UniOP BKDC-16 User manual

MANUUNIOP22- v.1.08 - 07.2004
UniOP
Universal Operator Panels
Installation Guide
StockCheck.com
Downloaded from StockCheck.com

UniOPTM
Universal Operator Panel
Installation Guide
Document code MANUUNIOP22
Version 1.08
Date 13.07.2004
The contents of this manual have been checked for correctness and conformance to
the described equipment, Nevertheless it is not possible to guarantee the absence of
possible discrepancies. The contents of the manual are checked on a regular basis and
any necessary corrections are introduced in successive versions.
Information in this document is subject to change without notice.
No part of this manual may be reproduced or transmitted in any form or by any
means, electronic or mechanical, for any purpose, without the prior written
permission of SITEK S.p.A
Windows is a registered trademark of Microsoft Corporation.
Copyright ©2001 SITEK S.p.A. All rights reserved.
SITEK S.p.A. - San Giovanni Lupatoto VR, Italy.
Printed in Italy.
StockCheck.com
Downloaded from StockCheck.com

Installation Guide
i
Installation Guide
Contents
Introduction.....................................................................................................1
Product Identification ..........................................................................3
Technical Specifications.................................................................................3
Installation ....................................................................................................26
Phisical Dimensions...........................................................................26
Connections.......................................................................................44
Power Supply and Grounding............................................................57
PLC Port............................................................................................58
PC/Printer Port...................................................................................59
AUX Port...........................................................................................61
Models without the PC/Printer Port...................................................63
External Keyboard Port .....................................................................63
Battery Replacement..........................................................................64
Removing the Legends......................................................................65
Dedicated LED’s ...............................................................................66
Usage and Safety Guidelines.............................................................67
Installation Environment ...................................................................67
Installation Procedures.......................................................................70
Handling the Memory Cards.........................................................................71
Getting Started..............................................................................................72
Command Summary..........................................................................73
Troubleshooting.................................................................................77
Touchscreen Calibration....................................................................77
StockCheck.com
Downloaded from StockCheck.com

UniOP
ii
StockCheck.com
Downloaded from StockCheck.com

Installation Guide
1
Introduction
This Installation Guide describes the main features of the UniOP operator panels.
The Guide refers to the following models:
BKDC-16 Operator interface with color display
BKDC-16T Operator interface with touch and color display
BKDC-46 Operator interface with color display
BKDL-16 Operator interface with EL display
BKDL-16T Operator interface with touch and EL display
BKDR-16 Operator interface with LCD display
BKDR-16T Operator interface with touch and LCD display
BKDR-46 Operator interface with LCD display
CP01F-02 Operator interface with VFD display
CP01R-04 Operator interface with LCD display
CP02F-02 Operator interface with VFD display
CP02R-04 Operator interface with LCD display
CP04F-04 Operator interface with VFD display
CP05R-04 Operator interface with LCD display
CP10G-04 Operator interface with LCD display
CP11G-04 Operator interface with LCD display
CP12G-04 Operator interface with LCD display
CP13G-04 Operator interface with LCD display
ECT-16 Operator interface with touch and color display
ECT-VGA Operator interface with touch and VGA color display
EF-02 Operator interface with VFD display
EF-04 Operator interface with VFD display
EL-16N Operator interface with EL display
ELT-16 Operator interface with touch and EL display
ELT-VGA Operator interface with touch and VGA display
EL-VGA Operator interface with VGA display
ePAD30 Operator interface with TFT display
ePAD30T Operator interface with touch and TFT display
ePAD31 Operator interface with LCD display
ePAD31T Opertor interface with touch and LCD display
ePAD32 Operator interface with VGA display
ePAD32T Operator interface with touch and VGA display
ePAD33 Operator interface with TFT display
ePAD33T Operator interface with touch and TFT display
ER-04 Operator interface with LCD display
ER-16 Operator interface with LCD display
ER-16TA Operator interface with touch and LCD display
ER-25 Operator interface with LCD display
StockCheck.com
Downloaded from StockCheck.com

