unication G1 User manual

Page1
封面

Page2
1. PREFACE .......................................................................................................................................3
1-1 IMPORTANT SAFETY INFORMATION........................................................................3
2. PACKAGE CONTENT .................................................................................................................4
2-1 STANDARD PACKAGE.....................................................................................................4
2-2 OPTIONAL PACKAGE .....................................................................................................4
3. APPEARANCE ..............................................................................................................................5
3-1 FRONT VIEW .....................................................................................................................5
3-2 REAR VIEW ........................................................................................................................6
3-3 LED INDICATOR ...............................................................................................................8
4. INSTALLATION............................................................................................................................9
4-1 Power Connection ................................................................................................................9
4-2 External Antenna Installation ............................................................................................9
5. Function Instruction ......................................................................................................................9
5-1 CHARGING.........................................................................................................................9
5-1-1 CHARGING G1 UNIT ............................................................................................9
5-1-2 CHARGING SPARE BATTERY..........................................................................10
5-1-3 CHARGING EXTERNAL BLUETOOTH HEADSET......................................10
5-2 Voice Message Amplify ...................................................................................................... 11
5-3 External Equipment .......................................................................................................... 11
5-3-1 Horn Speaker.......................................................................................................... 11
5-3-2 Fire Alert Indicator ................................................................................................ 11
6. SPECIFICATION ........................................................................................................................12
6-1 GENERAL SPECIFICATION .........................................................................................12
6-2 POWER ADAPTOR SPECIFICATION .........................................................................13
6-3 EXTERNAL ANTENNA SPECIFICATION ..................................................................13
Index

Page3
1. PREFACE
Unication thanks you for purchasing the G1 product. Before using the G1 charger amplifier, please read this manual and follow the instructions for
correct charging and installation of the other accessories.
1-1 IMPORTANT SAFETY INFORMATION
This charger is used for the G1 pager only. Please be aware of the following important information for the safety on using the G1 charger amplifier.
※Use your charger only with the original power adapter.
※Do not put a pager with a non-rechargeable battery inside into the charger.
(Using a rechargeable battery provided by Unication is recommended.)
※Keep your charger away from any dangerous environments with high temperature, high humidity,
dust, chemicals and corrosive materials.
※Do not disassemble your charger or power adapter.
(暫時先放 FCC 文字)

Page4
2. PACKAGE CONTENT
2-1 STANDARD PACKAGE
The G1 charger amplifier standard package contains the following items ：
ITEM Charger
Amplifier
DC Power
Adapter
External
Antenna User’s Guide
Illustration
※Referred picture
2-2 OPTIONAL PACKAGE
The G1 charger amplifier optional package contains the following items ：
ITEM
Vehicular Charging
Adaptor Cable
Illustration
※Referred picture

Page5
3. APPEARANCE
3-1 FRONT VIEW

Page6
標號改成 F1、F2、、、…….
9. Alert LED
3-2 REAR VIEW

Page7
標號改成 R1、R2、、、…….
2. 4 Pin Connector Socket
6 改成 Bluetooth Headset Charging Jack

Page8
3-3 LED INDICATOR
G1 Charger Amplifier 提供下列不同的 LED 指示燈以顯示 Charger 不同的狀態：
No. LED Status
Color
LED Action Definition
1
Charger AMP.
Power LED
& G1
Charging LED
Green
Constant light
1 second Standby (Power On)
Orange
Constant light G1 Battery Charging
Green
Constant light G1Battey Full
Red
Blink G1 Battery Error
2
Spare Battery 1
Charging LED
& Spare Battery 2
Charging LED
Orange
Constant light Spare Battery Charging
Green
Constant light Spare Battery Full
Red
Blink Spare Battery Error
3
Alert
LED
Green
Blink Alert Message Incoming
4
Horn Speaker
Status LED
Green
Blink Horn Speaker Active

Page9
4. INSTALLATION
4-1 Power Connection
G1 Charger Amplifier Power Source Option：
a. DC 12V Power Adapter－Plug Adapter plug on, and then plug DC Jack plug into G1 Charger
Amplifier DC12V power socket.
b. Vehicular Charging Adaptor Cable－Plug the vehicular charging adaptor cable into power
socket on the vehicle, and then plug DC Jack plug into G1 Charger Amplifier DC12V power
socket.
4-2 External Antenna Installation
G1 Charger Amplifier External Antenna Option:
a. Low Band Antenna
b. VHF/UHF
Please follow the instruction of the external antenna to install the antenna.
5. Function Instruction
5-1 CHARGING
5-1-1 CHARGING G1 UNIT
G1 Charger Amplifier should be used to G1 pager only. Before charging the G1 pager, please make
sure that the batteries inside the pager are rechargeable (Ni-MH) type battery.
(Recommendation: Please use the battery provided by Unication.)
Step 1. Please insert the pager into the charger’s pager pocket as in the following illustration:
Step 2. Once the pager is inserted correctly the charger amplifier will detect the battery and start
charging. When the pager is being charged, the charging LED will turn into orange.
Step 3. When the pager is fully charged, the charging LED will turn into green.
NOTE: When the charging hour or the charging voltage is exceeding, the charging LED will turn

