QUICK REFERENCE GUIDE [1]
www.uniden.com
Step 1 Checking the Package Contents
Make sure your cordless phone’s packaging includes the
following items (the number of items may vary depending on
model number within this series). If any of these items are
missing or damaged, contact the Uniden Parts Department.
•Base Unit
•Handset(s)
•AC Adapter(s)
• Wall Mount Adapter
• Rechargeable Battery Pack(s)
• Telephone Cord
•Belt Clip(s)
• Owner's Manual
• Other Printed Materials
Uniden Parts Department at [phone]
Hours: M-F 8:00 a.m. to 5:00 p.m. CST.
or visit our website at www.uniden.com for
replacement parts.
Step 2 Install and Charge the Handset Battery
TO INSTALL THE HANDSET BATTERY
(See page 12 for details)
Charge the handset battery pack for
at least 15-20 hours before using
your new cordless telephone for the
first time! Use only the Uniden
rechargeable battery pack supplied
with your new phone.
Remove the cover.
Connect the battery pack
connector with the correct
polarity and listen for a click
to insure connection.
Replace the cover.
Use only the Uniden AC
adapter supplied with your
new phone.
Plug the AC adapter
cord into the base unit
and then into a 120V
AC outlet.
Place the handset in the base and charge continuously for
15-20 hours before using the phone.
QUICK REFERENCE GUIDE
UP323BH(DCT6485)OMENG.book1ページ２００３年１０月２４日 金曜日 午前１０時５６分

[2] QUICK REFERENCE GUIDE
www.uniden.com
Step 3 Connect to Phone Line
When the handset battery pack
is fully charged after 15-20
hours of charging, plug the
telephone cord into the base
unit and then into a telephone
wall jack.
Your phone is set for tone
dialing. If your local network
requires pulse dialing, refer to
page 27.
Step 4 Setting Caller ID & Language Display Options
TO SET CALLER ID ON CALL WAITING AND CALL
WAITING DELUXE
For all Handset Menu Setup Options, refer to page 21.
Press menu/del in standby mode.
Press ring/vol/∧or ring/vol/∨to select
Global
Setup
and then select/.
Press ring/vol/∧or ring/vol/∨to select
CIDCW and
then select/.
Press ring/vol/∧or ring/vol/∨to select
CW On/CWDX
On
, CW On/CWDX Off , or CW Off/CWDX Off and
then select/. (See page 26 for details.)
TO SET LANGUAGE
Press menu/del in standby mode.
Press ring/vol/∧or ring/vol/∨
to select
Handset Setup and
then select/.
Press ring/vol/∧or ring/vol/∨
to select
Language and then
select/.
Press ring/vol/∨to choose a
language and then select/.
Step 5 Setting Up the Answering System
TO TURN THE ANSWERING SYSTEM ON/OFF
Each time ans on/off is pressed, the answering machine
switches between on and off.
TO SET GREETING MESSAGE
Press and hold greeting
until voice prompt
“record greeting” plays.
Position yourself near the
base mic, and begin
recording your greeting.
When finished recording,
press greeting or play/stop.
Your greeting will playback
for confirmation.
UP323BH(DCT6485)OMENG.book2ページ２００３年１０月２４日 金曜日 午前１０時５６分