UniOP
2
ER-25T Operator interface with touch and LCD display
ERT-16 Operator interface with touch and LCD display
ERT-VGA Operator interface with touch and VGA display
ER-VGA Operator interface with VGA display
eTOP05 Operator interface with LCD 5”7 display
eTOP10 Operator interface with TFT 5”7 display
eTOP11 Operator interface with LCD 5”7 display
eTOP12 Operator interface with LCD B/W 5”7 display
eTOP30 Operator interface with TFT 10”4 display
eTOP31 Operator interface with LCD 10”4 display
eTOP32 Operator interface with VGA B/W 9”4 display
eTOP33 Operator interface with TFT 10”4 display
eTOP40 Operator interface with TFT 12”1 display
eTOP50 Operator interface with XGA TFT 15” display
ETT-VGA Operator interface with touch and TFT color display
MD00G-04 Operator interface with LCD display
MD00R-02 Low-cost operator interface with LCD display
MD00R-04 Low-cost operator interface with LCD display
MD01R-02 Low-cost operator interface with LCD display
MD02F-02 Low-cost operator interface with VFD display
MD02G-04 Low-cost operator interface with LCD display
MD02R-04 Low-cost operator interface with LCD display
MD03R-02 Low-cost operator interface with LCD display
MD03R-04 Low-cost operator interface with LCD display
MKDC-VGA Operator interface with VGA color display
MKDC-VGA-
T
Operator interface with touch and VGA color display
MKDF-02 Operator interface with VFD display
MKDF-04 Operator interface with VFD display
MKDG-05 Operator interface with LCD display
MKDG-06 Operator interface with LCD display
MKDG-07 Operator interface with LCD display
MKDL-16N Operator interface with EL display
MKDL-VGA Operator interface with VGA display
MKDR-04 Operator interface with LCD display
MKDR-05 Operator interface with LCD display
MKDR-16 Operator interface with LCD display
MKDR-16TA Operator interface with touch and LCD display
MKDR-25 Operator interface with LCD display
MKDR-VGA Operator interface with VGA display
MKDR-VGA-
T
Operator interface with touch and VGA display
MKDT-VGA Operator interface with TFT color display
MKDT-VGA-
T
Operator interface with touch and TFT color display
StockCheck.com
Downloaded from StockCheck.com

Installation Guide
3
TP01C-16 Operator interface with color display
TP01R-16 Operator interface with LCD display
The products have been designed for installation in an industrial environ in
compliance with the regulations:
Emitted interference EN 61000-6-4
Noise Immunity EN 61000-6-2
In compliance with the above regulations the products are CE marked.
Product Identification
The product may be identified through a plate attached to the rear cover. You will
have to know the type of unit you are using for correct usage of the information
contained in the guide.
An example of this plate is shown in the figure below:
eTOP10-0050 product model name
11/01 month/year of production
13435 35508 serial number
H/W V hardware version of the product
S/W V software version of the product
Technical Specifications
Power supply voltage DC 18 - 30 V
Power consumption (1)
StockCheck.com
Downloaded from StockCheck.com

UniOP
4
Back-up battery (1) 3 V 270mA Lithium, not rechargeable,
life about 1 year, user replaceable,
model: CR2430.Change with same battery or
equivalent with the work temperature of UniOP.
Fuse 2 A T user replaceable
(except the models CP10G-04, CP11G-04,
CP12G-04, CP13G-04, MKDG-06, MKDG-07,
MD00G-04, MD00R-02/04, ePAD30, ePAD30T,
ePAD31, ePAD31T, ePAD32, ePAD32T,
ePAD33, ePAD33T and eTOP05/10/11/12
eTOP30/31/32/33/40/50 that are equipped with an
overcurrent protection device)
Environmental conditions
Operating temperature 0 ÷+50°C, with the exception
of the model indicated on note
(2)
EN 60068-2-14
Storage temperature -20 ÷+70°C EN 60068-2-14
Operating and storage humidity 5 ÷85 % RH not-condensing EN 60068-2-30
Vibrations 10 ÷57 Hz, 0,075 mm peak
57 ÷150 Hz, 1 G EN 60068-2-6
Shock 50 G, 11 ms, 3 pulses per axis EN 60068-2-27
Protection class IP65 front panel (3) EN 60529
Keyboard reliability > 3 million operations
Touch screen tecnology Resistive
Touch screen reliability > 1 million operations
Electromagnetic Compatibility (EMC)
Emitted interference Class A EN 55011
Immunity to radiated radiofrequency
electromagnetic field 80 MHz ÷1 GHz, 10 V/m
900 MHz, 10V/m EN 61000-4-3
ENV 50204
Immunity to conducted disturbances
inducted by radiofrequency field 0.15 ÷80 MHz, 10 V EN 61000-4-6
Fast transient 2 KV power supply
1 KV signal lines EN 61000-4-4
Electrostatic discharge 8 KV in air EN 61000-4-2
PC/Printer Port(1) RS-232connector D-sub 15 pin female
300 - 38400 baud
PLC Port RS-232, RS-422, RS-485, C.L. 20 mA (active),
connector D-15 pin male
300 - 38400(1) baud
StockCheck.com
Downloaded from StockCheck.com

