WS037C Professional Wireless Weather Station
User Manual
1.Introduction
Thank you for your purchase of the Professional Wireless
Weather Station. The following user guide provides step by
step instructions for installation, operation and troubleshooting.
2.Warnings and Cautions
Warning: Any metal object may attract a lightning strike,
including your weather station mounting pole. Never install the
weather station in a storm.
Warning: Installing your weather station in a high location
may result in injury or death. Perform as much of the initial
check out and operation on the ground and inside a building or
home. Only install the weather station on a clear, dry day.
3.Getting Started
The professional weather station consists of a display console,
a sensor array with Integrated Outdoor Sensor, and mounting
hardware.

2
3.1 Parts List
The weather station consists of the following parts (as
referenced in Figure 1 ).
QTY Item Image
1
Display Console
Frame Dimensions (LxHxW):
7.6x5.5x1.1inch
(193X140X28mm)
LCD Dimensions (LxW):
6.3x 3.7inch (160X93mm)
3.4 Display Console
3.4.1 Layout of Display Console
The following illustration shows the segment of LCD display for
feature description purposes only in Figure 7.
.

3
Figure 7
1) Outdoor temperature
display
2) Outdoor humidity HI/LO
alarm
3) Channel 1-8 indicator
4) Outdoor humidity display
5) WIFI network
6) Indoor temperature display
7) Indoor humidity display
8) Date
9) Time
10) Week
11) Moon phases
12) Outdoor temperature
change indication
13) Outdoor dew point and
feels like temperature display
14) Temperature units (°F
or °C)
15) Weather forecast
16) Rainfall units of measure
17) Wind gust HI alarm
18) Wind direction
19) Wind speed average HI
alarm
Pressure (REL and ABS)
display
3.4.2 Setup the Display Console
1. Plug in the display console with power adapter.

4
BL ON will display in the time area for three seconds when
powered up. Conversely, The AC OFF icon will display .
Note: It is recommended to plug in the power adapter to
reduce the battery consumption and extend the service life.
2. Display Console Batteries Installation
Remove the battery door on the back of the display, as shown
in Figure 8. Install three AAA (alkaline or lithium)) batteries. The
display will beep once and layout of display will light up for a
few seconds to verify all segments are operating properly.
Figure 8

5
Replace the battery door, and unfold out the desk stand to
place the console in the upright position.
Note: The battery is a back-up of weather station console,
saving console settings when powered off from adaptor
3.4.3 Connect Sensor with Display Console
Once the display console is powered up, it will automatically
scan all the nearby Integrated Outdoor sensors.
Note: Do not press any button until all the remote sensors
report in the display screen, otherwise the display console will
terminate to connect with remote sensors.
Note: While in the search mode, the remote search icon
will be constantly displayed until all the measured values
received. The console will automatically switch to the normal
mode from which all further settings can be performed.
When connected with the Integrated Outdoor Sensor, the
measured value (Indoor temperature,humidity,pressure,moon
phase,time,wind speed,wind gust,wind direction,rain,outdoor
temperature and humidity) will show up on the display console.
Note: Make sure that the distance between weather station
sensors and display console should be within 10ft (3m) to 100ft
(30m). If the weather station sensors is too close or too far
away, it may not receive a proper signal.
3.5 Sensor Operation Verification

6
The following steps verify proper operation of the sensors prior
to install the sensor array.
1. Verify proper operation of the rain gauge. Tip the
Integrated outdoor sensor back and forth several times. You
will heard a “ticking” sound within the rain gauge. Verify the rain
reading on the display console is not reading 0.00. Each
“ticking” represents 0.1 inch of rainfall.
2. Verify proper operating of the wind speed. Rotate the
wind cups manually or with a constant speed fan. Verify the
wind speed is not reading 0.0.
3. Verify proper operation of in/outdoor temperature.
Verify the indoor and outdoor temperature match closely with
the console and sensor array in the same location (about 5 to
10’ (1.5 to 3 meters) apart).The sensors should be within 4°F
/2°C (the accuracy is ± 2°F/1°C). Allow about 30 minutes for
both sensors to stabilize.
4. Verify proper operation of in/outdoor humidity. Verify
the indoor and outdoor humidity match closely with the console
and sensor array in the same location (about 5 to 10’ (1.5 to 3
meters) apart).The sensors should be within 10% (the accuracy
is ± 5%). Allow about 30 minutes for both sensors to stabilize.
7. Display Console Operation
7.1 Quick Display Mode
Note: The display console has five keys for easy operation:
CHANNEL/+ key, SET key, SNOOZE/LIGHT key, ALARM key
and MAX/MIN/- key.