Guía de referencia rápida [3]
www.uniden.com
Al enchue CA
Al CC IN 9V
Adaptador CA
(suministrado)
Enrolle el cable.
1° Paso Inspección del contenido del embalaje
Asegúrese de que haya recibido los siguientes artículos en el
paquete (la cantidad de artículos puede variar dependiendo del
número del modelo dentro de la serie). Si alguno de estos
artículos falta o está dañado, comuníquese con el departamento
de partes de Uniden.
•Base
• Receptor(es)
• Adaptador(es) CA
• Adaptador de montaje de pared
• Paquete(s) de pilas recargable(s)
• Cable telefónico
• Pinza(s) para la correa
• Manual para el usuario
• Otros impresos
Uniden Parts Department
Teléfono: [phone]
Horas: de Lunes a Viernes desde las 8 a.m. hasta las
5:00 p.m., hora central
O visítenos en nuestra página Web en www.uniden.com
para conseguir las partes de reemplazo.
2° Paso Instalación y carga de la pila para el receptor
Para instalar la pila del receptor
(Consulte la página 12 para más detalles)
Cargue el paquete de batería to pila
por lo menos de 15 á 20 horas antes de
conectarlo a una línea telefónica.
Use solamente el paquete de pilas
recargable de Uniden suministrado con
su nuevo teléfono.
Quite la tapa.
Conecte el enchufe del paquete
de las pilas con la polaridad
correcta y escuche por un clic
para asegurar la conexión.
Reponga la tapa.
Use solamente el adaptador
CA de Uniden suministrado
con su nuevo teléfono.
Conecte el cable del
adaptador CA en la
base y luego en una
toma CA de 120 V.
Antes de usar el teléfono, coloque el receptor en la
base y cárguelo continuamente por 15 – 20 horas.
Negro
Rojo
Negro Rojo
Guía de referencia
UP323BH(DCT6485)OMENG.book3ページ２００３年１０月２４日 金曜日 午前１０時５６分

[4] Guía de referencia rápida
www.uniden.com
Al enchufe Telefónico
Cable de línea Telefónica
(suministrado)
A la línea Telefónica
3° Paso Conexión a la línea telefónica
Cuando el paquete de pilas del receptor esté
totalmente cargado, después de una carga de
15-20 horas, conecte el cable telefónico en la
base y luego en el enchufe telefónico de la pared.
Su teléfono está programado
paramarcar por tono.
Si su red local requiere la
marcación por pulso, consulte la
página 27.
4° Paso Programación de las opciones de identificación
de llamadas y del lenguaje en la pantalla
Para programar las opciones de identificación
de llamadas de llamadas en espera y llamada en
espera de lujo
Para todas las demás opciones de programación en el menú,
consulte la página 21.
Oprima menu/del en el modo de espera.
Oprima ring/vol/∧o ring/vol/∨para seleccionar la
Progr global , y luego select/.
Oprima ring/vol/∧o ring/vol/∨para seleccionar
CIDCW , y luego select/.
Oprima ring/vol/∧o ring/vol/∨para seleccionar CW Act/
CWDX Act, CW Act/CWDX Apg, o CW Apg/CWDX Apg, y
luego select/. (Consulte la página 26 para más detalles.)
Para programar el lenguaje
Oprima menu/del en el modo de
espera.
Oprima ring/vol/∧o ring/vol/∨
para seleccionar la
Progr
receptor
, y luego select/.
Oprima ring/vol/∧o ring/vol/∨
para seleccionar el
Lenguaje , y
luego select/.
Oprima ring/vol/∨para escoger el
lenguaje, y luego select/.
5° Paso Programación del contestador automático
Para encender o apagar el contestador automático
Cada vez que se oprima ans on/off, el contestador automático
cambia entre encendido y apagado.
Para programar un mensaje personal
Mantenga oprimido greeting
hasta que escuche la indicación
para grabar el mensaje.
Colóquese cerca del micrófono
en la base, y comience a grabar
su mensaje.
Cuando termine con la
grabación, oprima greeting o
play/stop. Su mensaje se
escuchará como confirmación.
UP323BH(DCT6485)OMENG.book4ページ２００３年１０月２４日 金曜日 午前１０時５６分

