UNITY LAUNDRY SYSTEMS UTS62 User manual

INSTALLATION AND MAINTENANCE
INSTRUCTIONS
MODEL NUMBER: UTS62
EN
INSTALLATION/MAINTENANCE
UTS62
Part. 14000101
Rev. 12/2019
110 Canal Street, 3rd Floor
Lowell, MA 01854
United States
www.ulaundrysystems.com
®/™ ©2019 Unity Laundry Systems. All rights reserved.

®/™ ©2019 Unity Laundry Systems. All rights reserved.

00 SAFETY INFORMATION
0.1. Explanation of Safety Messages ...............................................................1
0.2. Important Safety Instructions.....................................................................1
0.3. Safety Decals ............................................................................................4
0.4. Operator Safety .........................................................................................5
0.5. Emergency Stop........................................................................................5
01 INTRODUCTION
1.1. Delivery Inspection ....................................................................................6
1.2. Serial Plate Location .................................................................................6
1.3. Accessories in Machine ............................................................................6
1.4. Customer Service .....................................................................................6
02 SPECIFICATIONS AND DIMENSIONS
2.1. GeneralSpecications ..............................................................................7
2.2. Machine Dimensions .................................................................................8
03 INSTALLATION
3.1. Requirements of Installation Location .......................................................9
3.2. Foundation Requirements .........................................................................10
3.3. Water Connection......................................................................................10
3.4. Drain Connection ......................................................................................11
3.5. Electrical Installation..................................................................................12
3.6. ConnectionSpecications .........................................................................12
3.7. Supply Dispensing.....................................................................................13
3.8. Removal of Shipping Braces ....................................................................14
04 CONTROL INTERFACE VENDED
4.1. Vended .....................................................................................................15
05 CONTROL INTERFACE ON-PREMISE
5.1. On-premise ...............................................................................................19
06 MAINTENANCE
6.1. Maintenance .............................................................................................23
6.2. Daily .........................................................................................................23
6.3. Weekly.......................................................................................................24
6.4. Monthly......................................................................................................25
6.5. Quarterly ...................................................................................................25
6.6. Out of Balance Protection ........................................................................25
6.7. Variable Frequency Drive (VFD) ...............................................................25
6.8 Troubleshooting.........................................................................................26
CONTENTS
®/™ ©2019 Unity Laundry Systems. All rights reserved.

1
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
00 SAFETY INFORMATION
0.1 EXPLANATION OF SAFETY MESSAGES
Precautionarystatements[“DANGER,”“WARNING,”and“CAUTION”],followedbyspecicinstructions,arefoundinthis
manual and on decals on the washer. These precautions are intended for the personal safety of the operator, user, servicer
and those maintaining the machine.
DANGER
Indicates an imminently hazardous situation that, if not avoided, will
cause severe personal injury or death.
WARNING
Indicates a hazardous situation that, if not avoided, could cause
severe personal injury or death.
CAUTION
Indicates a hazardous situation that, if not avoided, may cause minor
or moderate personal injury or property damage.
Additionalprecautionarystatements[“IMPORTANT”and“NOTE”]arefollowedbyspecicinstructions.
IMPORTANT: The word “IMPORTANT” is used to inform the reader of specic procedures where minor machine
damage will occur if the procedure is not followed.
NOTE: The word “NOTE” is used to communicate installation, operation, maintenance or servicing information that is
important but not hazard related.
0.2 IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of re, electric shock, serious injury or death to
persons when using your washer, follow these basic precautions:
1. The actions described in these instructions are strictly reserved for personnel who have successfully completed training by
UNITY LAUNDRY SYSTEMS.
2. The company responsible for the Authorized Technical Service accepts full liability for the work done and any possible
consequences that may derive from it.
3. Any actions carried out by personnel who are not authorized by the manufacturer will be considered to be improper and will
resultintheautomaticvoidingofthemachine’swarranty.
4. The manufacturer will not accept responsibility for any physical and/or material damage caused by actions performed on the
machine undertaken by unauthorized personnel.
5. Do not store or install the machine in areas exposed to the ELEMENTS or where it may be splashed by water.

