USER MANUAL
User Guide
FOX T/R USB
Extender Plus
USB Extenders
Fiber Optic Extenders for USB Peripherals
68-2665-01 Rev. E
08 21


Copyright
© 2016-2021 Extron. All rights reserved. www.extron.com
Trademarks
All trademarks mentioned in this guide are the properties of their respective owners.
The following registered trademarks (®), registered service marks (SM), and trademarks (TM) are the property of RGBSystems, Inc. or Extron (see the
current list of trademarks on the Terms of Use page at www.extron.com):
Registered Trademarks (®)
Extron, Cable Cubby, ControlScript, CrossPoint, DTP, eBUS, EDID Manager, EDID Minder, eLink, Flat Field, FlexOS, Glitch Free, GlobalConfigurator,
GlobalScripter, GlobalViewer, Hideaway, HyperLane, IPIntercom, IPLink, KeyMinder, LinkLicense, LockIt, MediaLink, MediaPort, NAV,
NetPA, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, ShareLink, Show Me, SoundField, SpeedMount, SpeedSwitch, StudioStation,
SystemINTEGRATOR, TeamWork, TouchLink, V-Lock, VideoLounge, VN-Matrix, VoiceLift, WallVault, WindoWall, XPA, XTP, XTPSystems, and ZipClip
Registered Service Mark(SM) : S3 Service Support Solutions
Trademarks (™)
AAP, AFL (Accu-RATEFrameLock), ADSP(Advanced Digital Sync Processing), AVEdge, CableCover, CDRS(ClassD Ripple Suppression),
CodecConnect, DDSP(Digital Display Sync Processing), DMI (DynamicMotionInterpolation), DriverConfigurator, DSPConfigurator, DSVP(Digital
Sync Validation Processing), EQIP, Everlast, FastBite, Flex55, FOX, FOXBOX, IP Intercom HelpDesk, MAAP, MicroDigital, Opti-Torque,
PendantConnect, ProDSP, QS-FPC(QuickSwitch Front Panel Controller), RoomAgent, Scope-Trigger, SIS, SimpleInstructionSet, Skew-Free,
SpeedNav, Triple-Action Switching, True4K, True8K, Vector™ 4K, WebShare, XTRA, and ZipCaddy

FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part15 of the FCC rules. The ClassA limits provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause interference. This interference must be corrected at the expense of the user.
ATTENTION:
• The Twisted Pair Extension technology works with unshielded twisted pair (UTP)
or shielded twisted pair (STP) cables; but to ensure FCC Class A and CE
compliance, STP cables and STP Connectors are required.
• La technologie extension paires torsadées fonctionne avec les câbles paires
torsadées blindées(UTP) ou non blindées(STP). Afin de s’assurer de la
compatibilité entre FCC ClasseA et CE, les câbles STP et les connecteurs STP
sont nécessaires.
NOTES:
• This unit was tested with shielded I/O cables on the peripheral devices. Shielded
cables must be used to ensure compliance with FCC emissions limits.
• For more information on safety guidelines, regulatory compliances, EMI/EMF
compatibility, accessibility, and related topics, see the Extron Safety and
Regulatory Compliance Guide on the Extron website.
• Laser products see NOTE on next page
VCCI-A Notice

Class 1 Laser Product
Any service to this product must be carried out by Extron and its qualified service personnel.
CAUTION: Using controls, making adjustments, or performing procedures in a manner
other than what is specified herein may result in hazardous radiation exposure.
NOTE: For more information on safety guidelines, regulatory compliances,
EMI/EMF compatibility, accessibility, and related topics, see the “Extron Safety and
Regulatory Compliance Guide” on the Extron website.
Complies with 21 CFR 1040.10 and 1040.11.
Produit laser de classe1
Si ce produit a besoin d’un quelconque entretient, celui-ci doit être fait par Extronet son
personnel qualifié.
ATTENTION : L’utilisation de commandes, la réalisation de réglages, ou l’exécution
de procédures de manière contraire aux dispositions établies dans le présent
document, présente un risque d’exposition dangereuse aux radiations.
Remarque : Pour plus d'informations sur les directives de sécurité, les conformités
de régulation, la compatibilité EMI/EMF, l'accessibilité, et les sujets en lien, consultez le
«Informations de sécurité et de conformité Extron» sur le site internet d'Extron.
Conforme aux section 1040.10 et 1040.11 du titre 21 du Code des règlements
fédéraux des États-Unis.

