unication G Series User manual
Note: Please read the following sections before using the
Charger Amplifier for Digital G-Series Voice Pager.
※IMPORTANT SAFETY INFORMATION
To ensure the safe use of this product:
Use your charger amplifier only with the supplied power adaptor.
Use the batteries provided by Unication for your G-Series product.
Keep your charger amplifier away from high temperature, high humidity, dust, chemicals and
corrosive materials.
Do not disassemble your charger amplifier or power adaptor.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2
OVERVIEW
A-1 Standard Package:
Standard package contains:
Charger Amplifier for Digital G Series Pager
Adaptor
External Antenna
Manual
3
A
Item Specification
Charging Type Main Charging Socket For one Digital G-Series Voice Pager
BT Charging Socket For USB Device (BT headset supported)
Power Supply Adaptor Input / Output Input: 100~240VAC / 50~60 Hz Output:12Vdc /1.5A
Normal Charge Current 900 mA / 5.0 V
Full Recharge Time 3Hours
SPL Alert Output ≧106 dBSPL
SpeechOutput ≧104 dBSPL
Audio Distortion • Audio Distortion:
Real Time Audio: < 5 % (Electrical) / < 6 %(Acoustic)
•Audio Distortion:
Stored-Voice Playback: < 8 % (Electrical) / < 10 % (Acoustic)
External I/O Audio Out 3.5mm Audio Jack *1
Ext. Antenna Port BNC Jack *1
USB Charging Port USB A-Type *1
Controller Port RS485 (DB-9 Female) *1
Power Input (DC) 12Vdc / 1.5A
Horn Speaker Port 4 Pin Port
6 Pin DIN Port 6 Pin DIN Port
LED Indicators Power LED Green
Charging LED Red / Orange /Green
Alarm LED Orange /Green
Horn Speaker LED Orange /Green
Physical Dimensions 162(L) x 115(W) x 53(H) mm
Weight 600 g
Handing Temperature OperationTemperature 0 ~ + 40°C
StorageTemperature -10 ~ + 60 °C
Certification CE, FCC, RoHs,UL, CUL
4
A-2 Specification:
51 mm
116 mm
162 mm
F1
F2
5
Item Description
F1 Speaker
F2 Volume ControlKnob
APPEARANCE
B-1 Front View:
OVERVIEW
B
F1
F9 F6
F4
F5
F3
F8 F7
6
Item Description
F3 Pager Socket
F4 Alert Light
F5 Reset Button
No. Item Color LED Action Description
F6 Power LED Green Steady Charger Amplifier Power Turn ON.
F7 Charging LED Orange Steady Pager is charging.
Green Steady Pager is fully charged.
F8 Alarm LED Off Steady Alarm device is not connected.
Orange Steady Alarm device is connected, no
messages received.
Green Steady Alarm device is connected, receiving
alarm messages.
F9 Horn
Speaker
LED
Off Horn Speaker is not connected.
Orange Steady Horn Speaker is connected, no
message received.
Green Steady Horn Speaker is connected, Horn
Speaker message received.
B-3 LED Indicators:
B-2 Top View:
R1 R2 R3 R4 R5 R6 R7
Item Description
R1 External Antenna Port (BNC)
R2 Horn Speaker 4 Pin Horn Port
R3 Controller Port (RJ485)
R4 Alarm Device 6 Pin Din Port
R5 Audio Out
R6 USB Charging Port
R7 Power Input (DC)
7
B-4 Rear View:
1Power Source:
A Connect the Charger Amplifier to power outlet (110/60Hz) with the supplied Adaptor.
B Connect the Charger Amplifier to vehicle’s lighter socket with optional vehicle charger cable.
2Charging Digital G Series Pager:
Insert Digital G Series Voice Pager into Charger Amplifier’s Pager Socket tightly. The charging
process starts with Charging LED indicator shows orange. When the battery is fully charged, the
LED turns green.
3Charging USB device:
Connect the USB device to the Charger Amplifier’s USB Charging Port with USB Cable.
4Voice Message Amplification:
Turn on Digital G Series Voice Pager and put into Charger Amplifier’s pager socket.
When the pager receives voice messages, it will be amplified based on the volume knob setting.
8
OERATION
OVERVIEW
C
6789
5 4 3 2 1
PIN 1
Horn Relay
Contact
PIN 1
Audio
PIN 2
Horn Relay
Contact
PIN 3
Ground
(Audio)
7 Controller Port:(RJ485)
The Controller Port is for external LED or Uni-controller use.
PIN 3: RS485_A
PIN 2: RS485_B
PIN 3: RS485_A
PIN 2: RS485_B
8 3.5mm Audio Jack:
This connections audio output is controlled by the volume knob on the device and mutes the onboard
speaker when in use.
5External Antenna Port:
Please select antenna depending on the frequency use. Unication provides the antenna options below:
UHF1750~860 MHz
UHF2406~512 MHz
VHF 136~174MHz
Low Band 30~88 MHz
6Horn Speaker 4Pin Horn Port:
PIN 1 Horn Relay Contact
PIN 2 Horn Relay Contact
PIN 3 Ground (Audio)
PIN 4 Audio*
9
PIN 2
Relay Dry
Contact
PIN 3
Relay Dry
Contact
PIN 1
Audio
PIN 5
Relay Closure
Timing
PIN 4
Relay Closure
Timing
PIN 1 Audio*
PIN 2 Relay Dry Contact
PIN 3 Relay Dry Contact
PIN 4 Relay Closure Timing
PIN 5 Relay Closure Timing
PIN 6 Ground (Audio)
*This Connection provides line level audio not controlled by the volume knob. Using this
connection will not mute the onboard speaker.
10 USB Charging Port:
This port is for charging USB device and Bluetooth earpiece. (5V/300mA)
11 Power Input :
The Charger Amplifier for Digital G Series Pager use a 12V/1.5A DC ADAPTOR,
power input is 100~240VAC with maximum power 18W. Please connect to the power
outlet with supplied power adaptor.
9Alarm Device 6Pin Din Port:
The Charger Amplifier for Digital G-Series Pager provides 2 modes to select via Side Switch
1. M5 Mode (default)
2. Horn Speaker Mode
DIN Jack Pin Definition:
10
PIN 6
Ground
(Audio)
11
12 External Equipment Control
The Charger Amplifier provides a variety of I/0 for external device control.
12-1. Horn Speaker (Loudspeaker)
Step 1. Insert the G-Series Pager, turned on, into the Charger Amplifier.
Step 2. Select RCA connector and connect the external equipment.
Step 3. When any message is received, the relay closure is asserted and audio is active.
Step 4. Audio can be terminated by either shutting the G5 off or depressing the Reset button
on the G5.
12-2. Fire Alert Indicator
Step 1. Insert the G-Series Pager, turned on, into the Charger Amplifier.
Step 2. Using the DIN Connector, connect the external equipment to the appropriate signaling
pins.
•Pins 1 and 6 are outputs and are used to control a remote speaker.
•Pins 2 and 3 are normally open dry contacts and close when a page is received.
•Pins 4 and 5 are not utilized on the G4/G5 Amplified Charger, all timing of the dry contacts
is controlled via the Pager Programing Software.
Step 3. Upon receiving a page, the relay and audio output are activated.
13 Amp Charger Connectors
G-Series Charger Amp Terminal Connector Block
Part Number: 2811923-AMP
G-Series Charger Amp Din Connector
Part Number: CP-1050-ND