2
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
00 SAFETY INFORMATION
6. The room where the machine is located MUST comply with the environmental conditions (air venting, temperature, humidity,
etc.)speciedinthetechnicalspecicationstable.NEVERINSTALLTHEMACHINEINENVIRONMENTSwhereitwillbe
splashed with water or where there is a very high level of humidity in the atmosphere.
7. Install the washer according the INSTALLATION instructions. All connections for water, drain, electrical power and grounding
must comply with local codes and be made by licensed personnel when required. It is recommended that the machine be
installedbyqualiedtechnicians.
8. Topreventreandexplosion,keeptheareaaroundmachinefreefromammableandcombustibleproducts.Donotaddthe
following substances or textiles containing traces of the following substances to the wash water: gasoline, kerosene, waxes,
cookingoils,vegetableoils,machineoils,dry-cleaningsolvents,ammablechemicals,thinners,orotherammableor
explosivesubstances.Thesesubstancesgiveoffvaporsthatcouldignite,explodeorcausethefabrictocatchrebyitself.
9. Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for two weeks
ormore.HYDROGENGASISEXPLOSIVE.Ifthehotwatersystemhasnotbeenusedforsuchaperiod,beforeusinga
washingmachineturnonallhotwaterfaucetsandletthewaterowfromeachforseveralminutes.Thiswillreleaseany
accumulatedhydrogengas.Thegasisammable,donotsmokeoruseanopenameduringthistime.
10. Never operate the washer with any guards, panels and/or parts removed or broken. DO NOT bypass any safety devices or
tamper with the controls.
11. Use washer only for its intended purpose, washing textiles. Never wash machine parts or automotive parts in the machine.
This could result in serious damage to the basket or tub.
12. Use only low-sudsing, no-foaming types of commercial detergent. Be aware that hazardous chemicals may be present.
Wearhandandeyeprotectionwhenaddingdetergentsandchemicals.Alwaysreadandfollowmanufacturer’sinstructions
onpackagesoflaundryandcleaningaids.Heedallwarningsorprecautions.Toreducetheriskofpoisoningorchemical
burns, keep them out of the reach of children at all times [preferably in a locked cabinet].
13. Always follow the fabric care instructions supplied by the textile manufacturer.
14.LoadingdoorMUSTBECLOSEDanytimethewasheristoll,tumbleorspin.DONOTbypasstheloadingdoorswitchby
permitting the washer to operate with the loading door open. Do not attempt to open the door until the washer has drained
and all moving parts have stopped.
15.Beawarethatcoldwaterisusedtoushthesoapdispenser.Avoidopeningthedispenserlidwhilethemachineisrunning.
16.Donotattachanythingtothesupplydispenser’snozzles.Theairgapmustbemaintained.
17. Do not operate the machine without the water reuse plug or water reuse system in place, if applicable.
18.Besurewaterconnectionshaveashut-offvalveandthatllallhoseconnectionsaretight.
19. Keep washer in good condition. Bumping or dropping the washer can damage safety features. If this occurs, have washer
checkedbyaqualiedserviceperson.
20. Before servicing the machine, ensure that lockout and tag out procedures are in place for both electrical and water
connections.
21.Donotrepairorreplaceanypartofthewasher,orattemptanyservicingunlessspecicallyrecommendedintheuser-
maintenance instructions or in published user-repair instructions.
22.Toreducetheriskofanelectricshockorre,DONOTuseanextensioncordoranadaptertoconnectthewashertothe
electrical power source.
23. Do not allow children to play on or in the washer. Close supervision of children is necessary when the washer is used near
children.Thisapplianceisnotintendedforusebyyoungchildrenorinrmpersonswithoutsupervision.Youngchildren
should be supervised to ensure that they do not play with the appliance. This is a safety rule for all appliances.

