UniGuard GT06L User manual

1
UniGuard Technology Limited
4G GPS Tracker
GT06L User Manual

2
UniGuard Technology Limited
1 Features
◇ Vehicle/scooter/motorcycle tracking
◇ Real-time tracking by SMS/Platform/APP
◇ Speeding alarm/Geo-fence alarm
◇ Power Cut alarm with built-in battery
◇ Vibration alarm
◇ Ignition ON/OFF alarm
◇ Disable fuel or electricity
◇ Alarm speaker
◇ Remote controller set arm/disarm
◇ Movement alarm

3
UniGuard Technology Limited
2 Specs
3 Install SIM Card
Preparation: insert 4G SIM card with activated GPRS data; Make sure SIM card
with full balance; If SIM card with PIN code, must remove it advance.
4 Device light description
Light
Signal
Flashing
Always on
Red
Power
Battery low
Charging
Green
GSM signal
flashes every 3s after connected server
No GSM/LTE network
Blue
GPS signal
flashes 3 times per second if GPS located
NO GPS signal
Content
Specs.
Dim.
89*44*16mm
Network
LTE/GSM/GPRS
Frequency
LTE-FDD B1/B2/B3/B4/B5/B7/B8/B28/B66
GSM :850/900/1800/1900Mhz
Module & Chipset
A7670SA+AT6558R
GPS channel
66
Tracking sensitivity
-165dBm
Location accuracy
<5 meters CEP
Time To First Fix(open sky)
Cold status <35s
Hot status <1s
Working voltage
9-36VDC
GPRS Protocol
Class12, TCP/IP
Operating temp.
-20°C to +70°C
Back up battery
200mAh /3.7V Li-Polymer battery
Standby & Working consumption
5mA~50mA
GSM / GPS antenna
Built-in
G-Sensor
Support
Ignition status detection
Support
Micro USB interface
Flash firmware/Configuration
Configuration Mode
PC –USB/GPRS /SMS
Power interface
8 PIN(Power/ACC/Relay/Speaker /SOS)

4
UniGuard Technology Limited
5 Installation
The device has built-in GSM and GPS antenna, make sure front side
upward and there is no metal shielding.
6Wires connection

5
UniGuard Technology Limited
7 Command List
Note: All Alarms only will be sent to admin Number
Command
Function
apn123456 APN APNname APNpassword
Set APN
adminip123456 www.gpspos.net 8000
Set IP Port
password123456 888888
Change password
smslink123456
google link
fix020s060m***n123456
Set upload interval
ANGLE123456 30
Set angle change upload interval
acc123456
ACC ON OFF alarm
noacc123456
Cancel ACC ON OFF alarm
acc123456 1
Activate ACC ON alarm via speaker
acc123456 0
Cancel ACC ON alarm via speaker
quickstop123456
fast cut fuel
noquickstop123456
Cut fuel based on speed less than 20km/h
stop123456
Cut fuel based on speed less than 20km/h
resume123456
resume fuel
arm123456
Set arm mode when ACC OFF
disarm123456
Cancel arm mode
silent123456
Silent mode(speaker no sound but SMS alarm)
move123456 0200
movement alarm(200meters)
nomove123456
Cancel movement alarm
vibrate123456 1
Activate vibrate alarm(alarm speaker beep 5s)
vibrate123456 0
Cancel vibrate alarm
sensitivity123456 1
Set vibrate level 1
sensitivity123456 2
Set vibrate level 2
sensitivity123456 3
Set vibrate level 3
sleep123456 on
GSM/GPS sleep when vehicle stopping
sleep123456 off
Cancel sleep mode
suppress123456
Activate GPS drifting control
nosuppress123456
Cancel GPS drifting control
check123456
Check device parameters
IPAPN123456
IP APN Check
reset123456
Reset device
KC123456 0
Cancel alarm
KC123456 1
GPRS alarm (default)
KC123456 2
GPRS+sms alarm
KC123456 3
GPRS+sms+call alarm
admin123456 15018500598
Set admin number
noadmin123456 15018500598
Delete admin number
begin123456
Back to factory settings

6
UniGuard Technology Limited
8 Function of Remote Controller (B optional )
Button
Function
Description
ARM
Press for 1 time, siren will beep 1 time
DISARM
Press for 1 time, siren will beep 1 time
SOS
Press for 1 time, tracker will send SOS alert to
admin phone number.
Deterrence/c
ar search
Press for 1 when it is in arm state, siren will beep all
the time, press disarm button
to quit.
9Web platform GPS tracking software
Website: www.gpspos.net
Default IMEI as user name, password 123456.
Searching APP: Search GPSPOS at Appstore, Search POSGPS at Google Play
