UFirebird II - UC6580
Dual-frequency GNSS Positioning Chip
HARDWARE
REFERENCE DESIGN

UC6580 Hardware Reference Design
i
Revision History
Version
Revision History
Date
R1.0
First release
Sep., 2023

ii
Legal right notice
This manual provides information and details on the products of Unicore Communication, Inc.
(“Unicore”) referred to herein.
All rights, title and interest to this document and the information such as data, designs, layouts
contained in this manual are fully reserved, including but not limited to the copyrights, patents,
trademarks and other proprietary rights as relevant governing laws may grant, and such rights
may evolve and be approved, registered or granted from the whole information aforesaid or any
part(s) of it or any combination of those parts.
Unicore holds the trademarks of “和芯星通”,“UNICORECOMM”and other trade name, trademark,
icon, logo, brand name and/or service mark of Unicore products or their product serial referred
to in this manual (collectively “Unicore Trademarks”).
This manual or any part of it, shall not be deemed as, either expressly, implied, by estoppel or
any other form, the granting or transferring of Unicore rights and/or interests (including but not
limited to the aforementioned trademark rights), in whole or in part.
Disclaimer
The information contained in this manual is provided “as is” and is believed to be true and
correct at the time of its publication or revision. This manual does not represent, and in any
case, shall not be construed as a commitments or warranty on the part of Unicore with respect
to the fitness for a particular purpose/use, the accuracy, reliability and correctness of the
information contained herein.
Information, such as product specifications, descriptions, features and user guide in this
manual, are subject to change by Unicore at any time without prior notice, which may not be
completely consistent with such information of the specific product you purchase.
Should you purchase our product and encounter any inconsistency, please contact us or our
local authorized distributor for the most up-to-date version of this manual along with any
addenda or corrigenda.

UC6580 Hardware Reference Design
iii
Foreword
This document gives the hardware reference design of the chip UC6580 from Unicore.
Target Readers
This document applies to technicians who possess the expertise on GNSS receivers.

I
Contents
1Reference Design....................................................................................1
1.1 LDO Mode.........................................................................................................................1
1.2 DC/DC Mode.....................................................................................................................2
2Attention ................................................................................................3
2.1 Power................................................................................................................................3
2.2 Reset Signal .....................................................................................................................4
2.3 RTC....................................................................................................................................4
2.4 TCXO.................................................................................................................................5
3Recommended BOM ...............................................................................6
Appendix Simplest Design to Replace UC6226..............................................8

UC6580 Hardware Reference Design
UC-06-C21 EN R1.0 Reference Design 1
1Reference Design
If you do not need the RTC and backup function, connect V_BCKP to VDD_IO.
RTC and backup function are the prerequisites of GNSS hot start. Refer to UC6580
Datasheet for more details.
1.1 LDO Mode
Under the LDO mode:
DCDC_IN and VDD_IO use the same power supply;
Use the internal LDO_EX to power the system;
Power the external TCXO by LDO_X;
Connect RTC Crystal externally;
Connect LNA and SAW externally;
Use the UART interfaces to communicate;
Lower cost but higher power consumption.
RF Short 50ohm Line
TCXO
VBCKP：1.7V~3 .6V
VMAIN：2.7V~3 .6V
V_DET：2.7V~3 .6V
LDO_RE TLDO_X
LDO_X
VMAIN
DCDC_O UT
VDD_ANT
LDO_C
LDO_EX
VMAIN
VMAIN
V_DE T
V_BC KP
Figure 1-1 Reference design of LDO mode
If the antenna feed supply and the chip’s main supply use the same power rail, the
ESD, surge and overvoltage from the antenna will have an effect on the main supply,
which may cause damage to the chip. Therefore, it is recommended to design an
independent power rail for the antenna feed supply to reduce the possibility of chip
damage.

2 Reference Design UC-06-C21 EN R1.0
1.2 DC/DC Mode
Under the DC/DC mode:
DCDC_IN and VDD_IO use the same power supply;
Use the internal DC/DC to power the system;
Power the external TCXO by LDO_X;
Connect RTC Crystal externally;
Connect LNA and SAW externally;
Use the UART interfaces to communicate;
Lower power consumption but higher cost due to the use of power inductor
comparing with LDO mode;
RF Short 50ohm Line
TCXO
V_COR E
LDO_X
VMAIN
DCDC_O UT
LDO_RE TLDO_X VD D_AN T
LDO_C LDO_EX
VMAIN
VMAIN
V_DE TV_BC KP
VBCKP：1.7V~3 .6V
VMAIN：2.7V~3 .6V
V_DET：2.7V~3 .6V
Figure 1-2 Reference design of DCDC mode
If the antenna feed supply and the chip’s main supply use the same power rail, the
ESD, surge and overvoltage from the antenna will have an effect on the main supply,
which may cause damage to the chip. Therefore, it is recommended to design an
independent power rail for the antenna feed supply to reduce the possibility of chip
damage.

