Unity M1913 User manual

©Copyright 2020, UNITY Tactical. All Rights Reserved.
STANDARD / SYNC
1Press Baseplate onto Control Module, ensuring edges line up.
2Seat M-LOK™ Nuts into recesses on underside of Baseplate
and thread bolts into them from the top. TORQUE TO 5 IN-LB.
3Place assembly in desired location on M1913
Picatinny Rail. Fully seat right and left rail
grabbers into slots, ensuring they are on the
proper side.
4Place Hex Nuts into appropriate rail grabber side.
Insert Cross Bolts and thread into Hex Nuts.
TORQUE TO 5 IN-LB.
WARNING: Over-torquing fasteners can damage your mount and will not be covered by warranty.
M1913 PICATINNY RAIL INSTALLATION
5Route cable from TAPS™ to light and laser device, and
fully seat plug in sockets. Avoid sharp bends in cables
and routing over extreme heat areas and sharp edges.

©Copyright 2020, UNITY Tactical. All Rights Reserved.
STANDARD / SYNC
1Press Baseplate onto Control Module, ensuring edges line up.
2Place Bolts through holes in top of assembly and begin
threading M-LOK™ Nuts onto them. DO NOT TIGHTEN.
3Install TAPS™ to M-LOK™ or Key Mod™ Rail.
Lightly snug all screws before applying torque to
any. DO NOT EXCEED 35 IN-LBS ON METAL RAIL,
OR 15 IN-LBS ON POLYMER RAIL. Ensure M-LOK
™ nuts are fully perpendicular to slots in rail
(fully seated).
WARNING: Over-torquing fasteners can damage your mount and will not be covered by warranty.
M-LOK™ / Key Mod RAIL INSTALLATION
4Route cables from TAPS™ to light and laser device, and
fully seat plug in sockets. Avoid sharp bends in cables
and routing over extreme heat areas and sharp edges.