7
Note: To exit the Quick Display Mode at any time, press the
SNOOZE/LIGHT key of the display console.
While in Normal Mode, press (do not hold) the SET key to enter
the Quick Display Mode as follows:
once for time, time/week and second
Twice for rainfall
three for pressure
four for sensor temperature
1. Time, Time/Week and Second. Press the CHANNEL/+ or
MAX/MIN/- key to toggle between time, time/week and second.
2. Rainfall. Press the CHANNEL/+ or MAX/MIN/- key to toggle
between 1h,24h week, month and total.
To clear the total rain, press the CHANNEL/+ or MAX/MIN/-
button until total rain is displayed. The total rain will flash. Press
and hold the SET button for five seconds until total rain reads
0.0.
3. Absolute Pressure and Relative Pressure. Press the
CHANNEL/+ or MAX/MIN/- key to toggle between absolute
pressure and relative pressure.
4. Outdoor Temperature. Press the CHANNEL/+ or
MIN/MAX/- key to toggle between dew point and feels like.
7.2 Set (Program) Mode
While in Normal Mode, press and hold the SET key for at least
three seconds to enter the Set Mode. The first setting will begin
flashing. You can press the SET key again to skip any step, as
defined below.

8
Note: In the Set mode, press the CHANNEL/+ key or
MAX/MIN/- key to change or scroll the setting value. Hold the
CHANNEL/+ key or MAX/MIN/- key for three seconds to
increase/decrease rapidly.
Note: To exit the Set mode at any time, press the
SNOOZE/LIGHT button of the display console.
1. 12/24 Hour Format (default: 24h). Press the SET key
again to adjust the 12/24 hour format setting (FMT). Press the
CHANNEL/+ key or MAX/MIN/- key to change between 12 hour
and 24 hour format.
2. Change Hour. press the SET key again to set the hour.
Press the CHANNEL/+ key or MAX/MIN/- key to adjust the hour
up or down.
3. Change Minute. Press the SET key again to set the minute.
Press the CHANNEL/+ key or MAX/MIN/- key to adjust the
minute up or down.
4. Date Format (default: D-M). Press the SET key again to
enter the Day/Month format mode. Press the CHANNEL/+ or
MAX/MIN/- key to switch between M-D, D-M.
5. Change Month. Press the SET key again to set the
calendar month. Press the CHANNEL/+ key or MAX/MIN/-
key to adjust the calendar month.
6. Change Day. Press the SET key again to set the calendar
day. Press the CHANNEL/+ key or MAX/MIN/- key to adjust the
calendar day.
7. Change Year. Press the SET key again to set the calendar
year. Press the CHANNEL/+ key or MAX/MIN/- key to adjust
the calendar year.

9
8. Max/Min Clearing (default: ON). Press the SET key again
to set the Max/Min clearing mode (CLR). The Max/Min can be
programmed to clear daily (at midnight) or manually. Press the
CHANNEL/+ key or MAX/MIN/- key to switch between ON
(Clears 24h) and OFF (Manually).
9. Temperature Units of Measure (default: °C). Press the
SET key again to change the temperature units of measure.
Press the CHANNEL/+ key or MAX/MIN/- key to switch
between °F and °C units of measure.
10. Wind Speed Units of Measure (default: m/s). Press the
SET key again to change the wind speed units of measure .
Press the CHANNEL/+ key or MAX/MIN/- key to toggle the
wind speed units between m/s, bft,knots,mph or km/h.
11. Rainfall Units of Measure (default: mm). Press the SET
key again to change the Rainfall units of measure. Press
CHANNEL/+ key or MAX/MIN/- key to toggle the rainfall units
between mm and inch.
12. Barometric Pressure Display Units(default: hPa).Press
the SET key again to change the pressure units of measure.
Press the CHANNEL/+ key or MAX/MIN/- key to toggle the
pressure units between mmHg, inHg or hPa.
13. Pressure Threshold Setting (default level 2). Press the
SET key again to change the pressure threshold. Press the
CHANNEL/+ key or MAX/MIN/- key to change pressure
threshold 2 hPa to 4 hPa. (For detailed information of this part
please refer to 10.5)
14. Weather Icons Setting (default: partly cloudy). Press
the SET key again to change the initial weather icon. Press the
CHANNEL/+ key or MAX/MIN/- key to select the initial weather