UC6580 Hardware Reference Design
UC-06-C21 EN R1.0 Attention 3
2Attention
2.1 Power
DCDC_IN and VDD_IO use the same external power supply. For all the power supplies,
the ripple voltages must not exceed 50 mV.
The value of LDO_X must be lower than VDD_IO and the default is 1.7 V to 1.9 V.
To improve the product stability, it is recommended to control the power on and off of
UC6580 by the controlling terminal of the power supply. When an unstable factor out of
control occurs, the terminal does power on/off operations on UC6580 to make the
system recover, which ensures a continuous work of the system.
Note:
VMAIN
The VMAIN initial level when power-on should be less than 0.4 V.
The VMAIN ramp when power-on should be monotonic, without plateaus.
The voltages of undershoot and ringing should be within 5% VMAIN.
VMAIN power-on waveform: The time interval from 10% rising to 90% must be
within 100 μs ~ 10 ms.
Power-on time interval: The time interval between the power-off (VMAIN < 0.4 V) to
the next power-on must be larger than 500 ms.
VBCKP
The VBCKP initial level when power-on should be less than 0.4 V.
The VBCKP ramp when power-on should be monotonic, without plateaus.
The voltages of undershoot and ringing should be within 5% VBCKP.
VBCKP power-on waveform: The time interval from 10% rising to 90% must be
within 100 μs ~ 10 ms.
Power-on time interval: The time interval between the power-off (VBCKP< 0.4 V) to
the next power-on must be larger than 500 ms.

4 Attention UC-06-C21 EN R1.0
2.2 Reset Signal
UC6580 supports system reset. The reset signal is active low and the active time should
be no less than 5 ms.
2.3 RTC
RTC is usually driven by an on-chip 32.768 kHz oscillator, which needs to be connected
to an external 32.768 kHz crystal.
Instead of this, UC6580 supports directly inputting RTC_I with an external 32.768 kHz
digital clock signal. In this situation, make sure that the signal amplitude is less than
1.98 V, otherwise it may cause damage to the chip.
In addition to the general rules of RTC layout and routing, you should pay special
attentions to:
Have a complete reference GND under the chip and the RTC crystal.
The RTC crystal shall be placed as close to the chip as possible, and there shall be
no other devices between the two;
Devices, signals, wiring, etc. with high power or strong interference should be
avoided around RTC crystal;
It is recommended to do ground shields for the relevant circuits of RTC.

UC6580 Hardware Reference Design
UC-06-C21 EN R1.0 Attention 5
2.4 TCXO
The CLK_I pin connects an external TCXO of 26 MHz. The power supply of TCXO can be
LDO_X or an external independent LDO power supply.
In order to ensure the chip boots normally, the 26 MHz clock should work stably no later
than 10 ms after the chip is powered.
The basic parameter requirements for TCXO are as follows:
Frequency and temperature: 26 MHz ± 0.5 ppm (-40 °C to +85 °C);
Short-term frequency stability: < 5 ppb/s.
Special attentions should be paid to the layout and routing of TCXO in addition to the
general rules:
It is recommended to maintain copper void for the layer where TCXO is placed and
the adjacent layers, and keep the reference ground complete for other layers, so as
to reduce the impact of heat conduction on the performance of TCXO.
Place TCXO as close to the chip as possible, with ground shields for the
surrounding
circuits.
Avoid placing any high-power or strong interference devices, signals, traces, etc.
around the TCXO. Keep a distance of more than 3 times the trace width between the
clock signal trace and other traces.

6 Recommended BOM UC-06-C21 EN R1.0
3Recommended BOM
Table 3-1 Recommended BOM
Category
Description
Type
Manufacturer
Capacitor
0402 surface mount
capacitor
10 μF, ± 20%, X5R, 6.3 V
CC0402MRX5R5BB106
YAGEO
Capacitor
0201 surface mount
capacitor
1 μF, ± 20%, X6S, 6.3 V
GRM033C80J105ME05D
Murata
Capacitor
0201 surface mount
capacitor
100 nF, ±10%, X7S, 10 V
C0603X7S1A104K030BC
TDK
Capacitor
0201 surface mount
capacitor
100 pF, ± 10%, X7R, 25 V
CC0201KRX7R8BB101
YAGEO
Capacitor
0201 surface mount
capacitor
10 pF, ± 2%, COG, 50 V
GRM0335C1H100GA01D
Murata
TVS
ESD protective diode
DFN0603-2L
1100 W ± 18 kV
JEB05UCDS-AH
JIEJIE
MICROELECTR
ONICS CO. ,
Ltd
Ferrite
Bead
Ferrite Bead
BLM15AG221SN1D
BLM15AG221SN1D
Murata
Inductor
Chip inductor: 1 μH
DC resistor: 300 mΩ
Maximum current: 0.7A
Tolerance: ± 20%
Size: 1.6 mm × 0.8 mm ×
0.95 mm
MLP1608V1R0BT0S1
TDK
Resistor
Surface Mount
0 Ω, 1/16 W, ± 5%, 0402
RC0402JR-070RL
YAGEO
Resistor
Chip resistor
0 Ω, 1/20W, ± 1%, 0201
RC0201FR-070RL
YAGEO
Resistor
Chip resistor
10 kΩ, 1/16 W, ± 5%, 0402
RC0402JR-0710KL
YAGEO
Resistor
Chip resistor
10 kΩ, 1/20 W, ± 1%, 0201
RC0201FR-0710KL
YAGEO
Resistor
Chip resistor
4.7 kΩ, 1/16 W, ± 5%, 0402
RC0402JR-074K7L
YAGEO