Conventions Used in this Guide
Notifications
The following notifications are used in this guide:
WARNING: Potential risk of severe injury or death.
AVERTISSEMENT : Risque potentiel de blessure grave ou de mort.
CAUTION: Risk of minor personal injury.
ATTENTION : Risque de blessuremineure.
ATTENTION:
• Risk of property damage.
• Risque de dommages matériels.
NOTE: A note draws attention to important information.
TIP: A tip provides a suggestion to make working with the application easier.
Software Commands
Commands are written in the fonts shown here:
^AR Merge Scene,,0p1 scene 1,1 ^B 51 ^W^C.0
[01] R 0004 00300 00400 00800 00600 [02] 35 [17] [03]
E X! *X1&*X2)*X2#*X2! CE}
NOTE: For commands and examples of computer or device responses used in this
guide, the character “0” is the number zero and “O” is the capital letter “o.”
Computer responses and directory paths that do not have variables are written in the font
shown here:
Reply from 208.132.180.48: bytes=32 times=2ms TTL=32
C:\Program Files\Extron
Variables are written in slanted form as shown here:
ping xxx.xxx.xxx.xxx —t
SOH R Data STX Command ETB ETX
Selectable items, such as menu names, menu options, buttons, tabs, and field names are
written in the font shown here:
From the File menu, select New.
Click the OK button.
Specifications Availability
Product specifications are available on the Extron website, www.extron.com.
Extron Glossary of Terms
A glossary of terms is available at https://www.extron.com/technology/glossary.aspx.

viiFOX T/R USB Extender Plus • Contents
Contents
Introduction .................................................... 1
About this Guide................................................. 1
About the FOX T/R USB Extender Plus............... 2
Features ............................................................. 2
USB System Architecture ................................... 3
Application Diagrams.......................................... 5
Installation and Operation ............................. 7
Rear Panel Features ........................................... 7
Transmitter Rear Panel.................................... 7
Receiver Rear Panel ....................................... 9
Front Panel Features......................................... 10
Transmitter Front Panel................................. 10
Receiver Front Panel..................................... 11
Cabling and Setup............................................ 12
Installation Overview ..................................... 12
Connecting the Fiber Optic Cable................. 13
Connecting for Serial Communication............... 14
Enabling and Disabling Peripheral Emulation..... 14
Connecting Multiple Extenders to a
FOX Matrix Switcher........................................ 15
System Operation............................................. 16
Troubleshooting................................................ 16
Remote Configuration
and Control ................................................... 17
SIS Commands ................................................ 17
Host-to-Extender Communications .................. 17
Extender-initiated Messages............................. 18
Error Responses............................................... 18
Using the Command and Response Table........ 18
Symbol Definitions ........................................ 19
Command and Response Table for SIS
Commands ................................................. 19
Mounting....................................................... 20
Tabletop Placement.......................................... 20
Rack Mounting ................................................. 20
Furniture Mounting ........................................... 20

FOX T/R USB Extender Plus • Contents viii

Introduction
This section provides an overview of the FOX T/R USB Extender Plus User Guide and the
following products:
• FOX T/R USB Extender Plus
• FOX T/R HID Only USB Extender Plus
The following topics are discussed:
• About this Guide
• About the FOX T/R USB Extender Plus
• Features
• USB System Architecture
WARNING:
AVERTISSEMENT :
• The FOX T/R USB Extender Plus units output continuous invisible light, which may
be harmful to the eyes. Use with caution.
• Do not look into the rear panel fiber optic cable connectors or into the fiber optic
cables themselves.
• Plug the attached dust caps into the optical transceivers when the fiber cable is
unplugged.
• Le FOX T/R USB Extender Plus unités émettent une lumière invisible en continu
(conforme à la classe1) qui peut être dangereux pour les yeux, à utiliser avec
précaution.
• Ne regardez pas dans les connecteurs de câble fibre optique sur le panneau
arrière ou dans les câbles fibre optique eux-mêmes.
• Branchez les protections contre la poussière dans l’ensemble émetteur/
récepteur lorsque le câble fibre optique est débranché.
About this Guide
This user guide contains information needed to install, configure, and operate the Extron
FOX T/R USBExtenderPlus and the FOX T/R HID Only USB Extender Plus transmitter
and receiver pairs. Additional product information can be found on the Extron Electronics
website at www.extron.com.
In this guide, the term “extender” refers to either the transmitter or the receiver. Differences
between the transmitter and receiver are noted. Unless otherwise specified, the product
name “FOX T/R USB Extender Plus” refers to both the standard and the HID-only
extenders.
FOX T/R USB Extender Plus • Introduction 1