10
icon of Sunny, Cloudy, Partly Cloudy or Rainy. (For detailed
information of this part please refer to 10.2)
15. Time SYNC(default:ON). Press the SET key again to set
the network time sync. Press the [+] key or [-] key to switch
between SYNC time ON and SYNC time OFF of measure.
16. Location Division. (default: Northern Hemisphere).
Press the SET key again to change the location division. Press
the CHANNEL/+ key or MAX/MIN/- key to toggle the position of
the earth Northern Hemisphere (NOR) or Southern
Hemisphere (SOU). (Refer to 5.0 Final Installation of
Sensors)
7.3 Sensor Search Mode
If Integrated Outdoor Transmitter data is lost, press and hold
the CHANNEL/+ button for 3 seconds, the search icon will
be displayed constantly for 3 minutes. Once the signal is
reacquired, the remote search icon will turn off, and the
current values will be displayed.
7.4 Max/Min Viewing and Reset Mode
7.4.1 Max Record Viewing and Reset
In normal mode, press (do not hold) the MAX/MIN/- key,the
MAX icon will be displayed in date area.
Press the SET key to view max values of rainfall (1h, 24h, week
or month), wind gust and average, pressure (ABS or REL),
outdoor temperature and humidity (dew point or feels like) and
indoor temperature and humidity.

11
Press the MAX/MIN/- key for three seconds to clear all Max
values.(Rainfall, wind gust and average, pressure, temperature
and humidity maximum values).
Press the SNOOZE/LIGHT key to exit the min/max checking
and clearing mode, return to normal display mode.
Note: The Maximum values will display the current values
after reset.
7.4.2 Min Record Viewing and Reset
Press the MAX/MIN/- key again (do not hold), the MIN icon will
be displayed. Press the SET key to view min values of pressure
(ABS or REL), outdoor temperature and humidity (dew point or
feels like), and indoor temperature and humidity.
Press the MAX/MIN/- key for three seconds to clear all Min
values.(pressure, temperature and humidity minimum values).
Press the SNOOZE/LIGHT key to exit the min/max checking
and clearing mode, return to normal display mode.
Note: The Minimum values will display the current values
after reset.
7.5 Snooze Mode
If the alarm sounds, and you wish to silence the alarm, press
the SNOOZE/LIGHT key, the backlight will turn on. The alarm
icon will continue to flash and the alarm will silence for five
minute.

12
Press any key (MAX/MIN/-, SET, ALARM, CHANNEL/+)to
permanently exit the Snooze mode.
7.6 Backlight Mode
7.6.1 Adjustable Brightness of Backlight
1. There are 3 levels of brightness of display backlight. When
the backlight is on, press SNOOZE/LIGHT key to switch
between the 3 levels.
2. When backlight is off, press the SNOOZE/LIGHT key , the
backlight will turn on permanently.
3. To turn off the display backlight at any time, press the
SNOOZE/LIGHT key for again ..
Note: If the display console plugged into AC adapter power,
thetimeareawilldisplayBLONandthebacklightwillremain
on. It is not recommended leaving the display backlight on for a
long period of time when operating on batteries only, or the
batteries will run out quickly.
Note: The backlight operation is different when operating on
batteries to save power.
3. If the display console only powered by battery, and backlight
is off, Press the SNOOZE/LIGHT button once. The backlight
will turn on for five seconds, and if no operation is performed for
three seconds, the backlight will turn off.
8. Alarm Mode