3
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
24. DO NOT reach and/or climb into the tub or onto the washer, ESPECIALLY if the wash drum is moving. This is an imminently
hazardous situation that, if not avoided, will cause severe personal injury or death.
25. All installations required for the proper operation of the machine MUST be carried out by a duly accredited Registered
Installation Contractors, in compliance with the legal regulations applicable in the country of use.
26.Avoidcarryingoutanyactiononthemachinewithouthavingrstreadandunderstoodthemachine’sInstallationand
Operating Manuals, paying special attention to the Safety Instructions.
27. Carrying out transport, installation, inspection routines, adjustments, maintenance, repairs, cleaning or any work on the
machineswithoutapplyingsafetymeasuresorhavingthenecessarytechnicalknow-howcanleadtoELECTRICALSHOCK
OR SERIOUS ACCIDENTS.
28.Whentoolsdesignedforspecictransport,installation,maintenanceandrepairroutinesareavailable,theiruseis
compulsory in order to avoid unnecessary risks.
29.Beforecarryingoutanyproceduresonmachinesttedwithpneumaticorhydrauliccircuits:
• Make the machines COMPLETELY SAFE by following the instructions set out in the corresponding Manuals or by wedging
them with wooden blocks where necessary.
• Bear in mind that working on a component without having previously understood the role that it performs in the circuit as a
whole involves a high risk of suffering a SERIOUS ACCIDENT.
30. BEFORE CARRYING OUT ANY inspection routine, adjustment, maintenance, repairs, cleaning or any work on the machine,
DISCONNECTITFROMALLTHEENERGYSOURCES.
• COMPLETELY disconnect the machine from the power supply and prevent the possibility of accidental reconnection by
mechanically locking the automatic external switch and/or the switch breaker. Stopping the machine with the NORMAL
STOP key or push-button is not enough.
• Disconnect the electrical connection of any circuit external to the machine; for example, external dosing equipment,
external vending units, folders or ironer feeders. These circuits are independent of the supply to the machine.
•Beforebeginninganyprocedurewaitforatleastveminutesaftertheelectricaldisconnection,toeliminateriskofresidual
voltage.
• Close and mechanically lock the manual supply valves.
• Check that the water bath has COMPLETELY drained, that no part of the machine is at an excessively high temperature
and that no parts are in movement through inertia.
31. DANGER! Some fault localization procedures require checking at different points of the electric circuit with the machine
connected to the power supply and other supply sources. When carrying out these procedures, respect the following
instructions:
• The appropriate checks must be carried out by ONLY ONE PERSON.
• During these procedures, ONLY remove the protective covers from the electric circuit and/or the inverter. Never remove the
covers protecting the moving parts of the machine.
35. Before the washer is removed from service or discarded, remove the door to the washing compartment.
36.Failuretoinstall,maintain,and/oroperatethiswasheraccordingtothemanufacturer’sinstructionsmayresultinconditions
which can produce bodily injury and/or property damage.
37.THEMANUFACTURERACCEPTSNORESPONSIBILITYIFTHESESAFETYINSTRUCTIONSANDALLTHE
INFORMATIONINTHECORRESPONDINGMANUALSARENOTFOLLOWED.KEEPTHESEINSTRUCTIONSINASAFE
PLACE.
00 SAFETY INFORMATION

