Uniclass KLEv2 Series User manual

User's Manual
KLEv2 Series
KVM Link Extender
Generation 2
Version: 1.0

2
KLEv2
Introduction..................................................................................................................3
Overview........................................................................................................................3
Features .........................................................................................................................3
Package contents ........................................................................................................3
Specifications ...............................................................................................................4
Product overview ........................................................................................................5
Front view..................................................................................................................5
Rear view ...................................................................................................................6
Console Connection ...................................................................................................7
KLEv2..........................................................................................................................7
KLEv2P........................................................................................................................8
Connect to Server/Video Source.............................................................................9
KLEv2..........................................................................................................................9
KLEv2P..................................................................................................................... 10
Operation ................................................................................................................... 11
Configuring the Server ....................................................................................... 11
KLEv2 Default Setting ......................................................................................... 12
Configuring KLEv2 Network Setting ............................................................... 12
Configuring TCP Port Base for the KLEv2....................................................... 13
Accessing the Remote Server ........................................................................... 14
Title Bar Information ........................................................................................... 16
KLEv2 Web Management Interface................................................................. 17
Viewers Menu Bar ................................................................................................ 20
Connection Dialog/ Detail Options ................................................................ 21
KCenter........................................................................................................................ 23
System requirement ............................................................................................ 23
Installation ............................................................................................................. 24
Operation............................................................................................................... 24
Detecting devices ................................................................................................ 25
Group Action ........................................................................................................ 29
Report ..................................................................................................................... 30
Settings................................................................................................................... 33
Static Device Management................................................................................ 36
Radius Clients........................................................................................................ 37
Frequently Asked Questions ................................................................................. 38
Technical support..................................................................................................... 39
FCC / CE Statements ................................................................................................ 39

3
KLEv2
Introduction
Thank you for purchasing our KLEv2 Series. We recommend that you read this manual
thoroughly and retain it for future reference.
Overview
KLEv2 (series) is the next generation of IP-based KVM Link Extender for remote server
management. It allows virtual management of server(s) or KVM(s) over the Internet. In
addition to support for secured access via 1024-bit PKI authentication, 256-bit SSL data
encryption, LDAP, RADIUS, and Active Directory authentication; it has virtualization of ISO
file that allowed accessing of remote drive to help manage server.
The Generation 2 of KLE provides a solid, reliable, and physical extension of keyboard,
mouse, and video to nearly unlimited distance. Video supports for both analog and digital
video through the DVI-I connector. Using two passive DVI to VGA adapters will provide
VGA connection at both the console and system ends.
KLEv2 options give user total control from the pre-boot stage such as BIOS-level CMOS
setting with USB interface, power cycling, and audio feedback. Along with the virtual
media, you can rebuild the operating system of any server that KLEv2 connecting on.
With properly plan KVM infrastructure, you can truly feel confident in your access to your
systems.
Features
■ Full-featured IP-based Remote Control Solution for server management
■ DVI/VGA video, USB keyboard, and mouse extension over the Internet
■ 1920 x 1200 resolution for clear and sharp video output
■ Supports virtual media/ISO
■ Supports audio and power management interface
■ Build-in 2-Port Ethernet Hub
■ Total transparent control
Package contents
■ KLEv2 or KLEv2P unit x1
■ Power adapter x1 (The power adapter may vary depending on models)
■ AC power cord x 1 (KLEv2P only)
■ User manual x1
■ KLEv2 Support CD x1
■ DVI-A to VGA Adapter x1
■ WiFi dongle x1 (optional)

4
KLEv2
Specifications
Model KLEv2 KLEv2P
Server/KVM Video Connector 1 x DVI-I Female
Server/KVM USB Connector 1 x USB Type B Female
Server/KVM Audio Connector 1 x 3.5mm Stereo Earphone Jack Female
Console Video Connector 1 x DVI-I Female
Console Audio Connector 1 x 3.5mm Stereo Earphone Jack Female
Console USB Connector 2 x USB 2.0 Type A Female Connector
Ethernet Connector 2 x RJ45 Female, 10/100 Base-T with auto-sensing
Push Button - 1 x Momentary
LEDs 2 (Power, Video) 3 (Power, Video, Switch)
Power Control Port 1 x RJ11
Video Resolution 1920 x 1200
Operation Temperature 0° ~40° C
Storage Temperature -20° ~60° C
Humidity Limits 0 ~90% RH, Non-Non-condensing
Housing Metal
Dimension 120 x 135 x 25 mm 220 x 135 x 42 mm
Upgrade Port 1 x USB Type A Female
Safety / Emission CE、FCC

