Unistellar eVscope User manual

Who
is this user guide for?
This guide is intended for all
members and users of the Unis-
tellar community, whether you are
a beginner, an experienced astro-
nomy enthusiast, or simply excited
about making new discoveries. This
guide will help you set up your te-
lescope correctly and observe the
sky under the proper conditions so
that you can get the most out of
your telescope and produce beau-
tiful images.
How
is it organized?
In this user guide, we will guide you
through each feature and setting,
step by step, to help you get the
most out of your telescope. You will
learn how to get the best possible
experience out of each observation
session. You will also learn more
about the Unistellar mission and
the scientic projects to which you
can contribute.
User guide |1
English

Introduction: Unistellar’s mission........................................................................................................P4
Contents of the box
Before you begin: Getting to know the eVscope product line..............................P7
Technical specifications.............................................................................................................................P8
1. eVscope 2
2. eQuinox
3. eQuinox 2
4. Accessories
Using your telescope | Prerequisites .....................................................................................P12
1. Installing and adjusting the tripod
2. Installing and turning on the telescope
Downloading and installing the Unistellar app...................................................................P14
Collimating your telescope ...................................................................................................................P16
Adjusting the focus .....................................................................................................................................P18
Observation tips ..............................................................................................................................................P20
1. Autonomous Field Detection (AFD)
2. Sensor calibration (or dark frame)
Software suite.......................................................................................................................................................P21
1. Enhanced vision
2. GPS and location
3. Light pollution
4. Frame
5. Gain
6. Exposure time
7. Zoom
8. Storing the telescope
Additional battery information...........................................................................................................P23
Storage and maintenance........................................................................................................................P24
1. Storing and maintaining the telescope
2. Maintaining the mirror
3. Storing the tripod
4. Traveling with the telescope
5. Warranty
Exploration & more..........................................................................................................................................P25
1. Catalogue
2. Data
Actively contribute to science .............................................................................................................P28
1. SETI Institute
2. Scientic campaigns
1
3
9
10
11
2
4
6
7
5
8
Contents
User Guide
User guide |2
English

3. Planetary
4. Asteroid occultation
Troubleshooting..............................................................................................................................................P29
1. Logging in
2. LED colors
3. Not powering on
4. Images
5. Stars are distorted
6. Stars are blue and red
7. Enhanced vision stops
8. Downloading data
Keeping in touch................................................................................................................................................P32
Need help?
12
User guide |3
English

Introduction
Unistellar's mission
Unistellar was founded in 2017 by two former laureates of the Nobel Prize
in Physics 2018, a visionary industrial engineer and a world-renowned as-
tronomer from California. The four of them are united by a common goal:
to make astronomy more accessible and exciting for everyone and, in ge-
neral, to bring the universe closer.
Unistellar is revolutionizing the astronomy industry by oering consu-
mer-level telescopes that are both simple to use and powerful enough to
reveal the wonders of the cosmos and lead to new scientic discoveries.
This fun and educational instrument provides access to thousands of ob-
jects. Whether you’re looking at the night sky from a balcony in the city or
out in the country, Unistellar telescopes are the most portable, fastest, and
most user-friendly option.
Our telescopes provide an unrivaled user experience. Not only are they
simple to use, but they also take just minutes to set up. They can even be
controlled through your smartphone and can automatically point to thou-
sands of objects in our catalog.
Our user community can easily upload and share data. This paves the way
for novel experiences like sending valuable scientic data to professional
astronomers or taking pictures of the sky with a large group of people at
the same time.
User guide |4
English