4
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
NOTE: The WARNINGS and IMPORTANT SAFETY INSTRUCTIONS appearing in this manual are not meant to cover
all possible conditions and situations that may occur. Common sense, caution and care must be exercised when
installing, maintaining, or operating the washer.
WARNING
Machine installations must comply with minimum specications
and requirements stated in the applicable Installation Manual, any
applicable municipal building codes, water supply requirements,
electrical wiring regulations and any other relevant statutory
regulations. Due to varied requirements and applicable local codes,
this machine must be installed, adjusted, and serviced by qualied
maintenance personnel familiar with applicable local codes and the
construction and operation of this type of machinery. They must also
be familiar with the potential hazards involved. Failure to observe
this warning may result in personal injury, property damage, and/or
equipment damage, and will void the warranty.
IMPORTANT: Ensure that the machine is installed on a level oor of sufcient strength. Ensure that the recommended
clearances for inspection and maintenance are provided. Never allow the inspection and maintenance space to be
blocked.
0.3 SAFETY DECALS
Safety decals appear at crucial locations on the machine. Failure to maintain legible safety decals could result in injury to the
operator or service technician.
Use manufacturer-authorized spare parts to avoid safety hazards.
00 SAFETY INFORMATION
ELECTRICAL RISK
Protection guard for electric components.
MECHANICAL RISK
Protection guard for moving parts.
FLAME RISK (only on some machines)
Protectiveguardforame.
ACCESS PROHIBITED
HIGH TEMPERATURE RISK
Operate with caution.
Use appropriate protections.
RISK OF INHALING HARMFUL OR
IRRITANT VAPORS
Keep the doors/covers closed.
Use appropriate protection.
RISK OF FALLING
Use proper access and safety methods.

5
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
00 SAFETY INFORMATION
0.4 OPERATOR SAFETY
WARNING
NEVER insert hands or objects into basket until it has completely
stopped. Doing so could result in serious injury.
The following maintenance checks must be performed daily:
1. Verify that all warning labels are present and legible, replace as necessary.
2. Check door interlock before starting operation of the machine:
a. Attempt to start the machine with the door open. The machine should not start.
b. Close the door without locking it and start the machine. The machine should not start.
c. Attempt to open the door while a cycle is in progress. The door should not open.
If the door lock and interlock are not functioning properly disconnect power and call a service technician.
3. Do not attempt to operate the machine if any of the following conditions are present:
a. The door does not remain securely locked during the entire cycle.
b. Excessively high-water level is evident.
c. Machine is not connected to a properly grounded circuit.
Do not bypass any safety devices in the machine.
WARNING
Operating the machine with severe out-of-balance loads could result
in personal injury and serious equipment damage.
0.5 EMERGENCY STOP
WARNING
In accordance with safety requirements for industrial machinery
standard ISO 10472-1,5-2) and other safety requirements, the laundry
owner/manager is responsible for installing an emergency stop
device that affects all the machines in the laundry.
Device features
• To be located in a visible place, separated from all machines and easily accessible.
• To break the electrical supply for all machines.
• To safely isolate all machines at maximum consumption.
• To need reinstating (the whole installation) after the emergency stop push-button has been released.

6
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
01 INTRODUCTION
Thank you for the purchase of a Unity Laundry Systems washing machine. Please read this manual carefully before installing
and operating the washer.
1.1 DELIVERY INSPECTION
Upon delivery, visually inspect crate, protective cover, and unit for any visible shipping damage. If signs of possible damage
are evident, have the carrier note the condition on the shipping papers before the shipping receipt is signed, or advise the
carrier of the condition as soon as it is discovered.
Thewasherhasprotectiveadhesivelmonthethefrontandsidestainlesssteelpanels.Thelmmaybepeeledoffbefore
putting the machine into service.
1.2 SERIAL PLATE LOCATION
Theserialplateislocatedattherearofthemachine.Providethemachine’sserialnumberandmodelnumberforwarranty
information, when ordering parts or seeking technical assistance.
1.3 ACCESSORIES IN MACHINE
Accessory Quantity
User Manuals (Installation, Operation,
Wiring)
1 (each)
Warranty Card 1
Registration Card 1
Shims 2
Shock Absorbers 2
Hoseadapters 3
ClampsforDrainHose 2
DrainHose 1
Keys 2
1.4 CUSTOMER SERVICE & REPLACEMENT PARTS
If you require any technical assistance or replacement parts for your washing machine in the future, please contact Unity
Laundry Systems.