UC6580 Hardware Reference Design
UC-06-C21 EN R1.0 Recommended BOM 7
Category
Description
Type
Manufacturer
Resistor
Chip resistor
4.7 kΩ, 1/20 W, ± 5%, 0201
AC0201JR-074K7L
YAGEO
Resistor
Chip resistor
33 Ω, 1/16 W, ± 5%, 0402
RC0402JR-0733RL
YAGEO
LNA
High gain, dual-band LNA
LGA 6-pin
MXDLN14TP
MAXSCEND
SAW
1.5 mm × 1.1 mm
1166 MHz to 1187 MHz
1559 MHz to 1606 MHz
L1: 2.4 dB Max.
L5: 2.0 dB Max.
L1: 50 MHz
L5: 20 MHz
MXDFD14A1
MAXSCEND
TCXO
± 0.5 ppm 26 MHz
2.0 mm × 1.6 mm ×
0.73 mm
X1G005441020416
EPSON
Crystal
32.768 KHz
± 20 ppm
-40 °C to +85 °C
1TJG125DR1A0004
KDS
Crystal
32.768 KHz
± 20 ppm
12.5 pF
-40 °C to +85 °C
X1A000061000200
EPSON

8 Appendix Simplest Design to Replace UC6226 UC-06-C21 EN R1.0
Appendix Simplest Design to Replace UC6226
UC6580 can replace the UC6226 (QFN40) in the circuits. If your product uses UC6226
(QFN40), you can upgrade it with UC6580. Please contact Unicore FAE if necessary.
This section introduces the simplest way to fulfill the replacement. You can design your
circuits according to Figure 0-1 and Table 0-1. Make sure that DCDC_IN and VDD_IO use
the same power supply and note that you need to adjust the value of the DCDC output
inductor (L2), RF_IN matching inductor (L3) and RF_IN matching capacitor (C14).
Except the pins listed in Table 0-1, the other pins of the UC6580 (QFN40) and UC6226
(QFN40) are the same.
RF Short 50ohm Line
LDO_XVMAIN V_BCKP
LDO_X
VMAIN
VMAIN
VBCKP：1.7V~3 .6V
VMAIN：2.7V~3 .6V
V_DET：2.7V~3 .6V
Figure 0-1 Simplest design to replace UC6226

UC6580 Hardware Reference Design
UC-06-C21 EN R1.0 Appendix Simplest Design to Replace UC6226 9
Table 0-1 Simplest design to replace UC6226
Pin No.
UC6226NI/AS
UC6580
Description
1
VDD_ANA
IF_OUT
UC6580: floating
Not compatible
4
XTAL_O
TM
Both floating
Compatible
5
LDO_F_OUT
LDO_EX
Both connect a 1 μF capacitor externally
Compatible
8
PIO17
V_DET
UC6580: can be floating or connect a 1 μF
capacitor externally
Partially compatible
9
NC
VDD_ANT
UC6580: can be floating or connect a 1 μF
capacitor externally
Partially compatible
10
PIO18
LDO_RET
UC6580: connects a 1 μF capacitor externally
Not compatible
20
T_SENSE
VQPS
Both floating
Compatible
22
V_DCDC_OUT
DCDC_OUT
UC6580: L2 = 1μH, C8 = 10 μF
Not compatible
38
LDO_RF_OUT
L5_IN
UC6580: connects RF signals if L5 channel is
used, otherwise floating
Not compatible
39
VDD_LNA
T_TEST
UC6580: internal test pin, floating
Not compatible
40
LNA_IN
L1_IN
UC6580: L3 = 2.2 nH, C14 = 2.0 PF
Not compatible

和芯星通科技（北京）有限公司
Unicore Communications, Inc.
北京市海淀区丰贤东路 7号北斗星通大厦三层
F3, No.7, Fengxian East Road, Haidian, Beijing, P.R.China,
100094
www.unicorecomm.com
Phone: [phone]
Fax: [phone]
[email protected]
www.unicorecomm.com