[5]
www.uniden.com
QUICK REFERENCE GUIDE 1
WELCOME/FEATURES/TERMINOLOGY 6
CONTROLS AND FUNCTIONS 8
DISPLAY AND ICONS 10
GETTING STARTED 11
Setting up the Phone 11
Mounting the Base Unit on a Wall 15
About the Menu Options 17
Setting Menu Options 21
BASICS 29
Making and Receiving Calls 29
Placing a Call on Hold 30
Redialing a Call 30
Adjusting the Handset Ringer, Earpiece and Speaker Volume 31
Do Not Disturb (DND) 32
Mute Microphone 33
Tone Dialing Switch-over 33
Traveling Out-of-Range 33
Clarity Booster 34
Privacy Mode 34
3-Way Conferencing 35
Find Handset 35
Flash and Call Waiting 36
New Message LED 36
PHONEBOOK 37
Phonebook 37
Storing Phone Numbers, Names, Distinctive Rings,
and Speed Dial 37
Chain Dialing 38
Steps for Entering Names and Special Characters 39
Viewing the Phonebook 41
Making Calls Using the Phonebook 42
Speed Dialing 42
Editing or Erasing a Stored Name,
Phone Number, Distinctive Ring, and Speed Dial 43
Memory Dialing (base only) 44
CALLER ID 45
Caller ID and CIDCW (Caller ID on Call Waiting) 45
Viewing the Caller ID List 46
Deleting a Caller ID Message 47
Using the Caller ID Message List 48
Call Waiting Deluxe Features 49
THE INTEGRATED ANSWERING DEVICE 50
The Integrated Answering Device 50
Turning the Answering System On/Off 51
Setting Up your Answering System 52
Using your Answering System 59
Remote Operation 62
EXPANDING YOUR PHONE 65
Expanding Your Phone 65
Connecting the Charger 65
Register the Handset to the Base 66
Using the DirectLink Mode 67
4-Way Conferencing 68
Intercom/Call Transfer Feature 68
Replacing the Base 70
ADDITIONAL INFORMATION 71
Changing the Digital Security Code 71
Installing the Beltclip 71
Headset Installation 71
Note on Power Sources 72
Maintenance 72
General Information 73
TROUBLESHOOTING 74
Liquid Damage 77
PRECAUTIONS & WARRANTY 78
I.C. NOTICE 80
INDEX 81
MEMORY LIST 82
REMOTE OPERATION CARD 83
Contents
UP323BH(DCT6485)OMENG.book5ページ２００３年１０月２４日 金曜日 午前１０時５６分

[6] WELCOME/FEATURES/TERMINOLOGY
www.uniden.com
Congratulations on your purchase of the Uniden Expandable Cordless System telephone. This unit
is different from conventional cordless telephones. When the base unit is connected to AC power
and a telephone line, it can support up to 4 handsets. Using extra handsets, you can establish a
4-way conference call (2 handsets - Base Speaker Phone - an outside line). Additionally, with 4-
way conference using 2 handsets, another 2 handsets can establish an intercom call. You can
now place a fully featured cordless handset anywhere in your home or office where AC power is
available to connect the handset chargers.
Note: Some illustrations in this manual may differ from the actual unit for
explanation purposes.
As an Energy StarPartner, Uniden has determined that this product or product
models meets the Energy Starguidelines for energy efficiency.
Energy Staris a U.S. registered mark.
Note: Energy Starapplies to DCT6485 only.
• 2.4GHz Frequency Hopping Spread Spectrum • Clock Display
• Integrated Answering Device • 10 Memory Dial Location at Base
• Trilingual Voice Prompts (English, French, Spanish) • Dual Keypad at Base
• 4 Handsets Expandability
• Hands Free Speaker Phone at Handset and Base
• Caller ID/Caller ID on Call Waiting
• Call Waiting Deluxe
• 100 Dynamic Memory Location (Phonebook & Caller ID)
• Call Transfer and/or Intercom between Handsets, or Handset and Base
• 20 Distinctive Ring Options (10 ringer tones and 10 melody ringers)
• DND Feature (Do Not Disturb)
• DirectLinkMode
• Room Monitoring Feature
• New Message Indicator with optional Alert Tone
• Remote Message Retrieval
• Operated Tad Functions using Handset
• Personal or Factory Pre-recorded Greeting Message
WELCOME/
FEATURES/
Welcome
Features
UP323BH(DCT6485)OMENG.book6ページ２００３年１０月２４日 金曜日 午前１０時５６分

