Unifosa Proware EP-4646JD-SCSC User manual

64 Bays
SAS to SAS/SATA
JBOD Subsystem
User Manual
Revision 1.0

64 Bays SAS to SAS/SATA JBOD Subsystem
2
User Manual
Table of Contents
Preface................................................................................................................................3
Before You Begin .............................................................................................................4
Safety Guidelines....................................................................................................................................................................4
Controller Configurations...................................................................................................................................................4
Packaging, Shipment and Delivery................................................................................................................................4
Unpacking the Shipping Carton................................................................................................................................5
Chapter 1 Product Introduction.................................................................................6
1.1 Technical Specifications ...........................................................................................................................................7
Chapter 2 Identifying Parts of the JBOD Subsystem ............................................8
2.1 Main Components......................................................................................................................................................8
2.1.1 Front View.............................................................................................................................................................8
2.1.1.1 LCD Display Panel LED...........................................................................................................................9
2.1.1.2 HDD Status LEDs ...................................................................................................................................10
2.1.1.3 Menu Diagram........................................................................................................................................11
2.1.2 Rear View............................................................................................................................................................ 12
2.3 Power Supply Fan Module (PSFM) .................................................................................................................. 13
2.3.1 PSFM Panel........................................................................................................................................................ 15
2.4 Fan Module.................................................................................................................................................................16
2.4.1 Turbo Fan ........................................................................................................................................................... 18
2.5 Disk Drive Installation into the Disk Slot...................................................................................................... 19
2.5.1 To install a disk drive in a disk tray: ......................................................................................................... 20
Chapter 3 Getting Started with the Subsystem................................................... 23
3.1 Installing the Rails and Mounting into Rack ..............................................................................................23
3.2 Removing the Disk Array from the Rack...................................................................................................... 36
3.3 Preparing the JBOD and Connecting to RAID Subsystem ................................................................... 38
3.4 Preparing the JBOD and Connecting to SAS HBA in Host System ................................................. 38
3.5 Powering On .............................................................................................................................................................. 39
3.6 Powering Off .............................................................................................................................................................. 40
Chapter 4 Maintenance............................................................................................. 41
4.1Upgrading the JBOD Controller Firmware...................................................................................................41

64 Bays SAS to SAS/SATA JBOD Subsystem
User Manual
3
Preface
About this manual
This manual provides information regarding the hardware features and installation of
the 64Bay JBOD subsystem. Information contained in the manual has been
reviewed for accuracy, but not for product warranty because of the various
environment/OS/settings. Information and specifications will be changed without
further notice.
This manual uses section numbering for every topic being discussed for easy and
convenient way of finding information in accordance with the user’s needs. The
following icons are being used for some details and information to be considered in
going through with this manual:
Copyright
No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying,
recording or otherwise, without the prior written consent.
Trademarks
All products and trade names used in this document are trademarks or registered
trademarks of their respective owners.
Changes
The material in this document is for information only and is subject to change without
notice.
WARNING!
These are the warnings that the user must follow to avoid
unnecessary errors and bodily injury during hardware and
software operation of the subsystem.
CAUTION:
These are the cautions that user must be aware of to
prevent damage to the subsystem and/or its
components.
NOTES:
These are notes that contain useful information and tips
that the user must give attention to in going through
with the subsystem operation.
IMPORTANT!
These are the important information that the user must
remember.

64 Bays SAS to SAS/SATA JBOD Subsystem
4
User Manual
Before You Begin
Before going through with this manual, you should read and focus on the following
safety guidelines. Notes about the subsystem’s controller configuration and the
product packaging and delivery are also included here.
Safety Guidelines
To provide reasonable protection against any harm on the part of the user and to
obtain maximum performance, user is advised to be aware of the following safety
guidelines particularly in handling hardware components:
Upon receiving of the product:
Place the product in its proper location.
Do not try to lift it by yourself alone. Two or more persons are needed to remove
or lift the product to its packaging. To avoid unnecessary dropping out, make
sure that somebody is around for immediate assistance.
It should be handled with care to avoid dropping that may cause damage to the
product. Always use the correct lifting procedures.
Upon installing of the product:
Ambient temperature is very important for the installation site. It must not
exceed 30◦C. Due to seasonal climate changes; regulate the installation site
temperature making it not to exceed the allowed ambient temperature.
Before plugging-in any power cords, cables and connectors, make sure that the
power switches are turned off. Disconnect first any power connection if the power
supply module is being removed from the enclosure.
Outlets must be accessible to the equipment.
All external connections should be made using shielded cables and as much as
possible should not be performed by bare hand. Using anti-static hand gloves is
recommended.
In installing each component, secure all the mounting screws and locks. Make
sure that all screws are fully tightened. Follow correctly all the listed procedures
in this manual for reliable performance.
Controller Configurations
This JBOD subsystem supports single JBOD controller configurations.
Packaging, Shipment and Delivery
Before removing the subsystem from the shipping carton, you should visually
inspect the physical condition of the shipping carton.
Unpack and verify that the contents of the shipping carton are complete and in
good condition.
Exterior damage to the shipping carton may indicate that the contents of the
carton are damaged.
If any damage is found, do not remove the components; contact the dealer where
you purchased the subsystem for further instructions.

