1Reference Circuit Using an Active Antenna
The supply voltage for VCC is 2.7 V ~ 3.6 V
Ground all GND pins of the module
Connect the RF_IN signal to the antenna; note the 50 Ω impedance matching
Feed the antenna with external power supply
The supply voltage for VBCKP is 1.7 V ~ 3.6 V
Requirement for the odometer speed pulse: width ≥100 us, frequency ≤5K Hz
Active Low
VCC 2.7 V~3.6V
VBCKP 1.7 V~3.6V
RF Short 50ohm Line
Figure 1-1 Reference Circuit Using an Active Antenna

UM621N V1R0 Hardware Reference Design
2
2Reference Circuit Using a Passive Antenna
When using a passive antenna, a low noise amplifier should be added between
the antenna and the RF_IN of the module in order to ensure the performance of
the system.
For the RF routing (antenna LNA RF_IN), note the 50 Ω impedance matching
The supply voltage for VBCKP is 1.7 V ~ 3.6 V
Requirement for the odometer speed pulse: width ≥100 us, frequency ≤5 KHz
Active Low
VCC 2.7 V~3.6V
VBCKP 1.7 V~3.6V
RF Short 50ohm Line
Figure 2-1 Reference Circuit Using a Passive Antenna

3
3Recommended BOM
Component
Order No.
Manufacturer
U1
RS-232
Transceivers
MAX3232EUE+
TI
U2
LNA
MXDLN14TP
MAXSCEND