Installation Guide
5
AUX Port connector D-9 pin female (functionality can be
configured with an optional communicatin
module)
User memory (1)
Recipe memory (1) 16 KB / 32 KB RAM with back-up battery
Hardware clock (1) Clock/Calendar with back-up battery
Alarms (1) 256/1024
Historical event list (1) last 256/1024 events with back-up battery
Programming software Designer version 6
Notes:
(1) feature depends on the panel models; see Table 1.
(2) for models with “A6” suffix range 0 ÷+60°C ,
for models with “A7” suffix range -20 ÷+60°C
for eTOP and ePAD range 0 ÷+45°C
(3) all the installation instructions listed in the chapter ‘Installation
Environment’ must be followed in detail.
StockCheck.com
Downloaded from StockCheck.com

UniOP
6
Model BKDC-16 BKDC-16T BKDC-46
Display 16x40 STN
COLOR 16x40 STN COLOR 16x40 STN COLOR
Backlight CCFL CCFL CCFL
Graphics 320x240 320x240 320x240
Display dimensions (mm) 121x91 121x91 121x91
Diagonal (inches) 5.6” 5.6” 5.6”
Character height (mm) - - -
User memory 512KB 512KB 8MB
User memory expansion up to 1MB up to 1MB -
Function keys 14 14 33
System keys 23 23 24
Touch screen - YES -
User LED’s 11 11 24
System LED’s 4 4 5
PC/Printer Port YES YES YES
PLC Port YES YES YES
AUX Port (1) YES YES YES
Esternal keyboard Port YES YES -
Programming speed 9600-38400 9600-38400 9600-38400
Battery YES YES YES
Recipe memory 32KB 32KB 32KB
Alarms 1024 1024 1024
Events list 1024 1024 1024
Hardware clock YES YES YES
Downloadable characters 256 256 256
Screen saver YES YES -YES
Buzzer - - -
Max current consumption on 24VDC (mA) 500 500 600
Suffix 45: dimensions WxHxD (mm) (2) 216x168x82 216x168x82 275x220x80
Suffix 50: dimensions WxHxD (mm) (3) - - -
Max panel thickness (mm) 8 8 5
Weight (Kg) 1.4 1.4 1.9
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

Installation Guide
7
BKDL-16 BKDL-16T BKDR-16 BKDR-16T BKDR-46 CP01F-02
16x40 EL 16x40 EL 16x40 LCD 16x40 LCD 16x40 LCD 2x20 VFD
CCFL CCFL CCFL CCFL CCFL LED
320x240 320x240 320x240 320x240 320x240 -
121x91 121x91 121x91 121x91 121x91 -
5.6” 5.6” 5.6” 5.6” 5.6” -
- - - - - 5
512KB 512KB 512KB 512KB 8MB 512KB
up to 1MB up to 1MB up to 1MB up to 1MB - up to 1MB
14 14 14 14 33 5
23 23 23 23 24 19
- YES - YES - -
11 11 11 11 24 5
4 4 4 4 5 1
YES YES YES YES YES YES
YES YES YES YES YES YES
YES YES YES YES YES YES
YES YES YES YES - -
9600-38400 9600-38400 9600-38400 9600-38400 9600-38400 9600-38400
YES YES YES YES YES YES
32KB 32KB 32KB 32KB 32KB 16KB
1024 1024 1024 1024 1024 1024
1024 1024 1024 1024 1024 256
YES YES YES YES YES YES
256 256 256 256 256 -
- - YES YES YES -
- - - - - -
800 800 500 500 600 300
216x168x82 216x168x82 216x168x82 216x168x82 275x220x80 138x186x82
- - - - - -
8 8 8 8 5 8
1.4 1.4 1.4 1.4 1.9 1.1
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