5
KLEv2
Product overview
Front view
KLEv2
AB
VDO PWR REMOTE I/O
CONSOLE
Remote Power Controller
AB
VDO PWR
CONSOLE ETHERNET
ON
SWITCH
1 2 3 4 5 6 7 8
KLEv2P
No. Item Description
1 Video LED Video source in status.
2 Power LED Power on status.
3 USB Device Ports Plug in USB keyboard, USB mouse, or USB storage
device.
4 Speaker Port Plug in stereo analog speaker.
5 DVI-I Video Out Port Connect to DVI-D monitor or with a passive converter,
connect to analog monitor
6 2-Ports Ethernet Hub Connect to a network.
7 AC Power Switch Turn on/off the power.
8 AC Power LED AC power on status.

6
KLEv2
Rear view
KLEv2
DC 5V PC SIDE
AUDIO
PWR CTRL WiFi
1 3 4 5 6 7
KLEv2P
AUDIO
PWR CTRL WiFi
PC SIDE
AC
OUT
AC
IN
1 2 3 4 5 6 7
No. Item Description
1 Power In Socket Plug power cable into this socket.
2 Power Out Socket Plug cable of the device being powered
3 DVI-I Video In Port Connect to DVI-D PC system/ video source or with a passive
converter, connect to analog VGA
4 USB Connection Connect to PC system/ server
5 Audio In Port Connect to PC system/ audio source
6Power Control Port Connect to external power control unit
7WiFi port Connect to a WiFi dongle (optional)

7
KLEv2
Console Connection
* The diagrams illustrated in the chapter are examples, the actual application may vary.
All illustrated accessories and monitors are not included in the package, it is for reference only.
KLEv2
■ Connect a keyboard to the USB Type A connector which a keyboard icon marked on the
unit.
■ Connect a mouse to the USB Type A connector which a mouse icon marked on the unit.
■ Connect a speaker to the audio jack.
■Connect to DVI or VGA monitor. Connecting to VGA monitor would require passive DVI-A
to VGA converter.
■ Connect to your local network using Cat5/6 cable.
■ Plug the power cord to a power socket (the power cord/adapter may vary, it is depending
on the models).

8
KLEv2
KLEv2P
AB
VDO PWR
CONSOLE ETHERNET
ON
SWITCH Remote Power Controller
■ Connect a keyboard to the USB Type A connector which a keyboard icon marked on the
unit.
■ Connect a mouse to the USB Type A connector which a mouse icon marked on the unit.
■ Connect a speaker to the audio jack.
■Connect to DVI or VGA monitor. Connecting to VGA monitor would require passive DVI-A
to VGA converter.
■ Connect to your local network using Cat5/6 cable.
■ Plug the power cord to a power socket (the power cord/adapter may vary, it is depending
on the models).

9
KLEv2
Connect to Server/Video Source
KLEv2
DC 5V PC SIDE
AUDIO
PWR CTRL WiFi
WiFi
Dongle
■ Plug PC Side USB to the USB ports of Server.
Note: Make sure the driver of USB peripheral on the server/source has been installed if
necessary before plugging into KLEv2.
■ Connect the PC Side DVI to the DVI Video Out of the Server. Connecting using VGA
would require passive DVI-A to VGA converter.
■ Plug the PC Side Audio In to the Speaker Out of the Server.
■ Connect to a wireless network by plugging a WiFi dongle into the WiFi port (optional).