PROHIBITED!
Never use a telescope to look at the Sun without an appropriate lter!
Looking at the sun or getting close to it can cause irreversible damage to your
product. Do not point the telescope at or near the Sun.
Children must always be supervised by an adult when observing the sky.
WARNING!
Never charge the telescope at temperatures below 50°F.
This could cause irreversible damage to the telescope’s battery. Always charge it at a
temperature between 50°F and 104°F.
WARNING!
Never leave the telescope’s battery connected without using the telescope for more
than a month. This could cause irreversible damage to the battery.
Always remove the battery when storing the telescope for a prolonged
period of time
!
!
WARNING
!
Your telescope and its accessories are not toys. Allowing small children to play with them may
result in injury to themselves or others, as well as damage to your equipment. Keep your device,
including all its parts and accessories, out of the reach of young children.
Your telescope is not designed for use in a damp environment. As with any electronic
item (with the exception of waterproof items), your telescope can be permanently
damaged if water or any other liquid gets inside it. Turn it o immediately and dry it.
Do not look at the Sun without an appropriate lter. Your telescope can be permanently
damaged, even after a short exposure. There is also a signicant risk of re. Also, do not expose
your telescope to temperatures above 104°F or below 50°F; extreme temperatures may impair
its performance.
Your telescope is fragile and should not be dropped. If it is dropped, this may cause permanent
damage.
Specications
Model: eVscope telescope
Mirror specications: aperture 114 mm, focal length 450 mm, material BK7
Battery specications: Lithium-ion: (6 x 18650), capacity 15,000 mAh (55.5 Wh)
Power supply unit (PSU): 100-240V ~50/60 Hz 0.6A Max; Output: 5.0 VDC, 2.4 A
WiFi frequency and bandwidth: 2.4 GHz, 72.2 Mbps
WiFi range: 150ft unobstructed
Input/output: USB-C (PSU); USB-A (smartphone charger)
Tripod: aluminum, adjustable height; designed for the telescope
User guide |5
English

Contents of the box
1
2
3
4
5
6
7
Telescope
Bahtinov mask (located in the cap cover)
Tripod
Charger with adaptors (UE, USA, UK)
Ocial documentation
Box of accessories and tools
(Tripod tool 1 (8 mm socket wrench) / Tripod tool 2 (M5.5 Allen wrench) / Tripod tool 3 (M4 Allen wrench)
/ Telescope tool 1 (T20 Torx wrench) / Telescope tool 2 (M3 Allen wrench)
Eyepiece cover (eVscope 2 only)
6
8mm
7
5
3
1
2
User guide |6
English
UJser Guide |6
English

What is the eVscope?
Enhanced Vision
Enhanced Vision is a proprietary, patent-protected technology that makes it possible
to observe low-light objects in real time by accumulating the light we receive
from them. Galaxies, nebulae, and comets are now visible, colorful, and detailed.
Depending on the observation conditions (light pollution, moon phase, weather, etc.)
and the objects you’re viewing, it can take just a few seconds to begin seeing the
beautiful colors and shapes of galaxies and nebulae that are normally invisible, even
through the eyepiece of a large conventional telescope.
Smart Light Pollution Reduction
Light pollution, or the presence of excessive and unwanted articial lighting, renders
celestialobjects invisible to the human eye. It even challenges cameras and computers
by blurring objects, distorting shapes, and adding noise to images. Unistellar’s
proprietary software quickly reduces the impact of light pollution and allows distant
objects to be observed in sharp detail, even in bright urban environments, delivering
the best possible image settings and results. Regardless of how bright the sky is,
users can enjoy more realistic images with enhanced contrast and color.
A powerful scientic device with a global community
Unistellar explorers can conduct valuable space science research in collaboration
with astronomers from the SETI Institute and other institutions, such as protecting
the Earth, detecting a dangerous asteroid, discovering and conrming the existence
of a celestial body around a distant star, or even unraveling the mystery of a comet
or supernova.
What makes the eVscope so easy to use?
Field recognition
With this telescope, you’ll spend less time setting up and calibrating the telescope
and more time observing space. Our system can instantly identify the objects in its
eld of view by comparing what it sees against a database with information on tens
of millions of stars. This enables the telescope’s automated tracking and pointing
system to be extremely accurate and simple to use, resulting in the most user-
friendly telescope on the market.
Dedicated app
With the touch of a button on the app, your Unistellar telescope can recommend
the most spectacular targets for deep space observation, all in a matter of minutes.
Use the app to learn about and identify cosmic objects, including the most relevant
objects to observe from your location, with a catalog of over 5,000 objects to choose
from. Through the use of our smart technology, you can capture and share your
experience with others, in person or remotely.
The Unistellar app oers engaging educational content and automates your
observing experience, allowing even beginners to enjoy their telescope right away.
The application also oers manual commands for advanced users.
Before you begin:
Getting to know the eVscope product line
User guide |7
English

