UNITY LAUNDRY SYSTEMS UTS62B User manual

Convenient Manual Dispenser
with an easy to ush design and four compartments:
pre-wash and main wash (powder or liquid), bleach
and fabric softener (liquid only)
Easy Access Front Panel
for front servicing key
components
Built For A Long Life
including a stainless-steel
drum and tub, high quality
bearings, and a durable
motor
Easy to Use Controls
with an intuitive design and
multi-lingual support
®/™ ©2021 Unity Laundry Systems. All rights reserved.
VENDED / ON-PREMISE LAUNDRY
HIGH EFFICIENCY SOFT MOUNT
WASHER EXTRACTOR
UNITY LAUNDRY SYSTEMS
MODEL UTS62B
5 Chemical Injection
Ports
for compatibility with
any external
automatic chemical
dosing system
Easy Installation
No concrete pad required -
just drop in place
Perfectly Tuned
Extract Performance
with optimally
designed RPMs and
G-forces to achieve
max extraction and to
prevent unbalanced
loads
Emergency Stop
for operator safety
Before We Ship
we perform a double quality
check to ensure that each
washer is perfect right out of
the box

See specic instructions for proper installation. Because of continuous product improvement,
Unity Laundry Systems reserves the right to change specications without notice.
®/™ ©2021 Unity Laundry Systems. All rights reserved.
MOTOR
Size – HP (KW) 3.0 (2.2)
CAPACITY
Cylinder Volume – cu. ft. (liters) 8.8 (251.3)
Cylinder Diameter – in. (mm) 30.5 (774)
Cylinder Depth – in. (mm) 21.0 (534)
Dry Load Capacity – lb. (kg) 62 (28.1)
OPERATING SPEED & EXTRACT FORCE
Washing Speed (RPM) 45-50
Maximum Extract Force (G-force) 277
Maximum Extract Speed (RPM) 800
CONNECTIVITY
USB Programmability Yes
DIMENSIONS
Depth – in. (mm) 45.4 (1152)
Width – in. (mm) 40.9 (1038)
Height – in. (mm) 58.4 (1484)
CRATED DIMENSIONS
Depth – in. (mm) 48.0 (1220)
Width – in. (mm) 43.4 (1102)
Height – in. (mm) 63.6 (1615)
APPROXIMATE WEIGHT
Uncrated – lb. (kg) 1433.2 (650)
Crated – lb. (kg) 1653.5 (750)
ELECTRICAL CONNECTION OPTIONS (VOLTS/Hz/PHASE)
208 – 240V / 50 – 60HZ / 1PH (no electrical heating) Yes
WATER HEATING OPTIONS
Hot / Cold Water Connections Only Yes
WATER, CHEMICAL DISPENSING, DRAINS
Number of Water Inlets 3
Inlet Sizes – in. (mm) 1 (25.4)
Manual Dispenser Compartments, Number 4
External Chemical Connections, Number 5
Dump Valve Drain Size – in. (mm) 3 (76.2)
INSTALLATION RECOMMENDATIONS
Recommended Clearance Between Machines - in (mm) 1.5 (40)
Recommended Clearance in front of Machines - in (mm) 39.4 (1000)
Recommended Clearance Behind Machines - in (mm) 31.5 (800)
MANUAL
DETERGENT DISPENSER
SIMPLE DIGITAL CONTROLLER
Easy to use control panel –
bi-lingual instructions
Convenient and easy to use
Pre-wash Main Wash
DETERGENT
Liquid
SOFTENER
Liquid
BLEACH
12
PROGRAMMABLE CYCLES
Ciclos Programables
START
Arranque
3
Load items in washer and close door
Cargue los artículos en la lavadora y cierre la puerta
Select wash cycle
Seleccione el ciclo de lavado
Press start button
Presione el botón de arranque
INSTRUCTIONS
Instrucciones
1
3
2