10
KLEv2
KLEv2P
AUDIO
PC SIDE
AC
OUT
AC
IN WiFi
Dongle
PWR CTRL WiFi
■ Plug PC Side USB to the USB ports of Server.
Note: Make sure the driver of USB peripheral on the server/source has been installed if
necessary before plugging into KLEv2.
■ Connect the PC Side DVI to the DVI Video Out of the Server. Connecting using VGA
would require passive DVI-A to VGA converter.
■ Plug the PC Side Audio In to the Speaker Out of the Server.
■ Plug the Power cable of the Server to the AC Out.
■ Plug the Power cord to the power socket AC In.
■ Connect to a wireless network by plugging a WiFi dongle into the WiFi port (optional).

11
KLEv2
Operation
1. Due to the topological data flow requirement, please follow the previous chapter to
connect power, PC, monitors and peripherals. Start from the console devices, press the
power button to turn it on, and then plug the power cord/adapter to the power socket.
2. Turn on the connected computer, the image will be outputted to DVI monitor.
3. The keyboard and mouse will be detected after turning on the computer.
* Some older computers with USB interface might need to manually enable the USB option in the BIOS settings before you can use
any USB devices. If your USB interface does not work, please check the USB option in the BIOS.
* If you see Windows 95/98/SE or Mac OS and has not yet installed a USB mouse on your computer, there might be an error message
telling you that mouse is not detected and prompting you to decide whether to ignore the same message in the future, and yet you
will find there is no mouse movement to disable this message. So it is suggested that you should install your USB mouse on your
computer first before connecting to this KVM switch.
Configuring the Server
There are several aspects that have to be taken into consideration when configuring you
computer/server for the best performance:
(1) Refrain from selecting too peculiar video resolution mode and choose resolution that's within KLEv2's
standard support.
(2) Turn off special transition effects on your operating system such as fade.
(3) Adjust the server desktop background preferably plain solid colors with simple designs.
(4) Please leave enough bandwidth on the network for KLEv2 to operate.
Below is a table of the KLEv2 supported video resolution, if there is problem of abnormal
display or no video, suggest using a more standard display mode from list below.
Resolution Refresh rates (HZ)
640x480 60
720x480 60
800X600 60
1024X768 60
1152X864 60
1280X720 50/59/60
1280X768 60
1280X800 60
1280X960 60
1280X1024 60
1440X1050 60
1600X1200 60
1920X1080 50/59/60
1920X1200 60
2048x1152 60

12
KLEv2
KLEv2 Default Setting
■The factory default network settings for KLEv2 are as follows:
IPv4 Address: 192.168.1.200
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.1.254
DNS Servers: 192.168.1.254
■The default access KLEv2 Web Browser Management Interface:
https://192.168.1.200:5908
■ The default administrator account name and password:
User name: superuser
Password: superu
Configuring KLEv2 Network Setting
■Temporary create a isolated network, not connected to the local or company network,
with KLEv2 and a computer that has a browser. Connect with the KLEv2 Remote I/O or
Ethernet Port, by having the computer in the same subnet as the KLEv2.
■Using the computer browser, login into the KLEv2 Web Browser Management Interface.
■Expand Main on the left menu --> Go to Networks to modify the IP settings in
accordance to your network or the information provided by your network administrator.
Click the Store Settings button to save the network setting. Then press the Soft Restart
to apply the settings. Once it restarts, you can add KLEv2 to your network and access to
KLEv2 will need to use the new network information.

13
KLEv2
■For example, the new KLEv2 Web Browser Management Interface will be
https://<IP_address>:<TCP Port Base + 8>
In my case, my IP Address is 192.168.1.192 and the TCP Port Base is 5920. To access my
KLEv2 Web Browser Management Interface, it is https://192.168.1.192:5928
Configuring TCP Port Base for the KLEv2
■There are two main methods of accessing the KLEv2 to have virtual presence of using
your computing resources.
(1) Separate independent program viewer. This can be downloaded from the KLEv2 Web
Management Interface -->Download --> Viewers. You have a choice of Windows
viewer or OS independent Java viewer.
(2) Java Applet viewer which uses your browser to access.
* The system that you are viewing the distant computing resource must have the latest Java. The viewer will check and initiate
update if needed.
* When login into the KLEv2 Web Management Interface, your browser may provide a website security certificate warning. Press
"Continue to this website (not recommended)" until the web certificate is properly install onto the KLEv2
* Network Administrator is responsible for safety of local network environment. Make sure you pass information on the KLEv2 to the
Network Administrator so that can make adjustment to the firewall, network configuration, and router for the KLEv2 to function
properly.