Eyepiece
The OLED screen features extremely high contrast and
deep blacks, as well as an optical conguration designed
to diuse the sensor view. The end result is a stunning
visual quality for your dark sky observations. By turning
the side dial, you can adjust the diopter and sharpen the
image to suit your eyesight, which is especially useful if
you wear glasses or contact lenses.
Telescope specications :
Aperture 4.5 inches
Focal Length 17.7 inches
Focal Ratio f/3.9
Mount Azimuth
Optical Design Newtonian
Image resolution 7,7 Mpx
Sensor's eld of view 0.75 x 0.56° (34x47 arcmin)
Weight 19.8 lbs
Maximum magnitude 18
Battery life 9h
Eyepiece Nikon Viewer
Dimensions 2.13 ft x 0.75 ft
Storage capacity 64 Go
Warning: Do not mount the telescope on any other
tripod.
Technical specications :
Getting to know the
eVscope 2
!
1
User guide |8
English

The eQuinox eVscope allows you to enjoy the beauty of deep space, protect the
planet from near-Earth asteroids, conduct hands-on science experiments, and
much more.
All of this with one smart, fast, portable, and connected device.
eQuinox specications:
Aperture 4.5 inches
Focal length 17.7 inches
Focal ratio f/3.9
Mount Azimuth
Optical design Newtonian
Image resolution 4.9 Mpx
Sensor's eld of view 30 arcmin
Maximum magnitude 18
Dimensions 2.13 ft x 0.75 ft
Storage capacity 64 Go
Weight 19.8 lbs
1Technical specications:
Getting to know the
eQuinox
User guide |9
English

The improved eQuinox 2 sensor provides for more detailed observations, allowing
you to see everything from Jupiter’s big red spot to the inner details of the Orion
Nebula, our nearest stellar breeding ground.
The eQuinox 2 sensor has a higher resolution than that of the eQuinox. Your images
will now be 27% more detailed.
You will be able to observe the full Moon directly in your eyepiece, as well as the
three galaxies of the Leo Triplet, thanks to this new sensor and its wider eld of view.
eQuinox 2 specications:
Aperture 4.5 inches
Focal length 17.7 inches
Focal ratio f/3.9
Mount Azimuth
Optical design Newtonian
Image resolution 6.2 Mpx
Sensor's eld of view 0.75x0.56° (34x47 arcmin)
Maximum magnitude 18
Dimensions 2.13 ft x 0.75 ft
Storage capacity 64 Go
Weight 19.8 lbs
1Technical specications:
Getting to know the
eQuinox 2
User guide |10
English

Technical specications:
Accessories
Tripod:
Designed for deep sky observations, this tripod has a bubble level at the top of the three leg
locks that can be adjusted to dierent angles, next to where the telescope attaches. Your
observations might be slightly o if your tripod isn’t perfectly level.
IMPORTANT: Tighten the screws on your tripod, but don’t overtighten them, as this could
damage them and make the tripod unstable. Also, make sure that the legs are properly locked
before transferring your telescope to the tripod.
WARNING : The tripod must not be used for any purposes other than for holding your
telescope.
Tripod specications :
Dimensions : 1.93 ft x 0.42 ft - 4.1 ft max height and 3.2 ft max when opened
Weight : 4.41 lbs
!
!
Backpack
The backpack is a separate accessory, not included with the telescope.
How is the telescope backpack made?
The telescope backpack is made using a durable fabric that has been reinforced and
padded with high density foam to protect your telescope..
WARNING: The backpack is not waterproof
Backpack specications :
• Integrated foam inserts that t the shape of your telescope.
• An inside strap to secure the instrument during transport.
• A removable rain cover (to protect against rain and moisture) located in the pocket of
the backpack.
• Adjustable padded shoulder straps and belt help distribute the load.
• 5 small inside pockets: 2 with zippers, 2 capable of holding the telescope’s cap
and the eyepiece cover.
• Ventilated back panel.
• 2 large outside pockets with zippers and 1 belt-level pocket with a zipper
Dimensions :
2.36 ft x 0.73 ft x 0.95 ft
(H x L x P)
Weight : 4.41 lbs
1
User guide |11
English

Using your telescope
Prerequisites
WARNING : The screws in the legs of the tripod may loosen during transport or use.
Please verify that all the screws are in place. If they are not, tighten them with the tool
provided in the accessory kit.
Installing and adjusting the tripod
Open the legs of the tripod
and adjust its height. Always
use your tripod on a rm
surface.
Locate the bubble level at
the top of one of the three
multi-angle tripod locks
(top). Adjust the legs so that
the bubble level is inside the
black circle.
Verify that the legs of the
tripod are secure.
Unscrew the two
screws on the crown of
the tripod.
IMPORTANT: TO ENSURE THE PRECISION AND ACCURACY OF YOUR OBSERVATIONS,
ALIGN AND RE-CENTER THE BUBBLE EVERY TIME YOU MOVE YOUR TELESCOPE.
Tighten the tripod screws with the tools included in the box to prevent the telescope
from falling, as they can loosen over time.
!
2
User guide |12
English