7
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
02 SPECIFICATIONS AND DIMENSIONS
2.1GENERAL SPECIFICATIONS
MOTOR
Size–HP 3.0
CAPACITY
Cylinder Volume – cu. ft. (liters) 8.8 (251.3)
Cylinder Diameter – in. (mm) 30.5 (774)
Cylinder Depth – in. (mm) 21.0 (534)
Dry Load Capacity – lb. (kg) 62 (28.1)
OPERATING SPEED & EXTRACT FORCE
Washing Speed (RPM) 45-50
Maximum Extract Speed (RPM) 277
Maximum Extract Force (G-force) 800
CONNECTIVITY
USB Programmability Yes
DIMENSIONS
Width – in. (mm) 45.4 (1152)
Depth – in. (mm) 40.9 (1038)
Height–in.(mm) 58.4 (1484)
CRATED DIMENSIONS
Width – in. (mm) 44.9 (1140)
Depth – in. (mm) 48 (1220)
Height–in.(mm) 61.1 (1552)
APPROXIMATE WEIGHT
Uncrated – lb. (kg) 1433.2 (650)
Crated – lb. (kg) 1653.5 (750)
ELECTRICAL CONNECTION OPTIONS (VOLTS/Hz/PHASE)
208–240V/50-60Hz/1PH(noelectricalheating) Yes
WATER HEATING OPTIONS
Hot/ColdWaterConnectionsOnly Yes
WATER, CHEMICAL DISPENSING, DRAINS
Number of Water Inlets 3
Inlet Sizes – in. (mm) 1 (25.4)
Number of Dispenser Compartments 4
Number of External Chemical Connections 5
Dump Valve Drain Size – in. (mm) 3 (76.2)
INSTALLATION RECOMMENDATIONS
Minimum Clearance Between Machines - in (mm) 0 (0)
Minimum Clearance in front of Machines - in (mm) 39.4 (1000)
Minimum Clearance Behind Machines - in (mm) 31.5 (800)

8
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
02 SPECIFICATIONS AND DIMENSIONS
2.2 MACHINE DIMENSIONS
Unlessotherwisespecied,alldimensionsareinmm.Thebelowdiagramshowsthevendedconguration.Theon-premise
congurationhasthesamedimensions.

9
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
03 INSTALLATION
3.1 REQUIREMENTS OF INSTALLATION LOCATION
Themachinemustbeinstalledmeetingtheminimumdistancesspeciedtoguaranteetheproperoperationandmaintenance
access of the machine.
A Working area in front of machine - in (mm) 39.4 (1,000)
B Maintenance area behind machine - in (mm) 31.5 (800)
C Width - in (mm) 34.6 (880)
D Depth - in (mm) 34.2 (870)
EHeight-in(mm) 55.1 (1,400)
F Distance between machines - in (mm) 0 (0)
D
E
F
C
A
B

10
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
03 INSTALLATION
3.2 FOUNDATION REQUIREMENTS
Themachinemustbeplacedonasolidoorwhichislevelinbothdirections,andofasufcientstrengthtobeabletosupport
the weight of the machine, of any existing machinery and the means of transport.
NOTE: Do not mount on tile oors, elevated oor levels, stacked multiple base frames, or over basements or crawl
spaces because of the high extract speed and the G-forces exerted.
WARNING
To reduce the risk of re, serious injury, property damage and/or
death, install the machine on a level, uncovered concrete oor of
sufcient strength at grade.
3.3. WATER CONNECTION
To connect water service to a machine with hoses, use the following procedure:
1. Beforeinstallinghoses,ushthebuilding’swatersystematthemachineconnectionvalvesforatleasttwo[2]minutes.
2. Checkltersinthemachine’sinletadapterhosesforpropertandcleanlinessbeforeconnecting.
3. Hanghosesinalargeloop;donotallowthemtokink.