About the FOX T/R USB Extender Plus
The FOX T/R USB Extender Plus is a USB transmitter and receiver pair that extends USB
signals over fiber optic cabling. It is compatible with USB 3.0, 2.0, 1.1, and 1.0 devices with
transfer data rates up to 480 Mbps. It features peripheral emulation, an active four-port hub
that supplies 5 V, 500 mA per port, and real-time system monitoring.
The FOX HID Only USB Extender Plus models extend the usable distance of USB human
interface peripheral devices (HID) and smart card readers. HID peripherals include standard
keyboards, mice, hubs and other devices that do not require special USB device drivers.
In addition, the FOX T/R USB Extender Plus can work with an Extron FOX matrix switcher.
Multiple transmitters and receivers can be connected to switcher inputs and outputs that
are tied together (see Connecting Multiple Extenders to a FOX Matrix Switcher on
page 15).
The transmitters and receivers are available in singlemode and multimode versions, which
are differentiated by the type of fiber optic cable that defines their range of transmission:
• Singlemode — Up to 30 kilometers (18.6 miles)
• Multimode (OM1, 62.5 µm) — Up to 300 meters (985 feet)
• Multimode (OM2, 50 μm) — Up to 1 kilometer (3280 feet)
• Multimode OM3 and OM4 — Up to 2 kilometers (6561 feet)
NOTE: The multimode and singlemode units are physically and functionally identical,
with the exception of the effective range of transmission. In this guide, any reference
applies to either transmission mode model unless otherwise specified.
A FOX T/R USB Extender Plus system consists of a transmitter (Tx) and a receiver (Rx). The
transmitter connects directly to a USB port on a PC or USB host. The receiver features a
four port USB hub to connect multiple peripheral USB devices. The transmitter and receiver
both feature a front panel USB host activity LED, power indicator, and a fiber cable Link LED
for local or remote troubleshooting.
NOTE: The only visible difference between the standard and HID-only models is an “HID
Only” label on the enclosures of the HID-only models.
The FOX USB Extender Plus complies with the USB 2.0 standard, supporting USB 3.0 and
2.0 (480 Mbps high speed), USB 1.1 (12 Mbps full speed), and USB 1.0 (1.5 Mbps low
speed) for data transmission throughout the system. It also supplies +5 VDC (up to 500 mA)
of power on each of the receiver USB peripheral ports.
Features
• Extends USB peripherals very long distances over fiber optic cabling —
Supports long-distance KVM extension when used with FOX Series DisplayPort, HDMI,
DVI, and VGA products from Extron.
• Supports USB 3.0, 2.0, 1.1, and 1.0 devices with data transfer rates up to
480 Mbps — Allows high speed data transfer between the host and a mass storage
device such as a USB flash drive.
• Integrated four-port hub with 5 Volts, 500 mA available on each port of the
receiver — Allows simultaneous connection to multiple peripheral devices such as
mass storage devices, keyboards, mice, and other Human Interface Devices (HID).
• Peripheral emulation — Offers increased system reliability by emulating a continuous
connection between the host and an HID-compliant keyboard and mouse.
• Supports USB data transfers — Supports bulk, control, interrupt, and isochronous
transfers.
FOX T/R USB Extender Plus • Introduction 2