WELCOME/FEATURES/TERMINOLOGY [7]
www.uniden.com
This series features include AutoTalkand AutoStandby. AutoTalk allows you to answer a call by just removing
the handset from the cradle so you don't have to waste time pushing buttons. AutoStandby allows you to hang up by
simply returning the handset to the cradle.
To protect you against mis-billed calls, which might result from your phone being activated by other equipment, this
series has Random Codedigital security, which automatically selects one of over approx. 130,000 digital security
codes for the handset and base.
Frequency Hopping Spread Spectrum (FHSS) technology improves calling range and clarity, and eliminates cross talk.
Because it rapidly changes transmission frequencies within the 2.4GHz bandwidth, this cordless phone helps reduce
the possibility of eavesdropping.
IntegriSoundBuilt in sound quality which provides lifelike conversations.
DirectLinkmode is used when you have 2 or more handsets. You can use your handsets as transceivers.
Be sure to visit our web site: www.uniden.com
Unidenis a registered trademark of Uniden America Corporation.
AutoTalk, AutoStandby, DirectLink, Random Code, and IntegriSound are trademarks of Uniden America.
Terminology
•Standby Mode - The handset is not in use and talk/flash has not been pressed.
•Talk Mode - The handset is not in the cradle and talk/flash or speaker has been pressed enabling a dial tone.
Talk
appears on the display.
WELCOME/
FEATURES/
UP323BH(DCT6485)OMENG.book7ページ２００３年１０月２４日 金曜日 午前１０時５６分

[8] CONTROLS & FUNCTIONS
www.uniden.com
Controls & Functions
1. Handset Antenna
2. Headset Jack Cover
3. Beltclip Hole
4. Hands-Free Speaker
5. Handset Battery Compartment
6. New Message LED
7. Handset Earpiece
8. LCD Display
9. Menu/del (delete) Key (P. 21 / P. 31, 43, 47)
10. (ring)/vol(volume)and∧/∨( P . 3 1 / P . 2 1 )
a. ringer and volume control b. scroll keys for display screen
11.
*
/tone/←Key (P. 33 / P. 40)
12. redial/pause Key (P. 30/ P. 29)
13. speaker Key (P. 29)
14.Select/(Handset Remote) Key (P. 21 / P. 63)
15.Call id (Caller ID) key (P. 46)
16.Talk/flash Key (P. 29 / P. 36)
17.End Key (P. 29)
18.#/→Key (P. 29 / P. 40)
19. (Phonebook) Key (P. 37)
20.Hold/transfer/int'com (Intercom) Key (P. 30 / P. 69 / P. 68)
21.Handset Microphone
22.Handset Charging Contacts
2
1
3
5
4
6
7
8
9
10
11
12
22
15
13
18
19
16
20
21
17
14
Repeat Key
Delete Key Stop Key
Play Key
Skip Key
Select/Key
Handset Remote Operation (P. 62)
(Review ITAD messages from handset)
CONTROLS &
FUNCTIONS
UP323BH(DCT6485)OMENG.book8ページ２００３年１０月２４日 金曜日 午前１０時５６分

CONTROLS & FUNCTIONS [9]
www.uniden.com
33
34
35
36
37
38
39
46 47 48 49 50
23 24 25 26 27 28 29 30 3231
40
41
42
43
44
45
23. Base Speaker
24. Clock/MENU Key (P. 53)
25. |<< repeat/SELECT Key (P. 59, 54)
26. ∅delete Key (P. 60)
27. Charge LED
28. Message Counter Display
29. In use LED
30. play/stop Key (P. 59)
31. >>| skip/SELECT Key (P. 60 / P. 54)
32. SET Key (P. 54)
33. Memo record Key (P. 61)
34. Ans on/off Key (P. 51)
35. Greeting Key (P. 52)
36. mem (memory) Key (P. 44)
37. Redial/p (pause) Key (P. 31 / P. 29)
38. Flash Key (P. 36)
39. Base Charging Contacts
40. Intercom Key (P. 68)
41.
Mute/find handset
Key (P. 33 / P.35)
42. Hold Key (P. 30)
43. (ring)
/volume
and
∧/∨
(P. 53)
44. (speaker) Key/speaker LED (P. 29)
45. Base Antenna
46. Do not disturb Key/DND LED (P. 32)
47.
*
/tone Key (P. 33)
48. Microphone
49. DC IN 9V Jack
50. TEL LINE Jack
52
51
53
For DCT6485-2 and DCT6485-3 only
51. DC IN 9V Jack
52. Charging Contacts
53. Charge LED
CONTROLS &
FUNCTIONS
UP323BH(DCT6485)OMENG.book9ページ２００３年１０月２４日 金曜日 午前１０時５６分