13
The weather station includes the following alarms:
8.1 Alarm Triggered
8.1 Alarm Triggered
When an alarm condition is exceed, the alarm icon will flash
(visual) and the alarm beeper will sound (audible). To silence
the beeper, press any key.
8.2 View High/Low Alarm Value
To view the current alarm settings, press the ALARM key to
enter the alarm mode. HI AL 1 will be displayed in the date area.
At the same time Alarm 1 time and HI alarm parameters of
indoor temperature and humidity, outdoor temperature and
humidity, outdoor feels like , 1h rainfall, absolute pressure,
wind gust, wind average are displayed.
Press SET key to view Alarm time and HI alarm parameters of
indoor temperature and humidity, outdoor temperature and
humidity ,outdoor dew point, 24h rainfall, relative pressure,
wind gust, wind average are displayed.
Press ALARM key again to view the LOW alarms along with
the alarm clock time in the same way as HI alarms.
Time (Alarm 1 and Alarm 2)
Wind Gust
Wind Average
Outdoor Temperature
Outdoor Humidity
Outdoor Feels Like
Temperature
Outdoor Dew Point
Hourly Rainfall
24 Hour Rainfall
Absolute Pressure
Relative Pressure
Indoor Temperature
Indoor Humidity

14
Press ALARM key again to return to normal mode.
Note: Press the SNOOZE/LIGHT key at any time to return
to the normal mode in HI/Low alarm mode.
8.3 Setting the Alarms
Press ALARM key to enter the alarm mode.
Press and hold the SET key for three seconds. The first alarm
parameter will begin flashing (alarm hour).
To save the alarm setting and proceed to the next alarm
parameter, Press (do not hold) the SET key.
To adjust the alarm parameter, press the CHANNEL/+ key or
MAX/MIN/- key to increase or decrease the alarm settings, or
press and hold the CHANNEL/+ key or MAX/MIN/- key for
three seconds to increase or decrease the alarm settings
rapidly.
Press the ALARM key to turn on (the alarm icon will appear )
and off the alarm.
Press the SNOOZE/LIGHT key once at any time to return to
the normal mode. After 30 seconds of inactivity, the alarm
mode will time out and return to normal mode.
The following is a list of the individual alarm parameters that
are set (in order):
1.Alarm hour(alarm 1)
2.Alarm minute(alarm 1)
3.Alarm hour(alarm 2)
4.Alarm minute(alarm 2)
5.Wind Gust HI alarm
6.Wind average HI alarm
7.Outdoor temp HI alarm
8
Outdoor
temp
low
alarm
10.Outdoor humidity low alarm
11.Outdoor feels like HI alarm
12.Outdoor feels like low alarm
13.Outdoor dew point HI alarm
14.Outdoor dew point low alarm
15.Rainfall (1h) HI alarm
16.Rainfall (24h) HI alarm
17 Absolute
pressure
HI
alarm

15
Note: To prevent repetitive temperature alarming, there is a
0.9 °F(0.5°C) tolerance band. For example, if you set the high
alarm to 80.0°F(26.7°C) and silence the alarm, the alarm icon
will continue to flash until the temperature falls below 80.0°F
(26.7°C), at which point, the alarm will reset and must increase
above 80.0°F(26.7°C) to activate again.
Note: To prevent repetitive alarming of humidity, there is a
4% tolerance band in humidity alarm. For example, if you set
the high alarm to 60% and silence the alarm, the alarm icon will
continue to flash until the humidity falls below 56%, at which
point, the alarm will reset and must increase above 60% to
activate again.
8.4 Alarm and Key Beeper ON/OFF
Press any button to silence the alarm sound.
19.Relative pressure HI alarm
20.Relative pressure low alarm
21.Indoor temperature HI alarm
22.Indoor temperature low alarm
23.Indoor humidity HI alarm
24.Indoor humidity low alarm

16
In normal mode, press and hold the ALARM key for three
seconds to toggle the BZ ON (beeper on) or BZ OFF (beeper
off) depending on the current setting.
Display console return to normal mode without any operation in
three seconds.
9. Optional Calibration Mode
Note: The calibrated value can only be adjusted on the
display console.The outdoor remote sensor(s) always displays
the un-calibrated or measured value.
Note: The measured humidity range is between 10% and
99%. Humidity cannot be accurately measured outside of this
range. Thus, the humidity cannot be calibrated below 10% or
above 99%.
The purpose of calibration is to fine tune or correct for any
sensor error associated with the devices margin of error. The
measurement can be adjusted from the console to calibrate to
a known source.
Calibration is only useful if you have a known calibrated source
you can compare it against, and is optional. This section
discusses practices, procedures and sources for sensor
calibration to reduce manufacturing and degradation errors. Do
not compare your readings obtained from sources such as the