11
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
03 INSTALLATION
3.4 DRAIN CONNECTION
IMPORTANT: Machine must be installed in accordance with all local codes and ordinances.
All drain systems must be vented to prevent an air lock or siphoning.
If proper drain size is not available or practical, a surge tank is required. A surge tank along with a sump pump should be used
when gravity drainage is not possible.
Drain Trough System
7
65
4
3
2
1
Direct Drain System
Drain line must be vented to meet local plumbing codes.
4
5*
3
6
1
2
IMPORTANT: Increasing the drain hose length, installing elbows, or causing bends will decrease drain ow rates and
increase drain times, impairing machine performance.
NOTE: Installation of additional machines will require larger drain connections.
1. REAR OF MACHINE
2. DRAIN PIPE
3. STEEL GRATE
4. DRAIN TROUGH
5. STRAINER
6. WASTE LINE
7. 1 IN. [25 MM] MINIMUM GAP
1. DRAIN HOSE
2. DRAIN VALVE
3. DRAIN TEE
4. OVERFLOW HOSE
5. VENT PIPE*
6. TRAP [AS REQUIRED
BY LOCAL CODES]

12
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
03 INSTALLATION
3.5 ELECTRICAL INSTALLATION
IMPORTANT: Electrical ratings are subject to change. Refer to serial plate for electrical ratings information specic to
your machine.
DANGER
Electrical shock hazard will result in death or serious injury.
Disconnect electric power and wait ve (5) minutes before servicing.
WARNING
Dangerous voltages are present inside the machine. Only qualied
personnel should attempt adjustments and troubleshooting.
Disconnect power from the machine before removing any cover and
guards, and before attempting any service procedures.
WARNING
Hazardous Voltage. Can cause shock, burn or death. Verify that a
ground wire from a proven earth ground is connected to the lug near
the input power block on this machine.
Electrical connections are made at the rear of the machine. The machine must be connected to the proper electrical supply
shown on the serial plate on the rear of the machine, using copper conductors only.
Fusing Requirements:
20 Amp Dual element time delay fuse or equivalent breaker is required. Supplementary circuit protection is not allowed.
3.6 CONNECTION SPECIFICATIONS
IMPORTANT: Connection must be made by a qualied licensed electrician using wiring diagram provided with
machine, or according to accepted state and local codes.
Connect machine to a dedicated branch circuit not shared with lighting or other equipment. Shield connection in a liquid-tight
orapprovedexibleconduit.CopperconductorsofcorrectsizemustbeinstalledinaccordancewithNECorotherapplicable
codes.
Single-Phase Connections
FOR SINGLE-PHASE 208V INPUT,
CONNECT L1, L2 AND PE (GROUND).
PE Ground
L1 208V
L2 208V
21 Pre wash
22 Main wash
23 Bleach
24 Fabric softner
19 Common
Grounding
For personal safety and proper operation,
the machine must be grounded in
accordance with state and local codes.
The ground connection must be made to a
proven earth ground, not to conduit or water
pipes.

13
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
3.7. SUPPLY DISPENSING
3.7.1 Manual Dosing
WARNING
Dangerous Chemicals. May damage eyes and skin. Wear eye and
hand protection when handling chemicals; always avoid direct
contact with raw chemicals. Read the manufacturer’s directions for
accidental contact before handling chemicals. Ensure an eye-rinse
facility and an emergency shower are within easy reach. Check at
regular intervals for chemical leaks.
This machine has 4 liquid chemical supply and 5 external liquid supply connections.
Pre-wash Main Wash
Liquid Liquid
(LIQUID OR POWDER) BLEACH SOFTENER
IMPORTANT: Undiluted chemical dripping can damage the machine. All chemical injection supply dispenser pumps
and dispenser tubing should be mounted below the washer’s injection point. Loops do not prevent drips if these
instructions are not followed.
IMPORTANT: Failure to follow these instructions could damage the machine and void the warranty.
3.7.2 External Dosing (Option)
CONNECTIONOFEXTERNALLIQUIDSUPPLIES
1. Facingtherearofthemachine,locatetheve3/8inchsupplyhoseconnectionsfoundontheright-hand
side of the valve panel.
2. Drillthroughtheveplasticholesonthevalvepanelfortheexternalsupplyhosesasneeded.
3. Remove plastic debris.
03 INSTALLATION
1
21 Pre wash
22 Main wash
23 Bleach
24 Fabric softner
19 Common
6