[10] DISPLAY AND ICONS
www.uniden.com
Display and Icons
Example of the standby mode display
ICON STATUS DESCRIPTION
Standby/Talk Battery icons indicate the handset battery status. This icon cycles depending on
the battery status (empty, low, medium, and full).
Standby Ringer off icon indicates that ringer is turned off.
Talk Mute icon appears when you mute the handset.
Talk Speaker icon appears when the handset speaker phone is used.
Talk Booster icon appears when the Clarity Booster feature is in use.
Talk Privacy icon appears when the Privacy Mode is turned on.
Talk Recording icon appears while recording a conversation.
570#
*CPFUGV
0GYࠕࠗ࠙
Day of the week and time / battery icon
Handset ID and Banner
Number of new Caller ID calls received / Ringer off icon (when the ringer is Off)
ࠕࠗ࠙
ߦ
㨮
$
ߥ
4
DISPLAY AND ICONS
UP323BH(DCT6485)OMENG.book10ページ２００３年１０月２４日 金曜日 午前１０時５６分

GETTING STARTED [11]
www.uniden.com
Setting up the Phone
Do the following steps:
A. Choose the best location.
B. Install the rechargeable battery pack into the handset.
C. Connect the base unit.
A. Choose the best location
Before choosing a location for your new phone, read “Installation Considerations” on page
79. Here are some important guidelines you should consider:
If your home has
specially wired alarm
equipment connected to
the telephone line, be
sure that installing the
system does not disable
your alarm equipment.
If you have questions
about what will disable
alarm equipment,
contact your
telephone company or
a qualified installer.
note
GETTING STARTED
UP323BH(DCT6485)OMENG.book11ページ２００３年１０月２４日 金曜日 午前１０時５６分

[12] GETTING STARTED
www.uniden.com
B. Install the rechargeable battery pack into the handset
Charge the handset battery pack for at least 15-20 hours before using your new cordless
telephone for the first time! The handset is powered by a rechargeable battery pack. The
battery recharges automatically when the handset is placed in the base unit. To maximize
the charge capacity of your battery pack, DO NOT plug the telephone cord into the base unit
and wall jack until the battery is fully charged.
1) Press down on the handset battery case cover (use the finger
indention for a better grip) and slide the cover downward
to remove.
2) Plug the battery pack connector (red & black wires) into the jack
inside the battery compartment (the connector notches fit into
the grooves of the jack only one-way). Match the wire colors to
the polarity label in the battery compartment, connect the
battery, and listen for a click to insure connection.
3) Make sure you have a good connection by slightly pulling on the
battery wires. If the connection is secure, the battery jack will
remain in place.
4) Place the battery case cover back on the handset by sliding it
upwards until it clicks into place.
5) Place the handset in the base unit for 15-20 hours without
interruption. The base unit's LED light (labeled charge)
illuminates once the handset is placed in the base. The LED light
will illuminate whether the battery pack is connected or not.
If the base charge LED light does not illuminate:
• Check to see if the AC adapter is plugged into the base unit and the electrical wall outlet
properly (use only the supplied AC adapter. Do not use any other AC adapter.)
• Check to see if the handset is sitting correctly in the base and making good contact with
the base unit's charging contacts.
• Use only the Uniden
(BT-446) rechargeable
battery pack supplied
with your cordless
telephone.
•Replacement battery
packs are also
available through the
Uniden Parts
Department at (800)
554-3988, Monday
thru Friday from 8:00
a.m. to 5:00 p.m. or
online at www.
uniden.com
note
UP323BH(DCT6485)OMENG.book12ページ２００３年１０月２４日 金曜日 午前１０時５６分