• Real-time status LED indicators for troubleshooting and monitoring — Provide
visual confirmation of port activity between an active host and each connected
peripheral device.
• Extron FOX matrix switcher compatibility — Distributes signals up to 1000 x 1000
and larger.
• Available in multimode and singlemode models —
• An 850 nm multimode model for moderate-range transmissions up to 2 km
(1.25 miles).
• A 1310 nm singlemode model for long distances up to 30 km (18.75 miles).
• Industry standard LC SFP connectors provide reliable physical connectivity and
precise fiber core alignment.
• JITC Certified — Successfully completed interoperability and information assurance
testing for use in government applications and other mission-critical environments.
• 1 inch (2.5 cm) high, 6 inches (15 cm) deep, quarter rack wide metal enclosures.
• External power supply — Highly reliable, energy-efficient universal power supply
provides worldwide power compatibility, with high demonstrated reliability and low
power consumption for reduced operating costs.
USB System Architecture
A USB system architecture refers to the physical bus topology of USB devices connected
to a host device. USB devices include USB hubs, USB peripheral devices, or compound
devices (devices with a combination of USB hubs and USB peripheral devices built into it).
The system is organized in a tiered star topology to prevent multiple or circular attachments
to the bus. Each tier represents a degree of separation from the host device. Per USB
specifications, there are seven supported tiers, starting with the host device (or root hub)
occupying the first tier.
NOTE: Do not connect more than five daisy-chained hubs to the root hub. The
architecture does not support peripheral devices connected to USB hubs occupying
the seventh tier.
FOX T/R USB Extender Plus • Introduction 3

Tier 1
Tier 2
Tier 3
Tier 4
Tier 5
Tier 6
Tier 7
PC
Compound Device
Camera
Speaker
Hub
Root Hub
Built-in Hub
Hub
Hub
Hub
Keyboard Mouse = USB hub
= USB peripheral device
Figure 1. Tiered Star Topology Example for a Computer with Four Monitors
NOTE: Some computers include multiple hubs already connected to each other,
occupying multiple tiers in the topology. For example, many computers with USB
ports on the front and rear panels or computers with a built-in USB hub and a
compound USB peripheral device (such as a touch display) occupy two tiers. For
information about USB hubs used in Extron products, see the USB Hub Usage Chart
at www.extron.com.
To review the USB system architecture, count all the cascading hubs (including USB hubs
enclosed in computers and compound devices) between the host device and the last USB
peripheral device.
NOTE: If the host device runs Windows®or macOS™ operating systems, use the
following programs to view the hierarchical relationships between USB devices:
• Windows: Device Manager
• macOS: System Profiler or System Information
FOX T/R USB Extender Plus • Introduction 4 4

Application Diagrams
OVERDTP
REMOTE
RS-232 IR
Tx RxGTxRx
CONTACT
1 2 3
RS-232
Tx Rx G
LINK
SIG
DTPOUT
DTP
HDBT
OUTPUTS
INPUTS
1 1UNIVERSAL HDMI DISPLAYPORT2 3 HDMI 2A HDMI 2B
LAN
RESET
USB
1
2
50/60Hz
100-240VAC --AMAX
HOST
POWER
12V
1.0A MAX
INPUT
OPTICAL
RxTx
1
2
3
4
OUTPUTS
OPTICAL
RxTx
POWER
12V
1.0A MAX
Extron
FOX R USB Extender Plus
Fiber Optic Receiver
for USB Peripherals
Ext
ron
FO
X T USB Extender Plus
Fi
ber Optic Transmitter
for USB Pe
ripherals
USB
HDMI
Extron
Annotator 300
HDCP-Compliant
Annotation
Processor with
DTP Extension
Fiber
Projector/Display
USB Touchscreen
Display
USB
Figure 2. FOX T/R USB Extender Plus Application with the Annotator 300
FOX T/R USB Extender Plus • Introduction 5

