NETWORK CAMERA
User Manual
V2.0.0
2009-8

Thank you for purchasing our product. If there are any questions, or requests, please
do not hesitate to contact the dealer.
This manual applies to DS-2CD802/812/892PF(NF)(-E)(-W), DS-2CD832F(-E),
DS-2CD802/812/892P(N)-IR1(IR3)(IR5), DS-2CD702/712/792PF(NF)(-E), DS-2CD732F(-E),
DS-2CD862MF-E, DS-2CD852MF-E, DS-2CD762MF-FB(H), DS-2CD752MF-FB(H),
DS-2CD752MF(-E), DS-2CD852F series Network Camera
This manual may contain several technical incorrect places or printing errors, and the
content is subject to change without notice. The updates will be added to the new
version of this manual. We will readily improve or update the products or procedures
described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of
the security or signaling aspects of this product. UL has only tested for fire, shock or
casualty hazards as outlined in UL’s Standard(s) for Safety, UL60950-1. UL
Certification does not cover the performance or reliability of the security or signaling
aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES OR
CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF
ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.”

User Manual of Network Camera
1
1
Safety Instruction
These instructions are intended to ensure that the user can use the product correctly to avoid
danger or property loss.
The precaution measure is divided into ‘Warnings’ and ‘Cautions’:
Warnings: Serious injury or death may be caused if any of these warnings are neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
Warnings
Follow these safeguards to
prevent serious injury or death.
Cautions Fol
low these precautions to
prevent potential injury or material
damage.
Warnings
1. In the use of the product, you must strictly comply with the electrical safety regulations of the
nation and region.
2. Source with AC 24V or DC 12V according to the IEC60950－1 standard. Please refer to technical
specifications for more details.
3. Do not connect several devices to one power adapter as an adapter overload may cause
over-heating and can be a fire hazard.
4. Please make sure that the plug is firmly inserted into the power socket.
5. When the product is installed on a wall or ceiling, the device should be firmly fixed.
6. If smoke, odor, or noise rise from the device, turn off the power at once and unplug the power
cable, then contact the service center.
7. If the product does not work properly, please contact your dealer or the nearest service center.
Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)

User Manual of Network Camera
2
2
Notice:
1. Make sure the power supply voltage is correct before using the camera.
2. Do not drop the camera or subject it to physical shock.
3. Do not touch CCD (Charge Coupled Device) modules with fingers. If cleaning is necessary, use a
clean cloth with a bit of ethanol and wipe it gently. If the camera will not be used for an
extended period of time, put on the lens cap to protect the CCD from dirt.
4. Do not aim the camera at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfunction however), and affecting the endurance of CCD at the
same time.
5. The CCD may be burned out by a laser beam, so when any laser equipment is being used, make
sure that the surface of the CCD will not be exposed to the laser beam.
6. Do not place the camera in extremely hot or cold temperatures (the operating temperature
should be between -10°C ~+60°C), dusty or damp locations, and do not expose it to high
electromagnetic radiation.
7. To avoid heat accumulation, good ventilation is required for a proper operating environment.
8. Keep the camera away from liquids.
9. While shipping, the camera should be packed in its original packing, or packing of the same
texture.
10. Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment should be
replaced regularly according to their average life time. The average time varies because of
differences between operating environment and usage history, so regular checking is
recommended for all users. Please contact with your dealer for more details.

User Manual of Network Camera
3
3
Index
Chapter 1 Introduction................................................................................................................................................. 1
1.1 Network camera Functions and Features....................................................................................................... 1
1.2 Applications................................................................................................................................................... 2
Chapter 2 Installation................................................................................................................................................... 3
2.1 Panels Description......................................................................................................................................... 3
2.1.1 Side Elevation of the Camera ............................................................................................................. 3
2.1.2 Rear Panel Description ....................................................................................................................... 4
2.2 Product Installation........................................................................................................................................ 7
2.2.1 Box camera Installation...................................................................................................................... 7
2.2.2 Dome camera Installation................................................................................................................... 8
2.2.3 Topological graph of network camera ................................................................................................ 9
2.3 Client Software Installation......................................................................................................................... 10
2.4 Special Client Software Installation for Wireless camera............................................................................ 12
Chapter 3 Parameter Configuration........................................................................................................................... 17
3.1 Network Camera access model overview.................................................................................................... 17
3.1.1 Wireless Network (Only “-w” series support) .................................................................................. 17
3.1.2 Wired network .................................................................................................................................. 18
3.2 Visit Network Camera in LAN.................................................................................................................... 18
3.3 Configuration via Web browser................................................................................................................... 19
3.4 Configuration via Client Software............................................................................................................... 22
3.5 Wireless Network Camera Access............................................................................................................... 28
3.6 Visit Network Camera in Internet................................................................................................................ 30
3.6.1 Visit network camera with static IP .................................................................................................. 30
3.6.2 Visit network camera with dynamic IP............................................................................................. 31
Appendix 1 SADP Introduction................................................................................................................................. 35
Appendix 2 Port Map ................................................................................................................................................ 37
Appendix 3 Pin Definition......................................................................................................................................... 39
Appendix 4 Product Specification............................................................................................................................. 40
DS-2CD802/812/892/PF(NF)(-E)(-W).............................................................................................................. 40
Specification.............................................................................................................................................. 40
Dimension.................................................................................................................................................. 41
DS-2CD832F(-E)............................................................................................................................................... 42
Specification.............................................................................................................................................. 42
Dimension.................................................................................................................................................. 43
DS-2CD802/812/892P(N)-IR1(IR3)(IR5)......................................................................................................... 44
Specification.............................................................................................................................................. 44
Dimension.................................................................................................................................................. 45
DS-2CD702/712/792PF (NF)(-E)...................................................................................................................... 46
Specification.............................................................................................................................................. 46
Dimension.................................................................................................................................................. 47
DS-2CD732F(-E)............................................................................................................................................... 48
Specification.............................................................................................................................................. 48