17
internet, radio, television or newspapers. They are in a different
location and typically update once per hour.
The purpose of your weather station is to measure conditions
of your surroundings, which vary significantly from location to
location.
The profession weather station supports up to eight remote
thermo-hygrometer sensors. Each of the eight sensors can be
calibrated.
9.1 Calibration of Temperature Mode
In normal mode, press and hold the SET and CHANNEL/+
keys at the same time for five seconds to enter the temp
calibration mode. The indoor temperature will begin flashing.
Press the CHANNEL/+ key or MAX/MIN/- key to increase or
decrease the temperature reading (in increments of 0.1). Press
and hold the CHANNEL/+ key or MAX/MIN/- key for three
seconds to increase or decrease rapidly.
Press the ALARM key to reset current value.
Press the SET key switch to outdoor Temperature.
To exit the temperature calibration mode at any time, press the
SNOOZE/LIGHT button of the display console. If no operation
is performed, the calibration mode will timeout in 30 seconds.
9.2 Calibration of Humidity Mode

18
In normal mode, press and hold the SET and MAX/MIN/- keys
at the same time for five seconds to enter into the humidity
calibration mode. The indoor humidity will begin flashing.
Press the CHANNEL/+ key or MAX/MIN/- key to increase or
decrease the humidity reading (in increments of 1%). Press
and hold the CHANNEL/+ key or MAX/MIN/- key for three
seconds to increase or decrease rapidly.
Press the ALARM key to reset current value.
Press the SET key switch to outdoor humidity.
To exit the humidity calibration mode at any time, press the
SNOOZE/LIGHT button on the top of the display console. If no
operation is performed, the calibration mode will timeout in 30
seconds.
Note: The Humidity is a difficult parameter to measure
accurately and drifts over time. The calibration feature allows
you to zero out this error. To calibrate humidity, you will need
an accurate source, such as a sling psychrometer or
Humidipaks One Step Calibration kit.
9.3 Calibration of Sensors Mode
In normal mode, press and hold the SET and ALARM keys at
the same time for five seconds to enter the pressure, wind gust,
rainfall calibration mode. The letter “CAL” will appear at the
bottom of the screen.

19
Press the SET key to skip over a parameter to the next.
Absolute Pressure Calibration
In the calibration mode, the “ABS” symbol will display at the
pressure section, the absolute pressure value will flash. (The
default value is 0.00 inHg)
Press the CHANNEL/+ key or MAX/MIN/- key to increase or
decrease the absolute pressure value (in increments of 0.01
inHg).
Press and hold the CHANNEL/+ or MAX/MIN/- key for three
seconds to increase or decrease rapidly.
Press the ALARM key to reset current value.
Example: The calibrated pressure sources measure 28.37
inHg. The display console pressure reads 28.75 inHg.
Offset = 28.37 - 28.75 = - 0.38 inHg
Relative Pressure Calibration
In the calibration mode, press the SET key once, the “REL”
symbol will display at the pressure section, the relative
pressure value will flash. (The default value is 0.00 inHg)
Press the CHANNEL/+ key or MAX/MIN/- key to increase or
decrease the relative pressure value (in increments of 0.01
inHg).
Press and hold the CHANNEL/+ or MAX/MIN/- key for three
seconds to increase or decrease rapidly.

20
Press the ALARM key to reset current value.
Example: The calibrated pressure sources measure 25.00
inHg. The display console pressure reads 24.85 inHg.
Offset = 25.00 - 24.85 = 0.15 inHg
Note: The display console displays two different pressures:
absolute (measured) and relative (corrected to sea-level).
To compare pressure conditions from one location to another,
meteorologists correct the pressure to sea-level conditions.
Because the air pressure decreases as you rise in altitude, the
sea-level corrected pressure (the pressure your location would
be at if located at sea-level) is generally higher than your
measured pressure.
Thus, your absolute pressure may read 28.62 inHg (969 mb) at
an altitude of 1000 feet (305 m), but the relative pressure is
30.00 inHg (1016 mb).
The standard sea-level pressure is 29.92 in Hg (1013.2hpa).
This is the average sea-level pressure around the world.
Relative pressure measurements greater than 29.92 inHg
(1013.2hpa) are considered high pressure and relative
pressure measurements less than 29.92 inHg are considered
low pressure.
To determine the relative pressure for your location, locate an
official reporting station near from you (the internet is the best
source for real-time barometer conditions, such as the website