FOXBOX SR HDMI
LINK LINK
OPTICAL
RxTx
HDMI
AUDIO
OUTPUTS
REMOTE
RS-232
Tx Rx
RS-232
OVER FIBERALARM
Tx Rx 1 2
POWER
12V
1.0 A MAX LR
OFF
ON
HDMI AUDIO
FOX T USW 203
RS-232CONTACT
RS-232
OVER FIBER
AUDIO
HDMI
HDMI
LOOP-THRU
ALARM
REMOTE
Tx Rx
Tx Rx
OPTICAL
INPUTS
1
POWER
12V
0.8A MAX
2
3
LINK LINK
GTxRxG12 123G
RGB/R-Y,Y, B-Y
OUTPUTS
FOXBOX Tx DVI Plus
DVI OVER TEMP
AUDIO
CONFIG
OPTICAL
Rx
Tx
LINK LINK
AUDIO
DVI-D INPUT
FOXBOX Tx DVI Plus
RS-232
OVER FIBER
ALARM
Tx Rx 1 2
12V
1.0A MAX
POWER
FOXBOX Tx HDMI
OPTICAL
HDMI INPUT AUDIO INPUT
RS-232
OVER FIBER ALARM
Tx Rx 1 2
POWER
12V
1.0 A MAX
LINK LINK
RxTx
ANAHEIM, CA
RESET
REMOTE
RS-232/RS-422
LAN
BI-LEVEL
TRI-LEVEL
ACT LINK
100-240V 50/60Hz 1.2A MAX.
100-240V 50/60Hz 1.2A MAX.
REDUNDANT
PRIMARY
DISCONNECT BOTH POWER
CORDS BEFORE SERVICING
SWITCH
REFERENCE
PRIMARY POWERSUPPLY REDUNDANT POWERSUPPLY
1 - 8
9 - 16
17 - 24
25 - 32
OUT IN
A
OUTIN
D
OUT IN
C
OUT IN
B
OUTIN
E
OUTIN
H
OUT IN
G
OUTIN
F
OUT IN
A
OUTIN
D
OUT IN
C
OUT IN
B
OUTIN
E
OUTIN
H
OUT IN
G
OUTIN
F
OUT IN
A
OUTIN
D
OUT IN
C
OUT IN
B
OUTIN
E
OUTIN
H
OUT IN
G
OUTIN
F
OUT IN
A
OUTIN
D
OUT IN
C
OUT IN
B
OUTIN
E
OUTIN
H
OUT IN
G
OUTIN
F
HOST
POWER
12V
1.0A MAX
INPUT
OPTICAL
RxTx
HOST
POWER
12V
1.0A MAX
INPUT
OPTICAL
RxTx
HOST
POWER
12V
1.0A MAX
INPUT
OPTICAL
RxTx
1
2
3
4
OUTPUTS
OPTICAL
RxTx
POWER
12V
1.0A MAX
Extron
FOX R USB
Extender Plus
Fiber Optic Receiver
for USB Peripherals
Extron
FOX T USB
Extender Plus
Fiber Optic Transmitter
for USB Peripherals
Extron
FOX T USB Extender Plus
Fiber Optic Transmitter for USB Peripherals
Extron
FOX T USB
Extender Plus
Fiber Optic Transmitter
for USB Peripherals
Extron
FOXBOX SR HDMI
Fiber Optic Scaling
Receiver
Extron
FOX Matrix 3200
Modular Fiber Optic
Matrix Switcher
Extron
FOXBOX Tx HDMI
Fiber Optic Transmitter
PC
PC
PC
Keyboard
Mouse
Ext
ron
FO
XBOX Tx DVI Plus
Fibe
r Optic Transmitter
Extron
FOX T USW 203
Fiber Optic Switcher
Figure 3. FOX T/R USB Extender Plus Application with an Extron FOX Matrix
Switcher
FOX T/R USB Extender Plus • Introduction 6

Installation and
Operation
This section describes how to connect and operate the FOX T/R USB Plus Extender. The
following topics are covered:
• Rear Panel Connections
• Front Panel Features
• Cabling and Setup
• System Operation
• Troubleshooting
Rear Panel Features
Transmitter Rear Panel
The transmitter rear panel contains the following:
B
B
B
HOST
POWER
12V
1.0A MAX
INPUT
OPTICAL
RxTx
A
A
A
E
E
E
E
ED
D
D
D
D
C
C
C
APower connector DRx (link) LED
BHost (input) connector ETx (link) LED
CLC SFP connector
Figure 4. Transmitter Rear Panel Connectors
FOX T/R USB Extender Plus • Installation and Operation 7