Installing and turning on the
telescope
A- Install your telescope vertically on the
tripod. Check that the tripod base is properly
inserted and ts snugly into the tripod crown.
It should be stable—not loose or wobbly.
C- Turn the telescope on by pressing
the ON button for 2 seconds. The LED
turns purple, then red.
(You may not see the button light up when
using your telescope in daylight because
it is not very bright.)
D - Remove the caps from the
telescope’s optical tube and its
eyepiece.
B- Tighten the screws in the crown of
the tripod to secure your telescope. Be
careful not to overtighten the screws,
which can damage the threading.
PRESS
ON
2 sec
User guide |13
English

Thermalization
What is thermalization?
Thermalization is the process of balancing the temperature of your telescope’s components
and its surrounding environment.
Why should I thermalize my telescope?
When the telescope’s mirror reaches thermal equilibrium, it performs at its best. This step
is critical to ensuring that the mirror and tube do not warp while in use, potentially causing
changes in focus and image quality.
How do I thermalize my eVscope?
If there is a temperature dierence between the outside and the room where your telescope
is stored, turn on your telescope and place it outside for 15 to 30 minutes before your
observation, depending on the temperature dierence.
Weather and temperature
If the sky is cloudy, you will not be able to observe with your telescope. The telescope is
highly sensitive to wind because it causes vibrations that can interfere with the enhanced
vision.
We recommend using your telescope within the following temperature range:
•O: 50°F to 104°F
•During use and charging: 50°F to 104°F
•During use: 32°F to 104°F
User guide |14
English

Downloading and installing
the Unistellar app
The Unistellar app is your portal to the Unistellar experience and our user community.
You can use the app to:
- Control the telescope.
- Discover recommended objects with your telescope.
- Share your observations with other members of the community and see theirs.
- Keep up with the latest news and scientic discoveries related to outer space.
- Contribute to scientic discoveries by participating in our observation missions.
ACTIVATE YOUR GPS BEFORE DOWNLOADING THE APP.
Where can I nd the Unisteller app?
In the Google® Play Store and the Apple® App Store (on
smartphones or tablets) by searching for Unistellar. The app lets you
control your wireless telescope over WiFi.
Minimum settings required to download the app:
• Android 6 or iOS 12 operating system
• Touch screen
• WiFi
• 140 MB available
The app is not supported on FireOS devices. If you are unable to download the app on your
smartphone, check your device’s operating system. Update the app whenever a new version
is available in the Apple® App Store (iPhone/iPad) or Google® Play Store (Android).
The telescope creates its own WiFi
network; it does not use your home’s
WiFi/internet. No internet connection
is needed for your telescope to work. NO INTERNET
CONNECTION
3
Did You
Know ?
Scan the QR code to watch
a video tutorial.
User guide |15
English

Collimating your telescope
What is collimation?
Collimation refers to the process of aligning the sensor and the mirror’s optical axis. You
do not need to carry out a collimation every time you use your telescope if it has not been
transported in a way that involves lots of movement, such as in the trunk of a car. We
recommend that you perform this operation once and then periodically check for shifts.
If you are having diculty focusing as described in the preceding sections or if you are having
diculty achieving high precision focus with your Bahtinov mask, your telescope may require
collimation.
How often should I collimate my telescope?
Collimation is rarely necessary. It should be done primarily when you transport your telescope in a
way that involves lots of movement, like after a trip in the trunk of a car.
How do I collimate my telescope?
Collimate your telescope using the two screws located
on the bottom of the optical tube. Turning these screws
adjusts the position of the mirror. The top screw is used
to move the star vertically, while the left screw is used
to move it horizontally.
For this procedure, you will need:
1- The T20 Torx wrench (telescope tool 1) supplied in
the toolbox.
2- A clear sky with bright, fully visible stars.
Point your telescope toward a bright star, selecting the
rst star that is recommended in the catalog.
Center it using the joystick in the app.
# Tool 1 (T20 Torx)
Look directly into the eyepiece for this procedure.
Turn the wheel counterclockwise as far as it will go.
4
Check the collimation for the rst time right after receiving your
telescope.
User guide |16
English