Page10
red and flash to indicate the abnormal operations. Please remove the pager from the
charger to stop charging.
NOTE: The charging green LED will remain flashing if ambient temperature is below 0℃or
higher than 50℃. Please remove the pager from the charger to stop charging.
5-1-2 CHARGING SPARE BATTERY
The Unication’s G1 charger amplifier offers Ni-MH spare rechargeable batteries charging
functionality.
Step 1. Put the rechargeable batteries into battery pocket as following illustration:
(Recommendation: Please use the battery provided by Unication.)
Step 2. Once the Ni- MH rechargeable batteries are inserted correctly, the charger amplifier will
detect the battery and start charging. When the rechargeable batteries are being charged, the
charging LED will turn into orange.
Step 3. When the rechargeable batteries are fully charged, the LED will turn into green.
Step 4. When exceeding normal charging hour or charging voltage, the charging LED will turn red
and flash to indicate the abnormal operations. Please remove the spare batteries from the
charger amplifier to stop charging.
5-1-3 CHARGING EXTERNAL BLUETOOTH HEADSET
The Unication’s G1 charger amplifier offers the external Bluetooth headset charging functionality.
(※Please make sure the charging specification of your Bluetooth headset meets the charging
limitation (4.5 V ~ 6.5 V) of the G1 Charger Amplifier)
Step 1. Insert the Bluetooth charging cable to the Charger Bluetooth headset charging jack as
following illustration.
Step 2. Connect Bluetooth headset with its charging cable

Page11
5-2 Voice Message Amplify
G1 Charger Amplifier supports to amplify the voice message of G1 Voice Pager as the following
steps:
Step 1. Put G1 Voice Pager on G1 Charger Amplifier.
Step 2. When G1 receives RF signal, G1 Charger Amplifier activates Speaker audio and plays voice
messages automatically.
Step 3. When user pulls out G1Pager from Charger Amplifier, Charger Amplifier stops amplifying
voice message. User can also turn off the G1 Pager to stop the amplifier.
5-3 External Equipment
G1 Charger Amplifier supports external equipment as Horn Speaker and Fire Alert Indicator. Also,
G1 Charger Amplifier can link to Unication Controller to control the power or level of external
equipments.
5-3-1 Horn Speaker
G1 Charger Amplifier support external Horn Speaker as the following steps:
Step 1. Put G1 Voice Pager on G1 Charger Amplifier.
Step 2. Link Horn Speaker Connector to Horn Speaker.
Step 3. When G1 receives RF signal, G1 Charger Amplifier activates Speaker audio and external
Horn Speaker, then plays voice messages automatically.
Step 4. When user pulls out G1Pager from Charger Amplifier, Charger Amplifier stops Horn
Speaker amplifying voice message.
Step 5. User can also turn off the G1 Pager to stop the Horn Speaker.
※Horn Speaker Connector Pin locates on rear side, following is the definition of 4 PIN:
5-3-2 Fire Alert Indicator
G1 Charger Amplifier support external Fire Alert Indicator as the following steps:
Step 1.Put G1 Voice Pager on G1 Charger Amplifier.
Step 2.Link DIN Jack cable to Fire Alert Indicator。
Step 3. When G1 Pager receive RF signals, G1 Charger Amplifier activates Fire Alert Indicator.

Page12
PI N 1
A udi o
PI N 4
Relay Closure Timing
PI N 2
Relay Dry Contact
PI N 5
Relay Closure Timing
PI N 3
Relay Dry Contact
PI N 6
Ground (A udi o)
■ACCESSORY
Note: When PIN4 and PIN5 of DIN Jack are “Open”, Fire Alert Indicator blinks 10 seconds.
Otherwise, Fire Alert Indicator continues light till users press Reset Button when PIN4 and PIN5
are closure.
6. SPECIFICATION
6-1 GENERAL SPECIFICATION
Item Specification
Charging Type
Main Charging Slot
For G1Pager *1
Spare Charging Slot
For Spare Ni-MH Battery AAA * 2
BT Charging Socket
For BT Headset (USB A-Type)
Power Supply
Adaptor Input / Output
Input : 100~240VAC / 50~60 Hz
Output :12Vdc / 1.5A
Normal Charge Current
800mA/2.4V (G1Pager)
800mA/1.2V (Spare Battery AAA*1)
80mA/5.0V (BT Headset )
Full Recharge Time
2.5 Hours
SPL
Alert output
≧
106 dB
External I/O
Audio Out 3.5 Ø Earphone Jack *1
Ext. Antenna Connector BNC Jack *1
Bluetooth Charging Port USB A-Type *1
Data Transfer RS485 (DB-9 Female) *1
DC Jack 12Vdc / 1.5A
Connector Socket 4 Pin Connector Socket (For External Horn Speaker)
DIN Jack 6 Pin DIN Jack
Physical Dimensions 162(L) x 115(W) x 53(H) mm
Handing
Operation Temperature
0 ~ + 40
℃

Page13
Temperature
Storage Temperature
-10 ~ + 60
℃
Certification
CE,FCC,IC, RoHs, UL,
6-2 POWER ADAPTOR SPECIFICATION
Item Specification
Input Voltage AC 90-265V ; 47~63Hz
Output Voltage DC 12V
Output Current 1.5A
Adaptor Power
18W
DC Power Cord Length
1.8m
AC Plug Type
North America, Europe, Australia and UK Standard
Adaptor Efficiency 82.6% Meet Energy Star Standard
Charger Charging Specification CC mode, Constant Current
CV mode, Constant Voltage
6-3 EXTERNAL ANTENNA SPECIFICATION
BAND
ITEM
UHF Band VHF Band
Operation Frequency
Range 380 ～512MHz 138 ～174MHz
Input Return Loss (VSWR)
≦2 ≦2
Antenna Gain ≧-5dBI ≧-8dBI
Length ≦60cm ≦60cm
Weight ≦300g ≦300g
Terminal Impedance 50 ohm 50 ohm
封底