APower connector — Connect a provided 12 VDC external power supply to this
2-pole, 3.5mm captive screw connector.
ATTENTION:
• The power supply must not be permanently fixed to the building structure or
similar structures.
• La source d’alimentation ne devra pas être fixée de façon permanente à une
structure de bâtiment ou à une structure similaire.
• Do not place the power supply within environmental air handling spaces or the
wall cavity.
• Ne pas placer les sources d’alimentation dans une zone de traitement de l’air
ni dans une cavité murale.
• The installation must be in accordance with the applicable provisions of
the National Electrical Code ANSI/NFPA 70, Article 725 and the Canadian
Electrical Code, Part 1, Section 16.
• Cette installation doit toujours être en accord avec les mesures qui s’applique
au National Electrical Code ANSI/NFPA70, article725, et au Canadian
Electrical Code, partie1, section16.
• The power supply must be located within the same vicinity as the Extron AV
processing equipment in an ordinary location, Pollution Degree 2, secured to a
podium, a desk, or an equipment rack within a dedicated closet.
• La source d’alimentation doit être située à proximité de l’équipement
audiovisuel Extron dans un emplacement habituel, avec un degré de pollution
2, fixée à une estrade, un bureau, ou dans une baie technique à l’intérieur d’un
placard dédié.
• Always use a power supply specified by Extron for the FOX T/R USB Extender
Plus. Use of an unauthorized power supply voids all regulatory compliance
certification and may cause damage to the supply and the extender.
• Utilisez toujours une source d’alimentation fournie ou recommandée par
Extron. L’utilisation d’une source d’alimentation non autorisée annule toute
conformité réglementaire et peut endommager la source d’alimentation ainsi
que le produit final.
• If not provided with a power supply, this product is intended to be supplied by
a power source marked with “class 2” or “LPS” and rated 12 VDC, minimum
1.0 A.
• Si ce produit ne dispose pas de sa propre source d’alimentation électrique,
il doit être alimenté par une source d’alimentation de classe 2 ou LPS et
paramétré à 12 V et 1.0 A minimum.
BHost (input) connector — Connect a USB A-B cable between this port and the
USB port of a host computer (this computer can be the same computer to which the
front panel Config port is connected for RS-232 control, or a different one). The FOX
USBExtender Plus is USB3.0 host controller compatible and supports data transfers of
480 Mbps (high speed), 12Mbps (full speed), and 1.5Mbps (low speed).
CLC SFP connector — Connect the fiber optic cable pair appropriate for your extender
model (singlemode or multimode) from the LC SFP connector of the receiver (see
figure 5, B, on the next page) to this LC SFP connector (see Connecting the Fiber
Cable on page 13).
FOX T/R USB Extender Plus • Installation and Operation 8

DRx (link) LED — Lights steadily when a signal is passing between the transmitter Rx
port and the receiver Tx port.
ETx (link) LED — Lights steadily when a signal is passing between the transmitter Tx
port and the receiver Rx port. The green Rx and Tx LEDs light and remain lit while a
valid connection exists between the LC SFP connector of the transmitter and receiver
and both units have power.
Receiver Rear Panel
The receiver rear panel has the following features:
1
2
3
4
OUTPUTS
OPTICAL
RxTx
POWER
12V
1.0A MAX
A
A
A
E
E
E
E
ED
D
D
D
D
C
C
C
B
B
B
APower connector DRx (link) LED
BLC SFP connector ETx (link) LED
CUSB hub connectors (Outputs)
Figure 5. Receiver (Rx) Rear Panel Connectors
APower connector — Connect a provided 12VDC power supply into this 2-pole,
3.5 mm captive screw connector.
ATTENTION:
• Do not connect any external power supplies until you have read the
Attention notifications on page 8.
• Ne branchez pas de sources d’alimentation externes avant d’avoir lu les
mises en garde de la page 8.
BLC SFP connector — Connect the free ends of the fiber optic cable pair attached to
the LC SFP connector of the transmitter (see figure 4, C, on page 7) to this LC SFP
connector (see Connecting the Fiber Cable on page 13).
CUSB hub connectors — The built-in four-port hub has four female USB Type A
connectors. The connections are USB 3.0 compatible, providing +5VDC at up to
500mA to connected USB peripherals requiring power.
DRx (link) LED — Lights steadily when a signal is passing between the transmitter Rx
port and the receiver Tx port.
ETx (link) LED — Lights steadily when a signal is passing between the transmitter Tx
port and the receiver Rx port.
These green LEDs light and remain lit while a valid connection exists between the
LC SFP connectors of the transmitter and receiver and both units have power.
FOX T/R USB Extender Plus • Installation and Operation 9

