Ultravolt HV RACK Parts list manual

© 12/2006 UltraVolt HV Rack System Installation and Operators Manual, Rev A
1 of 23
HV RACK®
POWER SUPPLY
INSTALLATION INSTRUCTIONS
AND OPERATOR’S MANUAL

© 12/2006 UltraVolt HV Rack System Installation and Operators Manual, Rev A
2 of 23
TABLE OF CONTENTS
Page
Part 1 – Safety and Warranty Information
General Safety Summary 03
Safety Terms and Warning Symbols 04
Warranty Information 05
Part 2 - General Information
Product Information 06
Part 3 - Installation
Unpacking 07
Bench-Top Installation 07
Rack-Mount Installation 08
Part 4 - Electrical Connections
Cables and Interconnects 10
Typical System Wiring Diagram 11
Part 5 – Controls and Indicators
Features 12
Front-Panel Controls and Indicators 12
Rear-Panel Connections, Controls and Indicators 14
Part 6 – Operation
Operation Using Front-Panel Controls 16
Operation Using Remote Control 17
Part 7 - Maintenance and Calibration
Routine Maintenance 19
Calibration 19
Appendix A - Specifications 20
Appendix B
Rear-Panel Interface, Control, and Functional Pinout 21
Appendix C
Regulatory 22
Appendix D
UltraVolt’s HV Rack®power supply block diagram 23

© 12/2006 UltraVolt HV Rack System Installation and Operators Manual, Rev A
3 of 23
PART 1
SAFETY AND WARRANTY INFORMATION
GENERAL SAFETY SUMMARY
Read all installation,
operation, and safety
instructions
Prior to operation, thoroughly review all safety, installation, and operating
instructions accompanying this equipment. All instructions must be
followed.
Use supplied power cord To avoid electrical or fire hazard, use only the power cord specified for this
product.
Use a properly wired
electrical service outlet
Connect the power cord only to a properly wired and grounded outlet.
Do not use AC power
extension cord
Do not use an extension cord when connecting this equipment to an AC
power source. An outlet socket must be located near the equipment and must
be easily accessible.
This equipment must be
connected to an earth safety
ground
This product is grounded through the grounding conductor of the power
cord. To avoid fire and electrical hazard, the grounding conductor must be
connected to protective earth ground. Before making connections to the
input or output terminals of this product, ensure the product is properly
grounded.
Use UltraVolt-approved
connectors and/or cable
assemblies
When configuring external cable assemblies, it is strongly recommended end
users use only those connectors and/or cable assemblies approved by
UltraVolt.
Connect external system
grounds
All external system device chassis should be connected to the HV Rack
system’s rear-panel system grounding stud.
Do not operate without
protective covers in place
To avoid electric shock or fire hazard, do not operate this product with
covers or panels removed.
Do not modify the unit Do not make any external or internal modifications to this unit.
Use properly rated fuse To avoid fire hazard, use only the fuse type and rating specified for this
product.
Do not operate in wet/damp
conditions
To avoid electric shock hazard, do not operate this product in wet or damp
conditions.
Avoid exposed connections Do not touch exposed connections when power is present.
Service is to be performed
by factory-qualified service
persons only
All servicing on this equipment must be carried out by factory-qualified
service personnel only.
Disconnect power before
servicing
To avoid electric shock hazard, disconnect the main power by means of the
power switch and power cord prior to servicing.
Installation shall be by a
qualified high-voltage
equipment technician
This product must only be installed by a qualified high-voltage equipment
technician.
May be rack mounted Rack mounting of this equipment must conform to the manufacturer’s
recommendations.
Do not block chassis
ventilation openings
Slots and openings in the chassis are provided for ventilation purposes to
prevent overheating of the equipment and must not be restricted.
Check for signs of visible
damage each time before
operating
If any external physical damage is observed to the equipment or
interconnecting cables, do not operate.