64 Bays SAS to SAS/SATA JBOD Subsystem
User Manual
5
Unpacking the Shipping Carton
The shipping carton contains the following:
NOTE: If any damage is found, contact the dealer or vendor for
assistance.
JBOD Subsystem Unit
64 pairs of HDD side brackets
Two (2) Power cords
Two (2) mini SAS HD cables
Two (2) serial cables DB9-to-DB9
Slide rail
Key of Top Cover
Screws
User Manual

64 Bays SAS to SAS/SATA JBOD Subsystem
6
User Manual
Chapter 1 Product Introduction
The 64 bays JBOD Subsystem
The JBOD subsystem is a 19-inch 4U rackmount JBOD unit. It is a versatile SAS3 /
SATA3 disk expansion system, ideal for high capacity and scalability storage in IT
demands. It offers high density storage, hardware redundancy and easily integrates into
versatile applications that request high performance and high scalability.
This JBOD subsystem comes with dual SAS Expander JBOD configuration. It features a
modular architecture for key components which ease system maintenance and
management.
Highest Density Avai labl e
- 4U chassis with 64 bays carriers
- Support the 3.5" enterprise class SAS3/SATA3 HDD drives
High Availability
- Dual SAS Expander JBOD consist of four 4x mini SAS HD ports
Power Supply
- Power supply and cooling system contained in 1 module for efficient cooling
- Two 1100W redundant hot swappable power supplies
Enclosure
- Incorporates SAS Expander on disk backplane for maximum signal integrity
- Utilizes industry-standard SCSI enclosure services (SES) to monitor enclosure and disk
environmental conditions
Enclosure monito ring
- S.E.S. support for standard enclosure management
- System LED indications
- Fan speed monitoring
- Power supply monitoring
- System voltage monitoring
- System temperature monitoring
- System alarm

64 Bays SAS to SAS/SATA JBOD Subsystem
User Manual
7
1.1 Technical Specifications
JBOD
Redundant
Host Interface
Two 4x mini SAS HD (12Gb/s)
Disk Interface
12Gb/s SAS, 6Gb/s SATA
SAS expansion
Two 4x mini SAS HD (12Gb/s)
Enclosure
Platform
Rackmount
Form Factor
4U
# of Hot Swap Trays
64
Tray Lock
Yes
Disk Status Indicator
Access / Fail LED
Disk Backplane
SAS3 / SATA3
# of PS/Fan Modules
1100W x 2 w/PFC
# of Fans
15
Monitor port support
Yes
Power requirements
AC 90V ~ 254V Full Range, 50Hz~60Hz
Environmental
Relative Humidity
10% ~ 85% Non-condensing
Operating Temperature
10°C ~ 40°C (50°F ~ 104°F)
Physical Dimension
880(L) x 482.6(W) x 177(H) mm
Weight (Without Disk)
43.5 / 45 Kg
Specification is subject to change without notice.

64 Bays SAS to SAS/SATA JBOD Subsystem
8
User Manual
Chapter 2 Identifying Parts of the JBOD Subsystem
2.1 Main Components
2.1.1 Front View
IMPORTANT: When powering off the JBOD subsystem, turn off first
the Main Switch and allow at least 4 minutes for the subsystem to
shutdown properly. Then turn off the switches of the 2 Power
Supply Fan Modules.

64 Bays SAS to SAS/SATA JBOD Subsystem
User Manual
9
2.1.1.1 LCD Display Panel LED
Main Switch Button
Flashing Blue
Indicates that the power cords are inserted and/or
indicates the 2 power supply switches are turn on.
Light Blue
Indicates that the sytem is on.
No Light
Indicates that the whole system is power off.
Part
Function
Power LED
Green indicates power is ON.

64 Bays SAS to SAS/SATA JBOD Subsystem
10
User Manual
2.1.1.2 HDD Status LEDs
The Front Panel shows the disk drives status.
Indicator
Color
Description
Activity LED
Blue
Blinking
Indicates the disk drive is busy or being
accessed.
Power
On/Fail LED
Green
Indicates the disk drive in this slot is good.
RED
Indicates the disk drive in this slot is
defective or failed.
LED is
off
Indicates there is no disk drive in this slot.
Activity LED
Power On/Fail LED