14
KLEv2
■The TCP Port Base will be relevant to both methods of viewers.
(1) Separate viewer uses the set <TCP Port Base> for access
(2) Browser Java Applet viewer uses the set <TCP Port Base + 8> for access.
■To change the TCP Port Base by login to the KLEv2 Web Management Interface -->Main
(on the left scroll down menu) -->Networks.
* To start using the new settings, Press Store Settings, then Press Soft Restart. When login into the KLEv2, please use the new network
settings.
Accessing the Remote Server
■Please select methods of accessing the KLEv2 to have virtual presence of using your
computing resources.
(1) Separate independent program viewer. This can be downloaded from the KLEv2 Web
Management Interface --> Download --> Viewers. You have a choice of Windows
viewer or OS independent Java viewer.
(2) Java Applet viewer which uses your browser to access.
Applications Viewers
■For Windows' Viewer: This viewer can be use on Windows 2000 or newer platform. First
time, please download and install the viewer.

15
KLEv2
1. Click (Viewer Link icon) to access the Windows' viewer. If insufficient rights is granted
to the viewer, User Access Control will pop up for authorization.
2. In the Connection Dialog, keyin the network information
to access KLEv2, then press Connect. If found, it will
come back and ask for KLEv2 User Authentication, key in
the User ID and Password for access.
■ For Java Viewer, this viewer can be use on any system that supports the latest version of
Java. If you continuously use the current system to access through Java, recommend the
jar file be save at a convenient location. Run or double click the jar file and it will pop up
the Connection Dialog similar to the Windows' viewer.
Java Applet Viewer
■ The Java Applet Viewer can be use on any browser that has been updated to the latest
version of Java. User of the Java Applet needs to access it through the KLEv2 Web
Management Interface.
*The port number for the browser is <TCP Port Base + 8>. So it would be 8 more than the application viewer.
Press the Viewer Applet in the Web Management. There is an added level of Java's
authorization before the KLEv2 User Authentication.

16
KLEv2
Title Bar Information
The application title bar provides some basic information for your reference. These data are
important for the technician when requested. Changing these basic setting will be further
introduce later on in the manual. Will use below example title as a reference.
- SvrName - The name given to the current video server
- CompName - The name given to the connected computer
- 33 ms - The time it takes to capture the image
- 0 ms - The time it used to transmit the video refresh
- shared - Currently session set mode
- 256-bit encryption - Currently used encryption mode
The same information can be found in the applet under the Information Menu -->
Connection Information
The below information is KLEv2_TEST server, with unnamed computer, 47 ms to capture,
0 ms to refresh, under shared mode, with 256-bit encryption.

17
KLEv2
KLEv2 Web Management Interface
The Web Management Interface is the main administrative user interface for the KLEv2.
This section will go into the detail use and display of this interface. After you have access
the Web Manager per instruction on page 12. On each of the sub-section title bar has a
Help icon which will provide the detail information on that section.
Download - see page 14.
Main
- Date and Time: Set the Time Region and the Local Time use by the product.
- Security: Upload the Certification Authority and PKI authentication use by the device. Also set the level of security for the SSL viewer
connection. Finally, it sets the User-Password Policy - No Password, Global Password, and User Password.
- Network: - see page 12.
- DDNS: Select the Dynamic DNS to be use.
Virtual Media - settings for ISO file support
- Remote Media: Shows the current link status of the connected virtual media and able to forcefully disconnect it. Setting to enable/
disable Virtual Media function along with writing to Virtual Media feature.
- Local Media: Shows the current link status of the connected ISO shared file on a Window shared in the same network as the target
system and able to forcefully disconnect it. Provide setting for accessing Windows file systems.

