Gefen EXT-HDMI-EDIDP User manual

®
HDMI Detective
Plus
EXT-HDMI-EDIDP
User Manual
www.gefen.com

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday, Pacic Time
Write To:
Gefen LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
[email protected]
Notice
Gefen LLC reserves the right to make changes in the hardware, packaging, and
any accompanying documentation without prior written notice.
HDMI Detective Plus is a trademark of Gefen LLC
© 2011 Gefen, LLC. All rights reserved.
All trademarks are the property of their respective owners.
ASKING FOR ASSISTANCE
Rev A9

CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Panel Layout
5 Panel Descriptions
6 Connecting the HDMI Detective Plus
7 Wiring Diagram
8 EDID Programming
8 Using a built-in EDID
9 Writing an EDID using a source device
10 Specications
11 Warranty

1
INTRODUCTION
Congratulations on your purchase of the HDMI Detective Plus. Your complete
satisfaction is very important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions
that harness integration, extension, distribution and conversion technologies.
Gefen’s reliable, plug-and-play products supplement cross-platform computer
systems, professional audio/video environments and HDTV systems of all sizes
with hard-working solutions that are easy to implement and simple to operate.
The Gefen HDMI Detective Plus
Computers and HDTV video source devices can sometimes lose the EDID --
(which is basically the electronic identication of a display) which lists its possible
resolutions and frequencies. When displays are switched away or disconnected
and then reconnected, the EDID can be lost and the computer or HD video
source device can lose the ability to display the image properly. The HDMI
Detective Plus product allows you to switch or relocate HDTV or Computer video
displays while “tricking” the source devices into thinking that the display is still
present -- maintaining smooth video operations throughout the process.
How It Works
The Gefen HDMI Detective Plus attaches to the HDTV display’s HDMI input
connector for initial programming. Power is applied and the HDMI Detective Plus
reads and stores the attached displays EDID to the internal memory. Then the
HDMI Detective Plus is attached to your source HDMI output and it will never
lose EDID again.
The HDMI Detective Plus includes 4 built-in selectable generic EDIDs that can be
used for meeting standard home theater setups. They can be selected by moving
the dip switches between the different settings.

2
OPERATION NOTES
THIS PAGE LEFT INTENTIONALLY BLANK

3
FEATURES
Features
• Quick and easy recording of EDID information from HDTV displays
• Write custom EDID information using an external source
(e.g. signal generator, etc)
• Selection of preset EDIDs
• Maintains 1920 x 1200, 1080p Full HD, and 2k resolution video
• No power required after initial programming
• HDCP Compliant
• Compact unit hides well behind equipment
Package Includes
(1) HDMI Detective Plus
(1) 1 ft. HDMI cable (M-M)
(1) 5V DC power supply
(1) Quick Start Guide

4
PANEL LAYOUT
Front
Back
12
3
4 5

5
1 Programming Button
Press and hold this button to program an EDID. See page 8 for more
information on recording an EDID.
2 HDMI In
Connect the included HDMI cable from this HDMI port to the source device.
3 DIP Switches
Use these DIP switches to use one of the pre-programmed EDIDs.
4 HDMI Out
Connect an HDMI cable from this HDMI port to the display (or other sink
device).
5 WR
Enables / disables the EDID write status. Set the WR switch to the “E” position
to allow the HDMI Detective Plus to be programmed with an EDID. Set the WR
switch to the “D” position to disable programming and prevent an accidental
erasure.
PANEL DESCRIPTIONS

CONNECTING THE HDMI DETECTIVE PLUS
6
How to Connect the HDMI Detective Plus
1. Power-on the display (or other sink device) containing the EDID to be
recorded.
2. Use an HDMI cable to connect the sink device to the HDMI Out port on the
HDMI Detective Plus.
3. Set all four DIP switches in the OFF (up) position, as shown in the illustration
below.
4. Set the WR (Write) switch to the “E” (enable) position to allow the HDMI
Detective Plus to be programmed.
5. Connect the included 5V DC power supply to the HDMI Detective Plus. The
power LED will glow bright green if the sink device contains a valid EDID.
If the sink’s EDID is corrupt or invalid, then the power LED will glow bright
red.
6. Press and hold the Program button on the front panel of the HDMI Detective
Plus until the power indicator begins to rapidly ash bright green, then
release the Program button. The power LED will continue to ash as the
EDID is written to the HDMI Detective Plus.
A successful recording will be indicated with a solid green LED. If the
recording process was unsuccessful, the LED will glow bright red.