If the black cross ap-
pears as shown here,
your mirror is correctly
aligned.
If the black cross appears
as shown here, you need to
realign your mirror.
REPEAT THE PROCEDURE UNTIL THE CROSS IS CENTERED. SEVERAL ATTEMPTS MAY
BE REQUIRED.
Turn the focus wheel to align the visual mark. Orient the telescope toward a target and
enjoy the view.
Scan this QR code to be redirected to our
video on collimating your telescope.
Use the T20 Torx
wrench (telescope tool
1) in the toolbox.
Use the joystick arrows to move the telescope so that the star is at
the edge of your screen. Which edge depends on your cross. If the
cross is right of center, use the joystick to place the star on the right
edge of the screen; if the cross is left of center, place it on the left
edge, and so on.
Once the star is on the correct side, turn the vertical or horizontal mirror
mount screw with the T20 torx wrench (telescope tool 1) to adjust the
mirror and re-center the star on the screen and eyepiece.
Use caution with the screws. If you are a beginner, take your time and do not
skip any steps.
User guide |17
English

Adjusting the focus
What is the focus?
The focus is the distance between the mirror and the sensor, which allows rays of light from
the object to converge correctly. The image will be blurry if the light rays converge before or
after the sensor.
How often should I adjust the focus?
Adjust the focus before any observation, including after leaving the telescope outdoors
to thermalize. You may need to readjust your focus during long nights of observation if the
temperature has dropped dramatically or if your other observation parameters have changed.
How do I use the Bahtinov mask for high-
precision focusing?
Go to the rst star recommended in the catalog because it will be the brightest star
available to you.
Separate the Bahtinov mask from the cover. Place it on the telescope’s tube, turning it
gently if necessary to t onto the tube.
This creates an X-shaped pattern visible in the eyepiece and on your screen. Pinch and
zoom on your device to see the X clearly.
If the pattern you see resembles the image below, your focus is complete.
Slowly turn the wheel until the line is centered in the X image.
The Bahtinov mask has three grills at
three dierent angles. It creates points of
diraction that allow for precise focusing.
5
Did You
Know ?
User guide |18
English

DO NOT ACTIVATE ENHANCED VISION MODE WHILE ADJUSTING THE FOCUS.
Scan this QR code to be redirected to our video
on adjusting the focus with the Bahtinov mask.
The default “auto” settings are usually too bright. Adjust these
settings manually by deactivating “auto” mode.
REMEMBER TO REMOVE THE BAHTINOV MASK ONCE THE TELESCOPE HAS BEEN
FOCUSED.
User guide |19
English

Orientation or Autonomous Field Detection (AFD)
What is AFD?
Autonomous Field Detection (AFD) is an algorithm that accurately identies any object in
the telescope’s eld of view by using an internal map containing tens of millions of star
coordinates.
What does AFD do?
AFD automatically points to objects in the night sky, making it easier to look for targets. It
also provides information about what you are observing, such as the distance from Earth,
the size, the age, and more.
Observation tips
Sensor calibration
(or dark frame)
What is the puprose of a dark frame ?
In digital photography, taking a dark
frame means recording an image
with no signal or noise. This process
improves your observations as well
as the quality of your images. A dark
frame enables the telescope’s onboard
computer to analyze and correct the
sensor’s inherent electronic noise.
How do I take a dark frame?
To take a dark frame, leave the cap on the telescope and make sure that you
are in a dark place. Do not expose the telescope to direct light.
Go to the user tab: My eVscope.
If an error message appears, try again later, ideally in a darker setting. It may be that too
much light was detected on the image.
Noise can occur during long exposures
or strong variations in temperature. The
appearance of hot pixels (red, blue or
green spots) on your images can reveal
the eects.
At what frequency should I take a dark frame?
Dark frames can be taken at any frequency you like. We recommend taking at least
one in the winter and one in the summer, as changes in temperature and altitude can
cause imperfections in the images. A dark frame should also be taken before each
scientic observation.
6
Did You
Know ?
User guide |20
English
Other manuals for eVscope
1
Table of contents
Other Unistellar Telescope manuals
Popular Telescope manuals by other brands

Celestron
Celestron AstroMaster 114AZ Quick setup guide

Meade
Meade DS-2090AT-TC instruction manual

Meade
Meade 114ST EQ-D instruction manual

Vortex
Vortex Diamondback manual

Celestron
Celestron AstroMaster 90 EQ Quick setup guide

ORION TELESCOPES & BINOCULARS
ORION TELESCOPES & BINOCULARS SkyView Deluxe 4.5 EQ 9402 instruction manual