14
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
03 INSTALLATION
4. Attach the external supply hoses to the ports at each of the drilled holes.
5. Secure with proper clamps.
6. Maketheelectricalconnectionasspecied.
NOTE: Do not attempt to make chemical injection supply pump electrical connections to points other than those
provided specically for that purpose by the factory.
3.8. REMOVAL OF SHIPPING BRACES
WARNING
DO NOT REMOVE THE SHIPPING RESTRAINTS BEFORE PLACING
THE WASHER IN ITS DEFINITIVE POSITION.
NEVER START THE MACHINE UP WITHOUT FIRST REMOVING THE
SHIPPING RESTRAINTS.
NON-COMPLIANCE WITH THIS PRECAUTION MAY CAUSE SERIOUS
PHYSICAL DAMAGES TO PEOPLE AND IRREPARABLE DAMAGES
TO THE WASHER. THE WARRANTY DOES NOT COVER THIS
INCIDENCE.
After positioning, remove the lower front and back panels and remove the four shipping brackets that were used for
transportation support. Save the shipping brackets. If the washer ever needs to be moved to another location, replace the
transport system.

15
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
04 CONTROL INTERFACE VENDED
The control panel of the washer is below:
Esc Enter
Note: the key function as shown in the gure.
The user interface is specially designed for the control of the washer for the self-service vended market. The controller
provides easy operation for the user and also provides access to all the menus to setup, to diagnosing error codes, and to
check the status and health of the machine.
The hot, warm, cold and start buttons are used to navigate the washer menus.
Hot - Up Arrow
Warm - Down Arrow
Cold - Escape
Start - Enter
4.1 BUTTONS INTRODUCTION
ICON FUNCTION MENU NAVIGATION
[HOT]button
Press this button to select hot water temperature. ↑
[WARM] button
Press this button to select medium water temperature. ↓
[COLD] button
Press this button to select cold water temperature. Escape
[Start] button
Press this button to start executing the selected wash cycle. Enter

16
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
04 CONTROL INTERFACE VENDED
4.2 ALARMING
When an error occurs, the computer will signal an alarm automatically with an audible sound. Pressing <Start(Enter)> button
will stop the audible alarm sound. Press <Start(Enter)> button again after troubleshooting to clear the alarm. If the error has
been resolved or can be ignored, the computer will go back to “open” or “close” or “locked” status or else the computer will
alarm again.
NO. ALARM NAME TROUBLESHOOTING
#1 Error door status Please check the door switch or door pin.
#2 Over shock Please check if the load in the machine is too small or too large.
4.3 PROGRAMMING AND SETTING
Refer to the Operating manual.
4.4 RUNNING
Startup
After power is on, the LCD shows the startup interface for 10 seconds.
Unity UTS40
X1LD041AX1700
1.V100A00
X1LL020AX26001-
1.V100A00
4
Idle
Default program is Cold.
Wash Temp: Cold
$: 3.00
Paid: 0.00

17
Part. 14000101 Rev. 12/2019
®/™ ©2019 Unity Laundry Systems. All rights reserved.
Automatic Running
Start Automatic Running.
On the control panel choose your desired wash temperature, insert coins and then press [start] button to start the program.
Wash Temp: Cold
18:52
Main Wash
Check running status message
Press [Up] and [Down] at the same time for 3 seconds to enter the “Run menu” to check the running status or error message
of the cycle and machine. Your password is required to access the run status menu.
Press [Esc] for 3 seconds to exit the running status menu.
Function Menu
Running Information
Error Check
<Esc>3S=Quit
Lev: 0/ 10cm
Temp: 22/ 40°C
Speed: 50/ 50RPM
Stand, Cold, Hot
Ending Automatic Running
After completing the cycle, the controller displays end status. The controller beeps to inform the user of a cycle completion.
The buzzer can be canceled by pressing [Start] button during this beeping time.
04 CONTROL INTERFACE VENDED
Table of contents