18
KLEv2
KVM Server - system settings for the KLEv2
- Server Log: Enable/ disable the recording of the login status information. Also enable/ disable the recording of statistical information
along with clearing the recording log. Once log file reach maximum size, oldest data is erase for new data.
- Video Capture: Sets the video quality of the video. Video quality selection is separated into two sections: digital and analog. The
tradeoff between quality and speed applies to both digital and analog.
- Video Connection: Sets the preference settings on the KLEv2. Items like Server Name, keyboard layout, language type, the mouse
synchronization hotkeys.
- Computer: Sets the information to be use on the connected port. Items like Name to be use, Type of system, Video Type, and Mouse
settings.
- Power Control: Additional settings are display once enabled. Selection is separated into those Power Control Units that comes with
this series (i.e. KLEv2P) and External Power Control Unit. External Power Control uses the Power Control RS232 serial
port.
Users
- Local Database: List and add/ remove the user accounts that can access the product.
- Remote Servers: Selects the authentication server for the product. Additional options are listed once you have selection the
authentication server type.
- Radius Accounting: For enterprise with RADIUS user management, port settings for those using the RADIUS accounting service.
- Connected Users: List the username and description of the those that are currently accessing the remote unit.

19
KLEv2
Alarms
- Emails: Settings to send out Email alarm notification.
- SNMP: Setting on the SNMP manager that will access the enabled alarm data.
- Selection: Setting on type of alarm and action to be performed when activated.
Maintenance
- Software Version: Basic information on the software.
- Networking Status: View current network information status.
- Software Upgrade: Upload firmware file onto device.
- Save/ Restore Settings: Save current configuration for future or upload a previous configuration file.
- Power Control: Shows status information and simple operation on the Power Control Unit. (KLEv2P only).
- Reboot: Emergency use of restarting from the boot loader.
Settings Reminders
■ After you have finish making the modification to the settings, click Store Settings to save the setting on to
the product, then click Soft Restart button in order to apply using the new settings.
■ For better understanding of the setting, it is recommended that you read this manual then click the Help on
the setting page to get the details of the setting that would be upgrade as changing are being made.
* To get the menu bar back in a full screen or disable menu bar mode: place the mouse on
viewer windows top title bar, right click for the mouse menu and click the "Show Menu Bar".
.

20
KLEv2
Viewers Menu Bar
This menu bar provides the daily usage of end user that does not need administrative
rights to the KLEv2. This section will go into the detail use of this menu bar and its display.
Log into the downloaded Windows' Viewer or Java Viewer and follow the instruction per
page 14.
Actions
- Select Computer: This will list the ports on the product using the assigned computer name
per page 16.
- Send Shortcut: This will list the mouse shortcut previously defined. Clicked on the defined
shortcut and it will be send to the remote system.
- Refresh screen: Force update of the viewer screen.
- Send Cntl-Alt-Del: Normal rebooting request by pressing the Control-Alt-Delete keys. When
press these key viewing a remote system, would only reboot the local
system. Mouse click this menu will send these keys to the remote system to
reboot the remote Window operating system.
- Refresh screen: Force update of the viewer screen.
- Power off current computer: This command needs administrator privilege and Power Control
Unit attached for its function. It will power down the attached
port.
- Power on current computer: This command needs administrator privilege and Power Control
Unit attached for its function. It will power up the attached port.
- New Connection (Win): Open another Connection Dialog to login to other remote server.
- Disconnect: Release access to the remote system. It will also automatically close the accessing
Windows' screen.
Settings
- Connection options: Local Cursor and Session adjustment to the connection option.
- Adjust screen: Change the local windows centering reference relative to the remote video and
adjust the brightness and contrast
- Full Display (Win): Full screen view of remote system.
- Show Menu Bar (Win): Enable/ disable of Application Viewer menu bar on top of the viewer.
- Save Settings/ Store Connection Options: Store Password with connection data.
- Device Management: Link to Web Management Interface.
Virtual Medium
- Manage Virtual Medium/ Drive Redirection: Local Cursor and Session adjustment to the connection option.
- Status: Show current Virtual Media connection status
- Hard Disk or CD ROM Drive (Win): Redirect or map local drive onto the remote system. Check "Enable Write Accesses" to enable read/
write, otherwise it would map it as a CD read only drive.
- ISO Image File: File that is in ISO format can be map onto remote system.
- Disconnect Button: Release the Virtual Media connection/ mapping.
