receiver
Step
Operation
Instructions
1
Connect the multichannel and turn the power
on.
1. The clearing operation should be finished
within 1 minute after it is powered on.
2. Unpairing operation can be performed
within the remote control range.
2
Press and hold the remote control “6”for 5
seconds. The indicator of the remote control
flashes quickly, means it enters the clearing
code transmission.
1. Remote controller will automatically exit
code transmission after 60 seconds, or by
pressing any key.
2. If the original remote control is lost, the
new remote controller can be used for
clearing operations.
3
The load flashes 3 times.
Clearing coding is finished successfully
•Pairing remote control to receiver
Step
Operation
Instructions
1
Connect the multichannel and turn the power
on.
1.It is necessary to clear the code of the
receiver first.
2.Pairing operation can be performed within
the remote control range.
2
Press and hold “5”on the remote control for 5
seconds. The indicator of the remote control
will flash quickly, means it enters the pairing
code transmission.
Remote controller will automatically exit code
transmission after 60 seconds, or by pressing
any key.
3
The load flashes 3 times.
Pairing is finished successfully

ver.1.1
3
www.ultralux.bg
3
www.ultralux.bg
•Remote control RF code learning from receiver
1. Turn off the power supply of the receiver.
2. Press and hold “2”key for 5 seconds until indicator of remote controller turns off.
3. Turn on the power supply of the receiver. Indicator of the remote controller flashes three times
after successful code learning.
Note: The distance from drivers/dimers to remote controllers should be less than 2 meters.
•Restoring factory settings of remote controller
1. Press and hold “2”key for 20 seconds until indicator of remote controller turns on.
2. Press “6”button. Indicator of the remote controller flashes three times after successful operation.
TAKING CARE OF THE NATURAL ENVIRONMENT CLEANLINESS
•The product and its components are not harmful to the environment
•Please dispose the package elements separately in containers for the corresponding material.
•Please dispose the broken product separately in containers for out of usage electrical
equipment.