UniOP
8
Model CP01R-04 CP02F-02 CP02R-04
Display 4x20 LCD 2x20 VFD 4x20 LCD
Backlight LED LED LED
Graphics - - -
Display dimensions (mm) - - -
Diagonal (inches) - - -
Character height (mm) 5 5 5
User memory 512KB 512KB 512KB
User memory expansion up to 1MB up to 1MB up to 1MB
Function keys 5 16 16
System keys 19 18 18
Touch screen - - -
User LED’s 5 16 16
System LED’s 1 1 1
PC/Printer Port YES YES YES
PLC Port YES YES YES
AUX Port (1) YES YES YES
Esternal keyboard Port - - -
Programming speed 9600-38400 9600-38400 9600-38400
Battery YES YES YES
Recipe memory 16KB 16KB 16KB
Alarms 1024 1024 1024
Events list 256 256 256
Hardware clock YES YES YES
Downloadable characters 8 - 8
Screen saver - - -
Buzzer - - -
Max current consumption on 24VDC (mA) 250 300 250
Suffix 45: dimensions WxHxD (mm) (2) 138x186x82 138x186x82 138x186x82
Suffix 50: dimensions WxHxD (mm) (3) - - -
Max panel thickness (mm) 8 8 8
Weight (Kg) 1.1 1.1 1.1
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

Installation Guide
9
CP04F-04 CP05R-04 CP10G-04 CP11G-04 CP12G-04 CP13G-04
4x20 VFD 4x20 LCD 4x20 LCD 4x20 LCD 4x20 LCD 4x20 LCD
LED LED LED LED LED LED
- - 120x32 120x32 120x32 120x32
- - 70x21 70x21 70x21 70x21
- - 2.8” 2.8” 2.8” 2.8”
5 5 - - - -
512KB 512KB 512KB 512KB 512KB 512KB
up to 1MB up to 1MB up to 1MB up to 1MB up to 1MB up to 1MB
10 5 12 12 23 23
19 19 23 23 24 24
- - - - - -
10 5 13 13 32 32
2 1 4 4 5 5
YES - YES - YES -
YES YES YES YES YES YES
YES YES YES YES YES YES
- - - - - -
9600-38400 9600 9600-38400 9600 9600-38400 9600
YES - YES - YES -
16KB - 16KB - 16KB -
1024 256 1024 256 1024 256
256 - 256 - 256 -
YES - YES - YES -
- 8 256 256 256 256
- - - - - -
- - - - - -
450 250 300 300 250 250
168x216x82 138x186x82 141x176x76 141x176x76 275x220x76 275x220x76
- - 141x176x80 141x176x80 275x220x85 275x220x85
8 8 5 5 5 5
1.3 1.1 1.1 1.1 2 2
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

UniOP
10
Model ECT-16 ECT-VGA EF-02
Display 16x40 STN
COLOR 30x80 STN COLOR 2x40 VFD
Backlight CCFL CCFL CCFL
Graphics 320x240 640x480 -
Display dimensions (mm) 121x91 212x159 -
Diagonal (inches) 5.6” 10.4” -
Character height (mm) - - 5
User memory 512KB 8MB 512KB
User memory expansion up to 1MB up to 1MB
Function keys - 8 -
System keys - 3 5
Touch screen YES YES -
User LED’s - 8 -
System LED’s 5 5 4
PC/Printer Port YES YES YES
PLC Port YES YES YES
AUX Port (1) YES YES YES
Esternal keyboard Port YES YES YES
Programming speed 9600-38400 9600-38400 9600-38400
Battery YES YES YES
Recipe memory 32KB 32KB 16KB
Alarms 1024 1024 1024
Events list 1024 1024 256
Hardware clock YES YES YES
Downloadable characters 256 256 -
Screen saver YES YES -
Buzzer YES - -
Max current consumption on 24VDC (mA) 500 700 500
Suffix 45: dimensions WxHxD (mm) (2) 216x168x82 311x220x89 311x111x89
Suffix 50: dimensions WxHxD (mm) (3) - - -
Max panel thickness (mm) 8 9 9
Weight (Kg) 1.4 2.7 1.7
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