GETTING STARTED [13]
www.uniden.com
Low battery alert
When the battery pack is very low and need to be charged, the phone is programmed to
eliminate functions in order to save power.
The battery pack needs to be charged when:
- The empty battery icon appears.
-
Low Battery
appears in the display.
If the phone is in standby mode, none of keys will operate.
If you are on a call, complete your conversation as quickly
as possible, and return the handset to the cradle.
Cleaning the battery charging contacts
To maintain a good charge, it is important to clean
the charging contacts on both the handset and the
base unit once a month. Using water only, dampen
a cloth to clean the charging contacts. Then make
sure to go back over the charging contacts with a
dry cloth before returning the handset to the base
to charge.
Caution: Do not use paint thinner, benzene, alcohol,
or other chemical products. Doing so may discolor the
surface of the telephone and damage the finish.
.QY$CVVGT[
•Even when the battery
pack is not being used,
it will gradually
discharge over a long
period of time.
For optimum
performance, be sure
to return the handset
to the base unit after a
telephone call.
•Standby Mode -
The handset is not in
use and talk/flash
has not been pressed.
•Talk Mode -
The handset is not in
the cradle and talk/
flash or speaker has
been pressed enabling
a dial tone.
Talk
appears on the display.
note
GETTING STARTED
UP323BH(DCT6485)OMENG.book13ページ２００３年１０月２４日 金曜日 午前１０時５６分

[14] GETTING STARTED
www.uniden.com
C. Connect the base unit
1) Connect the AC adapter to the DC IN 9V jack and to
a standard 120V AC wall outlet.
2) Set the base on a desk or tabletop, and place the
handset in the base unit.
3) Raise the antenna to a vertical position.
4) Make sure that the charge LED illuminates.
If the LED does not illuminate, check to see that the
AC adapter is plugged in and the handset makes
good contact with the base charging contacts.
•Connect the AC adapter to a continuous power supply.
• Place the base unit close to the AC outlet so that you can
unplug the AC adapter easily.
• After installing the battery pack in the handset, charge your
handset at least 15-20 hours before plugging into the phone
line.
5) Once the handset battery pack is fully charged,
connect the telephone line cord to the TEL LINE jack
and to a telephone outlet.
If your telephone outlet isn't modular, contact
your telephone company for assistance.
•Use only the supplied
[AD-830] AC adapter.
Do not use any other
AC adapter.
•Place the power cord
so that it does not
create a trip hazard or
where it could
become chafed and
create a fire or
electrical hazard.
note
UP323BH(DCT6485)OMENG.book14ページ２００３年１０月２４日 金曜日 午前１０時５６分

GETTING STARTED [15]
www.uniden.com
Mounting the Base Unit on a Wall
Standard wall plate mounting
This phone can be mounted on any standard wall plate.
1) Snap the wall mount adapter into the notches on the
base top.
2) Plug the AC adapter into the DC IN 9V jack.
3) Wrap the AC adapter cord inside the molded wiring
channel as shown.
4) Plug the AC adapter into a standard 120V AC wall outlet.
5) Plug the telephone line cord into the TEL LINE jack.
Wrap the cord inside the molded wiring channel as shown.
6) Plug the telephone line cord into the
telephone outlet.
7) Raise the antenna to a vertical position.
8) Align the mounting slots on the base with the
mounting posts on the wall. Then push in and
down until the phone is firmly seated.
DO NOT use an AC
outlet controlled by a
wall switch.
GETTING STARTED
UP323BH(DCT6485)OMENG.book15ページ２００３年１０月２４日 金曜日 午前１０時５６分

