UniGuard UM666A User manual

UniGuard Technology Limited
- - www.uniguardgps.com
1
Magnetic GPS Tracker
User Manual
UM666A
Attention:
Charge is forbidden.
24Hrs per locate: 3 Years (Default)
Text message: 109# (Change reply to English language)

UniGuard Technology Limited
- - www.uniguardgps.com
2
1 GPS Tracking System Introduction
Portable GPS Tracker UM666A integrates GPS and GSM functions, which could
send vehicle location and status to mobile and Internet. It utilizes GPS and LBS double
locating. Its advantage is that the builtin battery can last 3 years at reporting interval
every 24hrs. No wires connection. Place and Work. The system structure is as below:

UniGuard Technology Limited
- - www.uniguardgps.com
3
2 Product Description
2.1 Specification
Content
Specifications
Dimensions
80*68*23 mm
Weight
133g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS chip
UBLOX-7020
GSM Module
MTK6260D
GPS sensitivity
-159dBm
GPS accuracy
10m
Time to First Fix
Cold status 45-120s
Warm status 35s
Hot status 1s
Battery
Non-rechargeable dry battery
6000 mAh
Standby
3 years
Storage Temperature
-40 to 85 ℃
Operation Temp e r a t u r e
-20 to 55 ℃
Humidity
5%-95% non-condensing

UniGuard Technology Limited
- - www.uniguardgps.com
4
2.2 Picture and main functions:
3 Commands
Function
SMS command
Query current location
G1234
Set Domain and Port
IP www.gpspos.net 8000
Set APN
apn123456 aaa bbb ccc
Set Admin number
101#Tel# (e.g. 101#150123456#)
Check Device Status
cxzt
Restart Device
CQ

UniGuard Technology Limited
- - www.uniguardgps.com
5
Working Mode explanation:
【24HRS Tracking】: Device every 24 hours wakeup 1 time to send GPS data
Send command: WT24,TimeA,TimeB
E.g: WT24,1212,0800
Device starts 24hrs interval tracking at 12:12pm, and device currently wakes up at
8:00am.
【99HRS Tracking】: Device every 99 hours wake up 1 time to send GPS data
Send command: WT99,TimeA,Timeb
E.g.: WT99,1815,1345
Device starts 99hrs interval tracking at 18:15pm, and device currently wakes up at
13:45pm.
【999HRS Tracking】: Device every 999 hours wake up 1 time to send GPS data
Send command: WS099901,TimeA,TimeB
WS099901,1500,1345
Device starts 999hrs interval tracking at 15:00pm, and device currently wakes up at
13:45pm.
【Continuous Tracking】： Device keeps sending GPS data to server at set interval.
This command is only used for emergency, otherwise it consumes power fast.
Send command: DWX X=5~300
E.g. DW005, device shall work continuously for 5 mins and then go to 24Hr sleep

UniGuard Technology Limited
- - www.uniguardgps.com
6
mode.
DW000 is to activate continuous tracking forever.
4 Web Tracking
5.1Login www.gpspos.net to start web tracking service with your own
account
5.2 Download APP: Search GPSPOS at Appstore or Google Play.
6 Cautions
6.1 Keep the unit dry.
6.2 Don’t use & store the unit in dusty places.
6.3 Don’t put the unit in overheated or overcooled places.
6.4 Handle carefully. Don’t vibrate or shake it violently.
6.5 Clear the unit with a piece of dry cloth.
6.6 Don’t paint the unit.