Installation Guide
11
EF-04 EL-16N ELT-16 ELT-VGA EL-VGA ePAD30
4x40 VFD 16x40 EL 16x40 EL 30x80 EL 30x80 30x80 TFT
CCFL CCFL CCFL CCFL CCFL CCFL
- 320x240 320x240 640x480 640x480 640X480
- 121x91 121x91 212x159 212x159 218X159
- 5.6” 5.6” 10.4” 10.4” 10.4”
5 - - - - -
512KB 512KB 512KB 8MB 8MB 8MB
up to 1MB up to 1MB up to 1MB - - 16MB
- - - 8 8 12
5 5 - 3 3 47
- - YES YES - -
- - - - 8 24
4 4 5 4 5 5
YES YES YES YES YES YES
YES YES YES YES YES YES
YES YES YES YES YES YES
YES YES YES YES YES -
9600-38400 9600-38400 9600-38400 9600-38400 9600-38400 9600-38400
YES YES YES YES YES YES
16KB 32KB 32KB 32KB 32KB 32 KB
1024 1024 1024 1024 1024 1024
256 1024 1024 1024 1024 1024
YES YES YES YES YES YES
- 256 256 256 256 256
- - - - - YES
- - YES - - YES
700 800 800 1300 1300 700
311x111x89 311x165x89 216x168x82 311x220x89 311x220x89 -
- - - - -
311x276x100
9 9 8 9 9 4
1.9 2.4 1.4 2.7 2.7 2.7
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

UniOP
12
Model ePAD30T ePAD31 ePAD31T
Display 30x80 TFT 30x80 STN
COLOR 30x80 STN COLOR
Backlight CCFL CCFL CCFL
Graphics 640X480 640X480 640X480
Display dimensions (mm) 218X159 218X159 218X159
Diagonal (inches) 10.4” 10.4” 10.4”
Character height (mm) - - -
User memory 8MB 8MB 8MB
User memory expansion 16MB 16MB 16MB
Function keys 12 12 12
System keys 47 47 47
Touch screen YES - YES
User LED’s 24 24 24
System LED’s 5 5 5
PC/Printer Port YES YES YES
PLC Port YES YES YES
AUX Port (1) YES YES YES
Esternal keyboard Port - - -
Programming speed 9600-38400 9600-38400 9600-38400
Battery YES YES YES
Recipe memory 32 KB 32 KB 32 KB
Alarms 1024 1024 1024
Events list 1024 1024 1024
Hardware clock YES YES YES
Downloadable characters 256 256 256
Screen saver YES YES YES
Buzzer YES YES YES
Max current consumption on 24VDC (mA) 700 700 700
Suffix 45: diemnsions WxHxD (mm) (2) ---
Suffix 50: diemnsions WxHxD (mm) (3) 311x276x100 311x276x100 311x276x100
Max panel thickness (mm) 4 4 4
Weight (Kg) 2.7 2.7 2.7
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

Installation Guide
13
ePAD32 ePAD32T ePAD33 ePAD33T ER-04 ER-16
30x80 LCD 30x80 LCD 30x80 TFT 30x80 TFT 4x40 LCD 16x40 LCD
CCFL CCFL CCFL CCFL CCFL CCFL
640X400 640X400 640X480 640X480 - 320x240
218X159 218X159 218X159 218X159 - 121x91
10.4” 10.4” 10.4” 10.4” - 5.6”
- - - - 5 -
8MB 8MB 8MB 8MB 512KB 512KB
16MB 16MB 16MB 16MB up to 1MB
12 12 12 12 - -
47 47 47 47 5 5
- YES - YES - -
24 24 24 24 - -
5 5 5 5 4 4
YES YES YES YES YES YES
YES YES YES YES YES YES
YES YES YES YES YES YES
- - - - YES YES
9600-38400 9600-38400 9600-38400 9600-38400 9600-38400 9600-38400
YES YES YES YES YES YES
32 KB 32 KB 32 KB 32 KB 16KB 32KB
1024 1024 1024 1024 1024 1024
1024 1024 1024 1024 256 1024
YES YES YES YES YES YES
256 256 256 256 8 256
YES YES YES YES - YES
YES YES YES YES - -
700 700 700 700 400 500
----311x111x89 311x165x89
311x276x100 311x276x100 311x276x100 311x276x100 - -
4 4 4 4 9 9
2.7 2.7 2.7 2.7 1.7 2.4
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