[16] GETTING STARTED
www.uniden.com
Direct wall mounting
If you don't have a standard wall plate, you can mount your phone directly to the wall.
Before doing this, consider the following:
• Avoid electrical cables, pipes, or other items behind the mounting location that could
cause a hazard when inserting screws into the wall.
• Try to mount your phone within 5 feet of a working phone jack to avoid excessive lengths.
• Make sure the wall material is capable of supporting the weight of the base and handset.
• Use #10 screws (minimum length of 1-3/8 inches) with anchoring devices suitable for the
wall material where the base unit will be placed.
1) Insert two mounting screws into the wall (with their
appropriate anchoring device), 3-15/16 inches apart.
Allow about 1/8 of an inch between the wall and screw
heads for mounting the phone.
2) Refer to steps 1 through 8 on page 15 to mount
the telephone.
GETTING STARTED
UP323BH(DCT6485)OMENG.book16ページ２００３年１０月２４日 金曜日 午前１０時５６分

GETTING STARTED [17]
www.uniden.com
About the Menu Options
Your phone has six main menu setup options: DirectLink Mode, Room/Baby Monitor,
Handset Setup, Answ. Setup, Global Setup and System Reset. Each menu have submenu.
Summary of Main Menu Options and Submenu Option
DirectLink Mode (handset only)
In DirectLink Mode, a pair of handsets can function as two-way radios. DirectLink Mode allows
two handsets to communicate with each other without the base unit or a telephone line. Use
them at sporting events or while shopping to stay in contact with family members or friends.
You must set both handsets to DirectLink Mode activate this feature (see page 21).
Room/Baby Monitor
This feature allows you to monitor sounds in another room (see page 22 for setup). Place the
base or a handset in the room you wish to monitor; it will function as microphone. A second
handset can be set to function as a remote speaker, allowing you to monitor sounds in the room.
•For Global Setup and
System Reset, make
sure the line is not in
use and handsets are
within the range limit
of the base unit.
•If an incoming call is
received during room
monitor mode, the
user’s handset will
receive incoming tones
or beeps. To cancel
room/baby monitor
and receive the call,
press talk/flash or
speaker. If monitoring
from base unit, press
speaker. The handset
or the base that’s
placed in the room
being monitored, will
NOT sound or receive
incoming tones.
note
GETTING STARTED
UP323BH(DCT6485)OMENG.book17ページ２００３年１０月２４日 金曜日 午前１０時５６分

[18] GETTING STARTED
www.uniden.com
Handset Setup
The following submenu options must be set separately for each handset.
Submenu option Description
Ringer Tones
(Default is Flicker)Adjusting the ringer tone (see page 22).
Distinct. Ring
(Default is on)
Set the distinctive ring (tone your phone makes when ringing) (see page 23).
"Distinctive Ringer" allows you to preset memory locations with a designated
ring tone. When an incoming call is received and the Caller ID information
matches the information in one of the memory locations, the distinctive ring
that has been stored for that particular Caller will sound. If you have set
multiple memory locations with distinctive rings, switching the setting to
"Distinctive Off" will result in no distinctive ringing. All incoming calls will
have a normal ring tone. Switching to "Distinctive On" will activate all
programmed distinctive ring memory locations.
AutoTalk
(Default is off)
Allows you to answer the phone without pressing talk/flash or speaker.
When the AutoTalk is set to On, simply remove the handset from the cradle
and the phone automatically answers the call (see page 23).
Anykey Answer
(Default is off)
Allows you to answer the phone without pressing talk/flash or speaker.
When the Anykey Answer is On, you can answer a call by pressing any number
key,
*
/tone/←, or #/→on the handset (see page 23).
Banner (True Banner)
Customize your handset(s) by giving it a banner name.
The name will be displayed on the LCD screen during standby mode, Intercom,
Transfer, Room Monitor and Copy Phonebook operation. The banner name will
be displayed on the receiving handset as well (see page 23).
Language
(Default is English)
The menu display options can be set to English, French or Spanish for easy
setup use (see page 24).
Key Touch Tone
(Default is on)
Allows you to set your phone's key touch-tone to On or Off (tone your keypad
makes when keys are pressed) (see page 24).
GETTING STARTED
UP323BH(DCT6485)OMENG.book18ページ２００３年１０月２４日 金曜日 午前１０時５６分