© 12/2006 UltraVolt HV Rack System Installation and Operators Manual, Rev A
4 of 23
PART 1
SAFETY TERMS AND SYMBOLS
CAUTION: Caution statements identify conditions or practices that, if not avoided, can
result in personal injury and/or damage to the equipment or other property.
WARNING: Warning statements identify conditions or practices that, if not avoided,
can result in personal injury or loss of life, and/or damage to equipment or
other property.
DANGER: Danger statements identify conditions or practices that present an
immediate danger and, if not avoided, will result in personal injury or loss
of life.
Attention symbol: Indicates important installation, operating, and/or
maintenance instructions.
Shock Hazard symbol: Indicates risk of electric shock.
Shock Hazard label.
Indicates risk of electric shock and is located on the equipment itself.
Protective Earth Ground symbol, internal: Indicates primary protective
earth ground, internal to the equipment.
System Earth Ground symbol, external: Indicates system earth ground.

© 12/2006 UltraVolt HV Rack System Installation and Operators Manual, Rev A
5 of 23
PART 1
ULTRAVOLT INC, BASIC WARRANTY
WARRANTY: The Seller warrants all goods supplied hereunder will conform to any sample approved
by the parties and will be the kind described herein or in any specification, performance requirement, or
drawing approved by the Seller, and will be of merchantable quality and free from defects in material or
workmanship under normal use and prescribed maintenance for a period of one (1) year from the date of
shipment. To the extent the Buyer does not furnish the Seller with written specifications, the goods will
be manufactured in accordance with industry accepted standards. This warranty shall not apply to any
goods delivered hereunder that have been damaged or subjected to alteration, nor shall it apply to
negligent treatment after delivery or to any defects attributed to artwork or drawings furnished by the
Buyer. Also, unless specifically stated, the warranty does not extend to the electrical performance of any
assemblies or subassemblies to which the goods furnished hereunder are affixed, but is restricted to the
electrical continuity properties of such goods.
The Seller’s only obligation for breach of this warranty shall be the repair or replacement, without
charge, of any goods or parts thereof that within such one (1) year period is proven to the Seller’s
satisfaction to have been defective, provided (1) the Buyer shall have notified the Seller of the defect
within such one (1) year period, and (2) the Seller shall have the option of requiring the return of the
defective material or goods at the Buyer’s expense to establish the claim provided; however, the Seller
will bear any transportation costs incurred in repairing or replacing any goods that are shown to be
defective during the warranty period. The cost of any repairs made by the Seller to goods no longer
covered by this warranty shall be borne by the Buyer. The Buyer must contact the UltraVolt Customer
Service Department prior to the return of any material(s) to obtain an RMA number which will be used to
track the material. Material found to be out of warranty will be repaired or replaced at the Seller’s
discretion based on quantity (please contact the Customer Service Department for more information). The
Seller shall in no event be liable for the Buyer's manufacturing costs, lost profits, good will, or any other
special, consequential, incidental, or other damages resulting from a breach of the foregoing warranty.
There are no other warranties expressed or implied (including the warranty of merchantability) that
extend beyond the warranty set forth herein or that extend beyond the description of the goods contained
herein.
We at UltraVolt know that when developing new high-voltage applications, power supplies may
sometimes become unintentionally damaged. We, therefore, offer an enhanced warranty beyond the scope
of our basic one-year warranty to support customers’ efforts in new-product development. Should a
power supply unintentionally fail or become damaged through incorrect application, UltraVolt will repair
or replace the first unit at no charge during the Warranty period. Then, if the same unit is unintentionally
damaged again while still within the warranty period, UltraVolt will provide another replacement at half
price. For any such replacement, UltraVolt Applications Engineering must first review the customer’s
new product application. This is done to ensure mechanical installation and electrical connections are in
accordance with UltraVolt published datasheets and application notes. The combined free replacement
and expert UltraVolt engineering review is just one of many ways UltraVolt is Making High Voltage
Easier!®