UniOP
14
Model ER-16TA ER-25 ER-25T
Display 16x40 LCD 25x80 LCD 25x80 LCD
Backlight CCFL CCFL CCFL
Graphics 320x240 640x400 640x400
Display dimensions (mm) 121x91 194x121 194x121
Diagonal (inches) 5.6” 9.6” 9.6”
Character height (mm) - - -
User memory 512KB 512KB 512KB
User memory expansion up to 1MB Up to 1MB up to 1MB
Function keys - - -
System keys 5 5 5
Touch screen YES - YES
User LED’s - - -
System LED’s 4 4 4
PC/Printer Port YES YES YES
PLC Port YES YES YES
AUX Port (1) YES YES YES
Esternal keyboard Port YES YES YES
Programming speed 9600-38400 9600-38400 9600-38400
Battery YES YES YES
Recipe memory 32KB 32KB 32KB
Alarms 1024 1024 1024
Events list 1024 1024 1024
Hardware clock YES YES YES
Downloadable characters 256 256 256
Screen saver YES YES YES
Buzzer - - -
Max current consumption on 24VDC (mA) 500 600 600
Suffix 45: dimensions WxHxD (mm) (2) 311x165x89 311x220x89 311x220x89
Suffix 50: dimensions WxHxD (mm) (3) - - -
Max panel thickness (mm) 9 9 9
Weight (Kg) 2.4 2.7 2.7
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

Installation Guide
15
ERT-16 ERT-VGA ER-VGA eTOP05 eTOP10 eTOP11
16x40 LCD 30x80 LCD 30x80 LCD 16X40 LCD 16X40 TFT 16X40 STN
COLOR
CCFL CCFL CCFL LED CCFL CCFL
320x240 640x480 640x480 320x240 320x240 320X240
121x91 194x146 194x146 121x91 121x91 121x91
5.6” 9.6” 9.6” 5.7" 5.7" 5.7”
- - - - - -
512KB 2MB 2MB 8MB 8MB 8MB
up to 1MB - - - - -
- 8 8 - - -
- 3 3 - - -
YES YES - YES YES YES
- 8 8 - - -
5 5 5 5 5 5
YES YES YES YES YES YES
YES YES YES YES YES YES
YES YES YES YES YES YES
YES YES YES - - -
9600-38400 9600-38400 9600-38400 9600-38400 9600-38400 9600-38400
YES YES YES YES YES YES
32KB 32KB 32KB 32KB 32KB 32KB
1024 1024 1024 1024 1024 1024
1024 1024 1024 1024 1024 1024
YES YES YES YES YES YES
256 256 256 256 256 256
YES YES YES YES YES YES
YES - - YES YES YES
500 600 600 600 600 600
216x168x82 311x220x89 311x220x89 - - -
- - - 187x147x71 187x147x95 187x147x95
8 9 9 4 4 4
1.4 2.7 2.7 1.4 1.4 1.4
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com

UniOP
16
Model eTOP12 eTOP30 eTOP31
Display 16X40 LCD 30X80 TFT 30X80 STN
COLOR
Backlight CCFL CCFL CCFL
Graphics 320X240 640X480 640x480
Display dimensions (mm) 121X91 218X159 218x159
Diagonal (inches) 5.7” 10.4” 10.4"
Character height (mm) - - -
User memory 8MB 8MB 8MB
User memory expansion - - -
Function keys - - -
System keys - - -
Touch screen YES YES YES
User LED’s - - -
System LED’s 5 5 5
PC/Printer Port YES YES YES
PLC Port YES YES YES
AUX Port (1) YES YES YES
Esternal keyboard Port - - -
Programming speed 9600-38400 9600-38400 9600-38400
Battery YES YES YES
Recipe memory 32 KB 32 KB 32KB
Alarms 1024 1024 1024
Events list 1024 1024 1024
Hardware clock YES YES YES
Downloadable characters 256 256 256
Screen saver YES YES YES
Buzzer YES YES YES
Max current consumption on 24VDC
(A)
600 700 700
Suffix 45: dimensions WxHxD (mm) (2) ---
Suffix 50: dimensions WxHxD (mm) (3) 187x147x95 287x232x95 287x232x95
Max panel thickness (mm) 4 4 4
Weight (Kg) 1.4 2.25 2.25
Table 1 - UniOP Technical Data
StockCheck.com
Downloaded from StockCheck.com