User Manual of Network Camera
4
4
Dimension.................................................................................................................................................. 49

User Manual of Network Camera
1
1
Chapter 1 Introduction
Network camera is a kind of embedded digital surveillance product that combines the features
of both traditional analog camera and net DVS (Digital Video Server). Due to the embedded Linux
operation system and the latest Davinci hardware platform of TI, the system operates with high
scheduling efficiency. Furthermore, the firmware is burned in the flash, which makes the product
small, reliable and highly stable.
1.1 Network camera Functions and Features
Functions:
Network Function :support the TCP/IP protocols(TCP/IP,HTTP,DHCP,DNS,RTSP RTCP,PPPoE,
Furthermore,FTP,SMTP,NTP,SNMP addible),and IE browsing.
Heartbeat Function: The server can acquire real time operating performance of the network
camera through the heartbeat function.
Alarm Function: The product includes 1 channel of alarm signal input and 1 channel of alarm
on/off output, and supports motion detection, video missing, mask alarm and external alarm
input.(Get details in Specification)
Voice Talking：Support bidirectional voice talking and monomial voice broadcasting.
User Management: Support multilevel right management. The administrator can create up to
15 separate users with different right levels, which highly improves the system security.
The product offers a 10M/100M self-adaptive Ethernet interface.
Support set the parameters, browses real time videos or checks the camera performance
through software or IE, and gets external alarming and stores the compressed bit rate through
network.
Support remote upgrades and maintenance.
RS-485 supports monomial transparent channel function so that clients on remote PC can
control the serial devices.
Compression Functions:
Support 1 channel video signal and 25fps in Pal (704 × 576) ,30fps in NTSC (704 × 480) real time
H.264 video Encoding standard compression, which supports both variable bit rate and variable
frame rate; besides, you can self-define both the video quality and its compressed bit rate.
Support resolution of 4CIF (PAL:704 × 576, NTSC:704 × 480), DCIF (PAL:528 × 384, NTSC:528 ×
320), 2CIF (PAL:704 × 288, NTSC:704 × 240), CIF (PAL:352 × 288, NTSC:352 × 240),QCIF (PAL:176
× 144, NTSC:176 × 120).
Remote Control:
The product offers a 10M/100M self-adaptive Ethernet interface.

User Manual of Network Camera
2
2
Support TCP / IP, HTTP, DNS, RTP / RTCP, PPPoE protocols.
Set the parameters, browse real time videos or check the camera performance through
software or IE, and get external alarming and store the compressed bit rate through network.
Support remote upgrades and maintenance.
RS-485 supports monomial transparent channel function so that clients on remote PC can
control the serial devices.
Support NAS storage.
1.2 Applications
This camera is ideal for remote control network applications. E.g.:
1. Network surveillance for ATM, bank counters, supermarkets and factories.
2. Remote surveillance for nursing homes, kindergartens and schools.
3. AI janitors.
4. AI building/district management systems.
5. Self-service systems of power plants.
6. Outdoor monitoring systems for bridges, tunnels and crossroad traffic.
7. Pipelining and warehouse monitoring.
8. 24-hour monitoring for road traffic.
9. Remote monitoring of forest and water resources.
10. Surveillance for airdrome, railway station, bus stop etc.

User Manual of Network Camera
3
3
Chapter 2 Installation
Notes：
1. Please check if all the items on the package list have been included with your camera.
2. Read the following contents carefully before the installation.
3. Make sure that all the related equipment is power-off during the installation.
4. Check the power supply to prevent any damage caused by mismatching problems.
5. If the product does not operate properly, please contact your dealer or the nearest service
center. Never attempt to disassemble the camera yourself. Users are responsible for any
problem caused by modification or repairing without authorization.
2.1 Panels Description
2.1.1 Side Elevation of the Camera
Fig 2.1.1 Side Elevation of DS-2CD832F(-E) network camera
Fig 2.1.2 Side Elevation of DS-2CD802, DS-2CD812, DS-2CD892 series camera

User Manual of Network Camera
4
4
Fig 2.1.3 Side Elevation of DS-2CD702,DS-2CD712,DS-2CD732,DS-2CD792 series camera
2.1.2 Rear Panel Description
Fig. 2.1.4 Rear Panel of DS-2CD832F(-E)
1. Standard Ethernet (UTP) RJ45 (10M/100M self-adaptive).
2. 1 channel voice talk input,3.5mm audio interface, 2.0～2.4Vp-p, 1kΩ.
3. 1 channel voice talk output, 3.5mm audio interface, electric line level, 600Ω.
4. 1 channel alarm output (1A 1B). 1 channel alarm input signal (IN,G). RS-485 bus interface
(T＋T-).
5. SD card slot (Support SDHC ).