Front Panel Features
Transmitter Front Panel
The transmitter has the following indicator LEDs and connector:
FOX T USB EXTENDER Plus
STATUS
LINK
HOST
Extron
CONFIG
A
A
A
A
AB
B
BC
C
C
D
D
D
APower LED CHost LED
BConfig port DLink LED
Figure 6. Transmitter Front Panel
APower LED — This green LED lights to indicate that the unit is receiving power.
BConfig port — Connect a 9-pin D-to-2.5 mm tip-ring-sleeve (TRS) cable from a
computer to this 2.5 mm TRS jack for RS-232 communication (see Connecting for
Serial Communication on page 14). The Config port enables serial communication
with the computer for configuration and control of the transmitter via SIS commands
(see Remote Configuration and Control, beginning on page 17).
NOTE: You can connect the computer to either the transmitter or the receiver.
CHost LED — This green LED lights when both the transmitter and receiver are powered
and correctly connected by the appropriate fiber optic cable, and the transmitter is
communicating with the host PC.
The LED blinks when the transmitter and receiver are both powered and connected, but
no USBdevices are attached.
DLink LED — This green LED lights when the transmitter and receiver are correctly
connected together by the fiber optic cabling and are receiving power.
FOX T/R USB Extender Plus • Installation and Operation 10

Receiver Front Panel
The receiver has the following indicator LEDs and connector:
FOX R USB EXTENDER Plus
STATUS
LINK
HUB
1
2
3
4
HOST
Extron
CONFIG
E
E
E
A
A
A
A
AB
B
BC
C
C
D
D
D
APower LED CHost LED E Link LED
BConfig port DHub LEDs
Figure 7. Receiver Front Panel
APower LED — This green LED lights to indicate that the unit is receiving power.
BConfig port — Connect a 9-pin D-to-2.5 mm TRS cable from a computer to
this 2.5 mm TRS jack for RS-232 communication (see Connecting for Serial
Communication on page 14). The Config port enables serial communication with the
computer for configuration and control of the receiver via SIS commands (see Remote
Configuration and Control, beginning on page 17).
NOTE: You can connect the computer to either the transmitter or the receiver.
CHost LED — This green LED lights when both the transmitter and receiver are powered
and correctly connected by the appropriate fiber optic cable, and the receiver is
communicating with the host PC.
The LED blinks when the transmitter and receiver are both powered and connected, but
no USBdevices are attached.
DHub LEDs — A green LED for each port lights when a peripheral device (such as a
keyboard or mouse) is connected to the associated USB port and is recognized by the
host PC.
ELink LED — This green LED lights when the transmitter and receiver are successfully
connected together by the fiber optic cable and are receiving power.
FOX T/R USB Extender Plus • Installation and Operation 11

Cabling and Setup
USB
USB
Host
Computer
Four female USB 3.0 compatible type A
connectors provide +5 VDC at up to
500 mA to connected USB peripherals.
T
ransmitter Receiver
SM or MM Fiber Cable
Ground
+12 VDC
External
Power Supply
(12 VDC, 1 A )
-
1AMAX
100-240V 50-60Hz
-Ground
+12 VDC
External
Power Supply
(12 VDC, 1 A )
1AMAX
100-240V 50-60Hz
--
1
2
3
4
OUTPUTS
OPTICAL
RxTx
POWER
12V
1.0A MAX
HOST
POWER
12V
1.0A MAX
INPUT
OPTICAL
RxTx
Keyboard
Figure 8. FOX T/R USB Extender Plus Connection Guide with Two External
Supplies
Installation Overview
ATTENTION:
• Installation and service must be performed by authorized personnel only.
• L’installation et l’entretien doivent être effectués par le personnel autorisé
uniquement.
For proper operation, the transmitter, receiver, USB host, and peripherals must be
connected properly as shown in figure 8 and in the sequence described below.
1. (Optional) Mount the transmitter to a rack or furniture, following the directions provided
with the mounting kit (see Mounting on page 20).
2. Power off the transmitter and receiver, and ensure all peripheral USB devices are
disconnected.
3. Connect the fiber optic cable appropriate for your extender model (singlemode or
multimode) between the LC SFP port of the transmitter and that of the receiver (see
Connecting the Fiber Optic Cable on the next page).
FOX T/R USB Extender Plus • Installation and Operation 12
